Qlogic SANblade QCP2340 User manual

2-Gbps Fibre Channel (FC) to
cPCI Host Bus Adapters (HBAs)
QCP2340/
SANblade
®
QCP2342
2-Gbps Fibre Channel to cPCI Host Bus Adapters
cPCI
HOST BUS ADAPTERS
FIBRE CHANNEL
4
Gb
2
Gb
Ease of Use
•Autonegotiation of Fibre Channel speed bit rate (1 Gbps or 2 Gbps)
•Easy detection of activities through an LED panel:
•Power
•Online
•Signal acquired
•Loss of synchronization
•Firmware error
•Automatic topology detection
•Quick start guide
•Persistent binding
Superior Scalability
•Concurrent support for SCSI and IP protocols
•Load balancing for optimized performance
•Simultaneous initiator and target mode support
•Local and remote management
Enhanced Reliability
•Unique, single-integrated Fibre Channel controller for added reliability and optimum
performance
•HBA and LUN level failover •Loopback and read/write buffer tests •LUN masking
WHY QLOGIC? Designed as the optimum choice for Sun
Microsystems®‚ Sun Fire™ servers, the SANblade QCP2340 and
QCP2342 offer customers nondisruptive expansion of their storage
area network (SAN) with full support of cPCI hot swap functionality.
Delivering industrial strength performance, these 2-Gbps Fibre
Channel to 64-bit, 66-MHz CompactPCI (cPCI) HBAs incorporate a
robust mechanical design with high compute density. These
multimode optic HBAs are specifically designed for physically
demanding environments that require serviceability and availability.
Cost Effective. The QCP2340 is the right solution for mid-range and
enterprise-level server manufacturers implementing cPCI in mission
critical environments requiring single port, 2-Gbps cPCI. If you want
to maximize connectivity and optimize port density, the QCP2342, a
dual channel version of the QCP2340, is the perfect fit.
Leading Single Chip Integration. The QCP2340/2342 uniquely
integrates a RISC processor, a Fibre protocol engine, andtransceivers
into a single, efficient FC controller chip that increases reliability and
performance by lowering CPU utilization.
Broad OEM Acceptance. The QCP2340/2342L HBA is validated by
every major OEM including Dell, EMC, HDS, HP, IBM, and Sun. The
QCP2340’s extensive certification from major server and storage
manufacturers makes it the perfect choice for multiplatform
requirements.
Simplified Setup. Point-and-click installation and configuration
wizards simply the HBA setup process. Storage administrators can
quickly deploy HBAs across a SAN using standard HBA management
tools and device utilities. The QCP2340/2342 is also fully compatible
with industry standard application programming interfaces (APIs),
including SNIA HBA API and SMI-S, thereby allowing administrators
to manage QLogic HBAs using third-party software applications.
Proven Archetecture. The QCP2340/2342 architecture is the result
of more than 15 years of progressive development and testing.
Proven architecture from QLogic delivers higher overall reliability and
enables advanced functionality with its single-chip integration,
placing QLogic years ahead of its competitors. The QCP2340/2342
also has proven interoperability with all major software applications,
hardware platforms, and operating systems.
The Bottom Line. Driving the standard for interoperability with
extensive FC testing in SAN environments, you can feel confident in
choosing the QLogic solution.

TECHNICAL SPECIFICATIONS
SANblade
QCP2340/
QCP2432
CF2358001-00 D 12/06
Host Bus Interface Specifications
Speed 64-bit, 66-MHz cPCI
Signal voltage 3.3 V and 5.0 V buses supported
Compliance PICMG 2.0 CompactPCI Specification rev. 3.0, PICMG 2.1 Compact PCI (cPCI) Hot Swap Specification rev. 1.0, PCI Bus Power Management Interface Specification rev. 1.1
Fibre Channel Specifications
Speed 200 MBps maximum at half-duplex, 400 MBps maximum at full-duplex
Topology FC-AL, FC-AL-2, point to point, switched fabric (FL_Port and F_Port)
Buffer credits For 512-byte frame size, 9 credits issued. For 2K-byte frame size, 3 credits issued.
Class of service Class 3 Fibre Channel service
Protocols SCSI-FCP, IP, FC-TAPE
Compliance Second Generation FC Generic Services Definition (FC-GS-2), Third Generation FC Generic Services Definition (FC-GS-3), Fibre Channel-Physical and Signaling Interface (FC-PH),
SCSI-3 Fibre Channel Protocol (SCSI-FCP), Fibre Channel-Arbitrated Loop-2 (FC-AL-2), Fibre Channel-Private Loop Direct Attach Technical Report (FC-PLDA), RFC 2625 IP and APR
Over Fibre Channel, Fibre Channel Framing and Signaling (FC-FS)
Physical Specifications
Ports One (QCP2340)
Two (QCP2342)
Media Multimode optic
Optics Short wave laser
Connectors LC-style connector that supports non-OFC, multimode fibre optic cabling using a 2 ×5 fibre optic transceiver module.
Form factor CompactPCI: 16.0cm ×10.0cm (6.3" ×3.9")
Bracket size Standard size
Environment and Equipment Specifications
Temperature Operating: 0°C/32°F to 55°C/131°F. Storage: –20°C/–4°F to 70°C/158°F
Airflow 0 lf/m
Humidity Relative (noncondensing): 10% to 90%, Storage: 5% to 95%
Power dissipation ~ 5.0 watts
Cable 50/125µm multimode fiber, 62.5/125 µm multimode fiber
Cable distances 1 Gbps: 500 meters 50/125 µm fiber, 300 meters 62.5/125 µm fiber
2 Gbps: 300 meters 50/125 µm fiber, 150 meters 62.5/125 µm fiber
Agency Approvals—Product Safety Agency Approvals—EMI and EMC
US/Canada UL, cUL
UL60950
CSA C22.2 No.60950
Class 1 Laser Product per DHHS 21CFR J
US FCC Part 15, Class A
Canada Industry Canada ICES-003, Class A
Europe 89/336/EEC EMC Directive CE Mark:
EN55022: 1995 Class A
EN55024: 1998
EN61000-3-2:1995
EN61000-3-3:1994
Japan VCCI, Class A
Taiwan CNS 13438 Class A
New Zealand/Australia AS/NZS 3548 Class A C-tick
Europe 73/23/ECC Low Voltage Directive:
TUV:
EN60950: 2000
EN60825-1/A11: 1996
EN60825-1: 1994 +A11
Tools and Utilities
Management tools FC HBA Manager
Device utilities Command line interface; configuration utility resident with FCode
Boot support Solaris SPARC: FCode
APIs SNIA HBA API V2, SMI-S, and FDMI
Operating systems Solaris SPARC
Ordering Information
QCP2340 Ships to OEMs in an individually packed box.
QCP2340-BK Ships to OEMs in a bulk pack box in quantities of 20, 50, or 100.
QCP2340-CK Ships to authorized distributors and resellers in an individually packed box with the FC HBA Manager.
QCP2342 Ships to OEMs in an individually packed box.
QCP2342-BK Ships to OEMs in a bulk pack box in quantities of 20, 50, or 100.
QCP2432-CK Ships to authorized distributors and resellers in an individually packed box with the FC HBA Manager.
