Radio Shack 40-1014A User manual

Cat. No. 40-1014A
©1996 Tandy Corporation.
All Rights Reserved.
Radio Shack is a registered trademark used by Tandy Corporation.
10" Polypropylene Woofer
Your Radio Shack 10" Polypropylene
Woofer lets you increase the bass re-
sponse of your sound system,
whether it is a home or car, stereo or
monaural system.
FEATURES
Li
g
ht, Ri
g
id, Pol
y
prop
y
lene Cone
— extra-durable, long-life cone re-
sists effects of moisture and temper-
ature extremes, and withstands
greater stress at high volume levels.
Rolled Urethane Foam Surround
— minimizes distortion and im-
proves clarity.
Lon
g
-Throw Voice Coil — delivers
clean, solid sound.
MOUNTING
You can install the woofer from the
front or back of an enclosure so it is
flush with the baffle’s surface. Seal
the mounting surface so air cannot
leak around the woofer
For details, see our “Building Speak-
er Systems” book (not supplied),
available at your local Radio Shack
store.
40-1014a.fm Page 1 Tuesday, August 10, 1999 12:34 PM

SPECIFICATIONS
Nominal Impedance .................................................................................................................8 ohms
Frequency Response ...................................................................................................30 Hz-2500 Hz
Free Air Resonance (Fs) Frequency.......................................................................................... 30 Hz
Infinite Baffle Resonance Frequency ......................................................................................... 29 Hz
Piston Area (SD) .................................................................................................................0.0360 m2
Power Handling .................................................................................................................50WRMS
Maximum Power ....................................................................................................................... 100 W
Flux Density (BL).................................................................................................................... 8.27 TM
DC Voice Coil Resistance (RE, ohms) ..................................................................................6.6 ohms
Voice Coil Inductance (LVC at 1 kHz) ....................................................................................1.13 mH
SPL.......................................................................................................................... 87ð ±2 db/1W/1m
Moving Mass (Mms).................................................................................................................35.19 g
Electrical Q Factor (QES)..............................................................................................................0.61
Mechanical Q Factor (QMS)............................................................................................................4.6
Total Q Factor................................................................................................................................0.54
Equivalent Acoustic Volume (VAS)............................................................................................181.2 l
Mechanical Suspension Compliance (CMS, UM/N)....................................................... 963.17 UM/N
Mechanical Mass of Cone Assembly and Free Air Load..........................................................35.19 g
Mechanical Mass of Cone Assembly Only................................................................................31.14g
Peak-to-Peak (Maximum) Linear Excursion...........................................................................2.25 mm
Cutout ..................................................................................................................91/4Inches/23.5 cm
Depth................................................................................................................... 315/16 Inches/9.8 cm
Magnet Weight ........................................................................................................................11.6 oz.
Speaker Weight.......................................................................................................................42.4 oz.
Specifications are t
y
pical; individual units mi
g
ht var
y
. Specifications are subject
to chan
g
e and improvement without notice.
RADIO SHACK
A Division of Tandy Corporation
Fort Worth, Texas 76102
6A6 Printed in China
