Radio Shack CTR-98 User manual

Cat. No. 14-728
OWNER’S MANUAL
4-Band Portable Radio Cassette Recorder
Please read before using this equipment.
CTR-98
with Multi-Voltage Selection
14-728.fm Page 1 Wednesday, June 30, 1999 5:18 PM

2
FEATURES
© 1995 Tandy Corporation.
All Rights Reserved.
Radio Shack is a registered trademark used by Tandy Corporation.
Your Radio Shack CTR-98 4-Band
Portable Radio Cassette Recorder
with Multi-Voltage Selection is a ver-
satile, easy-to-use music system
with many useful features. You can
enjoy the radio or cassette player’s
high quality sound, record from the
radio, or make a live recording. Lis-
ten to shortwave broadcasts wherev-
er you are in the world.
The CTR-98’s compact design and
carrying handle let you take it almost
anywhere.
Its features include:
Automatic Level Control — automat-
ically adjusts the recording level so
you do not need to adjust the volume.
Automatic Stop — automatically
stops the tape and turns off power
when it reaches the end during play-
back, recording, fast-forward, or re-
wind to conserve power and protect
the motor.
Dual-Source Recording — lets you
record from the radio or use the built-
in microphone to make a live record-
ing.
Soft Cassette Tape Eject — softly
opens the cassette compartment
cover so the cassette does not pop
out.
One-Touch Recording — lets you
start recording quickly and easily.
Earphone Jack — lets you connect
an optional earphone so you can lis-
ten in privacy.
Two Power Sources — let you power
the CTR-98 from internal batteries or
AC power.
Multi-Voltage Selector Switch —lets
you use your CTR-98 virtually any-
where in the world.
Warning: To prevent fire or shock
hazard, do not expose this system to
rain or moisture.
This symbol is intended to
alert you to the presence of
uninsulated dangerous
voltage within the system’s
enclosure that might be of
RISK OF ELEC-
TRIC SHOCK.
DO NOT OPEN.
CAUTION: TO REDUCE THE
RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER OR
BACK. NO USER-SERVICE-
ABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED
PERSONNEL.
CAUTION !
14-728.fm Page 2 Wednesday, June 30, 1999 5:18 PM

3
sufficient magnitude to constitute a risk of electric shock. Do not open
the system’s case.
This symbol is intended to inform you that important operating and
maintenance instructions are included in the literature accompanying
this system.
!
14-728.fm Page 3 Wednesday, June 30, 1999 5:18 PM

4
TABLE OF CONTENTS
Power Sources4
Installing Batteries4
Using AC Power4
Using an Earphone6
Listening Safely6
Traffic Safety6
Radio Operation7
Cassette Player Operation8
Loading a Cassette Tape8
Playing a Cassette Tape8
Recording9
Recording from the Radio9
Making Live Recordings9
Care and Maintenance11
Tape Tips12
Recommended Tapes12
Erasing a Cassette Tape12
Preventing Accidental Era-
sure12 Restoring Tape Tension and
Sound Quality13
Cleaning the Tape-handling
Parts13
The FCC Wants You to Know14
Specifications15
14-728.fm Page 4 Wednesday, June 30, 1999 5:18 PM

5
POWER SOURCES
You can operate the CTR-98 using
internal battery power or the supplied
AC power cord.
INSTALLING BATTERIES
You can power the CTR-98 from four
D batteries (not supplied). For the
best performance, we recommend
alkaline batteries, such as Radio
Shack Cat. No. 23-550.
1. Press the battery compartment
cover’s tabs and pull out the
cover to remove it.
2. Install the batteries as indicated
by the polarity symbols (+ and –)
marked above the compartment.
Cautions:
• Use only fresh batteries of the
required size and type.
• Never mix fresh with old bat-
teries.
3. Replace the cover.
If the CTR-98 does not operate prop-
erly or if the sound weakens or dis-
torts, replace the batteries.
Cautions:
• Always dispose of the old batter-
ies promptly and properly.
• Never leave dead, old, or weak
batteries in the CTR-98. They
can leak chemicals and corrode
or damage electronic circuits.
• If you do not plan to use batter-
ies in the CTR-98 for a month or
more, remove the batteries to
protect the CTR-98 from possi-
ble battery leakage.
USING AC POWER
You can power the CTR-98 from
standard AC power using the sup-
plied AC power cord.
Use a flatblade screwdriver to set
VOLTAGE SELECTOR 120V/OFF/
230V to the correct setting (120V in
North America).
14-728.fm Page 5 Wednesday, June 30, 1999 5:18 PM

