1 Spare parts
1.1 Use of the parts lists
This document is meant as a reference book to be used to order parts.
How to order:
When ordering parts, please specify:
• Serial number (see the identification plate)
• Group (to which the relevant part belongs)
• Article number
• Number of parts required
• Description (in the relevant language)
• Dimensions (if applicable)
Remark:
• If a part does not have a position number, it means that the part concerned cannot be purchased separately. The part concerned is
part of the assembly shown. This assembly must be ordered as one piece. It has to be replaced in its entirety.
• Boxed position numbers refer to the relevant drawing.
Order address:
Please mail or fax your orders to your supplier.
Service technicians:
Repairs may only be carried out by trained and authorised service technicians.
During the execution of their work they are at all times fully responsible for the fulfilment of locally applicable safety guidelines and
standards.
Temporary employees and persons in training may only carry out repair and replacement work under the supervision of an authorised
service technician.

6 | Spare parts
Pos Qty Article number Description
1 1 41200 Front frame
2 2 91143 Insert cap round 30mm adjusted
3 2 02010.5910 Fork, 200x60, black, for swivel wheel, complete
4 2 41031 Swivel wheel PU, 7x1 3/4
- 2 AC40106 Swivel wheel air, 7x1 3/4
1.2 Carrier
01 Front frame BaseOne

Spare parts | 7
Pos Qty Article number Description
02 Rear frame BaseOne 12,5"
1 1 41207 Subframe, 12.5 inch
2 2 91103 Vibration damper 50x20
3 1 41211 Clamp block assembly hinge
4 2 91095 Pedal, rubber
5 1 41217 Hinge shaft
6 2 41227 Bierman bush
7 2 41208 Brake support plate
8 2 00000.4901 Ball knob M8 R/32 black
9 2 40001 Cap, pear-shaped, for brake pedal
10 2 91049 Slide bearing, plastic, 10 14x20x10
11 2 41026 Brake pawl
12 1 41212 Clamp block assembly cover
13 2 1001171 Hex bolt M12x90
14 1 41209 Brake handle
15 2 41032 Wheel, 12.5 inch, black plastic (without brake)
16 1 01010.4112 Drum brake for BaseOne, 12 inch, left
17 1 01010.4212 Drum brake for BaseOne, 12 inch, right
18 2 00000.1404 Shaft lock washer 7mm
19 2 40002 Ball joint, M6x25
- 1 AC40200 Anti tip, set
- 1 41043 Wheel, 12.5 inch, with solid tyre, black, plastic (without brake)

8 | Spare parts
Pos Qty Article number Description
03 Rear frame BaseOne 20"
1 1 41201 Subframe, 20-24 inch
2 1 41212 Clamp block assembly cover
3 2 41210 Wheel height plate, 20-24 inch
4 2 91103 Vibration damper 50x20
5 1 41211 Clamp block assembly hinge
6 2 91095 Pedal, rubber
7 2 41227 Bierman bush
8 1 41217 Hinge shaft
9 4 41233 Shim
10 2 1006777 Insert cap round 30mm
11 1 41205-D Cable brake corner plate
11,16-23 1 41205 Cable brake pin, set
12 1 41228 Brake lever, 20-24 inch, left
13 1 41229 Brake lever, 20-24 inch, right
14 2 8600283 Ball knob M6 R/32 black
15 2 91051 Collar bearing, plastic (directional stabilizer)
16 1 41205-A Cable brake pin
17 2 4363650 Cilinder pin M6x10
18 1 41205-B Cable brake lever
19 2 41226 Bearing cable brake, iglidur
20 2 41225 Bearing cable brake, bronze
21 1 41205-C Cable brake link
22 1 41205R Cable brake side plate, right
23 1 41205L Cable brake side plate, left
24 2 00000.1404 Shaft lock washer 7mm
25 1 1007748 Wheel 20" air left with brake
25 1 7000031 Wheel 20" PU left with brake
26 1 1007749 Wheel 20" air right with brake
26 7000032 Wheel 20" PU right with brake
50 1 41256 Battery carrier, BaseOne push wheelchair
51 2 41241-A Tube clamp bracket, 430, aluminium, round
52 2 41241-B Tube clamp bracket, 430, aluminium, unmachined

