6-ZONE GOOSENECK MICROPHONE
MODEL: RM6
Specificaons are subject to change without noce
Front Panel
•Indicators
Power (Blue), Signal (Green), Clip (Red), Busy (Red)
•MIC Input
XLR input Jack to Connect a condenser microphone
•ALL
Select and release all zones. Press and hold for locking all zones
• Z1 to Z6 – Individual Zone Selection
Select and release each zone 1 – 6
Press and hold for locking the selected zone
•CHIME
Turn ON and OFF the preannouncement chime
•TALK
Press and hold to start broadcasting after selecting the zone(s)
Release the button to end broadcasting
– 2 –
RM6
Rear Panel
•LINK
Terminals to connect to the PR-Series mixer-amplifier with UTP CAT5/6
We recommend a total distance of up to 200m between the microphone
and the mixer-amplifier. Up to 4 RM6 can be connected through the LINK
port
•CHIME volume
Adjust preannouncement chime volume
•MIC volume
Adjust microphone level
Performance
Audio Output
0dB (Balanced)
Audio Input
- 36 dB ±3 dB (Balanced)
Frequency Response
80Hz~15kHz (-1 dB)
Signal to Noise Ratio Better than 90dB
Total Harmonic Distortion (T.H.D.)
Less than 0.5%
Serial Interface
RS485 Max 200m (UTP CAT5/6)
Operating Temperature
0° ~ +40°C
Construction
Net Weight
0.5 kg
Carton Dimensions (Width/Height/Depth)
7.9(W) x 2.4(H) x 4.7(D) inches
200(W) x 60(H) x 120(D) mm
