R.V.R. Electronica TEX30LCD User manual

TEX30LCD TEX50LCD
TEX100LCD TEX150LCD
TEX300LCD
USER MANUAL
VOLUME1
Manufactured by R.V.R ELETTRONICA S.p.A. Italy

TEX30LCD TEX50LCD TEX100LCD TEX150LCD TEX300LCD
- User Manual
Version 1.0
© Copyright 2012
R.V.R. Elettronica SpA
Via del Fonditore 2/2c - 40138 - Bologna (Italia)
Telephone: [phone]
Fax: [phone]
Email: [e-mail]
Web: www.rvr.it
All rights reserved
Printed and bound in Italy. No part of this manual may be reproduced,
memorized or transmitted in any form or by any means, electronic
or mechanic, including photocopying, recording or by any informa-
tion storage and retrieval system, without written permission of the
File Name: TEX30_50_100_150_300-LCD_ING_1.0.indb
Version: 1.0
Date: 29/11/2012
Revision History
Date Version Reason Editor
29/11/2012 1.0 First Version J. H. Berti












TEX30/50/100/150/300LCD
ELETTRONICA
i
User Manual
Rev. 1.0 - 29/11/12
Table of Contents
1. Preliminary Instructions 1
2. Warranty 1
3. First Aid 2
3.1 Treatment of electrical shocks 2
3.2 Treatment of electrical Burns 2
4. General Description 3
4.1 Unpacking 3
4.2 Features 3
4.3 Frontal Panel Description 5
4.4 Rear Panel Description 6
4.5 Connectors Description 7
4.6 Technical Description 9
5. Quick guide for installation and use 10
5.1 Preparation 10
5.2 First power-on and setup 12
5.3 Operation 14
5.4 Management Firmware 16
5.5 Optional Function 22
 6. IdenticationandAccesstotheModules 24
 6.1  IdenticationoftheModules 24
7. Working Principles 27
7.1 TEX30/50/00/50/300LCD Common Parts 27
7.2 TEX30LCD Different Parts 28
7.3 TEX50/100/50LCD Different Parts 29
7.4 TEX300LCD Different Parts 31

ii User Manual
Rev. 1.0 - 29/11/12
TEX30/50/100/150/300LCD
ELETTRONICA
This page was intentionally left blank

