iQube SmartXonnect User manual

FOREWORD
Hello!
You are now a proud owner of the iQube Electric SmartXonnect scooter from the house of TVS Motor
Company.
The iQube Electric SmartXonnect is an electric scooter like no other. It gives you the unmatched
combination of performance, connected technology and practicality of use. So now you can ride in
style and comfort, with all the savings benefits of an electric vehicle.
For getting the best out of your TVS iQube Electric SmartXonnect, please read the manual carefully
and understand all features and operations of your vehicle. Follow the instructions and enjoy a
smart and convenient experience that comes with your iQube Electric SmartXonnect.
To ensure a worry free journey on your TVS iQube Electric SmartXonnect, we urge you to get your
vehicle serviced only at TVS Motor Company Authorized Dealers.
We hope you enjoy every aspect of being a proud owner of TVS iQube Electric SmartXonnect and
being a part of our community of smart, next-gen and sustainable riders.
Happy riding!
TVS MOTOR COMPANY LIMITED
1
OM TVS iQube Electric SmartXonnect - Rev 4 - As on 08 Jun 2022

2
CONTENTS
CONTACTS FOR SUPPORT........................................................................................................03
INTRODUCTION.....................................................................................................................05
UNIQUE FEATURES.................................................................................................................06
SAFETY INFORMATION...........................................................................................................10
KNOW YOUR TVS iQUBE ELECTRIC SMARTXONNECT................................................................12
CONTROLS.............................................................................................................................16
CHARGER SOCKET...................................................................................................................24
VEHICLE CHARGING................................................................................................................26
LED / TFT INSTRUMENT CLUSTER.............................................................................................28
MAINTENANCE SCHEDULE......................................................................................................36
SELF MAINTENANCE PROCEDURES..........................................................................................38
WARRANTY INFORMATION....................................................................................................40
TECHNICAL SPECIFICATIONS...................................................................................................43
GENERAL INFORMATION........................................................................................................45
OM TVS iQube Electric SmartXonnect - Rev 4 - As on 08 Jun 2022

4
11
12
TAMILNADU-1, 3 & 4
1. TVS Motor Company Limited
V Floor, Gee Gee Universal,
No. 2, MC Nichols Road,
Chetpet, Chennai - 600 031.
Phone : [phone]
Email : [e-mail]
[e-mail]
TAMILNADU-2
2. TVS Motor Company Limited
No. 10, 2nd floor,
Shree Shanmugapriya Towers,
Kannuswamy Street,
Behind Hotel Annapoorna,
R S Puram, Coimbatore - 641 002.
Phone : [phone]
Email : [e-mail]
KERALA
3. TVS Motor Company Limited
Ambady Towers, Second Floor,
Door No. 27/631, A6,
Edappally-Pookkaupady Road,
Edappally PO., Cochin - 682 024.
Phone : [phone]
Email : [e-mail]
KARNATAKA-1, 2 & GOA
4. TVS Motor Company Limited
No. 600, Anand Surya, 2nd Floor,
15th Cross, 6th Phase, JP Nagar,
Opp. BMTC Bus Stop,
Bangalore - 560 078.
Phone : [phone]
Email : [e-mail]
[e-mail]
ANDHRAPRADESH -1 & 2
5. TVS Motor Company Limited
Rukumani Towers, First Floor,
No. 3-11-30, Plot No. 11,
Paigha Colony, Behind Anand Theater,
Secunderabad - 500 003.
Phone : [phone]
Email : [e-mail]
[e-mail]
CONTACTS FOR SUPPORT
Under any circumstances, TVS Motor Company Limited will be glad to provide any additional
information or service assistance you require. Please feel free to contact us at our area offices:
MAHARASHTRA-1 & 2
6. TVS Motor Company Limited
No. 401, 4th Floor, The Chambers,
Plot No. 4/12/3, Near Ganapa Chowk,
Viman Nagar, Pune - 411 014.
Phone : [phone]
Email : [e-mail]
MAHARASHTRA-3 & CHATTISGARH
7. TVS Motor Company Limited
No. 502B, 6th Floor, B Wing,
Shriram Shyam Towers,
Near LIC Square, Sardar,
Nagpur - 440 001.
Phone : [phone]
Email : [e-mail]
[e-mail]
GUJARATH
8. TVS Motor Company Limited
109, Ayna Complex,
Opp. Suvarna Villa Bungalows,
100  Thaltej Hebbatpur Road,
Off : S.G. Highway, Thaltej,
Ahmedabad - 380 054.
Phone : [phone]
Email : [e-mail]
MADHYA PRADESH-1 & 2
9. TVS Motor Company Limited
No. 211-212, 2nd Floor,
Chinar Incube Business Centre,
Chinar Fortune City,
Near Brindhavan Dhaba,
Hosangabad Road,
Bhopal - 462 026.
Phone : [phone]
Email : [e-mail]
[e-mail]
RAJASTHAN-1 & 2
10. TVS Motor Company Limited
Plot No. 17-18,
2nd Floor of Naonal Motors Building,
Jhotwara Industrial Area,
Jaipur - 302 012.
Phone : [phone]
Email : [e-mail]
[e-mail]
3
OM TVS iQube Electric SmartXonnect - Rev 4 - As on 08 Jun 2022

