Qubic System QS-CH2 User manual

The Motion Systems, manufacturer of Qubic System, would like to thank you for choos-
ing the QS-CH2 , an innovative product that helps you develop highly reliable training
and entertainment solutions that reproduce key immersive elements, such as surface
textures, acceleration, engine vibrations and vehicle dynamics for multiple types of
land, air or sea vehicles. Our motion system has been designed to deliver the most
realistic simulation experience. We hope you enjoy your new Qubic System!
Join our sim racing channel at the Qubic System YouTube
https://www.youtube.com/c/QubicSystem

NEWS
& EVENTS
The latest news from the simulation world.
QubicSystem.com/News
CHECK OUR
SOCIAL MEDIA
Everything you wish to know is here!
facebook.com/qubicsystem
SUPPORTED
GAMES
Racing games and professional simulation software.
QubicSystem.com/Supported-Games

Contents
1 Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.1 EssentialInformation ............................... 1
1.2 Health and Safety Instruction . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2 Systemdescription.................................... 6
2.1 Systemcomponents ................................ 6
2.2 Platform layout and actuators mounting points . . . . . . . . . . . . . . . . 7
2.3 Transportationwheels............................... 9
2.4 Excursions...................................... 10
2.5 Dimensions ..................................... 10
2.6 Systemspecification................................ 11
2.7 PowerRequirements................................ 12
3 Installation ........................................ 13
3.1 SoftwareInstallation................................ 13
3.2 ConnectingwithuserPC.............................. 19
3.3 Connecting with QS-220-PL extened set - 4 actuators . . . . . . . . . . . . 20
4 ConformityInformation................................. 21
5 Environmental Impact and Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . 21
6 LiabilityDisclaimer.................................... 22
7 Warranty.......................................... 23
8 Copyright ......................................... 24
9 Manufacturerinformation................................ 24

QS-CH2
1. IMPORTANT SAFETY INSTRUCTIONS
INFO
Read all safety instructions before installing and using this product. Save this
document for future reference. If ownership of this product is transferred, be
sure to include this manual.
WARNING
QS-CH2 is not intended for use by children under 16 years of age. Close super-
vision and safety instruction is required when this product is used by or near
children or people with reduced physical, sensory or mental capabilities. Keep
the packaging away from small children as it poses a suocation risk.
1.1. ESSENTIAL INFORMATION
To reduce the risk of burns, fire, electrical shock, injury or mechanical damage:
WARNING
Always turn all the power switches o before plugging and
unplugging the QS-CH2 . Dangerous voltages level can be
present in power cabinet for a few minutes after turning o
the machine.
■Use the QS-CH2 only for its intended purpose, according to instructions.
■Unplug the QS-CH2 from the power supply if it is not used for an extended period
or when there is a need to perform hardware installation, maintenance, servicing
or repairs.
■Turn o the QS-CH2 when it is not in use.
■The QS-CH2 was designed for indoor use only - DO NOT store or use the product
outdoors.
■Keep the QS-CH2 away from the heat sources, high humidity, water, and other
liquids. DO NOT store in cold place where water condensation may occur.
■DO NOT disassemble the product. Any tampering with or altering the product will
void the warranty, poses a serious risk of electric shock, and may irreparably dam-
age the product.
User Manual R1.0 1

QS-CH2
■DO NOT cover the ventilation holes in the QS-SB2 power cabinet.
■Keep the power cord plug and the socket dry, clean and dust-free.
■Protect the power cord from damage caused by being stepped on, rubbed against,
or pinched.
■DO NOT use the QS-CH2 if the ambient temperature is below 4°Celsius (39°Fahren-
heit) or above 45°Celsius (113°Fahrenheit).
■DO NOT use the QS-CH2 if it has been damaged, or any component is broken or
missing. Please contact technical support.
■DO NOT use attachments or replacement parts not recommended or approved by
the manufacturer. If you must to replace the power cord use only certified one
with the same rating as replaced one.
WARNING
Stop using the QS-CH2 immediately and contact technical support when the ma-
chine starts to emit unusual noise, smoke or any other suspicious behaviour in-
dicating the machine is not working properly.
User Manual R1.0 2

QS-CH2
1.2. HEALTH AND SAFETY INSTRUCTION
The safety of Qubic System users is the top priority. To protect users and bystanders
against injuries caused by mechanical parts movement and electrical connectivity, the
following instructions must be strictly performed.
WARNING
As with any mechanical device, the user is responsible for inspecting the condi-
tion of the machine prior to use and adhering to safe operating procedures.
What must be done before turning on the machine:
■Check if cables are mounted properly – they are not stretched or loosely connected
to the socket and placed out of the moving range of the system components.
■Check that all elements are properly fixed.
■Check if there are no sharp edges nearby.
WARNING
Dangerous voltage level may occur in the QS-SB2 power cab-
inet and cables during the operation and for a few minutes
after turning o the machine.
User Manual R1.0 3

QS-CH2
How to turn on safely and use the QS-CH2 :
■Check if everyone around is aware of machine rapid movements.
■Make sure that no one stands in the range of motion (minimum 1.5 m).
■Kids should be kept away from the machine.
■Pets should be kept away from the machine.
■When the QS-CH2 is turned on, it performs start-up calibration.
WARNING
QS-220-PL will move automatically after turning it on in order to perform start up
procedure. Please be away of that movement and do not try to interrupt it.
■DO NOT interrupt or change the weight of payload mounted to the QS-CH2 during
start-up calibration.
To check if the platform is in the Motion Lock mode look at the main window of
the QubicManager. Status is visible in the lower left corner of the window:
–For VR Headset users:
*Remove the VR goggles before entering or exiting the rig.
*Check very carefully if cables from VR Headset are not limiting the oper-
ation range of QS-CH2 .
*Check if the whole VR setup is not in range of motion of the machine.
*Check if cables are protected from being crushed by the QS-CH2 – DO
NOT place them loosely under the motion rig.
User Manual R1.0 4