TEX30/50/100/150/300LCD
ELETTRONICA
1/ 32
User Manual
Rev. 1.0 - 29/11/12
1. Preliminary Instructions
• General Warnings
This equipment should only be operated, installed and
maintainedby“trained”or“qualied”personnelwhoarefamiliar
with risks involved in working on electric and electronic circuits.
“Trained” means personnel who have technical knowledge of
equipment operation and who are responsible for their own
safetyandthatofotherunqualiedpersonnelplacedunder
their supervision when working on the equipment.
“Qualified” means personnel who are trained in and
experienced with equipment operation and who are
responsiblefortheirownsafetyandthatofotherunqualied
personnel placed under their supervision when working on
the equipment.
WARNING: Residual voltage may be present inside
theequipmentevenwhentheON/OFFswitchissetto
Off. Before servicing the equipment, disconnect the
power cord or switch off the main power panel and
makesurethesafetyearthconnectionisconnected.
Some service situations may require inspecting the
equipmentwithlivecircuits.Onlytrainedandqualied
personnelmayworkontheequipmentliveandshallbe
assistedbyatrainedpersonwhoshallkeepreadyto
disconnectpowersupplyatneed.
R.V.R. Elettronica S.p.A. shall not be liable for injury to
persons or damage to property resulting from improper use
oroperationbytrained/untrainedandqualied/unqualied
persons.
WARNING:Theequipmentisnotwaterresistant.
Anywaterenteringtheenclosuremightimpairproper
operation. To prevent the risk of electrical shock or
re,donotexposethisequipmenttorain,drippingor
moisture.
Pleaseobservelocalcodesandrepreventionruleswhen
installing and operating this equipment.
 WARNING: This equipment contains exposed
livepartsinvolvinganelectricalshockhazard.Always
disconnectpowersupplybeforeremovinganycovers
orotherpartsoftheequipment.
Ventilation slits and holes are provided to ensure reliable
operation and prevent overheating; do not obstruct or
cover these slits. Do not obstruct the ventilation slits under
any circumstances. The product must not be incorporated
in a rack unless adequate ventilation is provided or the
manufacturer’s instructions are followed closely.
 WA R NING :  T his eq u ipmen t  c an ra d i ate
radiofrequencyenergyand,ifnotinstalledincompliance
with manual instructions and applicable regulations,
maycauseinterferencewithradiocommunications.
 WARNING: This equipment is tted with earth
connectionsbothinthepowercordandforthechassis.
Makesurebothareproperlyconnected.
Operation of this equipment in a residential area may cause
radio interference, in which case the user may be required
to take adequate measures.
Thespecicationsanddatacontainedhereinareprovided
for information only and are subject to changes without prior
notice. R.V.R. Elettronica S.p.A. disclaims all warranties,
express or implied.While R.V.R. Elettronica S.p.A.
attempts to provide accurate information, it cannot accept
responsibility or liability for any errors or inaccuracies in this
manual, including the products and the software described
herein. R.V.R. Elettronica S.p.A. reserves the right to make
changestoequipmentdesignand/orspecicationsandto
this manual at any time without prior notice.
• Notice concerning product intended purpose and use
limitations.
This product is a radio transmitter suitable for frequency-
modulation audio radio broadcasting. Its operating
frequencies are not harmonised in designated user countries.
Before operating this equipment, user must
obtain a licence to use radio spectrum from the
competent authority in the designated user country.
Operating frequency, transmitter power and other
characteristics of the transmission system are subject to
restrictionsasspeciedinthelicence.
2. Warranty
La R.V.R. Elettronica S.p.A. warrants this product to be free
from defects in workmanship and its proper operation subject
to the limitations set forth in the supplied Terms and Conditions.
Please read the Terms and Conditions carefully, as purchase
of the product or acceptance of the order acknowledgement
imply acceptance of the Terms and Conditions.
For the latestupdated termsand conditions,pleasevisitour web
siteatWWW.RVR.IT.Thewebsitemaybemodied,removed
or updated for any reason whatsoever without prior notice.
The warranty will become null and void in the event the
product enclosure is opened, the product is physically
damaged, is repaired by unauthorised persons or is used for
purposes other than its intended use, as well as in the event
of improper use, unauthorised changes or neglect.
In the event a defect is found, follow this procedure:
1 Contact the seller or distributor who sold the equipment;
provide a description of the problem or malfunction for
theeventaquickxisavailable.
Sellers and Distributors can provide the necessary
information to troubleshoot the most frequently encountered
problems. Normally, Sellers and Distributors can offer a
faster repair service than the Manufacturer would. Please
note that Sellers can pinpoint problems due to wrong
installation.
2 If your Seller cannot help you, contact R.V.R. Elettronica
S.p.A. and describe the problem; if our staff deems it
appropriate, you will receive an authorisation to return
the equipment along with suitable instructions;
3 When you have received the authorisation, you may
return the unit. Pack the unit carefully before shipment;
use the original packaging whenever possible and seal
the package perfectly. The customer bears all risks of
loss (i.e., R.V.R. shall not be liable for loss or damage)
until the package reaches the R.V.R. factory. For this
reason, we recommend insuring the goods for their full
value. Returns must be sent on a C.I.F. basis (PREPAID)
totheaddressstatedontheauthorisationasspecied
by the R.V.R. Service Manager.
IMPORTANT
The symbol of lightning inside a triangle placed on the product, evidences the operations for
which is necessary gave it full attention to avoid risk of electric shocks.
The symbol of exclamation mark inside a triangle placed on the product, informs the user
about the presence of instructions inside the manual that accompanies the equipment, im-
portantfortheefcacyandthemaintenance(repairs).

