QView QD3900 User manual

Visual Presenter
Owner’s Manual
Model: QD3900

1
PRECAUTIONS
Please follow these precautions:
To prevent fire or shock hazard, do not expose the unit to rain or moisture.
To prevent electrical shock, do not open the cabinet. Refer to qualified
personnel for service only.
Do not use the unit continuously for more than 24 hours with camera auto
focus on. It may cause damage to the camera lens.
Be careful not to spill water or other liquids onto the unit, or allow combustible
or metallic objects to get inside the cabinet.
Unplug the visualizer from the wall outlet when it is not in use for
an extended period of time.
Clean cabinet with a soft cloth lightly moistened with a mild detergent.
Clean lens carefully with an air spray or soft dry cloth to avoid scratching.
When lamps flash or become dark, they should be replaced with new ones.
Avoid interchanging arm lights and back light frequently.
Remove the camera lens cap before power the unit on.

2
CONTENTS:
PARTS IDENTIFICATION.................................................................................3
CONTROL PANEL ............................................................................................3
BUTTON INSTRUCTION..................................................................................4
REMOTE CONTROL........................................................................................4
CONNECTIONS................................................................................................6
BASIC PREPARATIONS...................................................................................6
PAL/NTSC VIDEO OUTPUTS ........................................................................10
WORKING ON THE STAGE...........................................................................10
WORKING OUTSIDE THE STAGE ................................................................10
LIGHT..............................................................................................................10
ADJUSTING IMAGE SIZE.............................................................................. 11
WORKING WITH NEGATIVES....................................................................... 11
FOCUSING ..................................................................................................... 11
FREEZING IMAGE ......................................................................................... 11
BRIGHTNESS ADJUSTMENT........................................................................12
WHITE BALANCE ADJUSTMENT..................................................................12
AUTO ADJUSTMENT .....................................................................................12
TEXT/IMAGE MODE.......................................................................................12
COLOR AND B&W MODE SWITCH...............................................................12
HDMI/VIDEO INPUTS.....................................................................................12
RGB INPUTS ..................................................................................................12
PROJECTOR ON/STANDBY..........................................................................13
PROJECTOR INPUTS SELECTION..............................................................13
IMAGE ROTATION..........................................................................................13
IMAGE REVERSION ......................................................................................13
INFRARED REMOTE CONTROL...................................................................13
4 X 4 MULTIPLE SCREEN DISPLAY.............................................................13
INSTALLING VISUALIZER SOFTWARE........................................................14
USB PORT......................................................................................................14
USB IMAGE CAPTURE..................................................................................15
CONTROLLING VISUALIZER BY COMPUTER ............................................16
CONTROLLING PROJECTOR BY VISUALIZER...........................................16
FOLDING THE UNIT.......................................................................................20
SPECIFICATIONS...........................................................................................21

3
PARTS IDENTIFICATION
Arm lights
Camera
Camera stand
Back light
Remote control slot
Operation panel
Stage
Connectors
Connectors
Button instruction
CONTROL PANEL
Rot (Rotate the image)
Frz (Freeze the image)
Neg (Display film negatives)
Text (Switch between image/text mode)
Save (Save captured images)
Title (Freeze the top 1/8 of the screen)
Split (Split Image function)
Mem (Multiple Screen Display, the stored images will be displayed in a
4 x 4 matrix)
Ppw (Control the projector On/Standby)
Pin (Projector input signal selection)
/(Move the image up/down)
POWER (Control the visualizer On/Off)
CAM/PC1/PC2 (CAM/RGB input signal selection)

4
HDMI/VIDEO (HDMI equipment/ Video input signal selection)
LAMP (Control the arm lights and back light)
AUTO (To auto white balance and auto focus)
+
T/W (Zoom in and out)
BUTTON INSTRUCTION
REMOTE CONTROL