DELHI & HARYANA
11. TVS Motor Company Limited
D-3 & D-4, 2nd Floor,
Sector - 10, Noida,
Uar Pradesh - 201 301.
Phone : [phone]
Email : [e-mail]
[e-mail]
PUNJAB & CHANDIGARH
12. TVS Motor Company Limited
4th Floor, Royal Business Park,
Chandigarh Ambala Highway,
Zirkapur - 140 603.
Phone : [phone]/465777
Email : [e-mail]
UTTAR PRADESH WEST
13. TVS Motor Company Limited
D-3 & D-4, 2nd Floor,
Sector - 10, Noida,
Uar Pradesh - 201 301.
Phone : [phone]
Email : [e-mail]
UTTAR PRADESH CENTRAL & EAST
14. TVS Motor Company Limited
1st Floor, Cyber Tower, TC-34/V-2,
Vibhu Khand, Gom Nagar,
Lucknow - 226 010.
Phone : [phone]
Email : [e-mail]
[e-mail]
WEST BENGAL
15. TVS Motor Company Limited
Ground Floor & First Floor,
133 A. S. P. Mukherjee Road,
Opp. Tollygunge Police Staon,
Kolkaa - 700 026.
Phone : [phone]
Email : AO.Kolka[e-mail]
BIHAR
16. TVS Motor Company Limited
N-Plaza, Jamal Road,
P.S. Kotwali,
Patna - 800 001.
Phone : [phone]
Email : [e-mail]
ORISSA & JHARKHAND
17. TVS Motor Company Limited
No. 303, 3rd Floor,
Creave Plaza, Rasulgarh,
Bhubaneshwar - 751 010.
Phone : [phone]
Email : [e-mail]
NORTH EAST STATES
18. TVS Motor Company Limited
147, Udayan, Ganesh Guri,
Opp. Punjab Naonal Bank,
R G B. Road, Guwaha - 781 005.
Phone : [phone]
Email : AO.Guwaha@tvsmotor.com
Or
Toll Free Number Relationship Manager : 1800-572-1818 (Mon - Fri: 9 am to 6 pm)
Toll Free Number Roadside Assistance : 1800-258-7111 (Available 24 x 7)
Email : [e-mail]
4
OM TVS iQube Electric SmartXonnect - Rev 4 - As on 08 Jun 2022

INTRODUCTION
One of the finest and modern technology products of TVS Motor is waiting to be unveiled; an
electric scooter which is futuristic and contains plenty of features and technological advancements.
However, before delving further into this manual, let us first have a glimpse of what your electric
two wheeler is and how it is different from an internal combustion engine powered vehicle. The
below info-graphic provides a broad idea about an electric two wheeler;
MCU
BATTERY PACKS
1 2 3
Powerful wheel mount hub motor
MCU electronic device to control EV POWER TRAIN
Advanced Lithium ion baery
An IC engine running on petrol
Fuel Tank
Convenonal transmission
FUEL
TANK
vs
5
OM TVS iQube Electric SmartXonnect - Rev 4 - As on 08 Jun 2022

