AcousticDesign (AD)
Quick Start Guide
Model: AD-C4T
TD-000526-00-A
TD-000526-00-A

EXPLANATION OF SYMBOLS
The term “WARNING!” indicates instructions regarding personal safety. If the instructions are not followed the result
may be bodily injury or death.
The term “CAUTION!” indicates instructions regarding possible damage to physical equipment. If these instructions are
not followed, it may result in damage to the equipment that may not be covered under the warranty.
The term “IMPORTANT!” indicates instructions or information that are vital to the successful completion of the procedure.
The term “NOTE” is used to indicate additional useful information.
The intent of the lightning ash with arrowhead symbol in a triangle is to alert the user to the presence of
un-insulated “dangerous” voltage within the product’s enclosure that may be of sucient magnitude to
constitute a risk of electric shock to humans.
The intent of the exclamation point within a triangle is to alert the user to the presence of important safety,
and operating and maintenance instructions in this manual.
IMPORTANT SAFETY INSTRUCTIONS
• Read these instructions
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not use this apparatus near water.
• Clean only with a dry cloth.
• Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including ampliers) that produce heat.
• Only use attachments/accessories specied by the manufacturer.
• Refer all servicing to qualied service personnel. Servicing is required when the apparatus has been damaged in any way, such as power‑supply
cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture,
does not operate normally, or has been dropped.
• Do not use this apparatus in or near water or liquids.
• Do not submerge the apparatus in water or liquids.
• Do not use any aerosol spray, cleaner, disinfectant or fumigant on, near or into the apparatus.
• Do not block any ventilation opening. Install in accordance with the manufacturer’s instructions.
• Keep ventilation opening free of dust or other matter.
• Adhere to all applicable, local codes.
• Consult a licensed, professional engineer when any doubt or questions arise regarding a physical equipment installation.
Maintenance and Repair
Advance technology, e.g., the use of modern materials and powerful electronics, requires specially adapted
maintenance and repair methods. To avoid a danger of subsequent damage to the apparatus, injuries to persons
and/or the creation of additional safety hazards, all maintenance or repair work on the apparatus should be
performed only by a QSC authorized service station or an authorized QSC International Distributor. QSC is not
responsible for any injury, harm or related damages arising from any failure of the customer, owner or user of the
apparatus to facilitate those repairs.
Warranty
For a copy of the QSC Limited Warranty, visit the QSC website at www.qsc.com
Para una copia de la Garantía Limitada de QSC, visite el sitio web de QSC, en www.qsc.com
Pour obtenir une copie de la garantie limitée de QSC, visitez le site de QSC à www.qsc.com
Besuchen Sie die Webseite von QSC (www.qsc.com) um eine Kopie der beschräenkte Garantie von QSC zu erhalten.
如果您想要QSC有限保修的複印本，请造访QSC音频产品的网站www.qsc.com

Mount the Loudspeaker
Refer to Figure 5.
1. Make sure all of the dog-ears are fully extended and in their
non-capture position.
2. Position the loudspeaker into the hole prepared in the ceiling.
3. Use a Phillips screwdriver to tighten each of the three dog-ear screws.
As you tighten the screws, the dog-ears will swing into capture position
over the ceiling. Be sure all dog-ears are properly positioned over the
ceiling.
4. Tighten the dog-ears until rm contact is made with the ceiling surface.
CAUTION: Do not overtighten the dog-ear screws! Insert
the grille saftey tether grommet into supplied hole on the
loudspeaker bae and install the grille.
Prepare Ceiling
Refer to Figure 1.
1. Use the template provided to mark and cut a hole (1) in the ceiling
where the loudspeaker is to be installed. For frame-construction
ceiling, skip to “Wire the Loudspeakers”.
2. Install two V-rails (2), one on each side of the hole, and supported by
the suspended-ceiling support rails (3).
3. Install the C-ring (4) over the hole, using the V-rails as support. Make
sure the clips on the C-ring are properly tted over the V-rail.
4. Use sheet-metal screws (5) to secure the C-ring to the V-rails.
Wire the Loudspeakers
1. Set the transformer tap switch located under the grille for the desired
wattage setting or 16Ω for low impedance operation as shown in Figure 2.
2. Back out the conduit covers Phillips retaining screw to its stop point and
pull the conduit cover straight out to remove as shown in Figure 3.
3. Pass the wires through the conduit/stress-relief clamp, leaving enough
wire for making connections. Carefully tighten the clamp over the wires,
or over the conduit if used.
4. Wire the female Euro-style plug as shown in Figure 4.
5. Plug the connector securely into the receptacle.
6. Reattach the conduit cover and secure with the Phillips retaining screw.
‑ Figure 1. ‑
‑ Figure 2. ‑
‑ Figure 4. ‑
‑ Figure 5. ‑
‑ Figure 3. ‑
Dog-ears against loudspeaker
1
Turn the screw clockwise to engage the
dog-ear with the ceiling.
2
1
2
3
4
5
Parallel Wiring Diagram
Amp
To more
speakers
From
Source
To Additional
Loudspeakers
1
70V 100V
16Ω
16Ω
3.75
N/A
30
30
15
15
7.5
7.5

AD-C4T
LF Transducer 114 mm [4.5 in] weather resistant paper cone woofer
HF Transducer 25 mm [1 in] aluminum dome tweeter
Rated noise power [Wrms] 1 30
Nominal Impedance [ohms] 16
Transformer Taps 70V: 30, 15, 7.5, 3.75 W
100V: 30, 15, 7.5 W
Effective frequency range 2 60 Hz – 20 kHz
Rated coverage (‑6 dB) [°} 3 150° conical DMT
Directivity factor 34.5
Directivity index [dB] 36.5
Sensitivity [dB] 4 87.5
Maximum continuous SPL [dB] 5102
Maximum peak SPL [dB] 5108
Enclosure material ABS bafe on powder coated steel back can
Grille material Powder coated steel
Cutout dimension Ø 195 mm [Ø 7.68 in]
Net weight 2.9 kg [6.4 lb]
Product dimensions (Diameter x Height) Ø 230 x 176 mm [Ø 9.06 x 6.93 in.]
Shipping weight 9.3 kg [20.5 lb] (pair packed)
Shipping dimensions (H x W x D) 279 x 711 x 318 mm [11 x 28 x 12.5 in] (pair packed)
1IEC noise, 2hrs
2‑10dB from rated sensitivity
3500 Hz–5 kHz average
4Transfomer bypassed, 1W, 1m, IEC bafe, 200‑10kHz
average, on‑axis
5Calculated from rated noise voltage and sensitivity
Mailing Address:
QSC, LLC
1675 MacArthur Boulevard
Costa Mesa, CA 92626-1468 USA
E-mail:
[email protected]
[email protected]
[email protected]
Telephone Numbers:
Main Number: +1.714.754.6175
Sales & Marketing: +1.714.957.7100 or toll free (USA only) +1.800.854.4079
Customer Service: +1.714.957.7150 or toll free (USA only) +1.800.772.2834
Fax Numbers:
Sales & Marketing FAX: [phone]
Customer Service FAX: [phone]
[7.48 in]
190 mm
[9.06 in]
230 mm
[6.74 in]
171 mm
[6.94 in]
176 mm
AD-C4T
qsc.com
Specifications
Dimensions:
