Purpose
This document provides instructions for replacing a faulty disk drive in the 3U16 / 2U12 Storage
Shelves that are connected to the NetBackup 5230 Appliance.
Electrical Safety
The static discharged by human bodies can damage static-sensitive components on the boards.
When installing and maintaining the equipment, observe appropriate electrostatic safety precautions
to prevent personnel injuries or device damage.
When operating a device in an electrostatic sensitive area, you must take electrostatic-discharge
(ESD)-preventive measures. These include wearing ESD-preventive gloves, an ESD-preventive wrist
strap, and ESD-preventive clothes to avoid personnel injury or device damage.
To prevent damage to the device, pay attention to the following during operations:
• Do not touch devices with bare hands because ESD from the human body may damage the
electrostatically sensitive elements on a board.
• When dealing with the server or any of the internal components, wear an ESD-preventive wrist
strap, ESD-preventive gloves, and ESD-preventive suit.
Hardware Part Replacement Procedure
About removing and replacing a faulty hot-swappable disk drive in a Veritas 3U16
24/36TB Storage Shelf or a Veritas 2U12 49TB Storage Shelf
This section describes how to replace a faulty hot-swappable disk drive in a Veritas 3U16 24/36TB
Storage Shelf or a Veritas 2U12 49TB Storage Shelf. These storage shelves are used with NetBackup
5230 Appliances.
Getting started
To replace a faulty disk drive in a Veritas 3U16 24/36TB Storage Shelf, see .
1
Veritas Appliance
Hardware Service Procedure

To replace a faulty disk drive in a Veritas 2U12 49TB Storage Shelf, see .
Requirements
• Replacement 2-TB hot-swappable disk drive for the Veritas 3U16 24TB Storage Shelf
• Replacement 3-TB hot-swappable disk drive for the Veritas 3U16 36TB Storage Shelf
• Replacement 6-TB hot-swappable disk drive for the Veritas 2U12 49TB Storage Shelf
• ESD wrist strap
•A T10 screwdriver (Veritas 2U12 49TB Storage Shelf only)
Replacing a faulty hot-swappable disk drive in a Veritas 3U16 24/36TB Storage Shelf
Caution: You must complete the disk drive swap within three minutes. Leaving the disk drive slot
open for longer than three minutes can result in higher drive bay temperatures, which can shorten
the life span of the remaining disk drives.
2
HSP #201 Replacing a faulty hot-swappable disk drive in storage shelves that are connected to a NetBackup 5230 Appliance

Caution: Only swap one disk drive at a time. Removing more than one disk drive at one time can
affect system functionality.
Locating the faulty disk drive in the storage shelf
To locate the faulty disk drive in the storage shelf
1Go to the unit with the failed component.
2Unlock and remove the storage shelf bezel if necessary.
3Verify that the unit contains a failed disk drive. The drive Status LED is solid amber when a disk
drive has failed.
Release Button
Drive
Status LED
Drive Capacity
Use the slot map below to verify that the failed drive is the correct drive to replace.
Disk module #1 of 16 Disk module release button
Disk status LED
Power activity
LED
4Verify that the drive capacity matches that of the replacement drive.
Veritas Storage Shelf drive carriers use Roman numeral markings in the bottom right-hand corner
to indicate the drive capacity.
• II = 2 TB
• III = 3 TB
Contact Veritas Technical Support if the correct drive cannot be identified.
Removing the faulty hot-swappable disk drive from a Veritas 3U24/36TB Storage Shelf
To remove the faulty hot-swappable disk drive from a Veritas 3U24/36TB Storage Shelf
1Put on an ESD-compliant wrist strap or take other ESD-protective measures.
3
HSP #201 Replacing a faulty hot-swappable disk drive in storage shelves that are connected to a NetBackup 5230 Appliance

Note: The static discharged by human bodies can damage static-sensitive components on the
boards. When installing and maintaining the equipment, you must observe appropriate electrostatic
safety precautions to prevent personnel injuries or device damage.
2Push the drive release button to release the disk drive and open the latch handle.
3Remove the faulty disk drive from the slot and place it in an ESD-protective bag.
Installing the replacement hot-swappable disk drive in the Veritas 3U24/36TB Storage Shelf
To install the replacement hot-swappable disk drive in the Veritas 3U24/36TB Storage Shelf
1Remove the replacement drive from the ESD-protective bag.
2Verify that the capacity of the drive is the same as the capacity of the drive that is being replaced.
3Open the latch handle and slide the drive into the drive slot until the drive makes connection with
the backplane and clicks.
4
HSP #201 Replacing a faulty hot-swappable disk drive in storage shelves that are connected to a NetBackup 5230 Appliance