2/ 32 User Manual
Rev. 1.0 - 29/11/12
TEX30/50/100/150/300LCD
ELETTRONICA
Units returned without a return authorisation may
be rejected and sent back to the sender.
4 Be sure to include a detailed report mentioning all
problems you have found and copy of your original
invoice (to show when the warranty period began) with
the shipment.
Please send spare and warranty replacement parts orders to
the address provided below. Make sure to specify equipment
model and serial number, as well as part description and
quantity.
R.V.R. Elettronica S.p.A.
Via del Fonditore, 2/2c
40138 BOLOGNA ITALY
Tel. [phone]
3. First Aid
All personnel engaged in equipment installation, operation
andmaintenancemustbefamiliarwithrstaidprocedures
and routines.
 3.1 Electricshocktreatment
3.1.1 If the victim is unconscious
Followtherstaidproceduresoutlinedbelow.
• Laythevictimdownonhis/herbackonarm
surface.
• the neck and tilt the head backwards to free
the airway system (Figure 1).
Figure 1
• If needed, open the victim’s mouth and check
for breathing.
• Ifthereisnobreathing,startarticialrespiration
without delay (Figure 2) as follows: tilt the head
backwards, pinch the nostrils, seal your mouth
around the victim’s mouth and give four fast
rescue breaths.
Figure 2
• Check for heartbeat (Figure 3); if there is
no heartbeat, begin chest compressions
immediately (Figure 4) placing your hands in
the centre of the victim’s chest (Figure 5).
Figure 3 Figure 4 Figure 5
• One rescuer: give 2 quick rescue breaths after
each 15 compressions.
• Two rescuers: one rescue breath after each 5
compressions.
• Do not stop chest compressions while giving
articialbreathing.
• Call for medical help as soon as possible.
3.1.2 If the victim is conscious
• Cover victim with a blanket.
• Try to reassure the victim.
• Loosen the victim’s clothing and have him/her
lie down.
• Call for medical help as soon as possible.
3.2 Treatment of electric burns
3.2.1 Large burns and broken skin
• Cover affected area with a clean cloth or
linen.
• Do not break any blisters that have formed;
remove any clothing or fabric that is stuck to
the skin; apply adequate ointment.
• Administer adequate treatment for the type of
accident.
• Get the victim to a hospital as quickly as
possible.
• Elevate arms and legs if injured.
If medical help is not available within an hour, the victim is
conscious and is not retching, administer a solution of table
salt and baking soda (one teaspoon of table salt to half
teaspoon of baking soda every 250 ml of water).
Have the victim slowly drink half a glass of solution for four
times during a period of 15 minutes.
Stopattherstsignofretching.
Do not administer alcoholic beverages.
3.2.2 Minor burns
• Apply cold (not ice cold) strips of gauze or dress
wound with clean cloth.
• Do not break any blisters that have formed;
remove any clothing or fabric that is stuck to
the skin; apply adequate ointment.
• If needed, have the victim change into clean,
dry clothing.
• Administer adequate treatment for the type of
accident.
• Get the victim to a hospital as quickly as
possible.
• Elevate arms and legs if injured.

TEX30/50/100/150/300LCD
ELETTRONICA
3/ 32
User Manual
Rev. 1.0 - 29/11/12
4. General Description
The TEX30/50/100/150/300LCD, manufactured by R.V.R. Elettronica SpA, are
excitersfor Frequency Modulated audio broadcasting in a frequency modulation
able to transmit in the band between 87.5 and 108 MHz, in step of 10 KHz, with
an RF output power adjustable up to a maximum of 30, 50, 100, 150 and 300 W
respectively into a 50 Ohm standard load.
The TEX30/50/100/150/300LCD are designed to being contained into a 19” rack
box of 2HE.
4.1 Unpacking
The package contains:
1 TEX30LCD,TEX50LCD,TEX100LCD,TEX150LCDor TEX300LCD
1 User Manual
1 Mains power cables
The following accessories are also available from Your R.V.R. Dealer:
• Accessories,sparepartsandcables
4.2 Features
Theseexciterscontainalow-passlterthatreducestheharmonicemissionto
provided for by international standards (CCIR, FCC or ETSI) and can be connected
directly to the antenna.
Two major features of TEX30/50/100/150/300LCD are compact design and user-
friendliness. Design is based on a modular concept: the different functions are
performed by modules that, for the most part, are connected through male and
facilitates maintenance and module replacement.
The RF power section of the TEX30LCD features a MOSFET module delivering
up to 30W output power, the TEX50/100/150LCD features a MOSFET module
delivering up to 150W output power, the TEX300LCD features a MOSFET module
delivering up to 300W output power.
Operating frequency stability is ensured by a temperature-compensated reference
oscillator and is maintained by a PLL (Phase Locked Loop) system. The exciters
will go into frequency lock within 30 seconds after power-on.
The TEX30/50/100/150/300LCD can operate throughout the frequency bank with
no need for calibration or set-up.

4/ 32 User Manual
Rev. 1.0 - 29/11/12
TEX30/50/100/150/300LCD
ELETTRONICA
An LCD on the front panel and a push-button board provide for user interfacing
with the microprocessor control system, which offers the following features:
• Output power setup.
• Operating frequency setup.
• Power output enable/disable.
• Power Good feature (User-selectable output power alarm threshold).
• Measurement and display of transmitter operating parameters.
• Communication with external devices such as programming or telemetry
systems via RS232 serial interface or I2C.
Four LEDs on the front panel provide the following status indications: ON, LOCK,
FOLDBACK and RFMUTE.
The exciters have an input for the external 24 Vcc supply. This auxiliary supply
source, that can be realized by the user with the help of rescue batteries, is
automatically used in case of AC voltage absence.
Theexcitermanagementrmwareisbasedonamenusystem.Userhasfour
navigation buttons available to browse submenus: ESC , , , ed ENTER.
The rear panel features the mains input connectors, as well as audio input
connectors and RF output connector, telemetry connector, protection fuses and
two inputs for signals modulated onto subcarriers by suitable external coders, such
as RDS (Radio Data System) signals commonly used in Europe.