Spare parts | 9
Pos Qty Article number Description
1 1 41201 Subframe, 20-24 inch
2 1 41212 Clamp block assembly cover
3 2 41210 Wheel height plate, 20-24 inch
4 2 91103 Vibration damper 50x20
5 1 41211 Clamp block assembly hinge
6 2 91095 Pedal, rubber
7 2 41227 Bierman bush
8 1 41217 Hinge shaft
9 2 00000.1404 Skiffy shaft lock washerA-7
10 2 1007750 Wheel, 24 inch, including brake, left
10 2 1007751 Wheel, 24 inch, including brake, right
11 1 1009577 Brake for 20-24-inch wheel, left
12 1 1009578 Brake for 20-24-inch wheel, right
13 4 41233 Shim
14 2 1006777 Insert cap round 30mm
15 1 41205-D Cable brake corner plate
15,20-27 1 41205 Cable brake pin, set
16 1 41228 Brake lever, 20-24 inch, left
17 1 41229 Brake lever, 20-24 inch, right
18 2 8600283 Ball knob M6 R/32 black
19 2 91051 Collar bearing, plastic (directional stabilizer)
20 1 41205-A Cable brake pin
21 2 4363650 Cilinder pin M6x10
22 1 41205-B Cable brake lever
23 2 41226 Bearing cable brake, iglidur
24 2 41225 Bearing cable brake, bronze
25 1 41205-C Cable brake link
26 1 41205R Cable brake side plate, right
27 1 41205L Cable brake side plate, left
04 Rear frame BaseOne 24"

10 | Spare parts
Continued from 03 Rear frame BaseOne 20"
Pos Qty Article number Description
28 1 41256 Battery carrier, BaseOne push wheelchair
29 2 41241-A Tube clamp bracket, 430, aluminium, round
30 2 41241-B Tube clamp bracket, 430, aluminium, unmachined
- 2 41230 Brake cable
- 2 41234 Ergo-grip, 24 inch, black

Spare parts | 11
Pos Qty Article number Description
1 1 41254 Rear frame Base-1 power assist
2 2 91095 Pedal, rubber
3 2 1006777 Insert cap round 30mm
4 2 91103 Vibration damper 50x20
5 2 41061 End cap, motor
6 2 21008 Spacer bushing, drive wheel, B/M
7 2 41062 Winged knob, brake freewheel
8 1 41211 Clamp block assembly hinge
9 1 41212 Clamp block assembly cover
10 2 11033 Wheel hub for aluminium rim
11 1 41217 Hinge shaft
12 2 1015258 Drive wheel, air 12 1/2 x 2 1/4, block profile
12 2 1015259 Drive wheel, PU 12 1/2 x 2 1/4, block profile
13 2 4506450 Key for motor for powered wheelchair
14 2 49004 Brake for motor 12V
15 1 41054 Motor, left, 12V, for motor-assisted version (50-770B), without brake
16 1 41055 Motor, right, 12V, for motor-assisted version (50-771B), without brake
17 2 00000.1404 Shaft lock washer 7mm
- 2 1015118 Inner tube 12 1/2 x 2 1/4
- 2 1015112 Outer tyre 12 1/2 x 2 1/4 grey block profile
05 Rear frame BaseOne with Power assist

12 | Spare parts
Pos Qty Article number Description
06 Carrier and motors Midway / Antibes (FWD)
1 1 11001-blauw Frame Bleu
1 1 11001-oranje Frame Pearl-Orange
1 1 11001-zwart Frame Black
2 2 11003 Fork, 17 mm
3 1 21029-E Motor bracket, extended for FWD, right
4 2 11060 Handle, EMD motor
4 2 1010153 Handle, Schmid motor
5 1 21028-E Motor bracket, extended for FWD, left
6 1 11516 Battery box
7 2 053.00001.000 Insert cap, flat, oval, 60x30
8 2 8744990 Insert cap, diameter 36
9 1 1015234 Swivel wheel left, air 300x4 (260 x 85)
9 1 1015236 Swivel wheel left, PU 300x4 (260 x 85)
9 1 1015235 Swivel wheel right, air 300x4 (260 x 85)
9 1 1015237 Swivel wheel right, PU 300x4 (260 x 85)
9 2 1015242 Swivel wheel, aluminium, air 2.80/2.50-4
9 2 1015243 Swivel wheel, aluminium, PU 2.80/2.50-4
10 2 00000.2806 Cupped spring washer 34,6x22,4x0,5
11 1 21042 Micro Motor 350W RWD left/FWD right (PGMST 90/50-L 038.8018)
11 1 1009565 Micro Motor 350W RWD left/FWD right for DX (PGMST 90/50-L 038.8018)
11 1 21051 EMD Motor 350W RWD left/FWD right (90BB-9100)
11 1 7000040 EMD Motor 350W RWD left/FWD right for DX (90BB-9100)
11 1 1008582 Schmid Motor 300W RWD left/FWD right
11 1 1009563 Schmid Motor 300W RWD left/FWD right for DX
- 2 91123 Carbon brush EMD
- 2 103.00031.000 Carbon brush Schmid
12 4 91067 Slide bearing plastic, M-250
13 2 4506450 Key for motor for powered wheelchair
14 2 1006751 Collar 18mm

