R/Evolution R/Evolution 2730 User manual

2730 Getting Started
Guide
P/N 83-00004284-12
Revision A
January 2009

Copyright Protected Material 2002-2009. All rights reserved. R/Evolution and the R/Evolution logo are trademarks of Dot
Hill Systems Corp. All other trademarks and registered trademarks are proprietary to their respective owners.
The material in this document is for information only and is subject to change without notice. While reasonable efforts have
been made in the preparation of this document to assure its accuracy, changes in the product design can be made without
reservation and without notification to its users.

3
Contents
Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Before You Read This Book . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Typographic Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Related Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
1. Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
System Management Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
RAIDar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Command-Line Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Hardware Components and LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
R/Evolution 2730 FC Controller Enclosure Components and LEDs . . . . . . . . . 11
R/Evolution SAS Expansion Enclosure Components and LEDs . . . . . . . . . . . .17
Obtaining IP Values for Your Storage System . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Installation Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
2. Installing and Cabling Enclosures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Unpacking an Enclosure and Verifying its Contents . . . . . . . . . . . . . . . . . . . . . . . . 25
Unpacking Rackmount Kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Preparing the Rack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Installing Enclosures in a Rack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Attaching the Ear Caps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Connecting Controller and Drive Enclosures . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Connecting AC Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

4R/Evolution 2730 Getting Started Guide • January 2009
Connecting DC Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Connecting DC Power Cords . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Disconnecting a DC Power Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
DC Ground Cable Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
DC Wiring and DC Power Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
DC Power System Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Cabling requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Testing the Enclosure Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Correcting Enclosure IDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Next Steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
3. Connecting Hosts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Host System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Installing the R/Evolution SES Driver for Microsoft Windows Hosts . . . . . . . 44
Configuration Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Using a Direct or Switch Attach Configuration . . . . . . . . . . . . . . . . . . . . . . . . 44
Using Host Port Interconnects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Using Loop or Point-to-Point Topology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Connecting Direct Attach Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Connecting Switch Attach Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Connecting One Data Host Through One Switch . . . . . . . . . . . . . . . . . . . . . . . 50
Connecting Two Data Hosts Through Two Switches . . . . . . . . . . . . . . . . . . . . 51
Connecting Two Data Hosts Through a Zoned Switch . . . . . . . . . . . . . . . . . . . 52
Connecting Remote Management Hosts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Next Steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
4. Configuring a System for the First Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Setting Management Port IP Addresses Using the CLI . . . . . . . . . . . . . . . . . . . . . . 56
Configuring Your Web Browser for RAIDar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Contents 5
Logging in to RAIDar from a Local Management Host . . . . . . . . . . . . . . . . . . . . . . 60
Setting the Date and Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Configuring Host Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Creating Virtual Disks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Mapping a Data Host to a Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Testing the Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Logging Out of RAIDar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Next Steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
A. Powering the System Off and On . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Powering Off the System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Powering On the System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67

6R/Evolution 2730 Getting Started Guide • January 2009

7
Preface
This guide describes how to install and initially configure a R/Evolution™ 2000
Series storage system, and applies to the following enclosures:
■2730 FC Controller Enclosure
■SAS Expansion Enclosure
Before You Read This Book
Before you begin to follow the procedures in this book, you must prepare the site
and learn of any late-breaking information related to installation as described in the
following documents:
■R/Evolution Storage System Site Planning Guide
■ R/Evolution 2730 Release Notes
Refer to the R/Evolution™ 2000 Series storage system product documentation on
the Dot Hill Systems Customer Resource Center for more information. If you
require additional assistance, contact Dot Hill Systems' Customer Service at+1-877-
368-7924 or [email protected].

8R/Evolution 2730 Getting Started Guide • January 2009
Typographic Conventions
Related Documentation
Typeface1
1 The fonts used in your viewer might differ.
Meaning Examples
AaBbCc123 Book title, new term, or
emphasized word See the Release Notes.
A virtual disk (vdisk) can ....
You must be an advanced user to ....
AaBbCc123 Directory or file name,
value, command, or
on-screen output
The default file name is store.logs.
The default IP address is 10.0.0.1.
Type exit.
AaBbCc123 Text you type, contrasted
with on-screen output # set password Enter new password:
AaBbCc123 Variable text you replace
with an actual value Use the format http://ip-address.
Application Title Part Number
Site planning information R/Evolution Storage System Site Planning Guide 83-00004283
Late-breaking information not
included in the documentation set R/Evolution 2730 Release Notes 83-00004282
Configuring and managing storage R/Evolution 2000 Series Administrator’s Guide 83-00004289
Using the command-line interface
(CLI) R/Evolution 2000 Series CLI Reference Manual 83-00004288
Troubleshooting R/Evolution 2000 Series Troubleshooting Guide 83-00004287
Recommendations for maximizing
reliability, accessibility, and
serviceability
R/Evolution 2000 Series Best Practices Guide 83-00004286

