QUAD CONCOURSE R6 User manual
SPECIFICATIONS:
SYSTEM:
POWER HANDLING: 50watts continuous, 100watts program,
200watts peak
Recommended amplifier: 10-100 watts
Impedance: Selectable 4 or 16 ohms nominal
Frequency response (-10dB): 40Hz-20kHz
Frequency response (+/-3dB): 70Hz-20kHz
Sensitivity: 89dB/1watt/1meter
Max SPL: 112dB
Coverage: 140*110
Directivity (Q): 6.14
TRANSDUCERS:
LF Driver: 6.5” Cone
HF Driver: 1” Dome tweeter
Crossover Frequency: 2.3kHz
PHYSICAL:
Type: Two way passive ported design
Material: Plastic ABS
Connector: Terminal strip
Dimensions (HxWxD): 332mm x 232mm x92mm
Nett Weight: 1.8kg
ARCHITECTURAL SERIES
RECTANGULAR TWO WAY
WALL/CEILING SPEAKER
KEY FEATURES:
✓Two way ported rectanuglar wall/ ceiling loudspeaker with 6.5” bass
driver, 1” soft dome tweeter and passive crossover
✓100watts program, 200watts peak
✓Optional 4ohm or 16ohm low impedance models
✓Integral 30/15/7.5/3.75watt tap line transformer
✓Integral mounts s to allow
simple installation from below the ceiling.
APPLICATIONS:
✓Corporate Meeting Rooms
✓Classrooms
✓Training Rooms
✓Restaurants
✓Retail Outlets
✓Hotels
✓Health Clubs
DESCRIPTION:
The QUAD Industrial CONCOURSE R6 is a two way rectangular wall/ ceiling
speaker with a 6.5” LF, 1” soft dome tweeter and passive crossover. The
Concourse R6 is intended for small to medium room applications requiring high
quality speech reinforcement and/or background music.
The CONCOURSE R6 can be ordered as either 4 or 16 ohm low impedance,
allowing efficient use of amplifier power and parallel looping connections with no
transformer losses or signal degradation.
The CONCOURSE R6 includes a pair of clamp mountings for weight distribution
on ceiling finishes.
CONCOURSE R6
Concourse R6 version3 19/3/04 10:47 am Page 1
CONCOURSE R6
STANDARD ACCESSORIES:
Color: White with color matched grill cloth
Clamp: A pair of clamp brackets are included with the loudspeaker to facili-
tate mounting on ceiling finishes.
ARCHITECTURAL & ENGINEERING SPECIFICATIONS:
The loudspeaker shall consist of a two way system with a 6.5” low frequen-
cy driver, 1” dome tweeter and internal crossover installed in a ported plas-
tic grill with a clamp mounting and terminal strip connection.
The loudspeaker shall have selectable 4 and 16 ohm impedance.
The loudspeaker shall have a color matched grill cloth to hide the transduc-
ers and switches.
The loudspeaker shall have the following performance specifications:
Power, 50 watts continuous
Sensitivity, 89 dB (1 watt, 1 meter, Hz-kHz).
Usable frequency response from 40Hz to 20kHz (-10 dB);
Coverage pattern of (nominal) 140*110