QS-CH2
INFO
Check if connected PC is capable of running the game at stable 90 frames per
second or more when VR Headset is used. Lower values can cause VR sickness.
■DO NOT use QS-CH2 if you are pregnant, tired, or under the influence of alcohol
or drugs.
■STOP USING the QS-CH2 immediately if pain, fatigue or any discomfort appears.
■For every two hours of playing, we recommend at least 15 MINUTES OF BREAK.
■DO NOT put your hands or legs in the actuators range of motion!
■DO NOT use the QS-CH2 around small children or pets.
■DO NOT put any items between actuators and stabilization plates.
■DO NOT pull the wires connecting the actuators with the power cabinets.
User Manual R1.0 5

QS-CH2
2. SYSTEM DESCRIPTION
The QS-CH2 is intended to be used as additional yaw and surge table which can be
placed under motion cockpit. It is suited to work together with the Qubic System QS-
CH1 motion cockpit by providing additional over steering eect. Platform is based on
the Qubic System linear actuator technology, which is part of the Qubic Ecosystem and
it is compatible with other Qubic System products.
2.1. SYSTEM COMPONENTS
User Manual R1.0 6

QS-CH2
2.2. PLATFORM LAYOUT AND ACTUATORS MOUNTING POINTS
User Manual R1.0 7

QS-CH2
Front side actuator foot mounting points:
Actuator foot
mounting plate
4 x mounting points
M8 x 1.25
Actuator foot
mounting plate
4 x mounting points
M8 x 1.25
Rear side actuator foot mounting points:
REAR
Actuator foot
mounting plate 4 x mounting
points
M8 x 1.25
Actuator foot
mounting plate
REAR
4 x mounting
points
M8 x 1.25
User Manual R1.0 8

QS-CH2
2.3. TRANSPORTATION WHEELS
Transportation wheels can be mounted for transportation purposes. Put the transporta-
tion wheels mounting bracket to the mounting points in the front and back of the QS-
CH2. Screw both bolts with nuts gradually one by one using 17 mm socket wrench until
the bracket is flush against the side of the device and platform is high enough to be
transported.
DIN 933 M10 x 35 bolt
DIN 9021 M10 washer
INFO
Transportation wheels can be mounted on CH-2 with attached payload.
User Manual R1.0 9

QS-CH2
2.4. EXCURSIONS
2.5. DIMENSIONS
User Manual R1.0 10

QS-CH2
2.6. SYSTEM SPECIFICATION
QS-CH2
Architecture 2DOF
Actuator stroke 100 mm
Platform weight 160 kg
Gross moving load 300 kg
Excursions
Yaw -7.2°, 7.2°
Surge -50 mm , 50 mm
Maximum velocity 800 mm/s
Maximum acceleration 0.8G*
*Value of acceleration is limited for safety reasons.
User Manual R1.0 11

QS-CH2
2.7. POWER REQUIREMENTS
Power Cabinet (QS-SB2) contains the power supply for connected actuators. If there
is no certainty if fuses or entire electrical installation can handle QS-CH2 , contact a
qualified electrician.
Converter specification Breaker
specification Power consumption
Average Power
[kVA]
Peak Power
[kVA]
Peak Current
[A]
Average Power
(stress test)
[kW]
Average Power
(typical game)
[kW]
120 V power supply
1 1,5 12,4 0,7 0,06
230 V power supply
1 1,7 7,4 0,6 0,06
*With heavy payload and /or intensive simulation, average power consumption may rise.
WARNING
Always UNWIND THE CABLE COMPLETELY when using a cable reel and untangle an
extension cord before connecting the device to the power supply.
WARNING
Check if the power cord plug has grounding connection (with 3 pins). In order
to reduce risk of electric shock DO NOT use plug without grounding connection
(without center pin).
User Manual R1.0 12

QS-CH2
3. INSTALLATION
3.1. SOFTWARE INSTALLATION
INFO
The base QS-CH1 requires MC6 controller set in order to connect it to the user PC
and install QubicManager.
The SERIAL NUMBER can be found on the M10 identification label in the XXXXXX-XXXXXX-
XXXXX-XXXXXX format. This serial number is also used for activation of FSMI (Force-
SeatMI) and MT (Motion Theater) licences.
To download the software visit : QubicSystem.com/Download
Once the QS-CH2 is installed and connected correctly:
1. Connect power supply cable to the wall socket.
2. Download QubicManager.
3. Proceed with the installation steps and launch the application.
4. Turn on the system by switching on the power switch button on the QS-SB2 power
cabinet.
5. The QS-CH2 will perform a start-up calibration.
WARNING
DO NOT change the payload during the start-up calibration.
User Manual R1.0 13

QS-CH2
6. If QubicManager has recognized the QS-220-PL correctly, the status of the machine
visible in the lower left corner will change to Connected.
7. Check Action Center on the right side panel for a list of actions that requires at-
tention:
It is possible to solve them one by one or by pressing the Resolve All button.
Firmware update may require additional confirmation in the dialogue box.
User Manual R1.0 14

QS-CH2
8. Go to Tools and Diagnostics →Devices and select Configure.
9. Choose correct layout from the list (0+T or 4+T)
10. Scroll down in the window, you can choose one of the operation modes:
INFO
Q-MODE is unavailable for 120V power supply.
User Manual R1.0 15