Spare parts | 13
Continued from 06 Carrier and motors Midway / Antibes (FWD)
Pos Qty Article number Description
15 4 0695560 Ball bearing 6003
16 4 31012 Spacer bushing, drive wheel for Antibes, Capri
17 2 8600282 Ball knob M6 R/20 black
18 1 21043 Micro Motor 350W RWD right/FWD left (PGMST 90/50-L 038.8019)
18 1 1009566 Micro Motor 350W RWD right/FWD left for DX (PGMST 90/50-L 038.8019)
18 1 21052 EMD Motor 350W RWD right/FWD left (90BB-9101)
18 1 7000041 EMD Motor 350W RWD right/FWD left for DX (90BB-9101)
18 1 1008584 Schmid Motor 300W RWD right/FWD left
18 1 1009564 Schmid Motor 300W RWD right/FWD left for DX
- 2 91123 Carbon brush EMD
- 2 103.00031.000 Carbon brush Schmid
19 2 11029 Star knob, M8, complete
20 2 1015252 Wheel, aluminium, air 300x8, block profile
20 2 1015253 Wheel, aluminium, PU 300x8, block profile
20 2 1015258 Drive wheel, air 12 1/2 x 2 1/4, block profile
20 2 1015259 Drive wheel, PU 12 1/2 x 2 1/4, block profile
21 2 11033 Wheel hub for aluminium rim
22 2 21030-E Spring strut support for FWD, long base
23 2 11009 Engine mounting pin
24 1 11039 Pin, suspension bracket with end stop
25 2 91018 Bush bearing IJzk 08/12-8
26 2 12020 Suspension bracket rubber, 20x25, M6
27 1 11015 Suspension bracket
28 2 AC20400 Spring strut, standard, L=240
- 1 91127 Motor brake left/right for EMD motor
- 1 1003243 Motor brake right for Schmid motor (3 mounting bolts) Till 10-05-2010
- 1 1003242 Motor brake left for Schmid motor (3 mounting bolts) Till 10-05-2010
- 1 1011125 Motor brake right for Schmid motor (2 mounting bolts) From 10-05-2010
- 1 1011124 Motor brake left for Schmid motor (2 mounting bolts) From 10-05-2010
- 2 VL10040 Fork and bearing set, 17 mm
- 2 8600283 Ball knob M6 R/32 black, for freewheel lever
- 1 11014 Battery strap
- 2 9002006 Wheelcover grey
- 2 91124 Carbon brush holder cap EMD motor 350W
- 2 SP20019 Fork with suspension
- 1 99120 Fuse holder set, complete
- 1 99117 Fuse 100A
- 2 1015115 Inner tube 3.00x4
- 2 1015105 Outer tyre 3.00x4 grey block profile
- 2 1015116 Inner tube 2.80/2.50x4
- 2 1015107 Outer tyre 2.80/2.50x4 grey line profile
- 2 1015117 Inner tube 3.00x8
- 2 1015111 Outer tyre 3.00x8 grey block profile
- 2 1015118 Inner tube 12 1/2 x 2 1/4
- 2 1015112 Outer tyre 12 1/2 x 2 1/4 grey block profile

