Radio Shack 273-1675 User manual

©2000 RadioShack Corporation.
All Rights Reserved.
RadioShack and RadioShack.com are trademarks used by RadioShack Corporation.
OWNER’S MANUAL — Please read before using this equipment.
Universal AC/DC Power Adapter
Your RadioShack Universal AC/DC Power Adapter can be used to
power electrical devices which require DC output from 3V to 12V in
countries all over the world,with AC power input ranging from 90V to
240V. The adapter features overload and short circuit protection to
protect it from damage.
You connect a device to the adapter’s multivoltage (3/4.5/6/7.5/9V/
12V DC) output jack using an Adaptaplugadapter of the appropri-
ate size, or to the adapter’s 12V DC cigarette-lighter socket. The
purchase of this adapter entitles you to one free Adaptaplug of your
choice from your local RadioShack store.
Caution: Do not connect devices to both outputs at the same time.
The supplied travel kit includes plug adapters that allow you to use
the Universal AC/DC Power Adapter in continental Europe, Austra-
lia, and the United Kingdom, plus a handy carrying pouch. Plug
adapters for other countries are available at your local RadioShack
store.
OPERATION
Caution: Do not use the adapter to power a device that exceeds the
25W maximum power rating.
1. If necessary, disconnect the adapter from AC power.
2. Use a flat-bladed screwdriver to turn the VOLT 3/4.5/6/7.5/9/12
switch to the desired output voltage.
Caution: Do not change the VOLT 3/4.5/6/7.5/9/12 setting
while the adapter is connected to AC power.
3. For devices which require 3, 4.5, 6, 7.5, 9, or 12V DC power,
connect an appropriate Adaptaplug to the multivoltage output
jack. If the tip on the device’s power jack is positive, align the
positive (+) marking on the Adaptaplug with TIP on the output
jack. If the tip on the device’s power jack is negative, align the
negative (–) marking on the Adaptaplug with TIP. Then insert
the Adaptaplug into the device’s power jack.
For devices with a cigarette-lighter plug which require 12V DC
power, insert the device’s cigarette-lighter plug into the
adapter’s cigarette-lighter socket.
Caution: Do not use the multivoltage output jack and the ciga-
rette-lighter socket at the same time.
Note: If VOLT 3/4.5/6/7.5/9/12 is set to any voltage other than
12, there is no output from the cigarette-lighter socket.
4. Connect a plug adapter that fits the AC outlets in the country
where you are using the device to the adapter’s foldable AC
plug. Then insert the plug adapter into an AC outlet. The
adapter’s indicator lights.
Notes:
• You can use the foldable plug without a plug adapter in the
United States.
• If the green indicator flashes or turns off when the product is in
use, it indicates that the output current is beyond the specifica-
tion and the overload/short circuit protection has been acti-
vated. Disconnect the adapter from AC power, then unplug the
adapter from the device. Reconnect the adapter first to the
device, then to AC power. If the indicator still flashes or does not
light, take the adapter to your local RadioShack store for assis-
tance.
CARE AND MAINTENANCE
To enjoy your adapter for a long time:
• Keep the adapter dry. If it gets wet, wipe it dry immediately.
• Use and store the adapter only in normal temperature environ-
ments.
• Handle the adapter gently and carefully. Do not drop it.
• Keep the adapter away from dust and dirt.
• Wipe the adapter with a damp cloth occasionally to keep it look-
ing new.
Modifying or tampering with the adapter’s internal components can
cause a malfunction and might invalidate its warranty. If your adapt-
er is not performing as it should, take it to your local RadioShack
store for assistance.
273-1675 052500.fm Page 1 Wednesday, June 7, 2000 3:13 PM

273-1675
0904-205-01305
06A00
Printed in Hong Kong
RadioShack Corporation
Fort Worth, Texas 76102
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
DANGER: TO REDUCE THE RISK OF FIRE
OR ELECTRIC SHOCK, FOLLOW THESE
INSTRUCTIONS
For connection to a supply not in the U.S.A., use an attachment plug
adapter of the proper configuration for the power outlet.
