Quectel Smart EVB G2 User manual

Smart EVB G2
User Guide
Smart LTE Module Series
Rev. Smart_EVB_G2_User_Guide_V1.1
Date: 2018-06-05
Status: Released
www.quectel.com

Smart LTE Module Series
Smart EVB G2 User Guide
Smart_EVB_G2_User_Guide 1 / 59
Our aim is to provide customers with timely and comprehensive service. For any
assistance, please contact our company headquarters:
Quectel Wireless Solutions Co., Ltd.
7th Floor, Hongye Building, No.1801 Hongmei Road, Xuhui District, Shanghai 200233, China
Tel: [phone]
Email: [email protected]om
Or our local office. For more information, please visit:
http://quectel.com/support/sales.htm
For technical support, or to report documentation errors, please visit:
http://quectel.com/support/technical.htm
Or email to: [e-mail]
GENERAL NOTES
QUECTEL OFFERS THE INFORMATION AS A SERVICE TO ITS CUSTOMERS. THE INFORMATION
PROVIDED IS BASED UPON CUSTOMERS’ REQUIREMENTS. QUECTEL MAKES EVERY EFFORT
TO ENSURE THE QUALITY OF THE INFORMATION IT MAKES AVAILABLE. QUECTEL DOES NOT
MAKE ANY WARRANTY AS TO THE INFORMATION CONTAINED HEREIN, AND DOES NOT ACCEPT
ANY LIABILITY FOR ANY INJURY, LOSS OR DAMAGE OF ANY KIND INCURRED BY USE OF OR
RELIANCE UPON THE INFORMATION. ALL INFORMATION SUPPLIED HEREIN IS SUBJECT TO
CHANGE WITHOUT PRIOR NOTICE.
COPYRIGHT
THE INFORMATION CONTAINED HERE IS PROPRIETARY TECHNICAL INFORMATION OF
QUECTEL WIRELESS SOLUTIONS CO., LTD. TRANSMITTING, REPRODUCTION, DISSEMINATION
AND EDITING OF THIS DOCUMENT AS WELL AS UTILIZATION OF THE CONTENT ARE
FORBIDDEN WITHOUT PERMISSION. OFFENDERS WILL BE HELD LIABLE FOR PAYMENT OF
DAMAGES. ALL RIGHTS ARE RESERVED IN THE EVENT OF A PATENT GRANT OR
REGISTRATION OF A UTILITY MODEL OR DESIGN.
Copyright © Quectel Wireless Solutions Co., Ltd. 2018. All rights reserved.

Smart LTE Module Series
Smart EVB G2 User Guide
Smart_EVB_G2_User_Guide 2 / 59
About the Document
History
Revision
Date
Author
Description
1.0
2017-09-19
Vae LIU
Initial
1.1
2018-06-05
Glenn GE
1. Updated the description of (U)SIM Interfaces in Table 1.
2. Updated the description of camera interface.
3. Added the reserved MIPI+SPI/I2S Interface.
4. Updated the size of the EVB into 26.5cm ×19.0cm.
5. Updated the description of USB interface (added a
Micro USB interface and USB switch S0601).
6. Updated power supply design and the description of
battery interface in Chapter 4.1.
7. Updated screen prints for some components.

Smart LTE Module Series
Smart EVB G2 User Guide
Smart_EVB_G2_User_Guide 3 / 59
Contents
About the Document...................................................................................................................................2
Contents.......................................................................................................................................................3
Table Index...................................................................................................................................................5
Figure Index.................................................................................................................................................6
1Introduction..........................................................................................................................................8
Safety Information.......................................................................................................................91.1.
2General Overview...............................................................................................................................10
Key Features.............................................................................................................................102.1. Interface Overviews ..................................................................................................................122.2. Top and Bottom Views of Smart EVB G2.................................................................................152.3. Smart EVB G2 KitAccessories.................................................................................................162.4.
3Smart EVB G2 Kit Accessories Assembly......................................................................................19
4Interface Applications .......................................................................................................................20
Power Supply Interfaces (J0201/J0202)...................................................................................204.1. 4.1.1. Adapter Interface............................................................................................................21
4.1.2. Battery Interface.............................................................................................................22
4.1.3. Switches for Power Supply............................................................................................23
Smart TE-A Interface.................................................................................................................244.2. LCM Interfaces..........................................................................................................................304.3. 4.3.1. Main LCM Interface........................................................................................................30
4.3.2. Secondary LCM Interface..............................................................................................31
4.3.3. Backlight Driver for Secondary LCM Interface ..............................................................32
Touch Panel Interfaces .............................................................................................................334.4. Camera Interfaces.....................................................................................................................344.5. USB Interfaces..........................................................................................................................364.6. Audio Interfaces........................................................................................................................384.7. 4.7.1. Loudspeaker Interface...................................................................................................38
4.7.2. Headset Interface...........................................................................................................38
4.7.3. Earphone Interface.........................................................................................................40
4.7.4. Microphone Interfaces....................................................................................................41
(U)SIM Interfaces......................................................................................................................424.8. UART Interfaces........................................................................................................................434.9. SD Card Interface .....................................................................................................................454.10. Flashlights.................................................................................................................................464.11. Sensors.....................................................................................................................................474.12. Emergency Download Interface................................................................................................484.13. Vibrator......................................................................................................................................494.14. Buttons......................................................................................................................................494.15. Status Indication LEDs..............................................................................................................504.16.

