Quadro MC-355 USB User manual

ENGLISH
Please read this User Manual carefully to ensure proper use
of this product and keep this manual for further reference.
MICRO AUDIO SYSTEM
MC-355 USB
USER MANUAL

ENGLISH
WARNING
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
The lightning flash with arrowhead symbol, within an equilateral triangle, is
intended to alert the user to the presence of uninsulated "dangerous voltage"
within the product's enclosure that may be of sufficient magnitude to constitute
a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user
to the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.
Dripping warning:" The product shall not be exposed to dripping or splashing
and that no objects filled with liquids, such as vases, shall be placed on the
product."
Ventilation warning: " The normal ventilation of the product shall not be impeded
for intended use."
Note: Minimum distances around the apparatus for sufficient ventilations. The
use of apparatus in tropical and/or moderate climates.
Dispose of old barreries safely. Do not throw them into a fire.
CLASS 1 LASER
PRODUCT
Class 1 laser product.
LASER SAFETY
“CAUTION:
DANGER:
CAUTION:
This unit employs laser. Only a
qualified service person should
remove the cover or attempt to service
this device, due to possible eye injury.
Use of controls or
adjustments or performance of
procedure other than specified herein
may result in hazardous radiation
exposure.”
Invisible laser radiatio
when open and interlock failed or
defeated avoid direct exposure to
beam.
Hazardous
laser radiation when open
and interlock defeated.

3
ENGLISH
SAFETY INSTRUCTION
1. READ INSTRUCTIONS - All the safety and operating instructions should
be read before the appliance is operated.
2. RETAIN INSTRUCTIONS - The safety and operating instruction should be
retained for future reference.
3. HEED WARNINGS - All warnings on the appliance and in the operating
instruc tions should be adhered to.
4. FOLLOW INSTRUCTIONS - All operating and use instructions should be
followed.
5. WATER AND MOISTURE - The appliance should not be used near water,
for example, near a bathtub, kitchen sink, laundry tub, swimming pool or in
a wet basement.
6. VENTILATION - The appliance should be situated so that its location or
posi tion does not interfere with its proper ventilation. For example, the
appliance should not be situated on a bed, sofa, rug or similar surface that
may block the ventilation openings; or, placed in abuilt-in installation, such
as a book case or cabinet that may impede the flow of air through the
ventilation open ings.
7. HEAT - The appliance should be situated away from heat sources such as
radia tors, heat registers, stoves, or other appliances (including amplifiers)
that produce heat.
8. POWER SOURCES - The appliance should be connected to a power
supply only of the type described in the operating instructions or as marked
on the appliance.
9. GROUNDING AND POLARIZATION - Precautions should be taken to
insure that the grounding or polarization means of an appliance is not
defeated.
10. POWER CORD PROTECTION - Power supply cords should be routed so
that they are not likely to be walked on or pinched by items placed upon or
against them, paying particular attention to cords at plugs, convenience
receptacles, and the point at which they exit from the appliance.
11. CLEANING - The appliance should be cleaned only as recommended by
the manufacturer.
12. POWER LINES - An outdoor antenna should be located away from power
lines.
13. NONUSE PERIODS - The power cord of the appliance should be
unplugged from the outlet when the appliance is to be left unused for a long
period of time.
14. OBJECT and LIQUID ENTRY - Care should be taken so that objects do not
fall and liquids are not spilled into the enclosure through openings.