5
POWER (Control the visualizer On/Off)
SAVE (Save captured images)
RECALL (Multiple Screen Display)
LAMP (Control the arm lights and back light/Press the button more than 5
seconds to delete all pictures stored in the Flash ROM)
ROTATE (Rotate the image)
FREEZE (Freeze the image)
NEG (Display film negatives)
MIRROR (V-Reverse the image)
XGA (Toggle among XGA, SXGA, WXGA, 720P, 1080P)
TEXT (Switch between image/text mode)
B&W (Switch between Color mode and Black & White mode)
TITLE (Freeze the top 1/8 of the screen)
SPLIT (Split Image function)
PROJECTOR POWER (Control the projector On/Standby)
PROJECTOR INPUT (Projector input signal selection)
EXIT (Exit selected function)
TELE/WIDE (Increase and decrease magnification)
FAR/NEAR (Focus near or far)
AUTO (To auto white balance and auto focus)
CAM/PC1/PC2 (CAM/RGB input signal selection)
HDMI/VIDEO (HD equipment/ Video input signal selection)
VOL+/- (Increase or decrease the volume)
RED+/- (Increase or decrease the red hue)
BLUE+/- (Increase or decrease the blue hue)
BRIGHT+/- (Increase or decrease the brightness)
SCROLL / (Move the image up/down)

6
CONNECTIONS
11
10
9
HDMI OUT
VIDEO OUT
HDMI IN
COMPUTER OUT PROJECTOR
COMPUTER IN
AUDIO IN
AUDIO
IN
VIDEO
DC 12V IN
17
58
7
15
6
14
13 Side Panel
Rear Panel
RS232
AUDIO INRGB IN
4
3
2
16
1
MIC
PROJECTOR USB
12
AUDIO OUT
#1 DC-12V-IN #2 VIDEO AUDIO IN
#3 VIDEO IN #4 COMPUTER AUDIO IN
#5 COMPUTER IN #6 COMPUTER OUT
#7 HDMI IN #8 AUDIO OUT
#9 PROJECTOR Connector #10 VIDEO OUT
#11 HDMI OUT #12 PROJECTOR RS232 Connector
#13 MIC IN #14 USB Connector
#15 RGB IN #16 RGB AUDIO IN
#17 COMPUTER RS-232 Connector
BASIC PREPARATIONS
1. Place one hand firmly on the base of the visualizer, while carefully
lifting up the camera stand using the other hand.

7
2. Open the arm lights and rotate the camera head until they are properly
positioned.
Arm lights
3. Making connections:
Before making any connections, turn off all the power. Please ensure that
the visualizer along with all other equipment to be connected are turned off.
Step 1: Connect power source.
First connect the power cord to the 12V IN connector.
Step 2: Connect to the projector.
12
USB
PROJECTOR MIC
16
RGB IN AUDIO IN RS232
Side Panel
13 14 15 17
1234678
5
DC 12V IN VIDEO
IN
AUDIO AUDIO IN COMPUTER IN PROJECTOR
COMPUTER OUT HDMI IN AUDIO OUT VIDEO OUT HDMI OUT
910 11
Projector
RGB Input
Screen
RS232 Cable
Rear Panel
Connect the PROJECTOR port to the projector‟s RGB IN port using the
RGB cable. You can also control a projector using the controls on the
visualizer by connecting the projector to the visualizer using a 6-pin to 9-pin

8
RS232 cable. Some projector models may require a converter cable in
addition to this standard RS232 cable to connect to the projector control
port, for the pin locations and shape of some projectors‟ control port
connector may be different from the connector of a standard RS232 cable.
Once the visualizer is connected to the projector, you can control the
projector‟s power on, standby and input selection by using the visualizer.
(Aside from Hitachi projectors, the Code Writing program that comes with
the visualizer is required to access this function.)
Step 3: Connect to a desktop computer.
12
USB
PROJECTOR MIC
16
RGB IN AUDIO IN RS232
Side Panel
13 14 15 17
1234678
5
DC 12V IN VIDEO
IN
AUDIO AUDIO IN COMPUTER IN PROJECTOR
COMPUTER OUT HDMI IN AUDIO OUT VIDEO OUT HDMI OUT
910 11
Rear Panel
RGB Output
To the
Monitor
USB Connector
Computer
RS232
Cable
Note: You can connect a laptop computer to the RGB IN port of side panel
using a RGB cable.
Step 4: Connect to the HD equipment with HDMI input.
To display equipment with HDMI
connector
HDMI Cable
HDMI out
HDMI equipment
Rear Panel
11
10
9
HDMI OUT
VIDEO OUT
AUDIO OUT
HDMI IN
COMPUTER OUT PROJECTOR
COMPUTER IN
AUDIO IN
AUDIO
IN
VIDEO
DC 12V IN
58
76
4
3
2
1