Smart LTE Module Series
Smart EVB G2 User Guide
Smart_EVB_G2_User_Guide 4 / 59
5Operation Procedures Illustration....................................................................................................52
Power ON Smart Modules........................................................................................................525.1. Communication Via USB or UART Interface............................................................................535.2. 5.2.1. Communication via USB Interface.................................................................................53
5.2.2. Communication via UART Interface...............................................................................54
Firmware Upgrade....................................................................................................................555.3. Power OFF Smart Modules ......................................................................................................565.4.
6Appendix A References.....................................................................................................................58

Smart LTE Module Series
Smart EVB G2 User Guide
Smart_EVB_G2_User_Guide 5 / 59
Table Index
TABLE 1: KEY FEATURES ............................................................................................................................... 10
TABLE 2: INTERFACES OF SMART EVB G2 .................................................................................................. 13
TABLE 3: ACCESSORIES LIST........................................................................................................................ 17
TABLE 4: PIN DEFINITION OF BATTERY INTERFACE .................................................................................. 22
TABLE 5: DESCRIPTION OF POWER SUPPLY SWITCHES.......................................................................... 24
TABLE 6: PIN DEFINITION OF B2B CONNECTORS....................................................................................... 25
TABLE 7: PIN DEFINITION OF TOUCH PANEL INTERFACES....................................................................... 34
TABLE 8: PIN DEFINITION OF HEADSET INTERFACE.................................................................................. 40
TABLE 9: PIN DEFINITION OF (U)SIM1 CARD CONNECTOR....................................................................... 43
TABLE 10: PIN DEFINITION OF MAIN UART PORT....................................................................................... 44
TABLE 11: DESCRIPTION OF BUTTONS........................................................................................................ 50
TABLE 12: DESCRIPTION OF STATUS INDICATION LEDS........................................................................... 51
TABLE 13: RELATED DOCUMENTS................................................................................................................ 58
TABLE 14: TERMS AND ABBREVIATIONS...................................................................................................... 58