4
ENGLISH
15. CARTS AND STANDS - The appliance should be used
only with a cart or stand that is recommended by the man
ufacturer. An appliance and cart combination should be
moved with care. Quick stops, excessive force, and
uneven surfaces may cause the appliance and cart
combination to overturn.
16. WALL OR CEILING MOUNTING - If the appliance is mounted to a wall or
ceiling it should be mounted only as recommended by the manufacturer.
17. DAMAGE REQUIRING SERVICE - The appliance should be serviced by
qualified service personnel when:
A. The power-supply cord or plug has been damaged.
B. Objects have fallen into, or liquid has been spilled into the appliance
enclo sure.
C. The appliance has been exposed to rain.
D. The appliance has been dropped, or the enclosure damaged.
E. The appliance does not appear to operate normally or exhibits a
marked change in performance.
18. SERVICING - The user should not attempt to service the appliance beyond
that described in the user's operating instructions. All other servicing
should be referred to qualified service personnel.
19. OUTDOOR ANTENNA GROUNDING
- If an outside antenna is connected to
the receiver, be sure that the antenna
sys tem is grounded so as to provide
some protection against voltage
surges and built up static charges.
Section 810 of the National Electrical
Code, ANS/NFPA No. 70 -1984
provides information with respect to
proper grounding of themas and
supporting structure, grounding of the
leadin wire to an antenna discharge
unit, size of grounding conductors,
location of antenna discharge unit,
connection to grounding electrodes, and require ments for the grounding
electrode. See figure-1.
20. PROTECTIVE ATTACHMENT PLUG The appliance is equipped with an
attachment plug having overload protection. This is a safety feature. See
instruction Manual for replacement or resetting of protective device. If
replacement of the plug is required, be sure the service technician has
used a replacement plug specified by the manufacturer that has the same
overload protection as the original plug (UK option only).
21. ENVIRONMENTALLY - FRIENDLY TREATMENT - Waste
electrical products must not be disposed of with household waste.
This equipment should be taken to your local recycling centre for
safe treatment.
S3125A
PORTABLE CART
WARNING
ANTENNA
LEAD IN
WIRE
FIGURE I
EXAMPLE OF ANTENA GROUNDING
AS PER NATIONAL
ELECTRICAL CODE
ANTENNA
DIBCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NF0 SPOTION 810-21)
POWER SERVICE GROUNDING
PROTECTOR SYSTEM
(NEC ART 250, PART R)
GROUND O AMFS
ELECTRIC
SERVICE
EQUIPMENT
Fig. 1

5
ENGLISH
HANDLING COMPACT DISCS
This unit has been designed to play compact discs bearing the
identification logo shown at the left. No other discs can be played.
1. Open a disc case by holding the bottom left and right sides
with the right hand, and then lighting the top cover with the
left hand.
2. Press down on the center of the case and lift the disc out
carefully.
3. Hold by the edges without touching the recording surface.
(Rainbow lighting side is to play).
1. Foreign objects, dust and finger prints should
be carefully wiped off in a straight motion from the inside to
the out side of the recorded side of the disc with a soft cloth
before use.
2. Do not expose discs to direct sunlight, heating implements
and high temperatures.
3. Do not bend the disc.
1. Avoid serious scratched that could cause the laser pickup to
skip
2. Do not attempt to widen the center hole in the disc. It will
result in damage to the disc.
3. Do not write anything with a ballpoint pen or pencil on the
disc (level) surface.
1. Never use chemicals such as record sprays,
antistatic sprays or fluid, benzine or thinner to clean
compact discs. Such chemicals would irreparably damage
the disc's plastic surface.
2. If a disc is suddenly removed from a cold to a hot area, it
will not be played due to moisture on the disc surface. So
wipe off with a soft cloth. Do not use a hair dryer to dry
moisture on discs.
•Remove the CD from the Disc tray of your unit, if it is not going to be used
for a long period.
•Keep the disc in a disc case when storing.
•Do not store the disc where it may be exposed to:
1. Direct sunlight for a long time.
2. High temperatures via any heating implements.
3. High humidity.
HANDLING THE DISCS

6
ENGLISH
CONTROL AND INDICATORS

7
ENGLISH
1. STANDBY Key
•Press to turn the power On/Standby.
2. MEMORY/CLK ADJ key
•In the Radio mode: for memory preset.
•In the CD/MP3 mode, USB or SD/MMC for setting program.
•In the clock mode: for setting of the clock or timer adjustment.
3. SLEEP/TIMER Key
•To set SLEEP TIME or auto play ON/OFF TIME.
4. FIND/ESP key
5. ALBUM/PRESET UP key
•In the CD/MP3 mode, USB or SD/MMC: selects next album.
•In the Radio mode: selects the next present station.
6. ALBUM/PRESET UP key
•In the CD/MP3 mode, USB or SD/MMC: selects previons album.
•In the Radio mode: selects the previons present station.
7. STOP /BAND Key
•In the CD/MP3 mode, USB or SD/MMC: to stop play or clear program.
•In the Radio mode: to select the receiving band.
8. SKIP+/UP Key
•In the Radio mode: to receiving frequancy steps up.
•In the CD/MP3 mode, USB or SD/MMC: select a next trackor search for
a passage during play.
•In the REC mode: select Bit rate forward.
9. VOLUME control
•To adjust the volume level.
10. SKIP-/UP Key
•In the Radio mode: to receiving frequancy steps down.
•In the CD/MP3 mode, USB or SD/MMC: to return to the start of a track,
select a previews track or search for a passage during play.
•In the REC mode: select Bit rate reward.
11. PLAY/PAUSE / Key
•In the CD/MP3 mode, USB or SD/MMC: to start or interrupt play.
12. RANDOM Key
•In the CD/MP3 mode, USB or SD/MMC: to set or release the random
mode.
13. REPEAT key
•In the CD/MP3 mode, USB or SD/MMC: to set or release the repeat
mode.

