Cat. No. 49-2020
OWNER’S MANUAL
Please read before using this equipment.
Smoke Alarm
Siren Detector
for use with the SAFE HOUSE
Wireless Alarm System
(Cat. No. 49-2010/49-2011)
49-2020.fm Page 1 Wednesday, August 18, 1999 2:57 PM

2
INTRODUCTION
Your Radio Shack Smoke Alarm Si-
ren Detector gives you extra protec-
tion if a smoke alarm is out of
normal hearing range. The detector
listens for the siren from the smoke
alarm. When the detector
hears the
siren, it sends a signal to the base,
which sounds the system’s alarm.
© 1997 Tandy Corporation.
All Rights Reserved.
Radio Shack is a registered trademark
used by Tandy Corporation.
49-2020.fm Page 2 Wednesday, August 18, 1999 2:57 PM

3
Notes:
• The siren detector does not
detect smoke. It only detects the
sound from a smoke alarm.
• We suggest you use a Radio
Shack Cat. No. 49-466 Smoke
Alarm with the siren detector.
Other smoke alarms might not
work properly.
• Be sure you test the siren detec-
tor as described under “Testing”
on Page 12.
49-2020.fm Page 3 Wednesday, August 18, 1999 2:57 PM

4
This device complies with Part 15 of
FCC Rules. Operation is subject to
the following two conditions: (1) the
device may not cause harmful inter-
ference, and (2) the device must
accept any interference received,
including interference that may
cause undesired operation.
49-2020.fm Page 4 Wednesday, August 18, 1999 2:57 PM

5
INSTALLATION
INSTALLING THE
BATTERY
1. Slide off the battery compartment
cover.
2. Connect a 9-volt alkaline battery
(Cat. No. 23-553) to the battery
connector. Then place the bat-
tery in the compartment.
illustration
49-2020.fm Page 5 Wednesday, August 18, 1999 2:57 PM

6
3. Replace the battery compart-
ment cover.
Note: Changing the detector’s bat-
tery sometimes triggers the fire
alarm. If this happens, turn off the
alarm system then turn it on again.
49-2020.fm Page 6 Wednesday, August 18, 1999 2:57 PM

7
CONNECTING TO THE
SYSTEM
Follow these steps to add the siren
detector to your alarm system.
1. Press LEARN on the system’s
base. The LEARN indicator
flashes.
2. Enter your access code on the
base’s keypad. The LEARN indi-
cator lights and the next avail-
able zone’s indicator flashes.
illustration
49-2020.fm Page 7 Wednesday, August 18, 1999 2:57 PM

8
3. Press TEST on the siren detector.
The system stores the detector’s
settings in the next available
zone, lights the zone’s indicator,
and sounds a brief tone.
Note: To assign the siren detec-
tor to a zone other than the next
available zone, enter the desired
zone number. For example, to
assign the detector to Zone 5,
press 05. Then press TEST on
the detector.
49-2020.fm Page 8 Wednesday, August 18, 1999 2:57 PM

9
MOUNTING THE
DETECTOR
To ensure the siren detector de-
tects the smoke alarm when it
sounds, mount the detector 4–6
inches from a UL-approved smoke
alarm (Cat. No. 49-466).
Follow these steps to mount the de-
tector.
1. At the desired mounting location,
drill two holes 13/4inches apart,
one above the other.
49-2020.fm Page 9 Wednesday, August 18, 1999 2:57 PM

10
2. Thread the supplied screws into
the holes until each screw’s head
extends about 1/4inch from the
wall.
3. Line up the keyhole slots on the
detector with the screws on the
mounting location, then slide the
detector down onto the screws
until it is secure.
After you mount the siren detector,
be sure you test it as described un-
der “Testing” on Page 12.