UNIQUE FEATURES OF TVS iQUBE ELECTRIC
SMARTXONNECT
LCD / TFT INSTRUMENT CLUSTER
Unlike conventional scooters this vehicle is
having a digital instrument cluster which
ensures brighter display and allows ease of
interaction between vehicle and the rider.
RETRACTABLE BAG HOOKS
Your scooter has two retractable Bag Hooks to
carry light luggage like carry bags weighing upto
3 kg.
One hook is located below the handle bar on
the rear panel and the other one is located on
the cover front below the front end of seat
Refer tails.page No. 22 for de
TELESCOPIC FRONT FORK
Your Scooter has Motorcycle-like 'Telescopic
Front Suspension' for extreme comfort for
excellent riding comfort even on bad roads.
TUBELESS TYRES
Another important unique feature in your
scooter is 'Tubeless Tyres'. Tubeless tyres
reduce the chances of getting punctured. Even
if there is a puncture, sudden leakage of air is
avoided, thereby providing better safety and
convenience. It is also very easy to repair the
punctured tyres.
6
OM TVS iQube Electric SmartXonnect - Rev 4 - As on 08 Jun 2022

ALL BLACK LARGER ALLOY WHEELS
All 'Black Larger Alloy Wheels' with high
mechanical advantage gives progressive
braking of your scooter, results in best-in-class
'shortest distance' braking. It also provide
superior comfort in bad road conditions.
PARKING BRAKE (BRAKE LOCK LEVER)
'Parking Brake' is another unique safety feature
which protects your scooter from falling due to
wheel rotation when it is parked with the side
stand on a slope. for details. Refer page No. 17
DISC SYNCHRONISED BRAKE TECHNOLOGY
(SBT)
Taking technological innovation to next level,
your scooter comes with 'Synchronised Brake
Technology (SBT)'. This feature enhances the
safety by avoiding skidding during sudden
braking.
ALL LED ILLUMINATION
Your Scooter comes in with premium LED
lamps. Efficient and bright, this gives TVS iQube
Electric SmartXonnect a totally upgraded Look
and Style with better visibility for night rides.
LED lamps consume less power with increased
luminous intensity.
7
OM TVS iQube Electric SmartXonnect - Rev 4 - As on 08 Jun 2022

UNDER-SEAT STORAGE (UTILITY BOX)
Your scooter has a 10 litre under-seat storage
space to carry your luggage belongings. Refer
page No. 22 for details.
SIDE STAND INDICATION
Vehicle will be immobile and side stand
indication will be shown in the instrument
cluster if the vehicle is on side stand.
MALFUNCTION INDICATION AND SERVICE
REMINDER
Malfunction indication notifies you to take the
vehicle for diagnostic and troubleshooting,
whereas service reminder recalls you to take
the vehicle for periodic maintenance (care) at
Authorised Service station based on the alert.
FLIP KEY WITH LED LIGHT
Foldable key with LED light helps you to see
ignition lock in dark.
PLEASANT HORN TONE
A newly designed horn produces a pleasant
tone when pressed by user.
Always release the side stand to its full up
position before moving the vehicle.
Caution
8
OM TVS iQube Electric SmartXonnect - Rev 4 - As on 08 Jun 2022

TEXTURED FLOORBOARD
Your scooter comes with a stylish textured floor
board.
TEXTURED FLOOR MAT
Your scooter comes with a stylish textured floor
mat.
9
ACCESSORIES FOR YOUR SCOOTER
SMART PHONE CHARGER
Your TVS iQ Electric SmartXonnect is ube
provided with a socket for charging your smart
phone even while you are traveling and it is
located in the utility box below the seat
assembly. Refer for usage details.page No. 23
OM TVS iQube Electric SmartXonnect - Rev 4 - As on 08 Jun 2022

SAFETY INFORMATION
Operating this vehicle safely is an important responsibility of the rider. To help you make safe
decisions while operating the vehicle, we have provided necessary operating procedures and other
information in this manual. This information alerts you on potential hazards that could cause injury
to you or others. Since it is not possible to warn you about all the hazards associated with operating
or maintaining the vehicle, you must use your own judgement.
You will find important safety information in following form in this manual. These words carry the
following connotations:
Warning
Disregarding this message might result in accidents or injury to the rider.
Note
This message provides further clarification for clear understanding of any particular
Note
Ÿ All informaon, illustraons, photographs and specificaons contained in this owners manual
are based on the latest product informaon available at the me of this publicaon. TVS Motor
Company Limited may, however, incorporate modificaons or improvements on its vehicles at
any me without noce and therefore, in such events it is possible that the relevant part of the
owner’s manual does not apply to your vehicle.
Ÿ Prior permission of TVS Motor Company Limited is required for quong, copying or reproducing
any part of the owner’s manual.
ŸAccessories shown in the picture may not be part of the standard equipment.
ŸPictures shown in this manual are of TVS iQube Electric SmartXonnect disc brake version unless
specified.
Caution
This message indicates special procedures or precautions to be followed to avoid damage to the
vehicle.
10
OM TVS iQube Electric SmartXonnect - Rev 4 - As on 08 Jun 2022

