QRS PMII Quick start guide

QRS PMII to PNO3WB
Upgrade Instructions
Manual Revision: March 2022
PNO3 OS Versions 5.xx & Above
PNO3
PMII

2
QRS PMII to PNO3WB Upgrade Instrucons
Table of Contents
Page Page
Package Contents 2 Inial System Setup‐QRS System (Connued)
Is PMII used on a QRS System or as a MIDI Controller? Pedal Adjust‐Mechanical
Disconnect and Remove the PMII Processor 3 Pedal Adjust 10
QRS System / MIDI Controller QRS PNOscan Record Setup, If Installed 11
Mount and Connect the PNO3WB Processor 4 PNOscan Key & Pedal Adjust
QRS System Master Volume Curves 12
MIDI Controller 5 Voice Prompts
PianoDisc / Disklavier Network Setup
13
MIDI Sengs‐MIDI Controller 6 Wireless Standalone
MIDI OUT: Key Adjust, Pedal Adjust and Delay Wired Network (LAN)
Power ON and Test the PNO3WB 7 Wireless Network
Accessing and Navigang... [Connect to the QRS Wi‐Fi] QRS Finder App
Inial System Setup‐QRS System
8
Customer Trial Acvaon & Preowned Music 14
Playback Parameters Song Menu Overview
Key Adjust Warranty & Extended Warranty Explanaon 15
9
Is the PMII processor connected to a QRS System or is it used as a MIDI Controller?
QRS System QRS Part Number for the PNO3WB QRS Upgrade Kit is 83525
A PMII processor used on a complete
QRS system will have a ribbon cable
connected to this POWER SUPPLY socket.
MIDI Controller QRS Part Number for the PNO3WB MIDI Upgrade Kit is 83529
A PMII processor used as a MIDI
Controller will have a power adapter
connected to the 9VDC socket and...
...A MIDI cable connected to the PMII
processor’s MIDI OUT port going to the
MIDI IN socket of the MIDI slave device.
The power adapter for the PMII will NOT connect to the
new PNO3WB processor! Order part # 803081 9V2A
adapter for the PNO3WB processor.
PMII
PNO3WB
Package Contents
83630 PMII to PNO3WB Upgrade Kit‐Includes a one‐year access to QRS Music Library
790234 PMII to PNO3WB Upgrade Kit‐Includes a five‐year access to QRS Music Library
80308WB 1 PNO3WB Processor
79236 1 QRS Music Library ‐Loaded Internally
80309 1 Magnec Mounng Bracket w/screws & straps
80321
1
PNO3WB to DB37‐Pin External Chassis “Legacy” Magnec Adapter
20‐Pin 4” Ribbon Cable permanently connected to the adapter
36117 24 1/2” Tie Strap
83525i 1 PNO3WB Upgrade Kit Instrucons
QGPM3/0418 1 PNO3 Quick Guide

3
QRS PMII to PNO3WB Upgrade Instrucons
Unplug the piano from the AC outlet and locate the PMII Processor.
Locate the PMII Processor.
Look under the soundboard area on a grand piano.
Remove the Lower Panel on an upright. Lower Panel
SD Card‐DO NOT remove, you won’t need it.
The QRS Music Library is now stored INSIDE the PNO3WB processor.
Return the PMII processor with the SD card to QRS Music using the UPS Return Label provided.
Unscrew and remove the PMII processor from the piano.
MIDI Controller
MIDI IN ‐This port may be connected to a MIDI Record strip.
MIDI OUT ‐This port connects to the MIDI slave device that the QRS processor is controlling.
9VDC Power Adapter
Disconnect and Remove the PMII Processor
Disconnect the cables and remove PMII processor from the piano.
USB HOST‐TheUSBHOSTportsarethesameso,thecablescanbere‐insertedineithersocket.
USB CLIENT
ETHERNET
AUDIO 1‐4‐Label the Audio cables before disconnecng.
MIDI IN‐This port may be connected to a MIDI Record strip.
KEYSCAN ALT
POWER SUPPLY
KEYSCAN PRIMARY ‐IfthePNOscanRecordSystemisinstalled.
QRS System
MIDI IN ‐This port may be connected to a MIDI Record strip.
Driver Port‐Disconnect the driver board cable, one of these three types.
Port B: 20‐pin connector [Black ribbon cable‐black plasc connector]
Port B: 37‐pin connector [Gray ribbon cable‐metal connector w/blue plasc]
Port A: 20‐pin flat connector [Black ribbon cable‐no connector]
KEYSCAN PRIMARY ‐IfthePNOscanRecordSystemisinstalled.

