DATA SHEET

QLE2460
Single-Port, 4Gbps Fibre Channel-
to-PCI Express Host Bus Adapter
HighPerformance
•150,000IOPSdelivershighI/Otransferratesfor
storageapplications.
•IntelligentinterleavedDMA(iiDMA)ensures
maximumutilizationofdatalinks.
•Out-of-orderframereassembly(OoOFR)reduces
congestionandretransmissions.
SuperiorScalability
•Multi-IDandN_Portvirtualizationready.Allows
physicalportstobepartofmultiplelogical
networks.
•Cisco®VSANready.Allowsphysicalportstobepart
ofmultiplelogicalnetworks.
•Comprehensiveoperatingsystem(OS)driver
supportincludingWindows®,Linux®,Solaris®,
NetWare®,MacOS®,Citrix®,Oracle®,andVMware®.
•Universalbootsupportmanagesmultiplehardware
platformsandbootoptions.
EnhancedReliability
•Overlappingprotectiondomainsforcontinuous
protectionofinternaldatapaths.
•T10cyclicredundancycheck(CRC)ensuresend-to-
enddataintegrityacrossSANs.
•ThreeLEDsdisplayreal-timestatusandlinkactivity
information.
QLE2460 Host Bus Adapter.  The QLE2460 is the industry’s first, true
enterpriseclass,4Gbps-to-PCIExpress®x4adapter.TheQLE2460delivers
unprecedentedlevelsofperformanceandavailability,aswellasintelligent
networkingfeaturesspecifictoenterpriseclassdatacenters.
EnterpriseClassFeatures.TheQLE2460adapteristhehighestperforming
andmostreliableadapterintheindustry.Itdeliversunmatchedperformance
by leveraging a single ASIC design, combining a unique hardware
architecturetodeliverover150,000IOPS,nearly800MBpsthroughput,and
support for PCI Express x4 bus speeds.  More importantly, the QLE2460
adapterprovidesnewintelligentstoragenetworkingfeaturesthatredefine
theenterpriseclassadapter,providingincreaseddataprotection,advanced
framerouting,andenterprise-widemanagementcapabilities.
Simplified Setup.  Point-and-click installation and configuration wizards
simplify the adapter setup process.  Storage administrators can quickly
deployadaptersacrossaSANusing standardadaptermanagementtools
and device utilities.  The QLE2460 is fully compatible with SNIAAPI and
SMI-S, thereby allowing administrators tomanageQLogicadaptersusing
third-partysoftwareapplications.
ComprehensiveOSSupport.QLogicoffersthebroadestrangeofsupportfor
allmajoroperatingsystemstoensureOSandhardwareservercompatibility.
Driversareavailableforallmajoroperatingsystemsandhardwareserver
platforms.AsingledriverstrategyperOSallowsstorageadministratorsto
easilydeployandmanageadaptersinheterogeneousSANconfigurations.
Guaranteed Interoperability.  Storage partner certifications, combined
withagencyandregulatorytesting, ensures that all products meet world
compliance hardware and software specifications.  All adapters are
testedextensivelywiththird-partyhardware,alongwithmultiplesoftware
applications,toensurebest-in-classSANinteroperabilityandcompatibility.
YoucanbeconfidentpurchasingQLogicadapterstomeetyourFibreChannel
storagenetworkingneeds.
InvestmentProtection.Forover15years,QLogichasbeenatechnological
leader with products that address the customer’s current needs.  In
addition,QLogicprovidesstronginvestmentprotectiontosupportemerging
technologies and standards.  QLogic stands alone in the industry with
its product portfolio depth and experience in successfully delivering
technologicalsolutionsthataddresstheneedsoftodayandtomorrow.

DATA SHEET
Corporate Headquarters QLogic Corporation 26650 Aliso Viejo Parkway Aliso Viejo, CA 92656 949.389.6000 www.qlogic.com
International Offices UK | Ireland | Germany | India | Japan | China | Hong Kong | Singapore | Taiwan
QLE2460 Single-Port, 4Gbps Fibre Channel-to-PCI Express Host Bus Adapter