1. Leaving the ignition cum steering lock in 'ON' position for a prolonged time will drain the battery
when the vehicle is not in use. Switch OFF and take the key out when the vehicle is not in use.
2. Always lock the steering while parking for safety.
3. It is recommended to use the tool kit in case of emergency only. It is always advisable to take
your vehicle to TVS Motor Company Authorized Main Dealer.
4. Never sit on vehicle when it is supported by stands.
5. Utility box can be used to carry a load of maximum 10 kg.
6. Do not carry perishable items inside the utility box. It is not fully sealed. Do not allow / spray
water inside the utility box. Take care not to spill liquid into the utility box.
7. Care should be taken not to attach the luggage which hangs out of your scooter. Please note that
the luggage attached to your scooter should not interfere with your feet movement.
8. The charging time of the vehicle may vary, depending on the vehicle's battery state of charge.
9. The flap has been designed to prevent water entry inside the charging port and is not
replaceable. No warranty is applicable for charger in case of flap damage.
10. Always release the side stand to its full up position before moving the vehicle.
11. Be aware of reverse park assist mode, in this mode vehicle will move in reverse when throttle is
given.
12. Always park the vehicle on a flat, firm surface, in shaded area and away from flood, fire and
other unsafe environments.
13. While charging vehicle always switch on AC supply, only after plugging in both end of the
charging cord at their respective positions.
1. Never attempt to move the vehicle when the steering is locked, you may lose balance.
2. Use appropriate head lamp beam ‘high / low’ as per the traffic and road conditions for your
safety and avoid inconvenience to other riders.
3. Operating the TVS iQube Electric SmartXonnect overloaded will hamper riding stability and may
lead to loss of control. Hence, it is advisable to carry the recommended amount of load only.
4. Don’t touch any open cables or terminals.
11
Caution
Warning
OM TVS iQube Electric SmartXonnect - Rev 4 - As on 08 Jun 2022

KNOW YOUR TVS iQUBE ELECTRIC SMARTXONNECT
VEHICLE IDENTIFICATION NUMBER
12
The frame and traction motor serial numbers are the only means of identifying your vehicle from
others of the same and type. They are also required to assist your Dealer for ordering parts or
referring to special information.
The frame serial number is stamped on the frame, at the rear end below the seat assembly. Open
the seat assembly and remove the VIN cover to read the frame number.
The traction motor serial number is stamped on the hub of the rear wheel assembly. Rotate the rear
wheel assembly to read the traction motor number.
OM TVS iQube Electric SmartXonnect - Rev 4 - As on 08 Jun 2022

6
4
3
2
1
5
25
1
VEHICLE RIGHT SIDE
1. Seat assembly
2. Crash Guard
3. Pillion foot rest R
4. Cover front
5. Bag hook (rear)
6. Front wheel axle nut
VEHICLE LEFT SIDE
1. Brake Disc
2. Front wheel axle
3. Side stand
4. Pillion foot rest L
13
4
3
OM TVS iQube Electric SmartXonnect - Rev 4 - As on 08 Jun 2022

VEHICLE REAR SIDE
1. Tail / brake lamp
2. Turn signal lamp rear R
3. License plate lamp
4. Turn signal lamp rear L
5. Pillion handle
VEHICLE FRONT SIDE
1. Front Position Lamp
2. Turn signal lamp front L
3. Headlamp (AHO)
4. Turn signal lamp front R
14
1
2
2
3
4
1
3
5
4
OM TVS iQube Electric SmartXonnect - Rev 4 - As on 08 Jun 2022

VEHICLE TOP SIDE
15
1. Instrument cluster
2. Rear view mirror R
3. Hazard switch
4. Right hand brake lever
5. Throttle grip
6. Park assist switch
7. Mode Switch
8. Ignition cum steering lock
9. Bag hook (front)
10. Charging Socket
11. Horn switch
12. Turn signal lamp switch
13. Left hand brake lever
14. Left hand brake lock lever
15. High/low beam switch
16. Rear view mirror L
2
4
5
1
16
3
6
7
8
9
11
12
10
13
14
15
OM TVS iQube Electric SmartXonnect - Rev 4 - As on 08 Jun 2022

