Racelogic VBSS100SL User manual

Speed Sensor Dual Antenna
(VBSS100SL)
19/11/2014
The Speed Sensor Dual Antenna (VBSS100SL) is a
100Hz GPS/GLONASS system, which combines high
level accuracy and test repeatability with the ability
to measure slip and pitch/roll angles at 100Hz.
Data is present on multiple outputs such as CAN,
RS232, Analogue and Digital lines.
The VBSS100SL can be used for non-contact sensing
of velocity providing signal output data on CAN,
analogue and digital, allowing easy integration with
data loggers and testing applications. The analogue
output can be assigned to vehicle speed, lateral
acceleration, longitudinal acceleration, or lap
beacon marker with user selectable scaling. The
digital output can be configured as either a digital
speed pulse output or a lap beacon marker.
With only 13cm in length , the 100Hz speed sensor is easy to mount and transport, making it ideal for automotive
testing, motorsport, marine, and telematics.
The VBSS100SL comes with a VBOX Manager, which enables the user to setup the dual antenna separation, change
the dynamic modes, level and align the antennas.
Features
High Performance GPS and GLONASS receiver: 100Hz
CAN Bus Output includes: Speed, Heading, True Heading, Slip Angle, Pitch or Roll Angle, Slip Translations,
Brake Stop Distance, Radius of Turn, Gyro Yaw Rate.
RS232 Serial Output of NMEA, position velocity and time
User Configurable Analogue + Digital Outputs
Virtual Lap Beacon Output
Compatible with DGPS BaseStation
Rugged Deutsch ASDD Autosport
connector
High quality aluminium enclosure
IP66 rated: water + dustproof
Wide 6.5V –30V operating range and
low current consumption
Low current consumption
Outputs

Speed Sensor Dual Antenna
(VBSS100SL)
19/11/2014
GPS Specifications
Velocity
Distance
Accuracy
0.1 Km/h (averaged
over 4 samples)
Accuracy
0.05% (<50cm per Km)
Units
Km/h or Mph
Units
Metres / Feet
Update rate
100 Hz
Update rate
100Hz
Maximum velocity
1000 Mph
Resolution
1cm
Minimum velocity
0.1 Km/h
Height accuracy
6 Metres 95% CEP1
Resolution
0.01 Km/h
Height accuracy with DGPS
2 Metres 95% CEP1
Latency
8.5 ms ±1 or 15.5 ms*
Absolute Positioning
Time
Accuracy
3m 95% CEP2
Resolution
0.01 s
Accuracy with SBAS DGPS
<1.8m 95% CEP1
Accuracy
0.01 s
Accuracy with BaseStation
RTCM DGPS
40cm 95% CEP1
Update rate
100 Hz
Resolution
1.8 cm
Heading
Acceleration
Resolution
0.01°
Accuracy
0.50%
Accuracy
0.1°
Maximum
20 G
Resolution
0.01 G
Update rate
100
* With fixed CAN latency
Brake Stop Accuracy (Trigger Activated)
Accuracy
±1.8 cm2
Slip Angle Accuracies
Pitch/Roll Angle accuracies
<0.2° rms at 0.5m antenna separation
<0.1° rms at 1.0m antenna separation
<0.05° rms at 2m antenna separation
<0.04° rms at 2.5m antenna separation
<0.14° rms at 0.5m antenna separation
<0.07° rms at 1.0m antenna separation
<0.035° rms at 2m antenna separation
<0.028° rms at 2.5m antenna separation
Definitions
1 Circle of Error Probable: 95% of the time the position readings will fall within a circle of the stated radius.
2 Based on <50m brake stop distance.

Speed Sensor Dual Antenna
(VBSS100SL)
19/11/2014
Outputs
CAN Bus
Output Data Rate
125Kbit, 250Kbit, 500Kbit & 1Mbit selectable baud rate. Software controlled CAN
termination.
Data available
Position, vehicle speed, heading, lateral acceleration, longitudinal acceleration, satellite
count, time, radius of turn, altitude, Distance from Trigger, Trigger Time, Trigger
Velocity, True Heading. Slip angle, Yaw rate, Pitch/Roll angle, Longitudinal and Lateral
Velocity
RS232
Output Data Rate
Up to 100Hz
Data Available
NMEA or RL Serial
Analogue Output
Output Data Rate
0 to 5v DC
Data Available
Either Speed, Lateral Acceleration, Longitudinal Acceleration, or Lap Beacon
Digital Output
Output Data Rate
Low = 0v, High = 5v, Max. frequency 4.4Khz
Data Available
Speed or Lap Beacon
Inputs
Power
Input Voltage range
1st Gen = 6.5v –30v DC / 2nd Gen = 7v –30v DC
Power
3.7w Max
GPS Antenna
5V Active Antenna (inc)
Digital Input
Cold Start Activate / Set Lap beacon Position
LED
Power, Satellite Count, Event Out
Environmental and physical
Environmental and physical
Weight
Approx 250g
Operating temperature
-30˚C to +70˚C
Size
140mm x 92mm x 31.85mm
Storage temperature
-40°C to +85°C
Connectors
Deutsch ASDD Autosport
Rated IP66

Speed Sensor Dual Antenna
(VBSS100SL)
19/11/2014
Hardware & Software Support
Support
Hardware
One Year Support Contract
Software
Lifetime Support Contract: Valid for a minimum of 5 years from the date of purchase and
limited to the original purchaser. Contract includes: telephone/ email technical support
provided by local VBOX Distributor and firmware/ software upgrades (where applicable).
Package Contents
Description
Product Code
1x Speed Sensor Unit
VBSS100SL
2x GPS L1 +GLONASS L1 Antenna
RLACS156
1x VBOX Manager
VBFMAN
1x VBOX Manager Manual
VBFMANMAN
1x 5way Lemo to 5way Lemo cable –CAN only (2m)
RLCAB005-C
1x VBOX Speed Sensor User Manual
VBSSMAN
1x VBOX Speed Sensor Software CD
CDVBSS
1x VBOX Tape Measure
RLACS091
1x Carry Case
RLACS106
Supplied separately
VBOX Speed Sensor Interface Cable with 5 way Lemo socket for CAN Communication
RLCAB093-C
Required equipment for Slip and Pitch measurements
VBSS100SL
Connecting Loom (RLCAB093-C)
VBOX File Manager + Lemo to Lemo cable (RLCAB005-C)
2 x GPS & GLONASS antenna (RLACS156)
Tape measure
