User Guide
DiNET DAN-RX2
2-Channel Dante Network Receiver
Radial Engineering Ltd.
1588 Kebet Way, Port Coquitlam
British Columbia, Canada, V3C 5M5
Tel: [phone] • Fax: [phone]
Email: [email protected]

Table of Contents Page
Overview.......................................................................................1
Features ................................................................................... 2-3
Getting Started .............................................................................4
Making Connections.....................................................................5
The Headphone Amplier.............................................................6
Specications ...............................................................................7
Warranty .......................................................................Back cover
Thank you for purchasing the Radial DiNET DAN-RX2. The
DAN-RX2 is a high-resolution digital-to-analog converter that
is designed to connect to a Dante or AES67-enabled Ethernet
network — seamlessly transferring the audio stream to a pair
of balanced audio outputs to feed a PA, recording device or
broadcast mixing console.
This manual covers the setup and operation of the DAN-RX2
in various applications. Please take a few minutes to read
through and familiarize yourself with the DAN-RX2 features and
functions. If you have any questions that are not covered in this
manual, please consult the FAQ section on our website. This is
where we post the latest updates. If you still do not nd what you
are looking for, feel free to send us an email at info@radialeng.
com and we will do our best to reply in short order.
Radial®DAN-RX2 User Guide

True to the Music
®
Radial Engineering Ltd. DAN-RX2
1
OVERVIEW
The Radial DiNET DAN-RX2 is a professional grade digital-to-analog
audio converter designed specically for use with Dante or AES67-
enabled networks. It allows you to create a stereo audio endpoint at
any location within a Dante network, featuring an Ethernet connector to
receive the digital signal, and balanced analog outputs to feed mixing
consoles, power ampliers, or self-powered speakers.
High quality 24bit/96kHz converters provide pristine audio and ensure
that the digital source content is reproduced as faithfully as possible, and
a rugged 14-gauge steel chassis features a locking etherCON connector
carrier that protects the Ethernet connectors from damage. The DAN-
RX2 also features a built-in headphone amplier with an adjustable level
control, allowing you to easily check the audio signals or feed a monitor
mix to any destination.
The DAN-RX2 is easy to use, with no setup required on the device
itself. It is completely congured by Dante Controller, which manages
digital audio routing across the Dante network. Dante Controller is a
software application by Audinate™ that allows the user to manage all
Dante-enabled devices across a network. Use Dante Controller to route
audio to the DAN-RX2 and all other components on the network. Simply
connect the DAN-RX2 to the network and it will automatically appear as
an available output device within Dante Controller.
The DAN-RX2 will initially have the name “DiNET-RX2-xxxxxx”, where
the last 6 digits will be the unique media access control address (MAC
address) of your DAN-RX2. As this can be changed to a user-generated
name using Dante Controller, we recommend writing down the MAC
address of your unit in the space provided below for future reference.
Record your DAN-RX2 MAC address here:
DiNET-RX2-__________________
Dante Controller can be downloaded for free at www.audinate.com. For
the latest rmware for the DAN-RX2 please visit www.radialeng.com.
Dante Network
Cat 5e / Cat6

Radial Engineering Ltd. DAN-RX2
True to the Music
®
2
FEATURES
1 72 3 4 5 6
1. HEADPHONE OUTPUTS:3.5mm and 1/4” TRS headphone
outputs work with earbuds and headphones.
2. HEADPHONE LEVEL: Sets the output level of the headphone
amplier.
3. HEADPHONES ON: Activates the headphone amplier.
4. SYNC LEDS: Red LED illuminates when the unit is powered.
Green LED will illuminate once connected to an Ethernet network.
Flashing green LED indicates that the DAN-RX2 is in master clock
mode, solid green LED indicates that it is in slave mode.
5. SYS LEDS: Red LED illuminates when power is rst applied.
Switches to green LED once Dante processor becomes active.
6. +15V LED: Illuminates when the DAN-RX2 is receiving power via
the included DC power adapter.
7. POE LED: Illuminates when the DAN-RX2 is receiving Power over
Ethernet (PoE).