CONTROLS
Your TVS iQube Electric SmartXonnect comes
with a pair of identical control keys. These keys
are to operate ignition cum steering lock and
seat lock.
IGNITION CUM STEERING LOCK
The ignition switch enables and disables the
electrical circuit and steering lock. The three
positions of the switch are described below.
1. 'OFF' position
All electrical circuits are deactivated. The key
can be removed from the lock.
2. 'ON' position
All electrical circuits are activated. The
connected instrument cluster will wake up and
the vehicle can be shifted to drive mode.
Control key cannot be taken out from the lock in
this position.
Instrument cluster background illumination,
front position lamp, illuminating logo,
automatic headlamp on (AHO) and tail lamp
glow automatically once the ignition key is
turned 'ON' without activating any other
switches.
Note
Leaving the ignition cum steering lock in ‘ON’
position for a prolonged time will drain the
battery when the vehicle is not in use. Switch
OFF and take the key out when the vehicle is not
in use.
Always lock the steering while parking for
safety.
Caution
Never attempt to move the vehicle when the
steering is locked, you may lose balance.
Warning
16
3. 'LOCK' position
Your TVS iQube Electric SmartXonnect steering
can be locked in both ‘left’ and ‘right’
directions. Turn the handlebar to the ‘left’ or
‘right’. Press the key IN and rotate it to the
‘LOCK’ position from ‘OFF’ position.
All electrical circuits are deactivated and the
steering is locked. Control key can be removed
from the lock.
Insert the key into the lock and press the key IN
and turn it to ‘OFF’ or ‘ON’ position to unlock
the steering.
OM TVS iQube Electric SmartXonnect - Rev 4 - As on 08 Jun 2022

HANDLE BAR LEFT SIDE
11. Horn switch
Press the switch ‘ ’ to operate the horn.
12. Turn signal lamp switch
Slide the turn signal lamp switch to left ‘ ’ or
right side ‘ ’ to operate respective turn signal
lamps (LH / RH). Press the center button of the
switch to turn ‘OFF’.
13. Left hand brake lever
The rear brake is applied by squeezing the rear
brake lever gently towards the handle grip. The
brake lamp glows on application of rear brake .
14. Left hand brake lock lever
Left hand brake lever lock is useful when your
scooter is parked with side stand on a slope to
avoid falling.
To apply the left hand brake lever lock, squeeze
the left hand brake lock lever fully towards the
grip. Hold the brake lever at the same position,
press and hold the left hand brake lock lever.
Now release the brake lever and ensure that
the brake is locked properly.
To release the left hand brake lock, squeeze the
left hand brake lock lever further in and the lock
will release automatically, release the brake
lever upon releasing the brake lock.
15. High/low beam switch
With the head lamp ‘ON’, press the switch
towards ‘ ’ to operate head lamp high beam
or press it towards ‘ ’ to operate head lamp
low beam.
Press
Locked
Lever
Unlocked
Use appropriate head lamp beam 'high / low' as
per the traffic and road conditions for your
safety and avoid inconvenience to other riders.
17
11
14
12
13
15
Ensure that the brake lock lever is released (if
applied) before start riding the vehicle.
Note
Caution
OM TVS iQube Electric SmartXonnect - Rev 4 - As on 08 Jun 2022

HANDLE BAR RIGHT SIDE
3. Hazard Switch
Whenever it is necessary to park TVS iQube
Electric SmartXonnect in a hazardous location,
press the hazard switch in ignition ‘ON’
condition to start simultaneously flashing of all
turn signal lamps, so as to make others aware of
your vehicle presence. Press switch again to
turn-off the lamps.
4. Right hand brake lever
The brake lever controls a hydraulic circuit
while squeezing and the hydraulic circuit
operates the front brake system. The brake
lamp glows on application of front brake.
5. Throttle grip
Vehicle speed is controlled by the rotation of
the throttle grip. Twist it towards you to
increase the vehicle speed and twist it away
from you or release it to decrease the vehicle
speed.
6. Park assist switch
Park assist switch activates park assist mode
and allows vehicle to roll forward or backward
in restricted speed thereby to reduce the effort
of parking by yourself.
7. Mode switch
Mode switch allows to switch between
following modes;
1. Economy mode
2. Power mode
AUTOMATIC HEAD LAMP ON (AHO)
TVS iQube Electric SmartXonnect comes with a
Automatic Headlamp ON (AHO) LED lamp
which glows automatically once the ignition is
turned ‘ON’.
18
3
4
57 6
OM TVS iQube Electric SmartXonnect - Rev 4 - As on 08 Jun 2022
