QUADRO VEHICLES OXYGEN User manual

Dear Customer,
QUADRO VEHICLES thanks you for choosing OXYGEN, and welcomes you as a Customer!
To maintain the efficiency, performance and safety conditions of the vehicle, careful maintenance is required; this must be performed
atauthorised QUADRO VEHICLES servicing centres.
Our technicians have produced this high quality vehicle, the result of our extensive experience, to guarantee you the pleasure
of safe driving over time.
Please read this Use and Maintenance Manual supplied with your QUADRO VEHICLES vehicle carefully, and make sure that
all routine and extraordinary maintenance and any technical servicing is performed exclusively by the specialist staff from our
Network ofQUADRO VEHICLES authorised servicing centres
To ensure the safety, reliability and value of your scooter, and to maintain the validity of the warranty, use only original QUADRO
VEHICLES spare parts and recommended lubricants.
Before you begin using the scooter, you must read this Use and Maintenance Manual carefully and follow all instructions it
contains precisely.
The scooter must not be used by persons who have not thoroughly read and understood the instructions contained in
this Use and Maintenance Manual.
This Use and Maintenance Manual contains simple and clear descriptions of the operations necessary to understand and use
your scooter, as well as recommendations for safe use of your scooter in order to avoid personal injury.
It also describes the main maintenance operations and periodic checks which must be performed on the scooter.
The guarantee of correct operation and safety of the scooter strictly requires that all instructions contained in this Use and
Maintenance Manual be applied.
This Use and Maintenance Manual must always be provided together with the scooter if it is resold, hired or lent out.
This Use and Maintenance Manual is an integral part of the scooter and it must therefore be kept in a safe place accessible to
all persons who might need to consult it.
If the Use and Maintenance Manual is lost or damaged, request a new one from your dealer, giving them the scooter specifications.
This Use and Maintenance Manual is an integral and essential part of your vehicle.

The text of this publication contains a series of dedicated symbols used to highlight the main requirements and recommendations
to be followed for keeping your scooter and its passengers safe.
The information contained in this Use and Maintenance Manual is provided as a guide only and may not be completely up to date
due to modifications which may be made by Quadro Vehicles at any time for technical and/or commercial reasons, or else to comply
with the legislation of the country in which the scooter is sold.
In order to learn and understand all features and functions of your scooter, you are advised to carefully read the following Use and
Maintenance Manual supplied with the scooter.
SYMBOLS USED
DANGER to persons and to the scooter.
The following symbol indicates that it is prohibited to use/handle flammable substances near the vehicle, lubricate/touch moving
mechanical parts or remove any guards on the scooter. It also invites you to wear appropriate clothing and protection at all times,
both when driving and servicing the vehicle, particularly if there is a possibility of coming into contact with any parts which could
cause burns, electric shocks or irritations.
WARNING which you must pay attention to in order not to risk damage to the scooter.
The following symbol invites you to use only original spare parts or parts specifically type-approved for OXYGEN and to
avoid all improper modifications which may compromise the scooter's functions, consequently causing the warranty to
become null and void
WARNING with an impact on the environment.
The following symbol invites you to dispose of all products (for example lubricants) and all mechanical and bodywork components
in the disposal and recycling methods laid down by the statutory regulations in force in each country.
NOTE of a general nature.