9
Step 5: Connect to the video equipment with Video input.
1234678
5
DC 12V IN VIDEO
IN
AUDIO AUDIO IN COMPUTER IN PROJECTOR
COMPUTER OUT HDMI IN AUDIO OUT VIDEO OUT HDMI OUT
910 11
Rear Panel
Video equipment
Video out
Audio out
Audio input
(or amplifier/speaker equipment)
Projector
Video Cable
4
In the step 2, the connection between the C-Video output signals to the
projector was established, where the RGB cable runs from the visualizer
and goes to the projector. Once the connections have been made as
detailed in the steps 2,3,4,5, input signals from the HD equipment,
computer, visualizer camera, and C-Video are going to the RGB1 input on
the projector and will be displayed on the projector screen as RGB1. These
signals can be seen in turn when pressing “CAM/PC1/PC2”and
“HDMI/VIDEO” on the control panel of the visualizer.
Step 6: Connections for external control from the computer.
RS232
AUDIO INRGB IN
MIC
PROJECTOR USB
Side Panel
RS-232 cable
USB cable
of the computer
of the computer
USB connector RS 232 connector
Use the computer RS232 cable (9-pin to 9-pin) to make the connections
displayed below to control the visualizer from an external computer.
A USB connection enables the computer to capture still images and/or
video streams from the visualizer. Special software is required for this
operation.
4. Turn on the power by pressing the “POWER”button.

10
PAL/NTSC VIDEO OUTPUTS
The S-Video and composite video outputs are set to PAL (NTSC) during
manufacturing.
WORKING ON THE STAGE
1. Place your material on the platform.
2. Select the enlargement required using the “
+
T”and “W”buttons.
3. Adjust the focus using the “Near” and “Far” buttons or “AUTO”button.
WORKING OUTSIDE THE STAGE
To show a 3-dimensional object using the visualizer, place the object on the
working surface and adjust the “
+
T”or “W”and “AUTO”keys. If the
object is too large for the stage or if you would like to show it from one of its
side, or a different angel, just place the object behind or in front of the unit
and manually tilt the camera head (remove the close-up lens prior to titling
the camera head).
Rotate 330 degrees
vertically
LIGHT
The arm lights are powered on when the power is turned on. Each time you
press the “LAMP” button, the lighting changes occur as demonstrated.
The arm lights turn on
The back light turns on
All the lights turn off

11
ADJUSTING IMAGE SIZE
To reduce or enlarge the image size displayed on the screen, press the
“
+
T” (Zoom in) or “W”(Zoom out) button.
WORKING WITH NEGATIVES
The visualizer is automatically set to display normal materials on the
screen when the power is on. To display negatives, turn on the backlight by
pressing the “LAMP”key, and then press the “Neg” button to display the
film negatives. Press the “Neg”button again to display normal materials in
the color mode.
FOCUSING
When the visualizer is turned on the focus automatically adjusts to the
stage, Only 3D objects require a focus adjustment.
Press the “AUTO”button to auto focus.
Press the “FAR”or “NEAR”button to focus manually.
FREEZING IMAGE
To show a still image on the screen, when the output signal is RGB, press
the “Frz” button. The frozen image cannot be adjusted (Zoom in/out, color
adjustment, etc.).

12
BRIGHTNESS ADJUSTMENT
If the image effect is not satisfactory, you can adjust the brightness to get a
better image effect. Use the “BRIGHT +”or “BRIGHT -” button to adjust the
brightness. To increase the brightness, press the “BRIGHT +”button. To
decrease it, press the “BRIGHT -”button.
WHITE BALANCE ADJUSTMENT
Each time the lighting condition changes, the user should adjust the white
balance of the camera.
Press the “AUTO” button to adjust the white balance automatically.
AUTO ADJUSTMENT
One of the visualizer‟s special functions is auto adjustment. Press the
“AUTO” button to auto adjust the white balance and the focus.
TEXT/IMAGE MODE
Press the “Text”button to switch between image/text modes. To display a
text file, switch to the text mode to get a clearer text effect.
COLOR AND B&W MODE SWITCH
Press “B&W”once to enter the Black & White mode; press again to return
to the Color mode. (On the remote control)
HDMI/VIDEO INPUTS
Press the “HDMI/VIDEO”button to switch between HDMI and composite
video signals.
RGB INPUTS
Use the “CAM/PC1/PC2”button to switch between Camera and different
RGB signals. Each time the “CAM/PC1/PC2”button is pressed, it provides
seamless transitions among different sources such as Camera,
COMPUTER (IN), and RGB (IN).
Notes: RGB OUT always outputs RGB IN signals.

