Quha Nemo User manual

USER MANUAL

2
Quha Nemo - Self Operated Quha Zono
Headband with Charging Dock
Welcome to the Quha Nemo self operated headband with char-
ging dock for Quha Zono. Before you start using your Quha
Nemo, for the best user experience, please read this manual care-
fully first.
Quha Nemo is a user operated headband with charging dock for
the Quha Zono gyroscopic mouse. It provides a handsfree way to
pick up, put down, use and charge Quha Zono without assistan-
ce.
Figure 1 - Quha Nemo

3
Quha Nemo Main Parts
1. UNC camera thread
2. USB cable
3. Charging connector
4. Magnet attachment point
3
1
4
Figure 2 - Charging dock
2

4
Quha Nemo Main Parts
5. Headband connector
6. Mini USB connector
7. Quha Zono slot
8. Quha Sento arm (optional)
9. Magnet
10.Connector for 3.5 mm switches
11.Charging connector
12.Headband
5
Figure 3 - Nemo cradle and headband
6
9
11
7
10
8
12

5
Installation
Before using Quha Nemo there are a few things to do.
Connect Quha Zono and Nemo cradle
1. Connect the Quha Nemo cradle to the headband.
2. Slide the Quha Zono mouse in the cradle so that the Quha
Zono mini USB charging port is connected to the cradle’s
mini USB connector.
Prepare the USB charger
The included USB charger includes AC input plugs for several
regions.
1. Choose the AC input plug suitable for your electrical mains
connector.
2. Attach the plug to the USB charger.

6
Attach dock
1. Attach the charging dock to a mount of your preference (not
included) with the standard 1/4” UNC camera thread.
2. Adjust the mount so that when the Quha Zono mouse has been
attached to the dock, its position enables picking up Quha
Zono without hands using head movements only. Make sure
that the dock stays firmly in its place.
3. Connect the USB cable to the included wall charger. Make
sure the cable is not tangled with the user or any moving ob-
jects.
4. Place Quha Nemo cradle into the charging dock.
Using Quha Nemo
Quha Nemo has two primary functions. It functions as a char-
ging dock for the Quha Zono gyroscopic mouse. It also provides
the possbility to use, pick up and put down the mouse without
assistance.

7
Charging
Quha Nemo charging dock has a magnet attachment that con-
nects to the Quha Zono cradle. There is only one possible way to
connect them together. The dock design and the magnet assist
the connection. The magnet in the dock will hold the cradle firm-
ly in its place when connected.
When the cradle is connected to the dock, the Quha Zono mouse
charging starts automatically. When the cradle is picked up from
the dock, the Quha Zono mouse is automatically turned on and it
can be used without pressing the power button. It is safe to leave
the mouse in the cradle when it is not used.
Picking up Quha Zono from the dock
When picking up the Quha Zono from the dock, the dock needs
to be in a suitable position for the user. Depending on the user,
Quha Zono can be picked up for example by rolling the
wheelchair under the headband and slightly moving the head to
place the headband in the preferred usage position. It may be
useful to try different positions to find the easiest way to do this.
Putting down Quha Zono to the dock
When putting down Quha Zono to the dock, the cradle is taken
close to the dock. When the cradle is near enough to the dock,
the dock’s magnet will guide the cradle to the correct docking
position. It is usually easy to feel when the cradle connects to the
dock.
Because the dock is typically located on the side of the user’s
head, it may be helpful to place a mirror to the front of the user
so that the user can see the dock.

8
Sento puff switch (with version including Sento)
Quha Sento is a contactless puff switch that is used to perform a
short mouse click (clicking) or a long mouse click (dragging)
together with the Quha Zono gyroscopic mouse.
Using Quha Sento
Quha Sento detects the air flow (puff) coming from the user’s
mouth. The puff sensor is located at the end of the sensor arm.
The more air flow there is to the sensor, the more accurately the
switch can be controlled. Therefore, it is necessary to place the
sensor to a position that the air flow can reach.
When the headband is on the user’s head, the flexible sensor arm
is adjusted so that the sensor is located in front of the user’s
mouth at a comfortable distance. A typical distance is 1-5 cm
(0.4-2 inch). Try different positions because the air flow strength
varies greatly. With some experimenting, a good position is
found in a few minutes.
Testing the switch is simple. Puff into the sensor and a click is
performed. Puff and keep puffing into the sensor and a long click
(dragging) is performed as long as the puff continues.
Using a Generic Switch
Any switch with a 3.5 mm connector can be used with Quha
Nemo. There is a connector (Figure 3-10) for this purpose in the
Nemo cradle. Attach the switch to the connector before turning
on the device power to ensure the switch is recognized correctly.

9
Technical Specifications
Dimensions Length 100 mm, width 160-180 mm, height 140
mm. Cable length 1 m.
Charger Universal USB charger, 5 V output.
Mounting ¼” UNC thread (camera mount)
Operating temperature
From +10°C to +35°C (from +50°F to +95°F)
Storage temperature
From +0°C to +45°C (from +32°F to +113°F)
Sales Package Contents
Quha Nemo cradle (optionally with Sento puff switch), head-
band and charging dock
USB charger with AC input plugs for EU, UK, US and SAA
User manual

10
Keeping Quha Nemo Clean
As a head worn device, Quha Nemo is easy to keep clean. All parts can
be cleaned with a physiologically sensitive area cleaning liquids, such as
water or Würth Multiclean.
Product Disposal
When the device has reached its end-of-life it should be recy-
cled as electric and electronic waste.
European Compliance
The manufacturer of this product confirms that this
product complies with the European Union regulati-
ons for safety, health, environmental and consumer
protection.
FCC Compliance
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2)
this device must accept any interference received, in-
cluding interference that may cause undesired operation.
Magnetic Fields
Quha Nemo contains magnets. Do not place it close to
magnetically sensitive devices such as pacemakers, hea-
ring devices, credit cards, mechanical watches, data stora-
ge media, etc. as they may get damaged.

Limited Warranty
Warranty on the product is 2 years from the date of purchase.
Product and Safety Information
The device includes sensitive electronic components and the user should
not try to open or service the device themselves.
This device is for indoor use only. Do not allow the device to get wet.
Any modifications not approved by Quha could void the user’s authority
to operate the device.
Keep the device clean. Do not clean the device with solvents, toxic che-
micals or strong detergents as they may cause damage to the product.
Store your device only on flat surfaces. Do not drop or shock the product
as it may be damaged.
Follow all instructions in the user guide to ensure the longest lifespan of
your device. Damage or poor performance caused by failure to follow
warnings and instructions can void your manufacturer’s warranty.
This product is RoHS compliant.
© 2018 Quha oy. Quha oy is not responsible for possible errors in this
user manual. Quha oy reserves the right to revise the content of this
user manual.

Designed and manufactured in
Finland by Quha.
www.quha.com
Copyright 2018 Quha oy.
Quha, the Q-mark, Quha Zono and Quha Nemo are
trademarks or registered trademarks of Quha oy.