8
ENGLISH
14. MONO/ST./INTRO key
•CD/MP3 mode, USB or SD/MMC: to set or release the intro mode.
•Radio mode: to set mono or stereo.
15. EQ Key
•For selecting Digital Sound Control: FLAT, CLASSIC, ROCK, POP &
JAZZ.
16. FUNCTION Key
•To select the TUNER, CD, USB, CARD or AUX mode.
17. REMOTE SENSOR
•To receive signals from the remote control.
18. MULTI-DISPLAY
19. PHONE JACK
Connection for headphones.
20. MP3 IN JACK
21. socket
22. SD/MMC socket
23. key
•Record sound from CD/MP3/TUNER/AUX
•File copy USB to card or card to usb.
24. INFO/BIT-SEL key
•MP3 mode:appear ID3 Information.
•REC mode:set various Bit rate.
25. MUTE key
•To terminate the sound output.
26. FM ANTENNA
27. AC POWER CORD
28. AUX INPUT socket
29. SPEAKER TERMINAL
30. CD TRAY
31. OPEN/CLOSE Key
32. AM ANT.

9
ENGLISH
REMOTE CONTROL
1. MUTE Key
2. INFO/BIT-SEL Key
3. PLAY/PAUSE / Key
(CD MODE SELECTION)
4. SKIP-/DOWN key
5. ALBUM/PRESET - Key
6. REPEAT Key
7. EQ Key
8. SLEEP/TIMER Key
9. MEMORY/CLK ADJ key
10. RANDOM key
11. MONOST./INTRO Key
12. ALBUM/PRESET + Key
13. FIND/ESP Key
14. SKIP+/UP key
15. VOLUME Key
16. STOP key
17. key
18. FUNCTION key
19. POWER Key
A. Unpack all parts and remove protective material.
B. Insert the batteries (2xUM-4/SIZE "AAA") into the remote control transmitter
as shown in the battery compartment.
C. Do not connect the unit to the mains before checking the main voltage and
before all other connections have been made.
D. Do not cover any vents and make sure that there is a space of several
centimetres around the unit for ventilation.
A. Terminals for 2 loudspeakers (minimum speaker
impedance 4 ohm). Attach loudspeaker cables to
the unit. Left speaker: connect the wire to terminal
'L'. Right speaker: connect the wire to terminal 'R'.
B. Terminal for FM antenna. The antanna wire can be
connected to terminal. Adjust the position of FM
antanna for optimum reception. For good FM
stereo reception, use an FM outdoor antanna or
connect the supplied antenna wire to your house distribution system.
C. Voltage selector (not on all version). If your version has this selector, check
that the setting corresponds with your local mains voltage. If the selector
must be reset, disconnect theAC power cord.
D. AUX input / MP3 input for connection of other sound sources. (e.g. TV or
VCR audio output).
INSTALLATION
CONNECTIONS