9
CHAPTER 1
Before You Begin
The R/Evolution 2730 FC Controller Enclosure and SAS Expansion Enclosure are
high-performance storage solutions that combine outstanding performance with high
reliability, availability, flexibility, and manageability.
Supported configurations include a controller enclosure with or without attached
drive enclosures. A controller enclosure can contain two RAID controller modules
that interact and provide failover capability for the data path. The controller
enclosure can use SATA or SAS disk drive modules. Enclosures can be installed in
standard 19-inch EIA rack cabinets.
This chapter provides information that you must know before installing and initially
configuring your storage system:
■“System Management Software” on page 10
■“Hardware Components and LEDs” on page 11
■“Obtaining IP Values for Your Storage System” on page 21
■“Installation Checklist” on page 22

10 R/Evolution 2730 Getting Started Guide • January 2009
System Management Software
Embedded management software includes the RAIDar web-browser interface (WBI)
and the command-line interface (CLI) described below.
RAIDar
RAIDar is the primary interface for configuring and managing the system. A web
server resides in each controller module. RAIDar enables you to manage the system
from a web browser that is properly configured and that can access a controller
module through an Ethernet connection.
Information about using RAIDar is in its online help and in the Administrator’s
Guide.
Command-Line Interface
The embedded CLI enables you to configure and manage the system using
individual commands or command scripts through an out-of-band RS-232 or
Ethernet connection.
Information about using the CLI is in the CLI Reference Manual.

Chapter 1 Before You Begin 11
Hardware Components and LEDs
This section describes the main hardware components of R/Evolution storage
system enclosures.
R/Evolution 2730 FC Controller Enclosure
Components and LEDs
The controller enclosure can be connected to Fibre Channel host bus adapters
(HBAs) or switches. Table 1-1 describes the enclosure components.
Table 1-1 Controller Enclosure Components
Description Quantity
FC controller (I/O) module 1 or 21
1 Air-management system drive blanks or I/O blanks must fill empty slots to maintain optimum airflow through the chassis.
SAS or SATA drive module 2–12 per enclosure
AC power-and-cooling module 2 per enclosure
2- or 4-Gbps FC host port with SFP 2 per controller module
3-Gbps, 4-lane SAS expansion port 1 per controller module
Ethernet port (RJ-45) 1 per controller module
CLI port (RS-232 micro-DB9) 1 per controller module
Service port (RS-232 3.5-mm jack) 1 per controller module

12 R/Evolution 2730 Getting Started Guide • January 2009
Figure 1-1 shows the components and LEDs on the front of an enclosure.
Figure 1-1 Enclosure (Front View)
Table 1-2 describes the LEDs on the front of an enclosure.
Table 1-2 Enclosure LEDs (Front)
Location LED Color
Operating
State Description
Left ear Enclosure ID Yellow On Shows the enclosure ID, which enables you to
correlate an enclosure with logical views
presented by management software. The
enclosure ID for a controller enclosure is zero
(0); the enclosure ID for an attached drive
enclosure is nonzero.
Drive
module OK to Remove (Upper LED) Blue Off The drive module is not prepared for removal.
On The drive module has been removed from any
active virtual disk, spun down, and prepared
for removal.
Drive
module Power/Activity/ Fault
(Lower LED)
Green Off If neither green nor yellow, the drive module is
not powered on.
On The drive module is operating normally.
Blink The drive module is active and processing I/O
or is performing a media scan.
Drive modules numbered left to right by row: 0–3, 4–7, 8–11
Drive module LEDs
Enclosure ID
Status LEDs (top to bottom):
Unit Locator
Fault/Service Required
FRU OK
Temperature Fault