14 | Spare parts
Pos Qty Article number Description
07 Carrier and motors Belize / Capri / Rhino (RWD)
1 1 11001-blauw Frame Bleu
1 1 11001-oranje Frame Pearl-Orange
1 1 11001-zwart Frame Black
2 1 21002-E Motor bracket, left, for RWD
3 2 11060 Handle, EMD motor
3 2 1010153 Handle, Schmid motor
4 1 21001-E Motor bracket, right, for RWD
5 1 11015 Suspension bracket
6 2 11003 Fork, 17 mm
7 1 11516 Battery box
8 2 11029 Star knob, M8, complete
9 2 12020 Suspension bracket rubber, 20x25, M6
10 2 8744990 Insert cap, diameter 38
11 2 053.00001.000 Insert cap, flat, oval, 60x30
12 4 0695560 Ball bearing 6003
13 1 21043 Micro Motor 350W RWD right/FWD left (PGMST 90/50-L 038.8019)
13 1 1009566 Micro Motor 350W RWD right/FWD left for DX (PGMST 90/50-L 038.8019)
13 1 21052 EMD Motor 350W RWD right/FWD left (90BB-9101)
13 1 7000041 EMD Motor 350W RWD right/FWD left for DX (90BB-9101)
13 1 1008584 Schmid Motor 300W RWD right/FWD left
13 1 1009564 Schmid Motor 300W RWD right/FWD left for DX
- 2 91123 Carbon brush EMD
- 2 103.00031.000 Carbon brush Schmid
14 2 4506450 Key for motor for powered wheelchair
15 2 8600282 Ball knob M6 R/20 black
16 1 21042 Micro Motor 350W RWD left/FWD right (PGMST 90/50-L 038.8018)
16 1 1009565 Micro Motor 350W RWD left/FWD right for DX (PGMST 90/50-L 038.8018)
16 1 21051 EMD Motor 350W RWD left/FWD right (90BB-9100)
16 1 7000040 EMD Motor 350W RWD left/FWD right for DX (90BB-9100)

Spare parts | 15
Continued from 07 Carrier and motors Belize / Capri / Rhino (RWD)
Pos Qty Article number Description
16 1 1008582 Schmid Motor 300W RWD left/FWD right
16 1 1009563 Schmid Motor 300W RWD left/FWD right for DX
- 2 91123 Carbon brush EMD
- 2 103.00031.000 Carbon brush Schmid
17 4 31012 Spacer bushing, drive wheel for Antibes, Capri
18 2 91018 Bush bearing IJzk 08/12-8
19 1 1015234 Swivel wheel left, air 300x4 (260 x 85)
19 1 1015236 Swivel wheel left, PU 300x4 (260 x 85)
19 1 1015235 Swivel wheel right, air 300x4 (260 x 85)
19 1 1015237 Swivel wheel right, PU 300x4 (260 x 85)
19 2 1015242 Swivel wheel, aluminium, air 2.80/2.50-4
19 2 1015243 Swivel wheel, aluminium, PU 2.80/2.50-4
20 2 1015252 Wheel, aluminium, air 300x8, block profile
20 2 1015253 Wheel, aluminium, PU 300x8, block profile
20 2 1015258 Drive wheel, air 12 1/2 x 2 1/4, block profile
20 2 1015259 Drive wheel, PU 12 1/2 x 2 1/4, block profile
21 2 21007 Spring strut support, anti-tip
22 2 11033 Wheel hub for aluminium rim
23 2 11009 Engine mounting pin
24 4 91067 Slide bearing plastic, M-250
25 2 1006751 Collar 18mm
26 2 00000.2806 Cupped spring washer 34,6x22,4x0,5
27 2 AC20400 Spring strut, standard, L=240
28 1 11039 Pin, suspension bracket with end stop
- 1 91127 Motor brake left/right for EMD motor
- 1 1003243 Motor brake right for Schmid motor (3 mounting bolts) Till 10-05-2010
- 1 1003242 Motor brake left for Schmid motor (3 mounting bolts) Till 10-05-2010
- 1 1011125 Motor brake right for Schmid motor (2 mounting bolts) From 10-05-2010
- 1 1011124 Motor brake left for Schmid motor (2 mounting bolts) From 10-05-2010
- 2 VL10040 Fork and bearing set, 17 mm
- 1 11014 Battery strap
- 2 9002006 Wheelcover grey
- 2 91124 Carbon brush holder cap EMD motor 350W
- 2 SP20019 Fork with suspension
- 1 99120 Fuse holder set, complete
- 1 99117 Fuse 100A
- 2 91003 Anti-tip wheel
- 2 1015115 Inner tube 3.00x4
- 2 1015105 Outer tyre 3.00x4 grey block profile
- 2 1015116 Inner tube 2.80/2.50x4
- 2 1015107 Outer tyre 2.80/2.50x4 grey line profile
- 2 1015117 Inner tube 3.00x8
- 2 1015111 Outer tyre 3.00x8 grey block profile
- 2 1015118 Inner tube 12 1/2 x 2 1/4
- 2 1015112 Outer tyre 12 1/2 x 2 1/4 grey block profile