4
QRS PMII to PNO3WB Upgrade Instrucons
Mount and Connect the PNO3WB Processor
The piano should sll be disconnected from AC power.
Insert straps in the bracket.
Aach the magnec bracket to the piano and the processor to the magnet.
Insert straps through slots
QRS System
DRIVER PORT B and PWM Control
Connect the driver board cable to the appropriate socket on the PNO3WB processor.
There are three possible driver board cables:
1 Driver Port B, black socket: 8‐wire harness to Smart Driver Boards
2 Driver Port B, white socket: 20‐pin ribbon to Rev 4 boards OR old style Magnec adapter.
Orientthesilvercontactsoftheribboncabletothecontactsoftheconnector!
3 PWM Control, 20‐Pin ribbon to Rev 7 boards OR 37‐Pin new style Magnec adapter.
Connect the Power supply and PLx cables.
Verify that the QRS power supply switch is OFF before connecng this cable.
NEVERconnectthePOWERSUPPLYandDC9VDCcablestothesameprocessor.
Record System, if installed.
PNOscan 10 [On systems with the QRS PNOscan record installed.]
CamefromthePMIIprocessor’sKEYSCANPRIMARYconnector.
Thesilver“contact”sideofribbonfacesawayfromPNOscan10label.
MIDI IN, from a KS1 Record Interface...as an example.
PMII
PNO3WB
Connect the cables to the PNO3WB processor
ETHERNET ‐Do NOT connect an Ethernet cable. The PNO3WB has built‐in WiFi.
USB HOST‐TheUSBHOSTportsarethesameso,thecablescanbere‐insertedineithersocket.
USB CLIENT
MIDI IN‐This port may be connected to a MIDI Record strip.
AUDIO 1‐4 [Audio #3 goes the piano speaker]
The silver “contact” side of the ribbon cable faces down, away from the label.
DO NOT insert the SD card.
The QRS Music Library is now stored INSIDE the PNO3WB processor.
Aach the two antennas to the end of the PNO3WB processor.
The center RFC connector is NOT used.

5
QRS PMII to PNO3WB Upgrade Instrucons
MIDI Controller
PianoDisc The PianoDisc controller is not needed to play the piano from PNO3WB processor.
The PianoDisc controller IS needed to calibrate the keys and pedal solenoid.
IF the PianoDisc controller is removed, do not discard, it can be reconnected to calibrate the system.
Locate the PianoDisc’s CPU Interface on the back side of the key solenoid rail.
Connect the MIDI cable from the MIDI OUT of the PNO3WB processor to the MIDI IN of the PianoDisc.
Disklavier Connect the MIDI cable from the MIDI OUT of the PNO3WB processor to the MIDI IN of the Disklavier.
On the back of the Disklavier controller set the HOST SELECT switch to “MIDI”.
Some units may not have the HOST SELECT switch and you may have to make a change in the controller’s setup menu.
Record system, connects to the MIDI IN, if installed.
Power Adapter The PNO3WB processor will begin to power ON as soon as it is connected to power.
Turn on the PianoDisc or Disklavier.
Connect the power adapter into the 9VDC jack on the end of the PNO3WB processor.
Connect the power adapter to an AC outlet.
PDS128 Plus
CPU Interface
Disklavier Mark
III Controller
PNO3 Power Adapter
9 Volts DC / 2 Amps
Center Posive
AC outlet

