Radio Shack OPTIMUS 15-1843 User manual

Cat. No. 15-1843
Stereo Indoor FM Antenna
Your Optimus Stereo Indoor FM Antenna is easy to install
and provides excellent reception of FM radio stations in
most listening locations. This antenna receives signals
equally well from any direction, reducing noise and static
and improving stereo quality. You can connect the anten-
na’s 75-ohm connector directly to your FM receiver. The
antenna’s compact, modern styling blends well with the
decor of almost any home.
BEFORE YOU BEGIN
Depending upon your audio system setup, you might also
need additional cables or adapters (available at your local
RadioShack store).
Choosing a Mounting Location
To get the best performance from your antenna, place it
indoors as high as possible. For the best results, make
sure the antenna is away from obstructions such as metal
cabinets or bookshelves. (Higher frequencies are notice-
ably affected by obstructions.) Do not mount the antenna
near any metal surface such as a refrigerator, a metal
door or wall, or a water pipe hidden behind a wall. This
greatly reduces the antenna’s ability to receive signals.
Working with Coaxial Cable
• Do not create very sharp bends or kinks in coaxial
cable. Tight bends can cause shorts and change the
cable’s impedance.
• Do not install coaxial cable where it will have a pulling
tension of greater than 50 pounds, or where it will be
crushed, stuffed, wedged, or pinched.
• Use only round-headed staples. Any clamps or
securing devices used with coaxial cable should grip
the cable evenly about the circumference without
crushing the cable. Flat staples can damage coaxial
cable.
• Do not expose coaxial cable to a temperature greater
than 176°F (80°C). Keep the cable away from heat-
ing vents and water heaters.
CONNECTING THE ANTENNA
75-Ohm Jack
If your FM receiver has a 75-ohm F-type connector, con-
nect the antenna’s 75-ohm coaxial cable directly to the
connector.
Screw-Type Connections
If your FM receiver has screw-type connections, connect
a matching transformer such as Cat. No. 15-1140 (not
supplied) to the antenna’s coaxial cable. Then use a flat-
head screwdriver to connect both of the lugs on the
matching transformer to your FM receiver’s screw termi-
nals.
Pushbutton-Type Connections
Follow these steps if your FM receiver has pushbutton-
type connections.
1. Connect a matching transformer such as Cat. No. 15-
1140 (not supplied) to the antenna’s coaxial cable.
2. Cut both of the metal lugs off of the matching trans-
former.
(illus - show end of
screwed onto 75-ohm
antenna cable being
jack)
(illus - show matching transformer
being screwed onto end of antenna
lugs being screwed into
cable and
screw terminals)
(illus - show lugs being
clipped from wires)
© 1998 Tandy Corporation.
All Rights Reserved.
Optimus and RadioShack are registered trademarks used by Tandy Corporation.

RadioShack
A Division of Tandy Corporation
Fort Worth, Texas 76102
5/98 Printed in China
3. Strip about 1/4 inch of insulation from both wires.
4. For both of the FM receiver’s pushbutton terminals,
press open the terminal’s tab, insert one of the
matching transformer’s bare wires, then release the
terminal.
POSITIONING THE ANTENNA
Follow these steps to find the best placement location.
1. Turn on your FM receiver, then tune it to any station
broadcasting near 98 MHz.
2. Position the antenna as high as possible at the
desired location.
3. Slowly move the antenna until you receive the clear-
est sound, then note the antenna’s location.
4. Tune your FM receiver to any station broadcasting
near 88 MHz. Repeat Step 3 until you receive the
clearest sound, then note the antenna’s location.
5. Tune your FM receiver to any station broadcasting
near 108 MHz. Repeat Step 3 until you receive the
clearest sound, then note the antenna’s location.
6. Using the locations you noted in Steps 2–5 as a
guide, place the antenna at the location that allows
the best reception of all stations.
SPECIFICATIONS
Reception .................................................................. FM
Operating Band .......................................... 88–108 MHz
Polarization Vertical
Reception Direction Omnidirectional
Output Impedance ............................................ 75 Ohms
Dimensions (HWD) ..................... 53/16 ¥ 51/8 ¥ 13/4Inches
(133 ¥ 130 ¥ 45 mm)
Weight .................................................................. 6.2 oz
(2.8 kg)
Specifications are typical; individual units might vary.
Specifications are subject to change and improvement
without notice.
(illus - show bare wires on
matching transformer wires)
(illus - show bare wires being inserted
terminals)into button