Smart LTE Module Series
Smart EVB G2 User Guide
Smart_EVB_G2_User_Guide 6 / 59
Figure Index
FIGURE 1: SMART EVB G2 INTERFACE OVERVIEW (TOP)......................................................................... 12
FIGURE 2: SMART EVB G2 INTERFACE OVERVIEW (BOTTOM)................................................................. 13
FIGURE 3: SMART EVB G2 TOP VIEW........................................................................................................... 15
FIGURE 4: SMART EVB G2 BOTTOM VIEW................................................................................................... 16
FIGURE 5: SMART EVB G2 KIT ACCESSORIES............................................................................................ 17
FIGURE 6: SMART EVB G2 KIT ACCESSORIES ASSEMBLY........................................................................ 19
FIGURE 7: SIMPLIFIED POWER SUPPLY BLOCK DIAGRAM OF SMART EVB G2...................................... 21
FIGURE 8: 5V DC POWER JACK..................................................................................................................... 21
FIGURE 9: POWER PLUG DESIGN................................................................................................................. 21
FIGURE 10: REFERENCE DESIGN FOR BATTERY INTERFACE.................................................................. 22
FIGURE 11: PIN ASSIGNMENT OF BATTERY INTERFACE........................................................................... 22
FIGURE 12: BATTERYASSEMBLY.................................................................................................................. 23
FIGURE 13: POWER SUPPLY SWITCHES ..................................................................................................... 23
FIGURE 14: B2B CONNECTORS..................................................................................................................... 24
FIGURE 15: SKETCH MAP OF SMART TE-A (TOP VIEW)............................................................................. 25
FIGURE 16: REFERENCE DESIGN FOR MAIN LCM INTERFACE ................................................................ 30
FIGURE 17: REFERENCE DESIGN FOR SECONDARY LCM INTERFACE .................................................. 31
FIGURE 18: PIN ASSIGNMENTS OF LCM INTERFACES............................................................................... 32
FIGURE 19: REFERENCE DESIGN FOR BACKLIGHT DRIVER.................................................................... 32
FIGURE 20: REFERENCE DESIGN FOR TOUCH PANEL INTERFACES ...................................................... 33
FIGURE 21: PIN ASSIGNMENTS OF TOUCH PANEL INTERFACES............................................................. 33
FIGURE 22: REFERENCE DESIGN FOR CAMERA INTERFACES ................................................................ 35
FIGURE 23: CAMERA INTERFACES WITH CAMERAS ASSEMBLED........................................................... 36
FIGURE 24: REFERENCE DESIGN FOR USB INTERFACES........................................................................ 37
FIGURE 25: USB INTERFACES AND S0601 SWITCH.................................................................................... 37
FIGURE 26: REFERENCE DESIGN FOR LOUDSPEAKER INTERFACE....................................................... 38
FIGURE 27: REFERENCE DESIGN FOR HEADSET INTERFACE................................................................. 39
FIGURE 28: PIN ASSIGNMENT OF HEADSET INTERFACE.......................................................................... 39
FIGURE 29: SKETCH OF AUDIO PLUG .......................................................................................................... 40
FIGURE 30: REFERENCE DESIGN FOR EARPHONE INTERFACE.............................................................. 40
FIGURE 31: REFERENCE DESIGN FOR MICROPHONE INTERFACES....................................................... 41
FIGURE 32: MEMS-TYPE AND ECM-TYPE MICROPHONES........................................................................ 41
FIGURE 33: SIMPLIFIED INTERFACE SCHEMATIC FOR (U)SIM CARD CONNECTOR J1001................... 42
FIGURE 34: PIN ASSIGNMENT OF (U)SIM1 CARD CONNECTOR ............................................................... 42
FIGURE 35: RS232 LEVEL MATCH CIRCUIT.................................................................................................. 44
FIGURE 36: PIN ASSIGNMENT OF MAIN UART PORT.................................................................................. 44
FIGURE 37: SIMPLIFIED INTERFACE SCHEMATIC FOR SD CARD INTERFACE ....................................... 45
FIGURE 38: PIN ASSIGNMENT OF SD CARD INTERFACE........................................................................... 46
FIGURE 39: REFERENCE CIRCUIT DESIGN FOR FLASHLIGHT INTERFACES.......................................... 46
FIGURE 40: FLASHLIGHTS ............................................................................................................................. 47
FIGURE 41: SENSORS .................................................................................................................................... 47

Smart LTE Module Series
Smart EVB G2 User Guide
Smart_EVB_G2_User_Guide 7 / 59
FIGURE 42: REFERENCE DESIGN FOR EMERGENCY DOWNLOAD INTERFACE .................................... 48
FIGURE 43: EMERGENCY DOWNLOAD SWITCH ......................................................................................... 48
FIGURE 44: REFERENCE DESIGN FOR VIBRATOR..................................................................................... 49
FIGURE 45: ERM-TYPE VIBRATOR ................................................................................................................ 49
FIGURE 46: BUTTONS..................................................................................................................................... 50
FIGURE 47: STATUS INDICATION LEDS ........................................................................................................ 51
FIGURE 48: LCD DISPLAY INDICATING MODULE’S POWER-ON................................................................ 52
FIGURE 49: USB COM PORTS........................................................................................................................ 53
FIGURE 50: “ADB SHELL” COMMAND............................................................................................................ 54
FIGURE 51: USB SERIAL PORT...................................................................................................................... 54
FIGURE 52: QCOM CONFIGURATION WHEN CONNECTING USB SERIAL PORT..................................... 55
FIGURE 53: FIRMWARE UPGRADE STEPS................................................................................................... 56

Smart LTE Module Series
Smart EVB G2 User Guide
Smart_EVB_G2_User_Guide 8 / 59
1Introduction
This document describes the evaluation board (Smart EVB G2) for Quectel Smart module SC60. The
smart evaluation board is an assistant tool to develop and test Quectel SC60 modules.