4The Drive Activity LED turns blue. The Drive Status LED starts flashing amber when the copyback
starts.
5Replace and lock the storage shelf bezel if necessary.
Replacing a faulty hot-swappable disk drive in a Veritas 2U12 49TB Storage Shelf
Caution: You must complete the disk drive swap within two minutes. Leaving the disk drive slot open
for longer than two minutes can result in higher drive bay temperatures, which can shorten the life
span of the remaining disk drives.
Caution: Only swap one disk drive at a time. Removing more than one disk drive at one time can
affect system functionality.
Locating the faulty disk drive in the storage shelf
To locate the faulty disk drive in the Veritas 2U12 49TB Storage Shelf
1Go to the unit with the failed component.
2Remove the front bezel if necessary by gripping the bezel on its sides and pulling it off of the
appliance.
3On the front panel, check the status of both LEDs. The activity LED is the top of the two LEDs
on the disk drive face plate and the fault LED is the bottom one.
5
HSP #201 Replacing a faulty hot-swappable disk drive in storage shelves that are connected to a NetBackup 5230 Appliance

Activity LED
Fault LED
Release Button
Drive Carrier Unlock Key Drive Capacity
The disk drive is not working properly in any one of the following situations:
• The activity LED is on and the fault LED is on.
• The activity LED is off and the fault LED is on.
• The activity LED is on and the fault LED flashes on for three seconds and then flashes off for
one second.
If you cannot identify the faulty drive, contact Veritas Support before you proceed.
Warning: Disconnecting the drive incorrectly can cause data loss or data corruption. Therefore,
if the fault LED is not on or it does not flash three seconds on and one second off and you are
an authorized Veritas service partner, contact your dispatch help desk, otherwise contact Veritas
Support.
Removing the faulty hot-swappable disk drive from the Veritas 2U12 49TB Storage Shelf
To remove the faulty hot-swappable disk drive from the Veritas 2U12 49TB Storage Shelf
1Put on an ESD-compliant wrist strap or take other ESD-protective measures.
Note: The static discharged by human bodies can damage static-sensitive components on the
boards. When installing and maintaining the equipment, you must observe appropriate electrostatic
safety precautions to prevent personnel injuries or device damage.
2If the drive carrier is locked, unlock it by using the T10 screwdriver to rotate the drive carrier unlock
key to the left till the red lock icon is no longer visible.
6
HSP #201 Replacing a faulty hot-swappable disk drive in storage shelves that are connected to a NetBackup 5230 Appliance

3Locate the drive that you want to replace. Check the status of both LEDs.
4Push the release button to the right-hand direction to release the disk drive lever.
5After you open the latch, hold the drive carrier lever and pull it open completely. Allow the drive
to spin down, which may take about 30 seconds.
7
HSP #201 Replacing a faulty hot-swappable disk drive in storage shelves that are connected to a NetBackup 5230 Appliance

6Hold the drive carrier and part of the disk drive, and gently slide the faulty disk out of the slot.
7Place the faulty disk in an ESD-protective bag.
8
HSP #201 Replacing a faulty hot-swappable disk drive in storage shelves that are connected to a NetBackup 5230 Appliance

Installing the replacement hot-swappable disk drive in the 2U12 49TB Storage Shelf
To install the replacement hot-swappable disk drive in the 2U12 49TB Storage Shelf
1Remove the replacement drive from the ESD-protective wrapper.
2Verify that the capacity of the drive is the same as the capacity of the drive that is being replaced.
Note: The capacity of a Veritas 2U12 49TB Storage Shelf disk drive is 6-TB.
If the drive capacity does not match, contact the Veritas Technical Support.
3Unlock the drive carrier unlock key if needed by using the T10 screwdriver to rotate the drive
carrier unlock key to the left till the red lock icon is no longer visible.
4Press the release button to release the lever.
5Pull the lever open completely.
6Insert the replacement disk drive into the correct slot and then gently slide it completely into the
slot.
7Close the lever to secure the drive carrier in the slot. The carrier clicks when contact is secure.
8Lock the drive carrier by using the T10 screwdriver to rotate the drive carrier unlock key to the
right until the red lock icon is visible.
9
HSP #201 Replacing a faulty hot-swappable disk drive in storage shelves that are connected to a NetBackup 5230 Appliance

9Check the status of the LEDs on the drive that you replaced. The activity LED is on when the
connection is good. After a short period, the fault LED flashes one second on and one second
off to indicate that the rebuild is in progress.
10
11 Replace the front bezel if necessary.