10
ENGLISH
OPERATION
OPERATION/CLOCK SETTING
OPERATION/TUNER
POWER STANDBY ON/OFF
STANDBY
MEMORY/CLK ADJ
MEMORY/CLK ADJ
MEMORY/CLK ADJ
TUNING
STANDBY
FUNCTION
STOP/BAND
PROGRAMMING OF PRESET STATIONS
STOP/BAND
MEMORY/CLK ADJ
ALBUM/PRESET DN ALBUM/PRESET UP
MEMORY/CLK ADJ
TUNING TO PRESET STATIONS
ALBUM/PRESET DN ALBUM/PRESET UP .
When you first plug the unit into the mains, the unit will go into standby mode.
The display will show the time.
•You can press to switch on the unit.
•The standby function of the unit remains on until the unit is switched on.
•Pull the main plug out of the wall socket if you want to switch off the main
voltage completely.
1. Under power standby mode, press key to access clock
setting.
2. The hour digit will flash, press or to set the correct hours.
3. Press again to select the minutes setting, minute digit
will flash, press or to set the correct minutes.
4. Press again to store in the memory.
1. Press to switch on the unit or remote.
2. Press to select the TUNER mode.
3. Select the tuning range with the button.
4. Press or for few seconds, then release the button.
•The tuner will automatically search for the first transmitter of sufficient
strength.
•Repeat this procedure if you wish to select another station.
5. To tune to weak stations, briefly depress or continuously until you
read the correct frequency or the reception is at its optimum.
6. Switch to MONO if there is interference noise during FM STEREO reception.
1. Select the tuning range with the button.
2. Tune to the desired station as described under Tuning.
3. Press . "06" will start to flash and "MEMORY" will
display.
4. Press or to assign a number
(FM 1-30 /AM 1-15) to the preset station.
5. Press again. The frequency, preset number and stereo
setting are now entered in the memory.
6. Repeat this procedure to store other frequencies and preset in the memory.
Select a number(FM 1-30 /AM 1-15) by pressing:
or button

11
ENGLISH
OPERATION/COMPACT DISC/MP3/WMA
Press key to select CD/MP3 mode.
1. Press to open the CD door.
2. Insert a MP3-CD/CD in the tray.
3. Press again to close the CD door.
•The MP3-CD/CD-player starts and scans the contents list of the
MP3/WMACD/CD.
After a few seconds, the total playing time and number of tracks appear on the
display.
After a few seconds, the total number of tracks, albums and MP3 or WMA
appear on the display.
1. Press .
•Play starts with the first track.
•The display shows the current track number and its elapsed playing time.
•When all the tracks have been played, the MP3-CD/CD stops and returns
pristine display.
2. To stop play, press .
3. To interrupt play, press .
4. To resume play, press again.
•Press or until the required track number appears in the display.
•MP3-CD mode only:
Press o once or more to find your
desired album.
STARTING AGAIN WITH THE TRACK THAT IS CURRENTLY PLAYING by
pressing once. The track will be started again from the beginning.
SEARCHING FOR A PASSAGE DURING PLAY by holding or to
search for the required passage. If you release the button, play will continue.
For MP3/WMA disc playback only: Press to access the search
function.
FUNCTION
INSERTING THE MP3/WMA-CD/CD DISC
OPEN/CLOSE
OPEN/CLOSE
NOTE: In TUNER and AUX mode OPEN/CLOSE are disabled.
FOR CD
FOR MP3/WMA
PLAYING THE ENTIRE DISC
PLAY/PAUSE /
STOP
PLAY/PAUSE /
PLAY/PAUSE
SELECTING A DIFFERENT TRACK DURING PLAY
ALBUM/PREST DN r ALBUM/PRESET UP
Find function
FIND/ESP
/