TEX30/50/100/150/300LCD
ELETTRONICA
5/ 32
User Manual
Rev. 1.0 - 29/11/12
4.3 Frontal Panel Description
[1] AIRFLOW  Airowfortheforcedventilation.
[2] ON Green LED, lit when the exciter is working.
[3] LOCK Green led, lit when the PLL is locked on the working frequency.
[4] FOLDBACK Yellow LED, lit when the foldback function is operating (automatic
reduction of the delivered RF power).
[5] R.F. MUTE Yellow LED, lit when the exciter’s power output is inhibited by an
external interlock command.
[6] CONTRAST Display contrast adjusting trimmer (on the top of the equipment).
[7] ESC Push button to exit from a menu.
[8] Push button to move in the menu system and to modify the
parameters.
[9] Push button to move in the menu system and to modify the
parameters.
[10]ENTER  Pushbuttontoconrmaparameterandtoenterinamenu.
[11] DISPLAY Liquid crystals display.
[12] POWER ON/OFF switch.

6/ 32 User Manual
Rev. 1.0 - 29/11/12
TEX30/50/100/150/300LCD
ELETTRONICA
4.4 Rear Panel Description
[1] PLUG VDE plug for mains supply.
[2] VENTOLA Fan for the forced ventilation of the exciter.
[3] R.F.OUTPUT RFoutputconnector,N-type,50Ω.
[4] 24 VDC IN- External 24Vdc supply input. Negative (black). Only for
TEX30/50/100/150LCD.
[5] 24 VDC IN- External 24Vdc supply input. Positive (red). Only for TEX30/
50/100/150LCD.
[6] INTERLOCK OUT Connettore BNC di interlock in uscita: quando l’eccitatore
entra in modalità stand-by, il conduttore centrale,
normalmenteottante,vienepostoamassa
[7] FWD EXT. AGC Trimmer for the control of the delivered power in function of
the FWD fold input.
[8] RFL EXT. AGC Trimmer for the control of the delivered power in function of
the RFL fold input.
[9] REMOTE DB15 connector for telemetry of the machine.
[10] GSM ANT Reserved for Future Uses - SMA connector for GSM
Antenna.
[11] PHASE ADJ Pilot tone phase adjustment trimmer.
[12] MODE/MPX IMP Dip-switch to set the operation mode (STEREO or MONO)
andtheMPXinputimpedance,50Ωor10kΩ.
[13] SCA/RDS BNC connector, SCA/RDS unbalanced input.
[14] MPX BNC connector, MPX unbalanced input.
[15] MPX ADJ Adjustment trimmer for MPX input.
[16] SCA/RDS ADJ Adjustment trimmer for SCA/RDS input.
[17] RIGHT ADJ Adjustment trimmer for the Right channel input.
[18] RIGHT XLR connector, balanced Right channel input.
[19] FUSE BLOCK Fuse carrier.Use a screwdriver to access the fuse.
[20] R.F. TEST RF test output, approx. 13 dBm wrt the RF output power
level. Not suitable for spectral analysis.
[21] MODEM DB9 connector connected to GSM modem (only with
telemetry option).
[22] I2C BUS Normally not used, or used for customized functions (only
with telemetry option).
[23] RS232 DB9 connector for direct serial communication or modem
(only with telemetry option).
[24] SERVICE DB9 connector for interconnection with other devices
and for factory parameters programming (only for factory
programming).
[25] EXT REF 10MHz Fine regulation trimmer for frequency transmission.
Optionally, Sync signal input BNC connector for external
devices.
[26]PREEMPHASIS Dip-switchtosetthepreenphasysat50or75μs.The
preenphasys setting is relevant only for the Left and Right
inputs in stereo mode and for the mono input in mono mode,