16 | Spare parts
Pos Qty Article number Description
08 Covers and lighting Midway / Antibes (FWD)
Pos Qty Article number Description
1 1 7000017 Side cover, extended, left
2 1 7000018 Side cover extended, right
3 1 11012 Battery box cover, standard
4 1 11013 Battery box shield
5 1 29002 Lighting cable, rear
6 2 00355.4224 Rear light
7 2 00355.4225 Indicator light
8 1 21033 Rear lighting bracket
9 1 29001 Lighting unit cover for Belize
9 1 29020 Lighting unit cover, raise, for RWD
10 2 21020 Support for directional stabilizer, mounting bar
- 1 AC40000L Lighting unit, halogen, left
- 1 AC40000R Lighting unit, halogen, right
- 1 AC40020L Lighting unit, halogen, for raise, left
- 1 AC40020R Lighting unit, halogen, for raise, right
- - 99008 Bulb 12 V, pin fitting
- - 99009 Bulb 24 V, pin fitting
- 1 29521 Rear lighting bar, complete, FWD

Spare parts | 17
Pos Qty Article number Description
09 Covers and lighting Belize / Capri / Rhino (RWD)
1 1 7000019 Side cover, left
2 1 7000020 Side cover, right
3 2 00355.4224 Rear light
4 2 00355.4225 Indicator light
5 1 29020 Lighting unit cover, raise, for RWD
5 1 29001 Lighting unit cover for Belize
6 1 11012 Battery box cover, standard
7 1 11013 Battery box shield
8 1 29002 Lighting cable, rear
- 1 AC40000L Lighting unit, halogen, left
- 1 AC40000R Lighting unit, halogen, right
- 1 AC40020L Lighting unit, halogen, for raise, left
- 1 AC40020R Lighting unit, halogen, for raise, right
- - 99033 Reflector, rectangular, red
- - LI10035 Lighting set without ALM module
- - LI10000 Lighting set incl. ALM module
- - 29520 Rear lighting bar, complete, RWD

18 | Spare parts
Pos Qty Article number Description Pos Qty Article number Description
1 1 41202 Column, short
2 1 41206 Gas spring adjustable bracket, long
3 1 41218 Lock pin, gas spring 37
4 1 41219 Lock pin, gas spring 50
5 6 41220 Inner spacer, gas spring
6 1 41010 Seat frame pin
7 1 41239 Gas spring tilt, long (800N 17cm)
8 2 91049 Slide bearing, plastic, 10 14x20x10
9 6 00000.1404 Skiffy shaft lock washerA-7
10 2 1006788 Carriage bolt M10x50
1.3 Seat adjustments
10 Mechanical tilt BaseOne 12,5"

Spare parts | 19
Pos Qty Article number Description
11 Mechanical tilt BaseOne 20 and 24"
1 1 41202 Column, short
2 1 41204 Gas spring adjustable bracket, short
3 1 41218 Lock pin, gas spring 37
4 1 41219 Lock pin, gas spring 50
5 6 41220 Inner spacer, gas spring
6 1 41010 Seat frame pin
7 2 91049 Slide bearing, plastic, 10 14x20x10
8 6 00000.1404 Skiffy shaft lock washerA-7
11 1 41240 Gas spring tilt, short (800N)
12 2 1006788 Carriage bolt M10x50

20 | Spare parts
Pos Qty Article number Description
12 Mechanical tilt Midway / Antibes (FWD)
1 1 12027 Connector bar, standard
2 2 91024 Ball joint, M8x18 (unmounted)
3 2 8600585 Threaded rod M8x135
4 2 16003 Tilt adjustment for FWD
5 2 16004 Hinge plate
6 2 11025 Collar bearing ring, 16-12-8