Smart LTE Module Series
Smart EVB G2 User Guide
Smart_EVB_G2_User_Guide 9 / 59
Safety Information1.1.
The following safety precautions must be observed during all phases of operation, such as usage, service
or repair of any cellular terminal or mobile incorporating SC60 module. Manufacturers of the cellular
terminal should send the following safety information to users and operating personnel, and incorporate
these guidelines into all manuals supplied with the product. If not so, Quectel assumes no liability for
customers’ failure to comply with these precautions.
Full attention must be given to driving at all times in order to reduce the risk of an
accident. Using a mobile while driving (even with a handsfree kit) causes
distraction and can lead to an accident. You must comply with laws and regulations
restricting the use of wireless devices while driving.
Switch off the cellular terminal or mobile before boarding an aircraft. Make sure it is
switched off. The operation of wireless appliances in an aircraft is forbidden, so as
to prevent interference with communication systems. Consult the airline staff about
the use of wireless devices on boarding the aircraft, if your device offers an
Airplane Mode which must be enabled prior to boarding an aircraft.
Switch off your wireless device when in hospitals, clinics or other health care
facilities. These requests are designed to prevent possible interference with
sensitive medical equipment.
Cellular terminals or mobiles operating over radio frequency signal and cellular
network cannot be guaranteed to connect in all conditions, for example no mobile
fee or with an invalid (U)SIM card. While you are in this condition and need
emergent help, please remember using emergency call. In order to make or
receive a call, the cellular terminal or mobile must be switched on and in a service
area with adequate cellular signal strength.
Your cellular terminal or mobile contains a transmitter and receiver. When it is ON,
it receives and transmits radio frequency energy. RF interference can occur if it is
used close to TV set, radio, computer or other electric equipment.
In locations with potentially explosive atmospheres, obey all posted signs to turn
off wireless devices such as your phone or other cellular terminals. Areas with
potentially explosive atmospheres include fuelling areas, below decks on boats,
fuel or chemical transfer or storage facilities, areas where the air contains
chemicals or particles such as grain, dust or metal powders, etc.

Smart LTE Module Series
Smart EVB G2 User Guide
Smart_EVB_G2_User_Guide 10 / 59
2General Overview
Quectel supplies Smart EVB G2 for designers to develop applications based on Quectel SC60 module.
This EVB can test basic functionalities of the module.
Key Features2.1.
The following table describes the detailed features of Smart EVB G2.
Table 1: Key Features
Features
Implementation
Power Supply
DC power supply: 4.75V~6.0V (typical: 5.0V)
VBAT: 3.55V~4.4V (typical: 3.8V)
LCM Interfaces
Two 5-inch 1280 ×720 HD resolution LCDs
4-lane MIPI DSI interface for each LCD
Touch Panel Interfaces
Two capacitive touch panels
Camera Interfaces
Support two cameras:
Rear camera supports 16M pixels with 4-lane CSI interface
Front camera supports 8M pixels with 2-lane CSI interface
USB Interface
USB type-C interface
Compliant with USB 3.0 and 2.0 specifications, with transmission rates up
to 5Gbps on USB 3.0 and 480Mbps on USB 2.0.
Support USB OTG
Used for AT command communication, data transmission, software
debugging and firmware upgrade
Audio Interfaces
Analog Input:
3 groups of analog microphone inputs, integrating internal bias voltage.
One headset input
One ECM-type microphone input
One MEMS-type microphone input
Analog Output:
3 groups of analog audio outputs, including:
One stereo headset output
One mono earphone differential output

Smart LTE Module Series
Smart EVB G2 User Guide
Smart_EVB_G2_User_Guide 11 / 59
One mono loudspeaker differential amplifier output
(U)SIM Interfaces
Support USIM/SIM cards: 1.8V and 2.95V
Support dual SIM dual standby
UART Interfaces
Two UART interfaces:
Main UART for data transmission and AT command communication
Debug UART for debugging
SD Card Interface
Support 4-bit SD card with hot-plug detection
MIPI+SPI/I2S Interface
Reserved
Flashlights
Support 2 flashlight LEDs for testing the module’s flashlight interfaces
Sensors
Support three sensors including ALS/PS, accelerometer/gyroscope and
compass
Vibrator
A vibrator for testing the motor drive interface of the module
Switches and Buttons
4 switches including two power supply switches ,one emergency
download switch and one USB switch;
4 buttons including RESET (reserved), PWRKEY, VOL_UP and
VOL_DOWN;
Status Indication LEDs
3 LEDs are available for signal indication
Physical Characteristics
Size: 26.5cm ×19.0cm

Smart LTE Module Series
Smart EVB G2 User Guide
Smart_EVB_G2_User_Guide 12 / 59
Interface Overviews2.2.
Figure 1: Smart EVB G2 Interface Overview (Top)
J0401
Vibrator
S0201
J0402
J0902
J1202
BAT0201
J0101 J0102
Speaker
Earphone
S0601
J0601
S0502 S0503 S0505 S0504
J1302
MICs
LEDs
J1301
Main LCM
Sub LCM
J0201
S0202
J0202
J0602
Sensors
S0501
MEM
ECM
Level Shifter
RS-232 Transceivers
J1101
J1001
D0302
J0803
J1002
J0804
D0301
J0801
J0802
U0301
U0302
U0304