CONTENTS
SAFETY AND RECOMMENDATIONS
POSITIONING INFORMATIVE STICKERS............................6
GENERAL RECOMMENDATIONS AND
REQUIREMENTS..................................................................8
CLOTHING ..........................................................................8
ELECTRIC VEHICLE BATTERIES ..........................................8
SAFE DRIVING...................................................................10
WHEN AT A STANDSTILL..................................................11
LOAD LIMITS.....................................................................12
UNAUTHORISED MODIFICATIONS/ACCESSORIES AND
SPARE PARTS.....................................................................12
RESPONSIBILITIES AND LIMITS OF USE ..........................13
GETTING TO KNOW YOUR SCOOTER
COMPONENT LOCATION................................................16
HANDLEBAR CONTROLS, LEFT-HAND SIDE ...................17
Dipped headlights .......................................................17
Full-beam headlights ...................................................17
Flasher..........................................................................17
Turn signals ..................................................................17
Horn .............................................................................17
HANDLEBAR CONTROLS, RIGHT-HAND SIDE.................18
Engine stop command.................................................18
SET button ...................................................................18
KEYS ..................................................................................18
STEERING LOCK ...............................................................19
STOPPING THE SCOOTER ...............................................19
INSTRUMENT PANEL ........................................................20
Standard configuration.................................................20
Extra Configuration Display 1 ......................................21
Extra Configuration Display 2 ......................................22
Instrument Panel Messages .........................................25
ON-BOARD COMPUTER...................................................26
Trip Computer..............................................................26
Drive mode ..................................................................26
Battery 1.......................................................................26
Battery 2.......................................................................26
Time indicator ..............................................................26
Speed...........................................................................26
The scooter speed is displayed. ..................................26
Speed unit of measurement.........................................26
Autonomy ....................................................................26
Odometer ....................................................................26
Power ...........................................................................26
Average speed.............................................................26
Fuel consumption ........................................................26
“OXYGEN” BLUETOOTH APPLICATION..........................27
REAR BRAKE LEVER ..........................................................29
UNIFIED BRAKE LEVER .....................................................29
REAR-VIEW MIRRORS........................................................29
CENTRAL STAND ..............................................................29
SEAT COMPARTMENT ......................................................30
DRIVE MODE.....................................................................30

USE
IGNITION KEY ...................................................................34
ENGINE START..................................................................34
ENGINE STOP ...................................................................35
PARKING............................................................................35
RECHARGING THE ELECTRIC VEHICLE BATTERIES ........35
ELECTRIC VEHICLE BATTERIES ........................................36
MAINTENANCE
GENERAL ISSUES ..............................................................40
CHECKS.............................................................................41
Brake oil.............................................................................41
Brake pads .........................................................................41
Drive belt ...........................................................................41
CLEANING.........................................................................42
PERIODICAL CHECKS .......................................................44
DEMANDING USE / PROLONGED INACTIVITY ...............44
SCHEDULED MAINTENANCE...........................................44
PLANNED MAINTENANCE PLAN.....................................45
FUSES ................................................................................48
HEAD LIGHT CLUSTER......................................................48
Replacing the dipped-beam/full beam headlamps .....48
TAIL LIGHT CLUSTER.........................................................49
Replacing Bulbs ...........................................................49
REPLACING TYRES............................................................49
INACTIVITY AND LAYING UP
SCOOTER INACTIVITY AND LAYING UP..........................52
TECHNICAL DATA
SCOOTER IDENTIFICATION.............................................56
Frame number..............................................................56
FEATURES..........................................................................57
PRODUCTS........................................................................58
BRAKE SYSTEM .................................................................58
TRANSMISSION.................................................................58
FRAME...............................................................................58
SUSPENSIONS...................................................................58
ELECTRIC VEHICLE BATTERIES ........................................58
WEIGHTS AND LOADS .....................................................58
RIMS...................................................................................59
TYRES ................................................................................59
TYRE PRESSURE ................................................................59
BARTTERY CHARGER........................................................59
DIMENSIONS ....................................................................60

SAFETY AND RECOMMENDATIONS 1

SAFETY AND RECOMMENDATIONS
6
fig. 1
4
6
7
1
2 3
4
5
6
7
181
This chapter contains the main
precautions you must take in order to
drive your vehicle as safely as possible.
POSITIONING INFORMATIVE STICKERS

1
7
REFER TO FIGURE 01 TYPE OF STICKER STICKER DESCRIPTION
1 VIN The VIN, or registration number, is punched on the head tube.
2 ECU ECU serial number. For use by authorised QUADRO VEHICLES servicing
centres.
3 Electric vehicle batteries Warnings and precautions for the correct use of electric vehicle batteries.
4 Charging Warnings and precautions for correct charging.
5 Tyres Front (2.4 bar) and rear (2.4 bar) tyre pressure.
6 Electric motor Electric motor serial number.
7Controller Controller serial number. For use by authorised QUADRO VEHICLES servicing
centres.
8 Manufacturer’s plate This is positioned next to the VIN code, on the head tube, and gives the
manufacturer’s data.

