Cat. No. 43-890
OWNER’S MANUAL
Please read before using this equipment.
ET-152
Headset Telephone
43-890.fm Page 1 Monday, August 16, 1999 2:01 PM

2
Warning: To prevent fire or shock hazard, do not expose this prod-
uct to rain or moisture.
This symbol is intended to alert you to the presence of uninsu-
lated dangerous voltage within the product’s enclosure that
might be of sufficient magnitude to constitute a risk of electric
shock. Do not open the product’s case.
This symbol is intended to inform you that important operating
and maintenance instructions are included in the literature ac-
companying this product.
RISK OF ELECTRIC SHOCK.
DO NOT OPEN.
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE
COVER OR BACK. NO USER-SERVICE-
ABLE PARTS INSIDE. REFER SERVIC-
ING TO QUALIFIED PERSONNEL.
CAUTION !
!
©1995 Tandy Corporation.
All Rights Reserved.
Radio Shack is a registered trademark used by Tandy Corporation.
43-890.fm Page 2 Monday, August 16, 1999 2:01 PM

3
FEATURES
Your Radio Shack ET-152 Headset Telephone is a telephone head-
set and dialer that connects to your telephone line in place of a tele-
phone. The ET-152’s long headset cable lets you move freely while
you talk on the phone, and the adjustable microphone boom swings
back and forth so you can wear the headset over either ear.
Its features include:
Quick-Disconnect Plug — lets you disconnect the headset from
the dialer without disconnecting the call, so you can step away from
the phone without removing the headset. You can return to the con-
versation by simply reconnecting the headset.
Lapel Clip — lets you securely anchor the headset’s modular cord
to your clothing to prevent the headset from slipping.
Studio-Quality Electret Condenser Microphone — provides
clear transmission of your voice.
Adjustable Volume — gives you full control of the volume.
Touch Tone or Pulse (Rotary) Dialing— lets you use your ET-152
with either type of telephone service.
Hold Button — lets you put a call on hold.
43-890.fm Page 3 Monday, August 16, 1999 2:01 PM

4
Flash Button — sends a timed electronic switchhook signal for use
with specialized telephone services, such as call waiting.
Ringer OFF/ON Switch — lets you turn the ringer on or off.
Last Number Redial — lets you automatically redial the last num-
ber dialed with the touch of a button.
Hearing-Aid Compatible — lets you use the ET-152 with hearing
aids that have a T (telephone) switch.
The ET-152 Headset Telephone has been tested and certified to
comply with applicable UL and FCC standards.
43-890.fm Page 4 Monday, August 16, 1999 2:01 PM

5
READ THIS BEFORE INSTALLATION
We have designed your ET-152 Headset Telephone to conform to
federal regulations and you can connect it to most telephone lines.
However, each device you connect to the phone line draws power
from it. This power draw is the device’s RingerEquivalence Number,
or REN. The REN is shown on the bottom of the ET-152.
If you use more than one phone or other device on the line, add up
all the RENs. If the total is more than five (or three in rural areas),
your phone(s) might not ring. If ringer operation is impaired, remove
one of the devices from the line.
FCC STATEMENT
Your ET-152 Headset Telephone complies with Part 68 of FCC
Rules
. You must, upon request, provide the FCC registration num-
ber and the REN to your telephone company. Both numbers are
marked on the bottom of the ET-152.
Note: You must not connect the headset telephone to:
• Coin-operated systems
• Party-line systems
• Most electronic key telephone systems
43-890.fm Page 5 Monday, August 16, 1999 2:01 PM

6
CONTENTS
Preparation 7
Connecting to the Phone Line 7
Adjusting the Headset 8
Setting the Dialing Mode 10
Setting the Ringer Off/On Switch 11
Using the Belt Clip 11
Operation 13
Initiating the Switchhook 13
Answering a Call 13
Placing a Call 14
Setting the Volume 14
Using Hold 15
Using Flash 16
Using Redial 17
Using Tone Services with a Pulse Line 18
Troubleshooting 19
Care and Maintenance 20
The FCC Wants You to Know 21
Lightning 22
43-890.fm Page 6 Monday, August 16, 1999 2:01 PM

7
PREPARATION
CONNECTING TO THE PHONE LINE
1. Plug one end of the supplied modular cord into the ET-152’s
TEL LINE jack. Then plug the other end into the telephone line’s
wall jack.
2. Plug the headset’s modular cord into the ET-152’s HEADSET
jack.
43-890.fm Page 7 Monday, August 16, 1999 2:01 PM

8
ADJUSTING THE HEADSET
1. Place the headset on your head as shown.
2. Adjust the headset band until it rests with almost no pressure
on your ear and the top of your head.
If the headset is loose, remove it and flex it inward slightly to
tighten it. If the headset is tight, gently pull the headset band
out to loosen it.
43-890.fm Page 8 Monday, August 16, 1999 2:01 PM

9
3. Hold the headset in place, and turn the microphone boom until
it is about even with your chin. Experiment until you find the
most comfortable position.
4. Route the headset’s modular cord through the lapel clip’s
channel and attach the lapel clip to your clothing. Leave
enough slack in the cord so you can move your head without
pulling the headset.
43-890.fm Page 9 Monday, August 16, 1999 2:01 PM

10
SETTING THE DIALING MODE
Set TONE/PULSE for the type of service youhave. If you are not sure
which type of service you have, do this simple test.
1. Set TONE/PULSE on the side of the dialer to TONE.
2. Press TALK/HANG UP so its indicator lights and listen for a dial
tone.
3. Press any number other than 0. If the dial tone stops, you have
touch-tone service. If the dial tone continues, you have pulse
service.
43-890.fm Page 10 Monday, August 16, 1999 2:01 PM