Chapter 1 Before You Begin 13
Yellow Off If neither green nor yellow, the drive module is
not powered on.
On • The drive module has experienced a fault or
has failed
• The vdisk is initializing or rebuilding
• The vdisk is down or critical.
Blink Physically identifies the drive module.
Right ear Unit Locator White Off Normal operation.
Blink Physically identifies the enclosure.
Right ear Fault/Service
Required Yellow Off No fault.
On An enclosure-level fault occurred. Service
action is required. The event has been
acknowledged but the problem needs attention.
Right ear FRU OK Green On The enclosure is powered on with at least one
power and cooling module operating normally.
Off Both power and cooling modules are off.
Right ear Temperature
Fault Green Off The enclosure temperature is normal.
Yellow On The enclosure temperature is above threshold.
Table 1-2 Enclosure LEDs (Front) (Continued)
Location LED Color
Operating
State Description

14 R/Evolution 2730 Getting Started Guide • January 2009
Figure 1-2 shows the ports and switches at the back of the controller enclosure.
Figure 1-2 Controller Enclosure Ports and Switches (Back View)
Table 1-3 describes the ports and switches on the back of the controller enclosure.
Table 1-3 Controller Enclosure Ports and Switches (Back)
Location Port/Switch Description
Powerand
cooling
module
Power switch Toggle, where:
•–isOn
•Ois Off
Controller
module Host ports 4-Gbps FC ports used to connect to data hosts. Each port contains a Small Form-factor Pluggable (SFP) transceiver. Host port 0 and 1 correspond to
host channel 0 and 1, respectively.
Controller
module Expansion port 3-Gbps, 4-lane (12 Gbps total) table-routed SAS Out port used to connect SAS drive enclosures.
Controller
module Ethernet port 10/100BASE-T Ethernet port used for TCP/IP-based out-of-band management of the RAID controller. An internal Ethernet device provides
standard 10 Mbit/second and 100 Mbit/second full-duplex connectivity.
Controller
module CLI port Micro-DB9 port used to connect the controller enclosure to a local management host using RS-232 communication for out-of-band
configuration and management.
Controller
module Service port 3.5-mm jack port used by service technicians only.
10/100 BASE-T STATUS
ACTIVITY
DIRTY
CLEAN
CACHE
CLI
Service
LINK SPEED LINK SPEED
FC
Port 0
FC
Port 1
10/100 BASE-T STATUS
ACTIVITY
DIRTY
CLEAN
CACHE
CLI
Service
LINK SPEED LINK SPEED
FC
Port 0
FC
Port 1
Power switch
Host ports Expansion portCLI port Ethernet portService (MUI) port

Chapter 1 Before You Begin 15
Figure 1-3 shows the LEDs at the back of the controller enclosure.
Figure 1-3 Controller Enclosure LEDs (Back View)
Table 1-4 describes the LEDs on the back of the controller enclosure.
Table 1-4 Controller Enclosure LEDs (Back)
Location LED Color State Description
Powerand
cooling
module
AC Power Good Green Off AC power is off or input voltage is below the
minimum threshold.
On AC power is on and input voltage is normal.
Powerand
cooling
module
DC Voltage/
Fan Fault/
Service Required
Yellow Off DC output voltage is normal.
On DC output voltage is out of range or a fan is
operating below the minimum required RPM.
Controller
module Host link status Green Off The port is empty or the link is down.
On The port link is up and connected.
Controller
module Host link speed Green Off The data transfer rate is 2 Gbps.
On The data transfer rate is 4 Gbps.
10/100 BASE-T STATUS
ACTIVITY
DIRTY
CLEAN
CACHE
CLI
Service
LINK SPEED LINK SPEED
FC
Port 0
FC
Port 1
10/100 BASE-T STATUS
ACTIVITY
DIRTY
CLEAN
CACHE
CLI
Service
LINK SPEED LINK SPEED
FC
Port 0
FC
Port 1
AC Power Good
Service Required
DC Voltage/Fan Fault/ Host link status
Host link speed
Unit Locator
OK to Remove Fault/Service Required
FRU OK
Cache status
Host activity
Expansion port status
Ethernet activity
Ethernet link status