SAFETY AND RECOMMENDATIONS
8
Using OXYGEN requires knowledge
of driving techniques for two-/three-
wheeled vehicles.
Ensure you have learnt and practised
these techniques with a qualified driving
instructor before using the scooter.
OXYGEN has been designed to offer
the driver and passenger maximum
comfort and safety, however this can
only be obtained through responsible
use of the scooter.
When necessary, we recommend prac-
tising the scooter functions away from
heavily trafficked areas.
GENERAL RECOMMENDATIONS
AND REQUIREMENTS
Do not drive the vehicle if you
do not have a valid driving licence.
Driving while under the influence
of alcohol and drugs or medicaments,
has a significant negative effect on
reaction times, decision-making and
driving abilities in general; it is also
generally punished in accordance with
the laws of the country in which you
are driving.
The driver and passenger must wear
clothing and safety equipment which
meets applicable legislation in the
country the vehicle is being driven in
and protects them as far as possible
in the case of an accident. We recom-
mend always wearing a type-approved
helmet, visor/goggles, gloves, overall
and boots; you should always avoid
any clothing or accessories which could
get caught in the moving parts of the
scooter and/or obstruct the driver's
view.
While the scooter is being serviced,
wear clothes and protective equipment
that are suitable for the operation being
carried out.
CLOTHING
Wear adequate technical
clothing and safety equipment that
is approved and certified and that
guarantees optimal protection to
the driver and passenger. You are
recommended to always wear cloth-
ing that makes the driver visible to
other road users.
ELECTRIC VEHICLE BATTERIES
The electric vehicle batteries consist of
high energy density lithium ion cells.
Do not tamper with the electric
vehicle batteries in any way; failure
to comply with this instruction leads
to electric/chemical risks, and con-
sequent harm to persons and/or
damage to property.
Each battery is equipped with
a device which counts the days from
when the charge level drops below
20% (equivalent to the indicator
light lighting up on the display).
The warranty will be immediately
invalidated if the charge level
remains below 20% for 40 or more
days. So charge the battery before
this occurs.

1
9
The inspection, repair or
replacement of the battery, or any of
its parts, by personnel not explicitly
authorised by the manufacturer, is
strictly forbidden.
Handling and/or repairs of
any electrical/electronic component
on the vehicle (engine, controller,
etc.) by any personnel not expressly
authorised by the manufacturer is
strictly forbidden.
Driving style affects the life of
the electric vehicle batteries.
Do not use the vehicle in extremely
hot or cold conditions (beyond the
limits indicated by the manufacturer).
Do not charge the electric vehicle
batteries in extremely hot or cold
conditions (beyond the limits indicated
by the manufacturer).
When not in use (for short or long
periods) the scooter must be stored
in a dry place away from hot and/or
cold sources and direct sunlight.
Avoid knocks and/or excessive
vibrations to the scooter.
Regularly check the correct insulation
of the electric vehicle batteries and
the chassis.
Monitor the electric vehicle battery
discharge.
If the scooter is not used for long
periods, make sure that the electric
vehicle batteries are fully charged.
After charging, leave the electric
vehicle batteries connected to the
battery charger for at least 20 minutes.
Use only battery chargers supplied
directly by the manufacturer or by
an authorised dealer.
When charging, do not switch on
and/or start the scooter.
The battery has built-in protection
against electrical risks, which are
activated automatically in the event
of a fault. If the battery does not
work correctly, contact an authorised
servicing centre.
Keep the electric vehicle batteries
clean and in good conditions, remove
any dust, dirt or foreign bodies inside
the battery compartment during use.
If any deterioration in the electrical
system wiring is noted, switch off the
vehicle and take it to an authorised
QUADRO VEHICLES servicing centre.
Water, mud and so on must
not come into direct contact with
the electrical system on the scooter.
If water accidentally gets inside one
of the electrical elements on the
scooter, switch it off and wait for it
to dry naturally before using again.