True to the Music
®
Radial Engineering Ltd. DAN-RX2
3
8 10 11 12 13 14
9
8. POWER: 15VDC connection for use with included Radial power
adapter.
9. CABLE CLAMP: Used to secure the power supply cable to prevent
accidental disconnection.
10. ETHERNET PORT: Connects to the Dante network via standard
CAT5e or CAT6 Ethernet cable. This port delivers the digital audio
signal from the network and powers the DAN-RX2 when Power over
Ethernet (PoE) is available.
11. ETHERCON COMPATIBLE CONNECTION: Locking connector
prevents accidental disconnection and damage to RJ45 connectors
when used with Neutrik etherCON cable connector carriers.
12. LEFT AND RIGHT XLR OUT: Balanced analog audio outputs.
Output level is controlled by the audio playback source.
13. GROUND LIFT: Lifts pin-1 on both XLR outputs to eliminate hum
and buzz from ground loops.
14. NON SLIP PAD: Provides electrical & mechanical isolation and
keeps the unit from sliding around.

Radial Engineering Ltd. DAN-RX2
True to the Music
®
4
Dante Network
GETTING STARTED
Before making any connections, always ensure your ampliers or
speakers are either turned down or turned o󰀨 in order to protect sensitive
components from damage due to loud transients that can occur when
plugging in or turning on various components.
POWERING THE DAN-RX2
PoE
Power for the DAN-RX2 can be provided
via Power over Ethernet (PoE) from a PoE-
capable network switch or a separate PoE
injector. Once power is available, the side
panel PoE LED indicator will illuminate and
the DAN-RX2 will be ready to use.
Power Supply
The included 15VDC power supply is provided
for use when PoE is not available. Once you
have connected the DAN-RX2 to the Ethernet
switch, plug in the power supply. The +15VDC
LED will illuminate and the DAN-RX2 will be
ready to use.
ETHERNET CONNECTION
The DAN-RX2 connects to an Ethernet switch using a standard CAT5e
or CAT6 cable. Once the Ethernet switch is connected to a computer
running the Dante Controller software, the DAN-RX2 will appear as an
available receive device.
As a backup option, the DAN-RX2 is designed to be able to have both
PoE and the 15VDC adaptor connected at the same time. If one fails, the
other will maintain power without interruption.

True to the Music
®
Radial Engineering Ltd. DAN-RX2
5
MAKING CONNECTIONS
Connect two standard balanced XLR cables from Output-1 and Output-2
to the inputs of your PA or recording system. These XLR outputs are
balanced to drive long cable runs up to 100 meters (300’) without noise,
and are suitable for connecting the DAN-RX2 to professional mixing
consoles, preamps and power ampliers. The signal level at these
outputs is controlled by the audio playback source.
IMPORTANT NOTE: The DAN-RX2 does not require phantom
power to operate. The DAN-RX2 is equipped with blocking capacitors
to prevent damage from DC voltage, but for best results please
ensure that the phantom power is switched o󰀨 when connecting to the
microphone input of a mixer.
Left
Right
Audio connections for PA system and recording systems use
balanced XLR cables up to 100 meters (300’) without noise.
MOUNTING THE DAN-RX2 IN A RACK
The DAN-RX2 can be mounted in standard 19” equipment racks using
the optional SA Series Rack Adaptor kit (Part # R800 9422). This 1 RU
adaptor allows you to mount one or two DAN-RX2 receivers in a single
rack space.

Radial Engineering Ltd. DAN-RX2
True to the Music
®
6
USING THE HEADPHONE AMPLIFIER
The DAN-RX2 is equipped with a dedicated stereo headphone amplier.
Headphone outputs are available over 3.5mm and 1/4” TRS connectors
for both earbuds and headphones. The headphone outputs are active
only when the ON switch is engaged on the front of the DAN-RX2: this
switch and the level control will only a󰀨ect the headphone outputs, as the
XLR outputs will always be active with their level controlled by the audio
playback source.
Always ensure the volume control is set to its lowest point (fully counter-
clockwise) when plugging in headphones, and slowly increase the level
to a satisfactory level. If no signal is present, ensure that audio is routed
to the unit via the Dante Controller software.
Headphone Safety Warning
Caution: Very Loud Amplier
As with all products capable of producing high sound pressure levels (SPL), users
must be very careful to avoid the hearing damage that may occur from prolonged
exposure. This is particularly important when applied to headphones, as prolonged
listening at high SPL’s will eventually cause tinnitus and can lead to partial or complete
loss of hearing. Please be aware of the recommended exposure limits within your
jurisdiction and follow them closely. The user agrees that Radial Engineering Ltd is
not liable for any health e󰀨ects resulting from the use of this product and the user
clearly understands that he or she is entirely responsible for the safe and proper use
of this product. Please consult the Radial Limited Warranty for further details.