12
ENGLISH
FIND BY FILE NAME
FIND/ESP
PLAY/PAUSE
FIND BYALBUM NAME
FIND
PLAY/PAUSE
TEXT DISPLAY
INFO/BIT-SEL
INFO/BIT-SEL
PROGRAMMING TRACKS
MEMORY/CLK ADJ
MEMORY/CLK ADJ
PLAYING A PROGRAM
PLAY/PAUSE /
CLEAR PROGRAM TRACKS
STOP
REPEAT PLAY
REPEAT
REPEAT
REPEAT
REPEAT PLAY
REPEAT
REPEAT
REPEAT
•Press once to access this search mode.
The display will show letter "A". If any file name start with letter "A",
It will appear on the display. You can Press or to search fromA-Z,0-9.
•If any file name start with letter "A" press stop key go to sub-mode.
•Press key to start playing this track with your selected letter.
•Press twice to access this search mode.
•Press or to search your desired album and press
to start playing.
(ID3 DISPLAY)
During MP3/WMA-CD playing, press key to switch to text display
mode, it will show the file name / title / album / artist name of the current track.
Press key for to return to the track playing time.
ID3 information: File name / Tille /Album / Artist name.
Up to 32 tracks can be stored in the memory.
1. Load a MP3/WMA-CD/CD as described previouly.
2. Press to start programming.
3. Press or to locate a particular track or album/track (MP3/WMA-
CD/CD).
Press to store it in the memory.
4. Continue this process until you have selected all the tracks you require.
1. Press .
2. Play starts with the first track of the program.
3. When all tracks have been played, the MP3/WMA-CD/CD player stops.
Press opening and closing the CD tray will erase all programmed tracks.
(For CD)
If at any time you wish to listen to a disc or program over and over again, the
REPEAT function will allow you to do so.
1. Press once.
2. "REPEAT 1" will be displayed on the LCD.
3. Press twice, "REPEATALL" will be displayed on the LCD.
4. Press again to cancel the repeat function.
(For MP3/WMA-CD/CD)
1. Press button once.
2. "PEPEAT 1" will be displayed on the LCD.
3. Press twice, "REPEATALL" will be displayed on the LCD.
4. Press three times, "REPEATALBUM" will be displayed on the LCD.
/
/

13
ENGLISH
5. Press four times to cancel the repeat function.
Press button once, "RANDOM" will be appear on the LCD, press
button twice to cancel the RANDOM function.
Press button once,"INTRO" will be appear on the LCD, play 10 sec of
each track/file.
Press button twice to cancel the INTRO function.
Insert a USB or SD/MMC in the USB socket or SD/MMC socket.
1. Press repeatly to select USB or CARD, the total number of
tracks, albums and MP3 appear on the display.
2. If there’s a USB, and you select the USB mode, the information of USB, the
total number of tracks, albums and USB, MP3 (or WMA) appear on the
diplay.
3. If there’s a SD/MMC, and you select the CARD mode, the information of
SD/MMC, the total number of tracks, albums, CARD, MP3 (or WMA) appear
the diplay.
Press to access the search function.
1. Press to access this search mode.
You can press or to search the file name.
2. Press key to start playing.
(ID3 DISPLAY)
During MP3 playing, press key to switch text display mode, it will
show the file name/title/album/ artist name of current track. Press
key again to return to the track playing time.
1. Press key, to select tuner mode, then press key, to
select FM band.
2. Press or until you wish select station.
3. Press key once, “BIT RATE”will dispaly on the LCD. Press
or to select recorder BIT RATE(64-96-128-192-256)kbps. Press BIT-SEL
key twice to confirm.
REPEAT
RANDOM PLAY
RANDOM
RANDOM
INTRO PLAY
INTRO
INTRO
INSERTING THE USB/SD/MMC
SELECT USB OR SD/MMC
FUNCTION
FIND BUTTON FUNCTION
FIND/ESP
FIND BYALBUM NAME
FIND
PLAY/PAUSE /
TEXT DISPLAY
INFO/BIT-SEL
INFO/BITSEL
The other functions are the same as MP3.
REC FM TUNER
Function STOP/BAND
FR/DOWN FF/UP
BIT-SEL
OPERATION/USB/SD/MMC
OPERATION/RECORDER