13
PROJECTOR ON/STANDBY
Press the “POWER” button to turn on the visualizer‟s power and press the
“Ppw” button to turn the projector power on. To place the projector on
standby after the use, press the “Ppw” button and hold for more than 2
seconds. (Using the remote control, press the “PROJECTOR POWER”
button)
PROJECTOR INPUTS SELECTION
When the projector is connected to several input sources, use the “Pin”
button to switch between projector signal inputs. (Using the remote control,
press the “PROJECTOR INPUT”button)
IMAGE ROTATION
In order to rotate the image, press the “Rot”button once, the displayed
image will be rotated clockwise. Continue to press the “Rot”button to
restore the image to its initial position.
IMAGE REVERSION
To display a vertically mirrored image, press the “MIRROR”button. Press
the “MIRROR” button again to exit.
INFRARED REMOTE CONTROL
The visualizer‟s remote control can control the camera from different
angels. On the left side of the visualizer stage, there is a built-in remote
control storage compartment where you can store the remote control when
it is not in use.
Please note that an infrared remote control can only be used up to a
certain distance to the unit. Objects situated between the visualizer and the
infrared remote control and a weak battery may interfere with the reception.
4 X 4 MULTIPLE SCREEN DISPLAY
Press “Mem”, the stored first sixteen images can be displayed in a 4 x 4
matrix. Use , , , button to Select the image that you want
to display, then click button to display the selected image, press

14
button to delete the selected image. Press to exit the 4 x 4 image
display mode.
On the remote control, the “RECALL ”,“ ”, “ ”, “ ”, “ ”, “ ” and “TEXT”
button can do the operation. Press “EXIT”to exit the 4 x 4 image display
mode.
INSTALLING VISUALIZER SOFTWARE
This function is to snap and display images with the USB interface, which
includes displaying static and dynamic pictures, snapping dynamic images and
playback the dynamic images with the Windows Media Player or its own
player.
A. Insert the CD-ROM that comes with the visualizer into the CD-ROM drive.
If Autorun is enabled on your system, then the Software Setup window will
be displayed automatically as below.
If it does not start automatically, after inserting the CD-ROM, Click [Start]
[My Computer], and double click (the CD-ROM drive letter might
be different in different computer systems), and then the above screen will
appear immediately.
B. Click the Install Capture Program button to install the program that
captures images in theAVI or JPG format.
C. Click the Install Code-Writing Program button to install Code-Writing
Program.
D. After the installation is finished, then click the Exit button to exit the
Software Setup window.
E. Shut down your computer when prompted in order for the changes to take
effect.
F. Use the USB2.0 cable provided to connect your computer to the visualizer
before your computer is restarted.
USB PORT
The USB port can be used to store still images from the visualizer in a
computer. Connect the visualizer to your computer with the supplied USB
cable. The visualizer software is available on the supplied CD-ROM.

15
* Please pay attention to the following:
1. Computer hardware requirement: CPU: 2.4GHz, RAM: 256M or above,
Graphic card 64M, USB 2.0 port, Hard disk 40G or more, Monitor
display resolution higher than XGA (1024x768).
2. Operating system: Windows XP SP2 ，Win7.
3. Must use a high-speed USB 2.0 cable provided .
4. When connecting the visualizer to a desktop computer with the
high-speed USB 2.0 cable provided, we recommend using the USB
port located on the rear of the mainframe. The USB port on the front
of the computer might have interference.
USB IMAGE CAPTURE
You can capture and control images on the visualizer from a computer
connected with a USB connector.
Click [Start] [Program] [VideoCap] “VideoCapx.xx”(x.xx is
software‟s version) to open the software.
A. Static Images Snap
Click “Capture”“Capture Frame”, input the file name in dialog box, or you
can click icon on the toolbar, then input file name in dialog window. The
image file is JPG format.
B. Snap Video Stream
Click “Capture”“Start Capture”, input the file name in dialog box, or click
icon on the toolbar, then input the file name in dialog box. If you want to
set the time limit for the capture, select “Capture”“Set Time Limit“to set
the time limit. Click “Start Capture”to start capture, and click “Stop
Capture”or icon on the toolbar to stop capture. (If you have set the
time limit, it will stop automatically when the time is up.) The video file is
AVI format.
C. Set the Frame Rate