True to the Music
®
Radial Engineering Ltd. DAN-RX2
7
SPECIFICATIONS*
* Subject to change without notice.
Note: This device has been tested and found to comply with the limits
for a Class A digital device, according to Part 15 of the FCC Rules and
EN55022. These limits are designed to provide reasonable protection
against harmful interference when the device is operated in a commercial environ-
ment. This device generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the user manual, may cause harmful
interference to radio communications. Operation of this device in a residential area
is likely to cause harmful interference, in which case the user will be required to
correct the interference at their own expense.
Audio Circuit Type: ............................................High current balanced active output device
Number of Channels:.........................................2
Sample Rate:.....................................................44.1kHz, 48kHz, 88.2kHz, and 96kHz
Bit Depth:...........................................................24 bit
Frequency Response: .......................................20Hz-20kHz
Idle Channel Noise: ...........................................-108dB
Dynamic Range:................................................>100dB
Channel Separation:..........................................>75dB
Gain:..................................................................+18dBu max @ 0dBFS
Total Harmonic Distortion + Noise: ....................0.007% @ -6dBFS
Output Impedance:............................................150Ω
Power Consumption: .........................................1.25W
Features
Input Connections:.............................................RJ45 Ethernet with locking etherCON
Output Connectors: ...........................................2x XLR male, 1x 3.5mm & 2x 1/4” headphone out
LED Indicators:..................................................SYNC, SYS, +15V, and PoE
Extras: ...............................................................Headphone amplier with level control
General
Power: ...............................................................15VDC 400mA (included) or PoE
Power over Ethernet (PoE):...............................Class 1 IEEE 802.3af
FCC Approval: ...................................................Meets FCC Part 15B Class A
Construction: .....................................................14-gauge steel
Finish:................................................................Durable powder coat
Size (L x W x D):................................................4.5” x 2” x 6” (121 x 6 x 147mm)
Warranty: ...........................................................Radial 3-year, transferable

®
www.radialeng.com
THREE YEAR TRANSFERABLE LIMITED WARRANTY
RADIAL ENGINEERING LTD. (“Radial”) warrants this product to be free from defects in
material and workmanship and will remedy any such defects free of charge according
to the terms of this warranty. Radial will repair or replace (at its option) any defective
component(s) of this product (excluding nish and wear and tear on components under
normal use) for a period of three (3) years from the original date of purchase. In the event
that a particular product is no longer available, Radial reserves the right to replace the
product with a similar product of equal or greater value. In the unlikely event that a defect
is uncovered, please call 604-942-1001 or email [email protected] to obtain an
RA number (Return Authorization number) before the 3 year warranty period expires.
The product must be returned prepaid in the original shipping container (or equivalent)
to Radial or to an authorized Radial repair centre and you must assume the risk of loss
or damage. A copy of the original invoice showing date of purchase and the dealer name
must accompany any request for work to be performed under this limited and transferable
warranty. This warranty shall not apply if the product has been damaged due to abuse,
misuse, misapplication, accident or as a result of service or modication by any other than
an authorized Radial repair center.
THERE ARE NO EXPRESSED WARRANTIES OTHER THAN THOSE ON THE FACE
HEREOF AND DESCRIBED ABOVE. NO WARRANTIES WHETHER EXPRESSED
OR IMPLIED, INCLUDING BUT NOT LIMITED TO, ANY IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE SHALL EXTEND
BEYOND THE RESPECTIVE WARRANTY PERIOD DESCRIBED ABOVE OF THREE
YEARS. RADIAL SHALL NOT BE RESPONSIBLE OR LIABLE FOR ANY SPECIAL,
INCIDENTAL OR CONSEQUENTIAL DAMAGES OR LOSS ARISING FROM THE USE
OF THIS PRODUCT. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND
YOU MAY ALSO HAVE OTHER RIGHTS, WHICH MAY VARY DEPENDING ON WHERE
YOU LIVE AND WHERE THE PRODUCT WAS PURCHASED.
Radial®DAN-RX2 User Guide - Part #: R870 1046 00 / 11-2018
Copyright 2018 Radial Engineering Ltd. All rights reserved.
Specications and appearance subject to change without notice.
Radial Engineering Ltd.
1588 Kebet Way, Port Coquitlam, British Columbia, V3C 5M5
Tel: [phone] • Fax: [phone] • Email: [email protected]
To meet the requirements of California Proposition 65, it is our responsibility to inform you of the following:
WARNING: This product contains chemicals known to the State of California to cause
cancer, birth defects or other reproductive harm.
Please take proper care when handling and consult local government regulations before discarding.