SAFETY AND RECOMMENDATIONS
10
SAFE DRIVING
OXYGEN has been designed to trans-
port the driver and a maximum of one
passenger. Before driving you must
perform a general check on the condition
of the scooter, particularly the safety
systems, lights and tyres; if you should
notice any serious faults, consult an
authorised QUADRO VEHICLES au-
thorised servicing centre.
While driving, the driver must keep
both hands on the handlebars and the
passenger must hold onto the handles
at the sides of the seat. Both the pas-
senger and driver must keep both feet
on the footrest while the scooter is in
motion. We therefore advise you do
not transport passengers who are not
able to keep their feet firmly planted
on the footrest.
Both the driver and the passenger
must sit in the right position that allows
the driver to control all the functions
of the vehicle and does not involve an
unbalancing of the load that could
jeopardise the stability of the scooter.
Always transport the passenger on the
rear of the seat.
When starting off, release the brake lever
and turn the throttle handle slowly in
the direction shown by the arrow; to
decelerate, release the throttle handle
accompanying it.
If you open and close the throt-
tle handle abruptly it could cause
the vehicle to race forward suddenly
and a possible loss of vehicle control.
Do not attempt to start the
vehicle with the throttle open as you
might lose control of the scooter.
Comfortable braking is guaranteed by
the gradual and simultaneous use of
both the front and rear brake.
Should it be necessary to
brake in an emergency, do not
let the throttle go abruptly but
accompany it as quickly as possible
to the "closed" position.

1
11
During a long stretch downhill, release
the throttle handle and brake gently
intermittently. Using the brakes for a
long time continuously could cause
them to overheat thus losing braking
efficiency.
In order to avoid possible collisions,
you should:
• always make yourself visible to
other drivers, ensuring you do not
drive in their blind spots;
• use appropriate caution when going
through road junctions;
• Use the direction indicators to signal
a lane change or turning.
OXYGEN has been designed
and developed for use on roads;
you should therefore avoid off-road
routes and/or particularly uneven
roads.
If the road surface is wet, drive very
carefully and never brake abruptly as
the wheels might lock as a prevention
thereby increasing the scooter's stopping
distance and time. Always drive over
bumpier road surfaces such as tram
rails or potholes slowly.
In case of strong gusts of wind, drive
the vehicle at a moderate speed.
You should always adapt your speed
on the basis of the current road/traffic/
atmospheric conditions, and must never
in any case exceed the applicable speed
limit.
Do not touch any of the mechanical
components, as these can reach high
temperatures during operation.
WHEN AT A STANDSTILL
When getting off the scooter place it on
the stand If you are carrying a passenger,
get the him or her to get off the scooter
first.
When parking your scooter, ensure it is
left in a location where it is not likely to
be hit by other traffic; it is also advisable
not to park the scooter on steep slopes,
uneven surfaces or on leaves, branches
or other flammable materials, as the high
temperature reached by some mechan-
ical and/or electrical components could
ignite them.

SAFETY AND RECOMMENDATIONS
12
LOAD LIMITS
In order not to compromise the stability of
the scooter, it is essential not to exceed
the maximum permissible load, and to
distribute this as uniformly as possible
(refer to the “Technical Data” chapter).
You must ensure that any loads are
correctly positioned and/or restrained
in the areas laid out for them. You
should also limit your speed on the basis
of the transported load.
Greater stability can be achieved by
placing loads inside the compartments
provided (the compartment under the
seat and the object compartment).
Furthermore it is advisable always to fix
loads being transported in such a way
that during the journey they do not
move so as to unbalance the weights
causing you to lose control of the vehicle.
UNAUTHORISED MODIFICATIONS/
ACCESSORIES AND SPARE PARTS
Do not make any type of modification
to the scooter (mechanical components
or bodywork), and always use original
Quadro Vehicles components/accesso-
ries in order not to compromise vehicle
operation and driver/passenger safety.
Never install accessories that require
the electrical system to be modified.
The use of non-original and/
or non-approved parts on your vehi-
cle, even if purchased at authorised
QUADRO VEHICLES servicing centres,
may result in your warranty lapsing
and/or scooter malfunctions.
The sum of the weight of the
driver, the passenger and the load
transported must never exceed
the maximum specified in chapter
“Technical Data” of this Use and
Maintenance Manual.
Never transport loads on the
scooter handlebars.

1
13
Never drive the scooter with
removed and/or damaged parts.
Rims and tyres are the point where
the scooter is in contact with the road
surface. The use of rims and tyres with
specifications different from those
indicated in this Use and Maintenance
Manual or not approved could cause
instability or a loss of control of the
vehicle.
RESPONSIBILITIES AND LIMITS OF
USE
Improper use of the scooter or any
work performed on it which does not
conform to the indications given in this
Use and Maintenance Manual shall relieve
the manufacturer of any responsibility for
vehicle safety and/or operation.

Page left intentionally blank
14

GETTING TO KNOW YOUR SCOOTER 2

16
GETTING TO KNOW YOUR SCOOTER
This chapter describes the functions
and systems your OXYGEN is equipped
with.
Carefully reading the following pages will
provide you with the knowledge to make
the most of your scooter's potential.
COMPONENT LOCATION
1 - Accelerator
2 - Brake lever
3 - Ignition key
4 - Instrument panel
5 - Drive belt
6 - Central stand
fig. 1
4
3
10
8
9 5
11
2
7
6
1
7 - Headlight
8 - Seat opening lock
9 - Electric motor
10 - Electric vehicle batteries
11 - Luggage rack hook

17
2
Horn
To sound the horn, press and hold
down button A fig. 4.
Full-beam headlights
With the key in the ON position, turn
selector A fig. 2 to position 1 in order
to turn on the full beam headlights; this
is indicated by the following light on
the instrument panel: .
Flasher
With the key in the ON position, you
can flash the lights by pressing button
A in fig. 2, position 3.
Turn signals
With the key in the ON position, place
selector A fig. 3 in position 1 or position
2 to operate the right or left turn signals
(momentary positions). The left-hand
turn signal indicator light comes on the
instrument panel .
To deactivate the turn signals, press
button A fig. 3 on the selector.
HANDLEBAR CONTROLS, LEFT-
HAND SIDE
The controls on the left-hand side of the
handlebar include: full beam headlights,
flasher, turn signals, horn.
Dipped headlights
With the key in the ON position and
selector A fig. 2 in position 0, the
dipped headlights are turned on;
A0
1
3
The dipped headlights always
stay on.
A
2
1
fig. 3
A
fig. 4
fig. 2

18
GETTING TO KNOW YOUR SCOOTER
HANDLEBAR CONTROLS, RIGHT-
HAND SIDE
The controls on the right-hand side
of the handlebar include: engine stop
command, SET button.
Engine stop command
To switch off the motor, move lever A
fig. 5 to position 1.
The motor stops but the scooter
is still in any case switched on.
A
1
B
fig. 5
KEYS
The scooter is supplied with two identical
keys, which allow you to start the vehicle,
engage the steering lock and open the
seat.
The keys are accompanied by a plate
showing their code.
If you need to make a duplicate of the
keys, contact an authorised QUADRO
VEHICLES servicing centre and provide
the plate with the code as well as the
key.
We recommend keeping the
spare key in a safe place so it does
not get lost.
SET button
The SET button B fig. 5 has three
functions:
• it sets the required drive mode (for
more information see paragraph
“DRIVE MODE” in this chapter);
• it resets the mileage on the TRIP
computer (for more information
see paragraph “ON-BOARD
COMPUTER” in this chapter);
• it changes the unit of measurement
from kilometres to miles and vice
versa (for more information see par-
agraph “ON-BOARD COMPUTER”
in this chapter).