TEX30/50/100/150/300LCD
ELETTRONICA
7/ 32
User Manual
Rev. 1.0 - 29/11/12
while MPX input is unaffected by this setting.
[27] 19 kHz PILOT OUT BNC output for the 19 kHz pilot tone. This can be used for
external devices (e.g. RDS coders) synchronization.
[28] SCA2 BNC connector, SCA2 unbalanced input.
[29] SCA2 ADJ Adjustment trimmer for SCA2 input.
[30] LEFT-MONO ADJ Adjustment trimmer for Left-Mono channel input.
[31] LEFT-MONO XLR connector, balanced Left-Mono channel input.
[32]IMPEDANCE  Dip-switchtosetthebalancedinputimpedance,600Ωor
10kΩ.
4.5 Connectors Description
4.5.1 RS232
Type: Female DB9
1 NC
2 SDA
3 SCL
4 NC
5 GND
6 NC
7 NC
8 NC
9 NC
4.5.2 Service (for programming of factory parameters)
Type: Female DB9
1 NC
2 TX_D
3 RX_D
4 Internally connected with 6
5 GND
6 Internally connected with 4
7 Internally connected with 8
8 Internally connected with 7
9 NC
4.5.3 I2C Bus
Type: Male DB9
1 NC
2 TX_D
3 RX_D
4 Internally connected with 6
5 GND
6 Internally connected with 4
7 Internally connected with 8
8 Internally connected with 7
9 NC

8/ 32 User Manual
Rev. 1.0 - 29/11/12
TEX30/50/100/150/300LCD
ELETTRONICA
4.5.4 Left (MONO) / Right
Type: Female XLR
1 GND
2 Positive
3 Negative
4.5.5 Remote
Type: Female DB15
Pin Name Type Meaning
1 Interlock IN By passes power if closed at GND
2 Ext AGC FWD IN Ext. signal,1-12V, for power
limitation (AGC)
3 GND Ground
4 SDA IIC I/O IIC communication serial data
5 VPA Tlm ANL OUT PA power supply voltage 3,9V F.S.
6 FWD Tlm ANL OUT Forward power 3,9V F.S.
7 Power Good DIG OUT Open collector, enabled whenpower
exceeds the set threshold
8 GND Ground
9 GND Ground
10 Ext AGC RFL IN Ext. signal.,1-12V, for power
limitation (AGC)
11 SCL IIC I/O IIC communication clock
12 IPA Tlm ANL OUT PA power supply current 3,9V F.S.
13 RFLTlm  ANLOUT Reectedpower3,9VF.S.
14 On cmd DIG IN One grounded pulse (500 ms)
enables power supply
15 OFF cmd DIG IN One grounded pulse (500 ms)
disables power supply

TEX30/50/100/150/300LCD
ELETTRONICA
9/ 32
User Manual
Rev. 1.0 - 29/11/12
 4.6 TechnicalDescription
Parameters
TEX30LCD TEX50LCD TEX100LCD TEX150LCD TEX300LCD
GENERALS
Rated output power 30W 50W 100W 150W 300W
Frequency range
Operational Mode
Modulation type
Primary Power 80 ÷ 260 Vac or 24 Vdc 80 ÷ 260 Vac
AC Power Consumption 130 VA / 70W 200 VA /100W 330 VA / 212 W 440 VA / 260 W 560 VA / 520 W
Phisical Dimensions (W x H x D)
Weight 7 kg 8,5 kg 8,5 kg 8,5 kg 9,5 kg
Environmental Working Conditions
Cooling
Frequency programmability
Frequency stability
Pre-emphasis mode
Spurious & harmonic suppression
Asynchronous AM S/N ratio ≥ 65 dB (typical 70) ≥ 60 dB (typical 65)
Synchronous AM S/N ratio ≥ 50 dB (typical 60) ≥ 50 dB (typical 55)
MONO OPERATION
S/N FM Ratio
Frequency Response
Total Harmonic Distortion
Intermodulation distortion
MPX OPERATION
Composite S/N FM Ratio
Frequency Response
Total Harmonic Distortion
Intermodulation distortion
INTERNAL STEREO CODER
OPERATION
Stereo S/N FM Ratio
Frequency Response
Total Harmonic Distortion
Intermodulation distortion
Stereo separation
AUDIO INPUT CONNECTORS
Left / Right
MPX unbalanced/RDS
SCA/RDS
OTHER CONNECTORS
RF Output
RF Monitor
Pilot output
Interlock Input
STANDARD COMPLIANCE
Safety
EMC
Radio
FCC -CCIR - OIRT - JPN
0/50 (CCIR) μS, 75 (FCC) μS
<75 dBc (80 typical)
Mono, Stereo, Multiplex
F3E
483 x 88 x 394 mm
115 / 230 ±15% or 28 Vdc
≥ 60 dB (typical 68)
EN 301 489-1 V1.4.1 (2002-08)
EN 301 489-11 V1.2.1 (2002-11)
EN 302 018-2 V1.2.1 (2005-06)
-10 ÷ +50 °C / 95% relative Humidity non condensing
Forced, with internal fan
From software, with 10 kHz steps
±1 ppm
EN 60215:1989
EN60215/A1:1992-07
EN60215/A2:1994-09
≥ 50 dB (typical 58)
> 80 dB RMS (typical 85 dB)
< ± 0.5 dB 30Hz ÷ 15kHz (typical ± 0.2 dB)
< 0.1 % 30 Hz ÷ 15 kHz (typical 0.07 %)
< 0.02 % with 1 kHz and 1,3 kHz tones
> 80 dB RMS (typical 85 dB)
± 0.2 dB 30Hz ÷ 53kHz / ± 0.5 dB 53kHz ÷ 100 kHz
BNC unbalanced; Impedance: 10 k or 50 ohm; Level: -13 to +13 dBu
2 x BNC unbalanced; Impedance: 10 k; Level: -8 to +13 dBu
N (50 ohm)
< 0.1% 30Hz ÷ 53kHz
< 0.05% with 1 kHz and 1,3 kHz tones
> 75 dB RMS (typical 78dB)
± 0.5 dB 30 Hz ÷ 15 kHz
< 0.05% 30 Hz ÷ 15 kHz
≤ 0.03% with 1 kHz and 1,3 kHz tones
BNC (- 30dBr referred to RF output )
BNC (1Vpp)
BNC
> 50 dB 30 Hz ÷ 15 kHz (typical 55 dB)
XLR balanced; Impedance: 10 k or 600 ohm; Level: -13 to +13 dBu