Smart LTE Module Series
Smart EVB G2 User Guide
Smart_EVB_G2_User_Guide 13 / 59
Figure 2: Smart EVB G2 Interface Overview (Bottom)
Table 2: Interfaces of Smart EVB G2
Interface
Reference Number
Description
VBAT
J0201
The power jack on the EVB. Typical power supply: +5.0V
J0202
Li-polymer battery connector
Power Supply
Switches
S0201
Used to select DC power supply or battery power supply
S0202
Used to power on/off the module
PWRKEY
S0502
Power key (push button)
Used to turn on/off the module
RESET
S0503
Reserved
USB_BOOT
S0501
Emergency download switch
EARPHONE
SPEAKER
BATTERY PACK

Smart LTE Module Series
Smart EVB G2 User Guide
Smart_EVB_G2_User_Guide 14 / 59
VOL_UP
S0505
Used to turn the volume up
VOL_DOWN
S0504
Used to turn the volume down
USB
J0601
Micro USB connector
J0602
USB type-C connector
Audio
Speaker
Used for loudspeaker
Rated resistance: 8Ω
Rated power: 1.5W
Earphone
Used for earphone
Rated resistance: 32Ω
Rated power: 30mW
MIC (MEMS)
Used for MEMS-type microphone
MIC (ECM)
Used for ECM-type microphone
J1202
Audio Jack for headset
(U)SIM
J1001
(U)SIM1 card connector
J1002
(U)SIM2 card connector
UART
J1301
Main UART port
J1302
Debug UART port
SD
J1101
SD card connector
LEDs
D0501
D0502
D0503*
D0501 indicates the power supply of the module
D0502 indicates the charge status of the module
D0503* indicates the operation status of the module
TE-A
J0101, J0102
Connectors for connecting Smart TE-A and Smart EVB G2
Cameras
J0401
Rear camera connector, support 16M CMOS sensor
J0402
Front camera connector, support 8M CMOS sensor
Flashlights
D0301
Flashlight LED1 for testing module’s flashlight interfaces
D0302
Flashlight LED2 for testing module’s flashlight interfaces
LCM and TP
J0803
Connector for main LCM
J0804
ZIF connector for main touch panel
J0801
Connector for secondary LCM

Smart LTE Module Series
Smart EVB G2 User Guide
Smart_EVB_G2_User_Guide 15 / 59
“*” means under development.
Top and Bottom Views of Smart EVB G22.3.
Figure 3: Smart EVB G2 Top View
J0802
ZIF connector for secondary touch panel
Sensors
U0301
Accelerometer and gyroscope sensor
U0302
Compass sensor
U0304
Ambient light sensor and proximity sensor
Coin Cell
BAT0201
Coin cell battery for RTC power supply
MIPI+SPI/I2S
J0902
Reserved
NOTE

Smart LTE Module Series
Smart EVB G2 User Guide
Smart_EVB_G2_User_Guide 16 / 59
Figure 4: Smart EVB G2 Bottom View
Smart EVB G2 Kit Accessories2.4.
All accessories of the Smart EVB G2 kit are listed as below. Please contact the supplier if there is
something missing.

Smart LTE Module Series
Smart EVB G2 User Guide
Smart_EVB_G2_User_Guide 17 / 59
USB to RS232
converter cable
Li-polymer battery USB flash drive Earphone
Wi-Fi/BT antenna
Main antennas
USB Type-C cable Bolts and coupling nuts
GNSS antenna
RF cables
5V DC adapter
Figure 5: Smart EVB G2 Kit Accessories
Table 3: Accessories List
Items
Description
Quantity
Cables
USB to RS232 converter cable
1
USB Type-C cable
1
RF cables
4
Antennas
Main antennas
2
Wi-Fi/BT antenna
1
GNSS antenna (passive)
1
Audio
Earphone
1

Smart LTE Module Series
Smart EVB G2 User Guide
Smart_EVB_G2_User_Guide 18 / 59
The main antenna can also be used for diversity reception.
USB Flash Drive
Including USB 2.0 to RS232 driver, USB driver, etc.
1
Battery
Li-polymer battery
1
Adapter
5.0V DC power supply
1
Others
Bolts and coupling nuts for fixing Smart EVB G2
4 for each
NOTE

Smart LTE Module Series
Smart EVB G2 User Guide
Smart_EVB_G2_User_Guide 19 / 59
3Smart EVB G2 Kit Accessories
Assembly
Figure 6: Smart EVB G2 Kit Accessories Assembly