FCC STATEMENT
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any in-
terference received, including interference that may cause undes-
ired operation.
Warning: Changes or modifications to this unit not expressly ap-
proved by RadioShack may cause interference and void the user’s
authority to operate the equipment.
Note: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equip-
ment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions may
cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular instal-
lation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equip-
ment off and on, the user is encouraged to try to correct the interfer-
ence by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
Consult your local RadioShack store if the problem still exists.
SPECIFICATIONS
Input Voltage .............................................................. AC 90–240V, 50/60Hz
Cigarette-Lighter Socket .................................................................... DC 12V
Multivoltage Adaptaplug ............................................... DC 3/4.5/6/7.5/9/12V
Total Maximum Output Current ........................................................... DC 2A
Tip Polarity ..................................................................................... Selectable
Operation Temperature ............................................... 32°to 113°F (0–45°C)
Storage Temperature ............................................. –13°to 140°F (–25–60°C)
Dimensions ............................................................... 41/8×23/4×13/8Inches
(105 ×70 ×35 mm)
Cord Length .......................................................................................... 6 feet
(182.88 cm)
Specifications are typical; individual units might vary. Specifications
are subject to change and improvement without notice.
Limited Ninety-Day Warranty
This product is warranted by RadioShack against manufacturing defects in material
and workmanship under normal use for ninety (90) days from the date of purchase
from RadioShack company-owned stores and authorized RadioShack franchisees
and dealers. EXCEPT AS PROVIDED HEREIN, RadioShack MAKES NO EX-
PRESS WARRANTIES AND ANY IMPLIED WARRANTIES, INCLUDING THOSE
OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE
LIMITED IN DURATION TO THE DURATION OF THE WRITTEN LIMITED WAR-
RANTIES CONTAINED HEREIN. EXCEPT AS PROVIDED HEREIN, RadioShack
SHALL HAVE NO LIABILITY OR RESPONSIBILITY TO CUSTOMER OR ANY
OTHER PERSON OR ENTITY WITH RESPECT TO ANY LIABILITY, LOSS OR
DAMAGE CAUSED DIRECTLY OR INDIRECTLY BY USE OR PERFORMANCE
OF THE PRODUCT OR ARISING OUT OF ANY BREACH OF THIS WARRANTY,
INCLUDING, BUT NOT LIMITED TO, ANY DAMAGES RESULTING FROM IN-
CONVENIENCE, LOSS OF TIME, DATA, PROPERTY, REVENUE, OR PROFIT OR
ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES,
EVEN IF RadioShack HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES.
Some states do not allow limitations on how long an implied warranty lasts or the
exclusion or limitation of incidental or consequential damages, so the above limita-
tions or exclusions may not apply to you.
In the event of a product defect during the warranty period, take the product and the
RadioShack sales receipt as proof of purchase date to any RadioShack store. Ra-
dioShack will, at its option, unless otherwise provided by law: (a) correct the defect
by product repair without charge for parts and labor; (b) replace the product with
one of the same or similar design; or (c) refund the purchase price. All replaced
parts and products, and products on which a refund is made, become the property
of RadioShack. New or reconditioned parts and products may be used in the perfor-
mance of warranty service. Repaired or replaced parts and products are warranted
for the remainder of the original warranty period. You will be charged for repair or re-
placement of the product made after the expiration of the warranty period.
This warranty does not cover: (a) damage or failure caused by or attributable to acts
of God, abuse, accident, misuse, improper or abnormal usage, failure to follow in-
structions, improper installation or maintenance, alteration, lightning or other inci-
dence of excess voltage or current; (b) any repairs other than those provided by a
RadioShack Authorized Service Facility; (c) consumables such as fuses or batter-
ies; (d) cosmetic damage; (e) transportation, shipping or insurance costs; or (f)
costs of product removal, installation, set-up service adjustment or reinstallation.
This warranty gives you specific legal rights, and you may also have other rights
which vary from state to state.
RadioShack Customer Relations, 200 Taylor Street, 6th Floor, Fort Worth, TX
76102
We Service What We Sell
12/99