6
Insert the AC power cord’s recepta-
cle into the AC IN jack on the back
of the CTR-98, then plug the AC
power cord into a standard AC outlet.
Note: The internal batteries automat-
ically disconnect when you connect
the AC power cord to the CTR-98.
14-728.fm Page 6 Wednesday, June 30, 1999 5:18 PM

7
USING AN EARPHONE
For private listening, you can con-
nect a monaural earphone (not sup-
plied) with a 1/8-inch plug to the
CTR-98. Your local Radio Shack
store carries a wide selection of ear-
phones.
Insert the earphone’s 1/8-inch plug
into the EAR jack on top of the CTR-
98.
Note: Connecting an earphone auto-
matically disconnects the built-in
speaker.
LISTENING SAFELY
To protect your hearing, follow these
guidelines when you use an ear-
phone.
• Set the volume to the lowest set-
ting before you begin listening.
After you begin listening, adjust
the volume to a comfortable
level.
• Do not listen at extremely high
volume levels. Extended high-
volume listening can lead to per-
manent hearing loss.
• Once you set the volume, do not
increase it. Over time, your ears
adapt to the volume level, so a
volume level that does not
cause discomfort might still
damage your hearing.
TRAFFIC SAFETY
Do not wear an earphone while oper-
ating a motor vehicle or riding a bicy-
cle. This can create a traffic hazard
and is illegal in some areas.
Even though some earphones are
designed to let you hear some out-
side sounds when listening at normal
volume levels, they still present a
traffic hazard.
14-728.fm Page 7 Wednesday, June 30, 1999 5:18 PM

8
RADIO OPERATION
Warning: To protect your hearing, set
VOLUME to MIN before you turn on
the radio.
1. Set FUNCTION to RADIO to
turn on the radio.
2. Set BAND to FM, AM, SW1, or
SW2 for the desired band.
Note: Select SW1 or SW2 for
shortwave signals.
3. Adjust VOLUME to the desired
listening level.
4. Adjust TUNING to the desired
station.
Notes:
• The AM antenna is built in.
For the best AM reception,
rotate the CTR-98.
• For the best FM and SW
reception, fully extend the
telescoping antenna and
swivel it to the position that
produces the best reception.
• If you tune to a shortwave sta-
tion, adjust FINE TUNING for
the best reception.
5. Adjust TONE for the desired
bass/treble sound. Turn it
toward LOW to enhance the
bass sound, or toward HIGH to
enhance the treble
6. Set FUNCTION to RADIO OFF/
TAPE to turn off the radio.
14-728.fm Page 8 Wednesday, June 30, 1999 5:18 PM

9
CASSETTE PLAYER OPERATION
LOADING A CASSETTE TAPE
1. Take up any slack in the tape by
turning the cassette’s hub with a
pencil. If you do not remove
excess slack, the tape might
become tangled in the record/
playback mechanism.
2. Press STOP/EJECT to open the
cassette compartment door.
3. Load the cassette with its open
edge facing up, its full reel to the
right, and the side you want to
play facing you.
4. Gently close the compartment
door.
PLAYING A CASSETTE TAPE
Warning: To protect your hearing, set
VOLUME to MIN before you begin
playing a cassette tape.
1. Set FUNCTION to RADIO OFF/
TAPE.
2. Load a cassette tape.
3. Press PLAY. The cassette plays
until it reaches the end of the
side, then the recorder automati-
cally stops it.
Notes:
• Press PAUSE to temporarily
stop playback. Press PAUSE
again to resume playback.
• Press FAST−F or REWIND to
rapidly wind the tape forward
or backward. Press STOP/
EJECT, then PLAY to resume
play.
4. Adjust VOLUME and TONE to
the desired listening levels.
5. Press STOP/EJECT to com-
pletely stop playback before it
automatically stops. Press
STOP/EJECT again to open the
cassette compartment and
remove the cassette tape.
14-728.fm Page 9 Wednesday, June 30, 1999 5:18 PM