6
QRS PMII to PNO3WB Upgrade Instrucons
MIDI Out Key Adjust
Min. MIDI Out [Adjusts the MIDI Out volume level ]
Used to make minor “MIDI Volume” adjustments so the keys play, and play evenly.
This adjustment does NOT replace the actual key “calibraon” performed using the PianoDisc or Disklavier control box.
Go to: System Setup / Performance Setup / Roung & Delay Sengs / MIDI Out Key Adjust.
MIDI Key Adjust Global ‐Red when ON ‐Any changes made will affect ALL keys. Do NOT use!
Tap Start. The selected Note should begin to play.
Tap the “‐‐>“ buon in the Note row to play chromacally up the keyboard.
See how the notes play up the keyboard.
Tap Stop
You CAN increase the MIDI level of each note but, you CAN’T decrease the level to make it any soer.
You would need to calibrate the keys using the PianoDisc or Disklavier controller.
To increase the MIDI level going out to the player:
Tap‐Use the “<‐” or “‐>“ buons to go to the note that you want to adjust.
Min. MIDI Out‐Use the “+” buon to increase the level. The minimum seng is 1.
The“‐‐>“buonattheendoftherow,setsthecurrentvaluetoallkeysupscale,fromtheselectednote. Changes are
automacally saved.
Tap Stop when finished.
MIDI Out Pedal Adjust
Go to: System Setup / Performance Setup / Roung & Delay Sengs / MIDI Out Pedal Adjust.
Pedal Test On Time: 500 just sets the repeat rate of the ON/OFF pedal during the test. Set to 500.
Tap Start
Pedal Max Out‐Use the “<‐” or “‐>“ buons to see if changes can be made to the to damper li.
Tap Stop
Audio Accompaniment‐Speaker Test
Go to: Play Piano / Genre / Country & Western Accompaniment and Tap the song name, Deed I Do. The audio should be heard.
MIDI OUT Delay
Use this adjustment to synchronize the piano with the audio.
Go to: System Setup / Performance Setup / Roung & Delay Sengs / MIDI Opons / 5 Pin Out.
5‐pin MIDI Out Delay (ms)
Tap the “‐” and “+” buons to change the delay of the piano.
MIDI Sengs‐MIDI Controller
MIDI Sengs [The piano won’t play unl 5 Pin MIDI Out opon is turned ON.]
From Home, go to: System Setup / Performance Setup / Roung & Delay Sengs / MIDI Opons / General
MIDI Player System=ON
Controller 7 Volume Control = ON
Apply Volume Curve to Velocies = ON
Per Channel Controller 7 Enable = Select #1
Number of MIDI Out Notes = 88
Lowest MIDI Out Note = 21
Go to: System Setup / Performance Setup / Roung & Delay Sengs / MIDI Opons / 5 Pin Out
5 Pin MIDI Out = ON [The PNO3WB won’t send data to the MIDI Out port unless this is ON.]

7
QRS PMII to PNO3WB Upgrade Instrucons
Power ON and Test the PNO3WB
Reconnect the piano to an AC outlet and turn ON the power supply switch.
The PLX lights begin to scan as the operang system is loaded.
Voiceprompts,announcements,shouldbeheardinabout90seconds.


These PNO3WB buon lights should illuminate. [1=OFF, 2=ON solid, 3=On blinking]
PlxMV light sequence:
Power/Standby/Play—Green=Ready, Yellow = Standby, Green‐flashing = Song is Playing.
System—Green=All Good, Yellow‐flashing=Hand‐held remote control command received.
[Wired Network [LAN] Green=Standalone & Yellow=Networked] Red=Not Networked, Red‐flashing=resolving IP address.
I/O Mode—Indicates the Source
MIDI OUT—Sending MIDI data.
Prompts/Audio—Yellow‐flashing=voice announcements and song audio being sent to audio outputs.
Within ninety (90) seconds
#1 “Power” light turns green
#2 “System” = green
#3 “Network” = green [The Network light indicates the status of the Wired Network(LAN) PNO3WB’s Ethernet Port connecon.]
Within two (2) minutes...
Voice‐Prompts should be heard from the speaker and the “Prompts” light flashes yellow.
Accessing and Navigang the PNO3WB Control Menu [Connect to the QRS Wi‐Fi]
PNO3WB processors have built‐in Wi‐Fi and are shipped to operate as soon as the system powers on.
1
2
3
Use your smart device [iPhone, iPad, iPod, Android phone/tablet or laptop] to wirelessly connecon to QRSPNO3_##### Wi‐Fi.
Enter the password = qrsmusic.
Open your web browser; Apple Safari, Android Browser or Google Chrome.
Enter 10.3.2.1in the address bar.
This QRS Splash Screen will appear.
Touch the center of the screen to open the QRS Menu.
You will see one of several possible screens.
Lookforthemenucolumnonthele,notinthebodyofthescreen.
If only three white bars show at the top leof the QRS screen...
...the Menu column is closed.
Tap three bars to open the Menu column.
An image of a white house, with no white arrow, and you’re at the Home page.
White arrow point toward the house, you’re NOT at the home page.
Tap the white arrow to go back in the menu one page at a me.
Tap the white house to go directly to the home page.
The gear image takes you to the System Setup page.
The four arrows opens the window to Full Screen.
Tap the three bars to close the menu column.
You may have this later version