16
Click [Capture] [Set Frame Rate], and click open “Choose Frame Rate”
to set the frame rate.
D. Set Time Limit
Click [Capture] [Set Time Limit] to set the time limit while capturing
video.
E. Note:
Do not connect / disconnect the USB cable when the application is running,
which will cause the program to be interrupted.
CONTROLLING VISUALIZER BY COMPUTER
You can control the visualizer from a computer connected with a RS232
connector.
A. Connect the computer and the visualizer using the RS232 cable.
B. Double click X:\ 232 Control\Control Panel (you can open this file from
the CD and double click it, or copy this file to any directory on your
computer‟s hard drive and double click to launch it).
CONTROLLING PROJECTOR BY VISUALIZER
The code writing software is used to inputting projector‟s control code, then
can control various projector with the visualizer.
1. Connect the visualizer to the projector with the RGB,VIDEO cables.
2. Connect the RS232 cable to the computer‟s connector. The visualizer‟s
RS232 port is located on its right side.
3. After completion of the connection, turn on the visualizer，click [start] 
[All Programs] Visualizer and the following
dialog box appears as below:

17
When the indicator of “Current RS-232 Connection Status”is green, that
means the connection between the visualizer and the computer‟s RS232
connector is good. If the indicator is red, please check if the RS232 cable is
connected correctly. When all the cables are connected correctly, please
click “Projector”to select your projector model under the drop-down list,
then click “Send”. If you can not find your particular projector model in the
“Projector”, please do the following:
1)．Select “Baud rate”and “parity”and input the projector control code.
(The baud rate, parity and control code is supplied by projector‟s
manufacturer, please refer to the projector‟manual)
The input format of projector‟s control code is as follows:
a. If the data is in the numerical value format, please input data directly,
block them off with comma, do not distinguish lowercase and uppercase.
For example: the “POWER ON”code in Hitachi projector manual is :
BE EF 03 06 00
BAD2
01 00
00 60
01 00

18
In the POWRE ON box,Input : be, ef, 03, 06, 00, ba, d2, 01, 00, 00, 60, 01,
00. Then use the same input rule to input other code.
b. If the data is in the character string format, input „character string‟.
For example: the “POWER ON”code in the SHARP C40/50 projector
manual is :
P
O
W
R
-
-
-
1
（“-”is space，is enter.）
In the POWER ON box, input ‟POWR 1‟, 0d, 0a
(Remarks: There are 3 spaces after POWER, 0d, 0a is enter.)
Input other codes in the same way.
c. If the data is in the numerical value and character format, then
synthesize the above-mentioned formats.
3)．Once done, click “Add”to add your projector model, then Click “Send”.
Afterward, click “Ok”. Now, you can use the visualizer to control your
projector.
4. Connect the visualizer‟s projector control port to the RS232 port with a
RS232 cable（Please disconnect the computer from the RS232 port first）.
Then use buttons on the operation panel to control the projector.
The visualizer provides a 6-pin to 9-pin RS232 cable. If this cable does not
match to your projector‟s RS232 port, an additional RS232 cable is needed.
This additional RS232 cable can be made based on the pin location of the
projector‟s RS232 control port. The pin locations of the visualizer are: the
pin 1 is RXD (Received Data); the pin 5 is TXD (Transmitted Data); the pin
4 is GND (Ground). Other pins are not defined. The pin location information
of the projector is provided by the projector‟s manufacturer. The projector‟s
RS232 control port normally has RXD pin, TXD
pin and GND pin, the name may be different. The
parallelism of each data pin is shown as follows:
Visualizer‟s RXD pin------------Projector‟s TXD pin
Visualizer‟s TXD pin------------Projector‟s RXD pin
Visualizer‟s GND pin------------Projector‟s GND pin
65
43
21

19
5. If you can not use buttons on the operation panel to control the projector,
please use Code-Writing software‟s projector control code testing function
to check if the control code is correct.
Click “Projector”button, the following dialog box appears as below:
Connect the visualizer to a computer with a RS232 cable (Please
disconnect the projector from the RS232 port first) and select the Baud
Rate and Parity based on the projector‟s Baud Rate, then click the “TEST”
button to pop up the Projector Code Test dialog box, input the Baud Rate
and Parity based on the projector‟s Baud rate, then click “Open”.
Click the projector control buttons on the visualizer‟s operating panel to
check if the control code that the program received is the same as the
sending code. If the receiving code is same to the sending code, the input
codes are correct. If the visualizer can not control the projector, please do
the following.
1. Check to see if the source control codes of projector are correct.
2. Check to make sure the connection between the visualizer and the
projector is correct.