11
4. If you have pulse service, set TONE/PULSE to PULSE.
SETTING THE RINGER OFF/ON SWITCH
You can set RINGER to OFF or ON. With RINGER set to OFF, the di-
aler does not ring, but you can still make outgoing calls. If you hear
an extension telephone ring, you can answer incoming calls.
USING THE BELT CLIP
Use the ET-152’s belt clip to hang the dialer on your waistband so
you can carry it with you wherever you go.
43-890.fm Page 11 Monday, August 16, 1999 2:01 PM

12
To attach the belt clip to the ET-152, place the belt clip in the slot,
then slide it in the direction of the arrow until it locks into place.
To remove the belt clip from the ET-152, press the belt clip’s tab and
slide it off in the direction of the arrow.
43-890.fm Page 12 Monday, August 16, 1999 2:01 PM

13
OPERATION
INITIATING THE SWITCHHOOK
You must initiate the switchhook function the first time you use your
ET-152, and anytime you move it to a new location and cannot get
a dial tone.
To initiate the switchhook function, press and hold down TALK/HANG
UP for 2 seconds.
ANSWERING A CALL
When the ET-152 rings, press TALK/HANG UP, then speak through
the microphone boom.
43-890.fm Page 13 Monday, August 16, 1999 2:01 PM

14
PLACING A CALL
1. With your headset on, press TALK/HANG UP so its green indi-
cator lights. Then listen for a dial tone.
2. Dial the number you want to call.
3. After you finish your conversation, press TALK/HANG UP. The
green indicator turns off.
SETTING THE VOLUME
VOLUME lets you adjust the volume you hear. This is especially use-
fulfor people who are hearing impaired, or whenyou encounterpoor
phone linesor especially noisy areas.Simply setVOLUME to the de-
sired listening level.
43-890.fm Page 14 Monday, August 16, 1999 2:01 PM

15
USING HOLD
To placea call on hold, press HOLD.The red indicatorlights to show
that the call is still on the line. To release a call from hold, press
TALK/HANG UP.
You can also continue your conversation from an extension phone
on the same line. The call is released from hold whenever you pick
up an extension phone on the same line.
When you place a call on hold, you can disconnect the headset if
you need to step away from the phone. When you want to continue
your conversation, reconnect the headset. Then press TALK/HANG
UP to release the call from hold.
43-890.fm Page 15 Monday, August 16, 1999 2:01 PM

16
USING FLASH
FLASH provides the electronic equivalentof a switchhook signal, re-
quired by some telephone services.
For example, if you have call waiting, you can put your current call
on hold and take another incoming call by pressing FLASH. Press
FLASH again to alternate between the two calls.
Note: If you do not have any special telephone services, pressing
FLASH during a telephone conversation might disconnect your cur-
rent call.
43-890.fm Page 16 Monday, August 16, 1999 2:01 PM

17
USING REDIAL
Each time you dial a number, the ET-152 Headset Telephone stores
that number into a temporary memory. To dial the last number di-
aled, press TALK/HANG UP, then REDIAL.
Notes:
• If you get a busy signal, you can press REDIAL again without
pressing TALK/HANG UP.
• If the phone line has call-waiting or requires extra time to get a
dial tone, one-touch redial might not work. If so, press FLASH,
then press REDIAL.
• The redial memory does not store a FLASH entry or any keys
you press before FLASH.
• The redial memory holds 31 digits for tone dialing and 32 digits
for pulse dialing.
43-890.fm Page 17 Monday, August 16, 1999 2:01 PM

18
USING TONE SERVICES WITH A PULSE
LINE
Some special services, such as bank-by-phone, require tone sig-
nals. If you have pulse service, you can still use these special tone
services.
With TONE/PULSE set to PULSE, press ∗at the point where tone sig-
nals are required. Any additional numbers you dial are sent as tone
signals. TONE/PULSE automatically resets toPULSE when you hang
up.
Note: You can set TONE/PULSE to TONE during the call at the point
where tone signals are required. If you do this, be sure to set TONE/
PULSE back to PULSE when the call is over.
43-890.fm Page 18 Monday, August 16, 1999 2:01 PM

19
TROUBLESHOOTING
If the ET-152 Headset Telephone volume level drops or if the phone
begins to make unusual sounds, determine if other phones on the
same line have been picked up. In areas with low telephone voltage,
the ET-152 might not operate when other phones are active on the
same line. Hanging up the other phones should correct the problem.
If you still have problems, immediately disconnect the ET-152. If oth-
er phones on the same line operate normally, the fault is in the ET-
152 or its installation. If you are unable to locate the problem, take
the ET-152 to your local Radio Shack store for assistance.
43-890.fm Page 19 Monday, August 16, 1999 2:01 PM

20
CARE AND MAINTENANCE
Your Radio Shack ET-152 Headset Telephone is an example of su-
perior design andcraftsmanship.The following suggestions will help
you care for the ET-152 so you can enjoy it for years.
Keep the ET-152 dry. If it gets wet, wipe it dry im-
mediately. Liquids might contain minerals that can
corrode the electronic circuits.
Handle the ET-152 gently and carefully. Dropping it
can damage circuit boards and cases and can
cause the ET-152 to work improperly.
Use and store the ET-152 only in normal tempera-
ture environments. Temperature extremes can
shorten the life of electronic devices and distort or
melt plastic parts.
Keep the ET-152 away from dust and dirt, which
can cause premature wear of parts.
43-890.fm Page 20 Monday, August 16, 1999 2:01 PM