8
QRS PMII to PNO3WB Upgrade Instrucons
Inial System Setup‐QRS SYSTEM
Playback Parameters [The path to menu items will always start at the Home page.]
Do the correct keys play?
System Setup / Performance Setup / Test Files.
Play the Chromac test file. If the keys play from right to lethen, flip the Notes Inverted switch...below.
Play the Middle C test file. If the middle C key does not play then change the number of notes...below.
System Setup / Performance Setup / Playback Parameters.
[Tapthelabelstodisplaythedefaultseng.]
Legacy Driver Board Enabled = ON [Legacy boards are all boards other than the Smart Driver Boards] Scrolltoboomofpage.
Notes Inverted = ? Test Files‐Chromac [To determines the direcon of play.]
Number of Notes [MostQRSsystemsuseonly80keysolenoids,thefirstandlastfourareNOTused.]
80 note system ‐Number of notes =80
88 note system ‐Number of Notes = 88
80 note system ‐Lowest Note = 25
88 note system ‐Lowest Note = 21
Transpose =0
Note Delay (ms) =500
Is there a Pedal Solenoid aached?
If the system does NOT have a Pedal Solenoid aached then, turn on the Magic Pedal.
Magic Pedal = ON If no pedal solenoid is aached.
Lowest Note Test Files‐Middle C [ThissengisaMIDIReferenceandNOTtheactualnote/keynumber.]
Example: IfC#playedduringtheMiddleCtest,increasingtheLowestNotenumberbyonewillthentriggermiddleC.
Key Adjust
System Setup / Performance Setup / Key Adjust.
Set each note to play as SOFTLEY as possible!
Min. Aack [SetsthelevelthatanotewillplaywhentheMasterVolume=1andPianoVolume=0...whenplayingsongs.]
Beware: Absolute Min Force and Master Volume Curve sengs can OVERRIDE the Key Adjust sengs.
Note‐Use the “<‐” or “‐>“ buons to go to note 5, or 1 on an 88 note systems.
Force Preset‐Set to Regular Acon and tap “‐‐>“ at the right.
Retro Time (ms)‐Set to 120 and tap “‐‐>“ at right.
Retro Divisor‐Set to 1/3 of Key Force and tap “‐‐>“ at the right.
Press Start. Note 5, or 1 should begin to play.
1] Min. Aack‐Tap “‐” or “+” to adjust the note to play as soly as possible.
2] Note‐Tap “‐>“ to move to the next note.
Repeat steps 1 & 2 for each note.
Press Stop when all notes have been adjusted.
Global ‐Red when ON ‐Any changes made will affect ALL keys. Do NOT use!
Use the “<‐‐” or “‐‐>“ buons, in the Note row, to play chromacally up or down keyboard. Use to check the Min. Aack sengs.
The four “‐‐>“ buons, at the end of the boom four rows, set the current value to all keys upscale, from the selected note.

9
QRS PMII to PNO3WB Upgrade Instrucons
Inial System Setup (Connued) QRS SYSTEMS
Pedal Adjust‐Mechanical.
Sustain Pedal Solenoid Adjustments for Old Style Trapwork. Adjust, if necessary.
1
Loosen lock‐nut & turn the bolt to move the bolt‐head away
from the straight lever. We don’t want any pressure on the
straight lever while making the next few adjustments
2
Check for this small wood block, with felt pad, as shown.
This block stops the lever and prevents the thread‐rod from
3 The thread rod should be inserted in the damper tray and
into the straight lever.
4
If necessary, loosen the bolt and center the top of the “Z”
bracket secon of the “U‐shaped” lever over the sustain
pedal rod. Verify that the assembled “U‐shaped” lever clears
5 Adjust the sustain pedal rod’s bolt so that the “U‐shaped”
lever is parallel to the keybed.
6
Turn the carriage bolt‐head so that it touches the straight
lever and pushes up on the damper tray. Adjust for 1/8” to
1/4” lost moon between the damper tray and the damper
7
Loosen the lock‐nut on the sustain pedal solenoid and adjust
the rubber‐pped bolt so that when the piston is pressed
down, as far as it can go, the dampers lijust enough to clear
all of the strings. Ideally, we want the piston to travel the
shortest distance possible and sll lithe dampers. The farther
the piston travels, the more noise it will make when released.
Tighten the lock‐nut.

10
QRS PMII to PNO3WB Upgrade Instrucons
Pedal Adjust QRS SYSTEM [Notnecessaryifthereisn’tapedalsolenoidaachedand/orMagicPedalisON]
Go to: System Setup / Performance Setup / Pedal Adjust.
Pedal Test On Time:500 =500 [Adjusts the pedal solenoid ON/OFF interval during the Pedal Adjust procedure.
Make the changes below before beginning the adjustment.
Tap “‐” or input “0” in the fields and select Enter/Return on your keyboard.
Pedal Pre‐Play Time = 0
Pedal Aack = 2000
Pedal Hold = 0
Pedal Retro = 0
Get in a posion where you can see the piano dampers and then, Tap the Start buon.
Pedal Aack: Tap “+” unl the dampers jump up offof the strings. Tap “+” two more mes.
Pedal Hold: Tap “+” unl the dampers stay up for a second before falling. Tap “+” two more mes.
Pedal Retro: Tap “+” or “‐” so that the dampers hold for about one second before falling.

Tap the Stop buon when finished.
Pedal Retro pulses the pedal solenoid as it falls. This adjustment is used to eliminate some of the mechanical noise.