14
ENGLISH
4. Press key, “USB CARD”will dispaly on the LCD. Press or to
select record into the USB or CARD.
5. Press key, start to record. Press key again, stop recording.
6. The MP3 music have been saved in the USB or CARD audio folder last song.
.”STEREO”icon must be appear on the LCD.
otherwise, while press key, will be appear on the LCD display.
1. Press key, to select CD, After reading TOC, press key
once to select recorder BIT RATE. “BIT RATE”will dispaly on the LCD.
Press or to select BIT RATE(64-96-128-192-256)kbps. Press BIT-
SEL key twice to confirm.
2. Press or to select desired song. Press play, then press key,
“USB CARD”will be appear on the LCD display. Press or to select
record into the USB or CARD.Press key again start to record, and the
CD start to play. While the song end. The CD will make automatically Mp3
format and save in the USB or CARD audio folder last song.
3. Press key on stop mode,The CD will be recorded entire disc.
4. While play MP3 disc, Press key, The MP3 file of disc will copy to USB or
CARD. Percentage of complete will display on the LCD. The speaker no
sound.File will be saved in the USB or CARD FCOPY folder.
NOTE: While recording CD song, if press key or key will cancel
record.
1. Press key, to select AUX mode, ensure AUX IN signal is moderate
and clear.
2. Press key, select bit rate. “BIT RATE”will dispaly on the LCD.
Press or to select BIT RATE(64-96-128-192-256)kbps. Press
BITSEL key to confirm.
3. Press key, “USB CARD”will dispaly on the LCD. Press or
select recorder position.
4. Press key, start to record. Press key again, stop recording.The
MP3 file will be saved in the USB or CARD audio folder last song.
1. Press key, to select USB or CARD mode.
2. In USB play mode, Press key, copy current file to SD or MMC card
FCOPY folder.
3. In CARD play mode, Press key, copy current file to USB FCOPY folder.
4. In STOP mode, Press key, copy all file to USB or SD/MMC card FCOPY
folder.
5. In USB or CARD mode ,select file to delete. Press key, “DELETE N Y”
will appear on the LCD.Press or to select Y, Press key to delete
current file.
6. In USB or CARD stop mode, Press and hold key, “FORMAT N Y”will
appear on the LCD.Press or to select Y, Press key to format
USB or SD or MMC card.
REC
REC REC
NOTE: AM station can not record; FM can record but must ensure the
transmitter is sufficient
REC NO GOOD
REC CD/MP3 DISC
Function BIT-SEL
REC
REC
REC
REC
REC STOP
REC AUX SIGNAL
Function
BIT-SEL
REC
REC REC
USB/CARD COPY
Function
REC
REC
REC
REC
REC
REC
REC
to
to

15
ENGLISH
OPERATION/TIMER
Before setting the timer, make sure the clock is correctly set.
Select TUNER or CD mode and select the desired sound source.
1. If you select BAND, press or to select a preset station.
2. The display will show the selected preset station and frequency.
3. Press key to select standby mode.
4. Press to confirm your selection.
5. " " will appear in the display.
6. The digit of hour segment will flash more than 2 second.
7. Press or to set the hour.
8. Press again, the digit of minutes segment will flash on the
display.
9. Press or to set the minutes.
10. Press again to store the start time.
11. Repeat steps 6~8 to set the timer off.
12. Press again to cancel time ON/OFF function, will be
disappear.
TIMER ON SETTING
STANDBY
SLEEP/TIMER
SLEEP/TIMER
SLEEP/TIMER
SLEEP/TIMER " "

16
ENGLISH
OPERATION/SLEEP
OPERATION/PRESET EQUALIZER
OPERATION/MUTE
GENERAL
1. Press , "SLEEP" appear on the display.
2. Keep pressing SLEEP to adjust the sleep time in the order of 90>80>70...10
minutes.
3. To cancel the sleep mode, press again.
Press PRESET EQ to select the digital sound performance in the order of FLAT,
CLASSIC, ROCK, POP and JAZZ.
Press to terminate the sound output. Press again to cancel this mode.
Set not reacting when any function button is pressed.
The normal function of the product may be disturbed by external interference,
just reset the product (reconnect of power source may be required) to resume
normal operation.
SLEEP/TIMER
SLEEP/TIMER
MUTE

17
ENGLISH
SPECIFICATIONS
Power Supply 230V/50Hz (EURO); 120V/60Hz (USA)
Output Power (Per Channel) 5 watts RMS into 4 ohm
Power Consumption 28W
Radio Section
Frequency Range MW 522 - 1620 KHz; FM 87.5 - 108 MHz (EUR)
AM 520 - 1710 KHz, FM 87.5 - 108MHz (USA)
Compact Disc Section
Frequency Response (-6dB) 60-15,000 Hz
Signal-to-noise Ratio 40 dB
Harmonic Distortion 1%
Channel Separation 35 dB
Continuous improvements are being made to our equipment both in quality and
performance, thus we reserve the right to alter specifications without notice.
ESD Remark:
In case of misfunction due to electrostatic discharge just reset the product (reconnect
of power source may be required) to resume normal operation.

Supplied by:
Electronic
Establishment
Switzerland