 PX2458002-00R 2
© 2004–2010 QLogic Corporation. Specifications are subject to change without notice. All rights reserved worldwide. QLogic, the QLogic logo, and SANsurfer are registered trademarks of QLogic Corporation. AMD and Opteron are trademarks or registered
trademark of Advanced Micro Devices, Inc. Apple, Mac OS, Power Mac, and Xserve are registered trademarks of Apple, Inc. Cisco is a registered trademark of Cisco Systems, Inc. Citrix and XenServer are trademarks or registered trademarks of Citrix Systems, Inc.
Linux is a registered trademark of Linus Torvalds. Oracle is a registerd trademark of Oracle Corporataion. PCI Express is a registered trademark of PCI-SIG Corporation. Red Hat is a registered trademark of Red Hat, Inc. Solaris and OpenSolaris are trademarks or
registered trademarks of Sun Microsystems, Inc. SPARC is a registered trademark of SPARC International, Inc. SUSE, Novell, and NetWare are registered trademarks of Novell, Inc. VMware, and ESX are trademarks or registered trademarks of VMware, Inc. Windows,
Windows Server, and Windows Vista are registered trademarks of Microsoft Corporation. XenServer is a registered trademark of Citrix Systems, Inc. All other brand and product names are trademarks or registered trademarks of their respective owners. Informa-
tion supplied by QLogic Corporation is believed to be accurate and reliable. QLogic Corporation assumes no responsibility for any errors in this brochure. QLogic Corporation reserves the right, without notice, to make changes in product design or specifications.
Host Bus Interface Specifications
Businterface
•PCIExpressx4
Memory
•1MBSRAM,1MBflash(SPI),and
2KBNVRAM(SPI)
Hardwareplatforms1
•IA32(x86),IA64,IEM64T,AMDOpteron™64,Sun™
SPARC®,Apple®G5(Xserve®andPowerMac®)
Compliance
• PCIExpressBaseSpecification ,revision1.0a, PCI
ExpressCardElectromechanicalSpecification 
rev.1.0, PCIBusPowerManagementInterface
Specification revision1.1
Fibre Channel Specifications
Datarate
•4/2/1Gbpsauto-negotiation(4.2480/2.1240/
1.0625Gbps)
Performance
•150,000IOPS
Topology
•Point-to-point(N_Port),arbitratedloop(NL_Port),
switchedfabric(N_Port)
Logins
•SupportforF_PortandFL_Portlogin:2,048
concurrentloginsand2,048activeexchanges
Classofservice
•Class2and3
Protocols
•FCP(SCSI-FCP),FC-TAPE(FCP-2)
Compliance
• SCSI-3FibreChannelProtocol(SCSI-FCP),Fibre
ChannelPhysicalandSignalingInterface(FC-PH),
FibreChannel2ndGeneration(FC-PH-2),Third
GenerationFibreChannelPhysicalandSignaling
Interface(FC-PH-3),FibreChannel-ArbitratedLoop
(FC-AL-2),FibreChannelFabricLoopAttachment
TechnicalReport(FC-FLA),FibreChannel-Private
1 SubjecttoavailabilityofOSandhardwarefrom
respectiveOEMs.
LoopDirectAttachTechnicalReport(FC-PLDA),
FibreChannelTape(FC-TAPE)profile,SCSIFibre
ChannelProtocol-2(FCP-2),SecondGeneration
FCGenericServices(FC-GS-2),ThirdGeneration
FCGenericServices(FC-GS-3),FibreChannel
FramingandSignaling(FC-FS)
Physical Specifications
Ports
•Single4GbpsFibreChannel
Connections
•Smallformfactorfixed(SFF)multimodeoptic
withLC-styleconnector
Formfactor
•Low-profilePCIExpresscard:16.765cm×
6.89cm(6.6in.×2.713in.)
Bracketsize
•Standard:1.84cm×12.08cm(.73in.×4.76in.)
•Low-profile:1.84cm×8.01cm(.73in.×3.15in.)
Tools and Utilities
Managementtools
•SANsurfer®FibreChannelHBAManager
Deviceutilities
•Commandlineinterface;utilitiesforfirmware,
driver,bootcode,NVRAM
Bootsupport
•BIOS,EFI,FCode
APIs
•SNIAHBAAPIV2,SMI-S,FDMI
Operatingsystems1
•WindowsServer®2003,2008,2008R2;Windows
2000;WindowsXPPro;WindowsVista®;Solaris10;
OpenSolaris™2008,2009;RedHat®RHEL3,4,5;
Novell®SLES8,9,10,11;NovellNetWare®6.5;Mac
OSX;CitrixXenServer®3.2–4.1,5.0,5.5;Oracle
EnterpriseLinux4,5;VMwareESX™/ESXi3.5,4.0
Environment and Equipment Specifications
Airflow(noairflowrequired)
Temperature
•Operating:0°C/32°Fto55°C/131°F
•Storage:–20°C/–4°Fto70°C/158°F
Humidity
•Relative(non-condensing):10%to90%
•Storage:5%to95%
Powerdissipation
•5.0W(maximum)
Cabledistances
•1Gbps:500meters50/125μmfiber,300meters
62.5/125μmfiber
•2Gbps:300meters50/125μmfiber,150meters
62.5/125μmfiber
•4Gbps:150meters50/125μmfiber,70meters
62.5/125μmfiber
Agency Approvals—Product Safety
USandCanada:UL,cUL:UL60950,CSAC22.2
No.60950,Class1LaserProductperDHHS21CFRJ
Europe:
•73/23/ECCLowVoltageDirective
–TUV:EN60950-1:2001,EN60825-1:
1994+A1+A2,EN60825-2:1994+A1
Agency Approvals—EMI and EMC
US:FCCPart15,ClassB
Canada:IndustryCanadaICES-003,ClassB
Europe:89/336/EECEMCDirectiveCEMark,
EN55022:1998/CISPR22:1997ClassB,EN55024:
1998,EN61000-3-2:1995,EN61000-3-3:1994
Japan:VCCI,ClassB
Taiwan:CNS13438ClassB
NewZealandandAustralia:AS/NZS3548ClassB
Korea:MIC
Ordering Information
QLE2460-CK
•Shipsinanindividuallypackedboxwitha
standardsizebracket,asparelow-profile
bracket,aSANsurferFibreChannelHBAManager
CD,andaQuickStartGuide
QLE2460-BK
•Shipsinabulkboxinquantitiesof20and50
withstandardsizebrackets