10 / 32 User Manual
Rev. 1.0 - 29/11/12
TEX30/50/100/150/300LCD
ELETTRONICA
5. Quick guide for installation and use
This section provides a step-by-step description of equipment installation and
congurationprocedure.Followthese procedures closely upon rst power-on
andeachtimeanychangeismadetogeneralconguration,suchaswhenanew
transmission station is added or the equipment is replaced.
Oncethedesiredcongurationhasbeensetup,nomoresettingsarerequired
for normal operation; at each power-up (even after an accidental shutdown),
the equipment defaults to the parameters set during the initial conguration
procedure.
The topics covered in this section are discussed at greater length in the next
sections,withdetailed descriptionsofall hardware andrmwarefeatures and
capabilities. Please see the relevant sections for additional details.
IMPORTANT: When conguring and testing the transmitter in which the equipment
is integrated, be sure to have the Final Test Table supplied with the equipment ready
at hand throughout the whole procedure; the Final Test Table lists all operating
parameters as set and tested at the factory.
5.1 Prepation
5.1.1 Preliminary checks
Unpack the exciter and immediately inspect it for transport damage. Ensure that
all connectors are in perfect condition.
The main fuse can be accessed from the outside on the rear panel. Extract the
fuse carrier with a screwdriver to check its integrity or for replacement, if necessary.
The fuse to be used is this type:
Fusibile principale
TEX30LCD
@ 90÷260 Vac (1x) 3.15A tipo 5x20
TEX50/100/150LCD
@ 230 Vac/115 Vac (1x) 6.3A tipo 5x20
TEX300LCD
@ 230 Vac/115 Vac (1x) 8A tipo 5x20
Table 5.1: Fuses
Provide for the following (applicable to operating tests and putting into service):
√ Single-phase 230 VAC or 115 VAC (-15% / +10%) mains power supply for
TEX50/100/150LCD, or 80÷260 VAC full-range mains power supply for TEX30/
300LCD, with adequate earth connection.

TEX30/50/100/150/300LCD
ELETTRONICA
11 / 32
User Manual
Rev. 1.0 - 29/11/12
√ For operating tests only: dummy load with 50 Ohm impedance and adequate
capacity (30W for TEX30LCD,50W for TEX50LCD,100W for TEX100LCD,
150W for TEX150LCD or 300W for TEX300LCD as a minimum).
√ Connection cable kit including:
• Mains power cable
• Coaxial cable with BNC connectors for interlock signal connection
• RF cable for output to load / antenna (50 Ohm coaxial cable with N-type
connector)
• Audio cables between transmitter and audio sources.
5.1.2 Connections
Connect the RF output of the transmitter to the antenna cable or a dummy load
capableofdissipatingamplieroutputpower.Tobeginwith,setexcitertominimum
output power and switch it off.
Connect the transmitter INTERLOCK IN input to the matching INTERLOCK OUT
outputttedonR.V.R.Elettronicaequipmenttoactashybridcouplers.Ifyour
equipment is a different brand, identify an equivalent output.
Figure 5.2: connections with amplier
WARNING:Electricshockhazard! Never handletheRFoutputconnector
whentheequipmentispoweredonandnoloadisconnected.Injuryordeath
may result.
Ensure that the POWER switch on the front panel of TEX30/50/100/150/300LCD
is set to “OFF”.

