Quarton ML-200 User manual

ML-100 / ML-200
INSTRUCTIONS
OPERATION FUNCTIONS
OPERATION THE ML-100 / ML-200
1. Attach the ML-100 / ML-200 to the cutting machine with four M4 screws (screws not included).
2. Plug in ML-100 / ML-200 with the Type-C to USB Male Cable, then connect cable to the USB adapter.
3. USB adapter plug in the outlet and turn on the ON/OFF switch.
4. Loose the fixing screw gently and adjust the module housing to project the laser
line into position you want. Tighten the fixing screw to fix the laser’s position.
5. Loose the fixing ring. Rotate the adjustable bushing to find the angle you want.
Tighten the fixing ring to fix the laser line’s angle.
6. Cut the stuff along the laser line.
APPLICATIONS
Fixing ring
Laser aperture
ON/OFF switch
Module housing
Adjustable bushing
Fixing screw
Setting holes
Type C female connector

SPECIFICATIONS
Model name
ML-100
ML-200
Dimension(L X W X H)
4.92”x2.13”x2.32” (12.5cm X 5.4cm X 5.9cm)
4.92”x2.13”x2.32” (12.5cm X 5.4cm X 5.9cm)
Weight
250±5g / 8.81±0.17 oz.
250±5g / 8.81±0.17 oz.
Wavelength
635 nm (Red)
520 nm (Green)
Width of laser line
<2mm at 4M
<3mm at 5M
Output power
CL II CW mode
Operating temp range
-20°C ~ 60°C / -4°F ~ 140°F
Emitting angle
>120 ﾟ
Housing
Metal
Finishing
Black anodized
Power
Type C (adapter included)
WARNING
Use of controls of adjustment or performance of procedures other than those
specified herein may result in hazardous radiation exposure
SAFETY PRECAUTIONS
Laser radiation is harmful to the eyes, never look directly into the laser beam or its direct reflection
1. Never aim the laser beam at persons’ eyes.
2. This unit must be used by experienced technical personnel only.
Do not leave the laser beam unattended.
3. Do not target vehicles or aircraft with the laser beam when the unit is used
Outdoors.
4. Do not look directly into laser beam with optical instrumentation unless adequate
protective filters are used to protect the eyes.
5. Avoid aiming the laser beam at mirror- likes surfaces. Remove any unnecessary
mirror-likes surface from the vicinity of the laser beam path.
6. The warranty will no longer exist once the product been taken apart.
Stone cutting
Press Brake
Wood cutting
Wood cutting
Safety Label