10
RECORDING
You can record from the radio, or use
the built-in microphone to make a live
recording.
Notes:
• Before you load a cassette tape
for recording, be sure the erase-
protection tabs are in place on
the cassette tape you are
recording onto (see “Preventing
Accidental Erasure”).
• The CTR-98’s Automatic Level
Control (ALC) automatically
adjusts the recording level. The
VOLUME setting has no effect
on recording.
RECORDING FROM THE RADIO
1. Load a blank cassette tape or
one you want to record over into
the cassette compartment.
2. Set FUNCTION to RADIO.
3. Set BAND to FM, AM, SW1, or
SW2.
4. Adjust TUNING to the station
you want to record.
Note: Adjust FINE TUNING if
you tune to a shortwave station.
5. Press RECORD to begin record-
ing. Both PLAY and RECORD
lock down.
Caution: Do not force down
RECORD. This can damage the
record mechanism.
Note: To temporarily stop
recording, press PAUSE. Press
PAUSE again to resume record-
ing.
6. Press STOP/EJECT to stop
recording.
MAKING LIVE RECORDINGS
Follow these steps to make live re-
cordings using the built-in micro-
phone.
1. Set FUNCTION to RADIO OFF/
TAPE.
2. Load a blank cassette tape or
one you want to record over into
the cassette compartment.
3. Place the CTR-98 2 or 3 feet
from the recording source.
14-728.fm Page 10 Wednesday, June 30, 1999 5:18 PM

11
4. Press RECORD to begin recording. Both PLAY and RECORD lock down.
Caution: Do not force down RECORD. This can damage the record mecha-
nism.
Note: To temporarily stop recording, press PAUSE. Press PAUSE again to
resume recording.
5. Press STOP/EJECT to stop recording.
14-728.fm Page 11 Wednesday, June 30, 1999 5:18 PM

12
CARE AND MAINTENANCE
Your Radio Shack CTR-98 4-Band
Portable Radio Cassette Recorder
with Multi-Voltage Selection is an ex-
ample of superior design and crafts-
manship. The following suggestions
will help you care for your CTR-98 so
you can enjoy it for years.
Keep the CTR-98 dry.
If it gets wet, wipe it
dry immediately. Liq-
uids might contain
minerals that can cor-
rode the electronic cir-
cuits.
Handle the CTR-98
gently and carefully.
Dropping it can dam-
age circuit boards and
cases and can cause
the CTR-98 to work
improperly.
Use and store the
CTR-98 only in nor-
mal temperature envi-
ronments.
Temperature ex-
tremes can shorten
the life of electronic
devices and distort or
melt plastic parts.
Keep the CTR-98
away from dust and
dirt, which can cause
premature wear of
parts.
Wipe the CTR-98 with
a damp cloth occa-
sionally to keep it
looking new. Do not
use harsh chemicals,
cleaning solvents, or
strong detergents to
clean the CTR-98.
Modifying or tampering with the
CTR-98’s internal components can
cause a malfunction and might inval-
idate its warranty and void your FCC
authorization to operate it. If your
CTR-98 is not performing as it
should, take it to your local Radio
Shack store for assistance.
CLEANER
14-728.fm Page 12 Wednesday, June 30, 1999 5:18 PM

13
TAPE TIPS
Recommended Tapes
Tape quality greatly affects the quali-
ty of the recording. We recommend
extended-range or low noise type 1
regular length (60- or 90-minute) nor-
mal-bias cassette tapes. We do not
recommend long-play cassette tapes
such as C-120s because they are
thin and easily tangle.
Erasing a Cassette Tape
To record over a cassette tape, sim-
ply record as usual. The cassette
deck records over the previous re-
cording.
Notes:
• You must set FUNCTION to
RADIO OFF/TAPE and the unit
must be placed in a very quiet
room.
• You can quickly erase both sides
of a cassette tape using a bulk
tape eraser such as Cat. No. 44-
232, available at your local
Radio Shack store.
Preventing Accidental Erasure
Cassette tapes have two erase-pro-
tection tabs — one for each side.
When a tab is in place, you can
record on that side. To prevent
RECORD from being pressed and
protect a recording from being acci-
dentally recorded over or erased, re-
move one or both of the cassette
tape’s erase-protection tabs.
If you later decide to record on a tape
side after you have removed the
erase-protection tab, place a piece of
strong plastic tape over that side’s
erase-protection hole. Be sure you
cover only the hole originally covered
by the erase-protection tab.
Caution: Removing the erase-protec-
tion tabs does not prevent a bulk
eraser from erasing a cassette tape.
14-728.fm Page 13 Wednesday, June 30, 1999 5:18 PM

