Qtx Dazzler User manual

www.avsl.com 150.466UK User Manual
Dazzler
80W LED RGBWA Moving Head
Item ref: 150.466UK
User Manual
Dazzle your venue with bright and colourful washes using this compact moving head unit comprising a
powerful 80W 5-colour COB LED. Easily operated using internal auto or sound to light programs or by
11/14 channel DMX connection for more precise control, the unit can be free standing or mounted to
trussing using the supplied brackets and is ideal for small stages, bars, nightclubs and mobile DJs.
In the box:
Your Dazzler should arrive with you in a single carton in good condition. The carton should contain
1 x main unit with bracket, 1 x UK IEC mains lead and 1 x manual.
Warning:
To prevent risk of fire or electric shock, do not expose the unit to rain or damp environments. In the event
of a spillage, disconnect the mains and allow the unit to dry out naturally. Qualified personnel should then
check the unit before continuing use.
Please read through this manual thoroughly before use, any damage
caused by misuse of product will not be covered by warranty.
Please do not open cover, contains high voltage. This
product is not serviceable or repairable by the end user.
Please refer to qualified personnel for service and repair.

www.avsl.com 150.466UK User Manual
Placement:
•Use the included mounting bracket to fix to a stand or lighting truss.
•Use secondary safety fixings if mounting overhead.
•Keep away from damp or dusty environments.
•Ensure adequate airflow around the fixture housings.
•Ensure adequate access to controls and connections.
•Do not aim LED output directly into line of sight, as this can result in eye injury.
Cleaning:
•Use a soft cloth with a neutral detergent to clean the casing as required.
•Use a vacuum cleaner to clear ventilation grilles of any dust or debris build-ups.
•Do not use strong solvents for cleaning the unit.
Rear panel and control:
1. Menu button
2. Up button
3. Down button
4. LED display
5. Enter button
6. Microphone
7. DMX input
8. DMX output
9. IEC input (110-240 Vac, 50/60 Hz)
Manual control menu:
Press the “MENU” button to enter the settings menu.
Press “UP” and “DOWN” buttons to navigate through various setting functions.
Press “ENTER” button to confirm the desired setting:
1.
2.
3.
4.
5.
6.
7.
8.
9.

www.avsl.com 150.466UK User Manual
Menu
Function
Description
Addr
A001-A512
DMX address settings
Chnd
11CH-14CH
DMX channel select
Line
0-100
Concurrent sessions
Slnd
MAST-SL1-SL2-Addr
Work mode selection
Shnd
Sh1-Sh4
Sound active modes (Sh4 is 180° forward only DJ mode)
Aut0
Aut0 –Aut4
Auto effect selection (Aut4 is 180° forward only DJ mode)
SP00 - SP99
Auto effect speed - slow to fast
SoUn
on-off
Sound on/off
SenS
0-100
Sound active mode sensitivity –low to high
LeD
on-off
LED display on/off
dISP
dSIP
LED display reverse mode
Pan
no-yes
Pan reversal
tiLt
no-yes
Tilt reversal
test
Auto test mode
hour
0-9999
Unit run time
ver
v10
Current firmware version
rset
Reset to factory settings
DMX mode:
The Dazzler can be controlled by DMX signal, simply connect the DMX signal source to the DMX input on
the unit via a balanced XLR lead. Extra fixtures can be controlled by the same DMX signal by looping
through the DMX out on the unit. To enter DMX mode, select A001 from the menu and confirm the correct
start address by using the “UP”and “DOWN”buttons and “ENTER”. The A on the LED display will begin
to flash once it’s received the DMX signal from the controller. This unit has either 11 or 14 DMX channels
as indicated in the table below:
11CH
mode
14CH
mode
Function
DMX value and description
1
1
PAN
0-255 PAN adjust 0-540°
2
PAN fine
0-255
2
3
TILT
0-255 TILT adjust 0-540°
4
TILT fine
0-255
3
5
PAN & TILT speed
0-255 Speed adjust fast to slow
4
6
Dimmer
0-255 Dimmer 0-100%
5
7
Strobe
0-007 No function, 008-015 Open, 016-131 Strobe slow to
fast, 132-139 Open, 140-181 Slowly open quickly close,
182-189 Open, Quickly open slowly close, 232-239 Open,
240-247 Random strobe, 248-255 Open
6
8
Red wash
0-255 (0-100%)
7
9
Green wash
0-255 (0-100%)
8
10
Blue wash
0-255 (0-100%)
9
11
White wash
0-255 (0-100%)
10
12
Amber wash
0-255 (0-100%)
13
Colour macro
See below table
11
14
Special
0-009 No function, 010-059 Auto mode 1, 060-109 Auto
mode 2, 110-159 Auto mode 3, 160-209 Auto mode 4,
210-239 Reset, 240-255 Sound active mode
Colour
Macro
000-007, Blackout
008-015, R
016-023, G
024-031, B
032-039, W
040-047, A

www.avsl.com 150.466UK User Manual
Colour
Macro
(cont’d)
048-055, R+G
056-063, R+B
064-071, R+W
072-079, R+A
080-087, G+B
088-095, G+W
096-103, G+A
104-111, B+W
112-119, B+A
120-127, W+A
128-135, R+G+B
136-143, R+G+W
144-151, R+G+A
152-159, R+B+W
160-167, R+B+A
168-175, R+W+A
176-183, G+B+W
184-191, G+B+A
192-199, G+W+A
200-207, B+W+A
208-215, R+G+B+W
216-223, R+G+B+A
224-231, R+G+W+A
232-239, R+B+W+A
240-247, G+B+W+A
248-255, R+G+B+W+A
Specifications:
Power supply
110-240Vac, 50/60Hz (IEC)
Power consumption
100W
Fuse rating
F3A
LED power
80W RGBWA COB LED
Modes
Auto, sound, master/slave, DMX512
DMX channels
11, 14CH
PAN range
540°
Tilt range
270°
Beam angle
36°
Dimensions
245 x 205 x 140mm
Weight
2.35kg
Troubleshooting:
No power (mains)
Check mains voltage is correct and outlet is switched on
Check IEC lead and fuse (if fuse continually blows, refer to your dealer)
No light output
Check control panel mode settings
Check DMX settings from controller (dimmer levels, blackout etc.)
Unresponsive to DMX
Check that unit is in DMX mode and ensure the A on the DMX address flashes
to confirm it’s receiving a DMX signal
Check DMX controller is not set to black out
Check DMX controller is on correct fixture/page
Check master dimmer value
Check correct DMX address is set
Check DMX connection and leads
Overheating/Cutting out
Ensure adequate ventilation and unit is not too close to a heat source
This product is classed as Electrical or Electronic equipment and should not be disposed with other household or commercial waste
at the end of its useful life. The goods must be disposed of according to your local council guidelines.
Errors and omissions excepted.