16 R/Evolution 2730 Getting Started Guide • January 2009
Controller
module Unit Locator White Off Normal operation.
Blink Physically identifies the controller module.
Controller
module OK to Remove Blue Off The controller module is not prepared for removal.
On The controller module can be removed.
Controller
module Fault/Service Required Yellow On A fault has been detected or a service action is required.
Blink Indicates a hardware-controlled power up or a
cache flush or restore error.
Controller
module FRU OK Green Off Controller module is not OK.
On Controller module is operating normally.
Blink System is booting.
Controller
module Cache status Green Off Cache is clean (contains no unwritten data).
On Cache is dirty (contains unwritten data) and
operation is normal.
Blink A Compact Flash flush or cache self-refresh is in
progress. Indicates cache activity.
Controller
module Host activity Green Off The host ports have no I/O activity.
Blink At least one host port has I/O activity.
Controller
module Ethernet link status Green Off The Ethernet port is not connected or the link is down.
On The Ethernet link is up.
Controller
module Ethernet activity Green Off The Ethernet link has no I/O activity.
Blink The Ethernet link has I/O activity.
Controller
module Expansion port status Green Off The port is empty or the link is down.
On The port link is up and connected.
Table 1-4 Controller Enclosure LEDs (Back) (Continued)
Location LED Color State Description

Chapter 1 Before You Begin 17
R/Evolution SAS Expansion Enclosure
Components and LEDs
A drive enclosure can be connected to a controller enclosure or to another drive
enclosure to provide additional disk storage capacity. Table 1-5 describes the
enclosure components.
The components and LEDs on the front of a drive enclosure are the same as on a
controller enclosure; see Figure 1-1 and Table 1-2.
Table 1-5 Drive Enclosure Components
Description Quantity
SAS expansion (I/O) module 1 or 21
1 Air-management system drive blanks or I/O blanks must fill empty slots to maintain optimum airflow through the chassis.
SAS or SATA drive module 2–12 per enclosure
AC power and cooling module 2 per enclosure
3-Gbps, 4-lane SAS In port 1 per expansion module
3-Gbps, 4-lane SAS Out port 1 per expansion module
Service port (RS-232 micro-DB9) 1 per drive module

18 R/Evolution 2730 Getting Started Guide • January 2009
Figure 1-4 shows the ports and switches at the back of the drive enclosure.
Figure 1-4 Drive Enclosure Ports and Switches (Back View)
Table 1-6 describes the ports and switches on the back of the drive enclosure.
Table 1-6 Drive Enclosure Ports and Switches (Back)
Location Port/Switch Description
Power and
cooling module Power switch Toggle, where:
•–isOn
•Ois Off
Expansion
module SAS In port 3-Gbps, 4-lane (12 Gbps total) subtractive ingress port used to connect to a controller enclosure.
Expansion
module SAS Out port 3-Gbps, 4-lane (12 Gbps total) table-routed egress port used to connect to another drive enclosure.
Expansion
module Service port Micro-DB9 port for manufacturing technicians.
Service
0 0
Service
0 0
Service (MUI) port SAS Out port
Power switch
SAS In port

Chapter 1 Before You Begin 19
Figure 1-5 shows the LEDs at the back of the drive enclosure.
Figure 1-5 Drive Enclosure LEDs (Back View)
Table 1-7 describes the LEDs on the back of the drive enclosure.
Table 1-7 Drive Enclosure LEDs (Back)
Location LED Color State Description
Powerand
cooling
module
AC Power Good Green Off AC power is off or input voltage is below the
minimum threshold.
On AC power is on and input voltage is normal.
Powerand
cooling
module
DC Voltage/
Fan Fault/
Service Required
Yellow Off DC output voltage is normal.
On DC output voltage is out of range or a fan is
operating below the minimum required RPM.
Expansion
module SAS In port status Green Off The port is empty or the link is down.
On The port link is up and connected.
Expansion
module Unit Locator White Off Normal operation.
Blink Physically identifies the expansion module.
Expansion
module OK to Remove Blue Off Not implemented.
Service
0 0
Service
0 0
AC Power Good
Service Required
DC Voltage/Fan Fault/ SAS In port status SAS Out port status
Unit Locator
OK to Remove Fault/Service Required
FRU OK

20 R/Evolution 2730 Getting Started Guide • January 2009
Expansion
module Fault/Service Required Yellow On A fault has been detected or a service action is required.
Blink Indicates a hardware-controlled power up or a
cache flush or restore error.
Expansion
module FRU OK Green Off Expansion module is not OK.
On Expansion module is operating normally.
Blink System is booting.
Expansion
module SAS Out port status Green Off The port is empty or the link is down.
On The port link is up and connected.
Table 1-7 Drive Enclosure LEDs (Back) (Continued)
Location LED Color State Description