12 / 32 User Manual
Rev. 1.0 - 29/11/12
TEX30/50/100/150/300LCD
ELETTRONICA
The exciter has two switches: one is embedded in VDE socket for mains power
cord and interrupts all mains power supply of the machine, while the second is on
the front panel and acts by inhibiting the switching power supply of the machine.
Connect the mains power cable to the MAINS connector on the rear panel.
Note: the mains must be equipped with adequate earth connection properly
connected to the equipment. This is a pre-requisite for ensuring operator safety
and correct operation.
Connect the audio and RDS/SCA signals from user’s sources to the transmitter
input connectors.
 5.2 Firstpower-onandsetup
Seguire le istruzioni riportate di seguito nel caso di prima accensione o dopo aver
effettuatouncambiamentoallacongurazione dell’eccitatorenel qualequesto
componente è integrato.
Note : Standard factory settings are RF output power off (Pwr OFF) and regulated
output power set to upper limit (unless otherwise specied by customer).
5.2.1 Power-on
When you have performed all of the connections described in the previous
paragraph, power on the exciter using the suitable power switch on the front
panel.
5.2.2 Power check
Ensure that the ONLEDturnson.Equipmentnameshouldappearbrieyonthe
display, followed by forward power and modulation readings. If the RF output is
disabled, those readings will be zero.
When the PLL locks to operating frequency, the LOCK LED will turn on.
5.2.3 How to enable the RF output
Check output power level and set it to maximum level (unless it has already been
set) from the Power Setup menu that you will have accessed by pressing the
following sequence of key: ESC (opens Default Menu) ⇒ENTER (hold down for
2 seconds) ⇒SET ⇒usekeystosetbartoupperlimit(gure5.2-menu2).
Check the state of the Pwroutput power by the Fnc menu. If it is set to OFF, press
ENTER to bring the selection toON.

TEX30/50/100/150/300LCD
ELETTRONICA
13 / 32
User Manual
Rev. 1.0 - 29/11/12
5.2.4 Controllo del livello di potenza di uscita
Note: The exciter incorporates Automatic Gain Control (AGC) and output power is
modulated based on the power level set by the user and actual operating conditions,
such as temperature, reected power and other parameters. Please read section
5.3 for more details of RF power modulation.
Access the PowerSetupMenu pressing the following keys in the order:
ESC (opens DefaultMenu) ⇒ENTER (hold down for 2 seconds)
Use the keys and in the SET menu to set exciter output power; the setting bar
at the side of SET provides a graphic indication of power setting; please consider
that the forward power readout provided on the display (FWD:xxxxW)reects
actual output power reading, whichmaybelowerthanregulatedpowersupply
whenAutomaticGainControlisrunninginpowersupplylimitationmode
(please read section 5.3 about RF power supply modulation for more details).
Note: Output power may be set using the PwrOFF control. In this condition, the
output power readout (Fwd) on the display will read 0 (zero); the SET bar will reect
any adjustments you make using the keys and provides a graphic indication of how
much power supply will be delivered the moment you return to PwrOn state.
5.2.5 Changing the Power Good alarm threshold
Change Forward Power Good alarm setting PgD from the Fnc menu as desired
(factory setting is 50%).
5.2.6 Setting equipment I2C address
Change the IIC address in the MIX (Miscellaneous) menu as desired (factory
setting is 01).
5.2.7 Adjustments and calibration
The only manual adjustments are the level adjustments and the audio mode
adjustment.
Therearpanelholdsthetrimmersforallexciterinputs.Trimmeridenticationis
printed on the rear panel. Input sensitivity can be set within the limits set out in
the tables below through the trimmers:

14 / 32 User Manual
Rev. 1.0 - 29/11/12
TEX30/50/100/150/300LCD
ELETTRONICA
Input sensitivity:
Input Figure 6.2 Trimmer Sensitivity Notes
SCA1/
RDS [13] [16] - 8 ÷ +13 dBu
SCA2 [28] [29] - 8 ÷ +13 dBu
Input level for 7,5 kHz overall deviation
(- 20 dB)
MPX [14] [15] -13 ÷ +13 dBu
Left/
Mono [31] [30] -13 ÷ +13 dBu
Right [18] [17] -13 ÷ +13 dBu
Input level for 75 kHz overall deviation
(0 dB)
When setting input sensitivity, please consider that the default menu reports
instantaneous modulation level and an indicator provides a 75 kHz reading. To
ensure correct adjustment, apply a signal with the same level as user’s audio
broadcast maximum level and then adjust using the trimmer until instantaneous
deviation matches the 75 kHz reading.
To set subcarrier input levels, you may use the same procedure and option “x10”
available in the Fnc menu. With this option, modulation level is multiplied by a factor
of10,whichmeansthatdefaultmenubarmeterreectsa7.5kHzdeviation.
A special menu with separate indications of Left and Right channel levels and
relating indicators of nominal levels for maximum deviation (75 kHz) is provided.
• Preemphasis:
ON
1
2
3
4
50 ms
ON
1
2
3
4
75 ms
• L and R (XLR type) input impedance:
Switch 1: R XLR input impedance, ON = 600 W, OFF = 10 kW
Switch 2: L XLR input impedance, ON = 600 W, OFF = 10 kW
• MPX input operation mode/impedance:
Switch 1: Mode of operation ON = Mono, OFF = Stereo
Switch 2: MPX input impedance, ON = 50 W, OFF = 10 kW
 5.3 Operation
NOTE: For better clarity, only the typical screens of TEX300LCD are reported
below. TEX30/50/100/150LCD screens look the same except that full scale
values are different.
1) Power on the exciter and ensure that the ON light turns on. Equipment name
should appear briey on the display, quickly followed by modulation and
forward power readings (Menu 1), provided that the exciter is delivering output
power.
ON
1 2
ON
1 2

TEX30/50/100/150/300LCD
ELETTRONICA
15 / 32
User Manual
Rev. 1.0 - 29/11/12
Menu 1
1b) To modifypowerlevelsetting, hold down the ENTER button until opening
the powersetupmenu.
The edit screen will look like this:
Menu 2
Next to SET indication, a bar provides a graphic display of preset output power.
Thelledportionofthebarisproportionaltosetpowerlevel.
Example
100% potenza di uscita Barra piena
≅300W in uscita
(mod.TEX300LCD)
≅150W in uscita
(mod.TEX150LCD)
≅100W in uscita
(mod.TEX100LCD)
≅50W in uscita
(mod.TEX50LCD)
≅30W in uscita
(mod.TEX30LCD)
25% potenza di uscita 1/4 della barra
≅75W in uscita
(mod.TEX300LCD)
≅700W in uscita
(mod.TEX702LCD)
≅37,5W in uscita
(mod.TEX150LCD)
≅25W in uscita
(mod.TEX100LCD)
≅12,5W in uscita
(mod.TEX50LCD)
≅7,5W in uscita
(mod.TEX30LCD)
The bottom line provides instantaneous power reading (300W for TEX300LCD
shown here), press button to increase level, press to decrease it. When
you have achieved the desired level, press ENTERtoconrmandexitthedefault
menu. Please note that the setting is stored automatically; in other words, if you
press ESC or do not press any keys before the preset time times out, the latest
power level set will be retained.

16 / 32 User Manual
Rev. 1.0 - 29/11/12
TEX30/50/100/150/300LCD
ELETTRONICA
NOTE: This feature prevents the equipment from delivering maximum power
as soon as output is enabled from menu 4, or in the event the equipment is
already set to ON when you energise it.
2) Ensure that the equipment is not in a locked-out state. Press ESC to call up
the selection screen (menu 3). Highlight Fnc and press ENTERtoconrmand
access the selected menu (menu 4).
If PWR is set to OFF, i.e. power output is disabled, move cursor to PWR. Press
ENTER and label will switch to ON, i.e. power output is enabled.
Press ESC twice to go back to the default menu (menu 1).
3) Fine tune power setting from menu 2 (see description of item 1b) until achieving
the desired value.
WARNING: Equipment is capable of delivering more than rated output power
(30/50/100/150/300 W for TEX30/50/100/150/300LCD respectively); however,
neverexceedthespeciedpowerrating.
NOTE: If power is set to 0 W in the PowerSetupMenu, the INTERLOCK OUT
contact is activated and any external appliances connected to it are immediately
inhibited.
Next, you can review all operating parameters of the equipment through the
managementrmware.
Normally, the equipment can run unattended. Any alarm condition is handled
automatically by the safety system or is signalled by the LED indicators on the
panel or by display messages.
NOTE: Standard factory settings are output power set to upper limit (unless
otherwisespeciedbycustomer)andOFF.
 5.4 ManagementFirmware
The equipment features an LCD with two lines by 16 characters that displays a
setofmenus.Thegurebelowprovidesanoverviewofequipmentmenus.
The symbols listed below appear in the left portion of the display as appropriate:
(Cursor) - Highlights selected (i.e. accessible) menu.
(Filled arrow) - Editable parameter marker. This symbol appears in menus that
take up more than two lines to aid browsing.
(Three empty arrows) - Parameter is being edited.
(Empty arrow) - Current line marker; the parameter in this line cannot be
edited. This symbol appears in menus that take up more than two lines to aid
browsing.