14
Restoring Tape Tension and Sound
Quality
After you play a cassette tape sever-
al times, the tape might become
tightly wound on the reels. This can
cause playback sound quality to de-
teriorate.
To restore the sound quality, fast-for-
ward the tape from the beginning to
the end of one side, then completely
rewind it. Then loosen the tape reels
by gently tapping each side of the
cassette’s outer shell on a flat sur-
face.
Caution: Be careful not to damage
the cassette when tapping it. Do not
touch the exposed tape or allow any
sharp objects near the cassette.
Cleaning the Tape-Handling Parts
Dirt, dust, or particles of the tape’s
coating can accumulate on the tape
heads and other parts that the tape
touches. This can greatly reduce the
cassette player’s performance.
To prevent noise and poor high-fre-
quency response, follow these steps
to clean the cassette player’s tape
handling parts after 20 hours of use.
1. Set FUNCTION to RADIO OFF/
TAPE.
2. Remove the batteries and dis-
connect the AC power cord.
3. Open the cassette compartment
cover.
4. Press and hold down the erase-
protection tab sensor, then press
RECORD to expose the record/
playback and erase heads.
5. Use a cotton swab dipped in
tape head cleaning solution or
denatured alcohol to gently
clean the capstan, pinch roller,
and tape head.
Note: Your local Radio Shack store
sells a complete line of cassette
cleaning kits.
14-728.fm Page 14 Wednesday, June 30, 1999 5:18 PM

15
THE FCC WANTS YOU TO KNOW
This equipment complies with the limits for a Class B digital device as specified
in Part 15 of FCC Rules. These limits provide reasonable protection against radio
and TV interference in a residential area. However, your equipment might cause
radio or TV interference even when it is operating properly. To eliminate interfer-
ence, you can try one or more of the following corrective measures:
• Reorient or relocate the radio or TV’s receiving antenna.
• Increase the distance between the CTR-98 and the radio or TV.
• Connect your CTR-98 to an AC outlet that is on a different electrical circuit
from either the radio or TV’s receiver.
Consult your local Radio Shack store if the problem still exists.
14-728.fm Page 15 Wednesday, June 30, 1999 5:18 PM

16
SPECIFICATIONS
RADIO
Frequency RangeFM — 88-108
MHz
AM — 530-1710 kHz
SW1 — 2.3-7.0 MHz
SW2 — 7.0-22.0 MHz
AntennaFM/SW Telescoping
Antenna
AM Ferrite Rod
CASSETTE PLAYER
Track System2 Track Mono Tape
Speed17/8 inches/second
Recording SystemDC Bias, Magnet
Erase
Frequency Response at –3 dB 125-
8,000 Hz
Wow and Flutter 0.3% (WRMS)
GENERAL
Power Requirements 120 Volts AC,
60 Hz
230 Volts AC, 50 Hz
6 Volts DC (4 D Batteries)
Power Consumption 8W
Dimensions 59/16 x 121/4 x 51/8
Inches (HWD)
(130 x 300 x 98 mm)
Weight4 lbs 6.5 oz.
(2 Kg)
Specifications are typical; individual
units might vary. Specifications are
subject to change without notice.
14-728.fm Page 16 Wednesday, June 30, 1999 5:18 PM

RADIO SHACK
A Division of Tandy Corporation
Fort Worth, Texas 76102
6A5 Printed in China
RADIO SHACK LIMITED WARRANTY
This product is warranted against defects for 90 days from date of
purchase from Radio Shack company-owned stores and autho-
rized Radio Shack franchisees and dealers. Within this period,
we will repair it without charge for parts and labor. Simply bring
your Radio Shack sales slip as proof of purchase date to any
Radio Shack store. Warranty does not cover transportation costs.
Nor does it cover a product subjected to misuse or accidental
damage.
EXCEPT AS PROVIDED HEREIN, RADIO SHACK MAKES NO
EXPRESS WARRANTIES AND ANY IMPLIED WARRANTIES
ARE LIMITED IN DURATION TO THE DURATION OF THE
WRITTEN LIMITED WARRANTIES CONTAINED HEREIN.
Some states do not permit limitation or exclusion of implied war-
ranties; therefore, the aforesaid limitation(s) or exclusion(s) may
not apply to the purchaser.
This warranty gives you specific legal rights and you may also
14-728.fm Page 17 Wednesday, June 30, 1999 5:18 PM
