Radio Shack 15-100 User manual

8-in-1 LCD Remote
15-100
Please read this user’s guide before installing,
setting up and using your new product
www.radioshack.com
RadioShack 8-in-1 LCD ENG.fm Page 1 Friday, February 9, 2007 6:11 PM

2
TABLE OF CONTENTS
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Installing Batteries. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Battery Use And Safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
To Install Batteries: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Features and Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Key Charts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Device Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Setting the Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Setting the Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Programming a Device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Programming a Device by Selecting Its Brand . . . . . . . . . . . 11
Programming a Device by Manually Entering Its Code . . . . . 12
Programming a Device by Searching for Its Code . . . . . . . .14
Using My System Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Control Organization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
About Control Groups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
About Device Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Factory Default Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Programming My System Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Using Learning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Learning Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Programming a Learned Key . . . . . . . . . . . . . . . . . . . . . . . . . 17
Deleting a Single Learning Key. . . . . . . . . . . . . . . . . . . . . . . . 17
Deleting All Learned Keys in a Specific Mode . . . . . . . . . . . . 18
Using Keymover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Programming Keymover. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Restoring a Single Keymover Key. . . . . . . . . . . . . . . . . . . . . . 19
Restoring All Keymover Keys in a Single Mode . . . . . . . . . . . 19
Programming Favorite Channel Scan . . . . . . . . . . . . . . . . . . . . . . . 20
Using Channel Scan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Setting the Power Macro . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Setting Time Macros . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Setting a Daily Time Macro. . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Setting a Weekly Time Macro. . . . . . . . . . . . . . . . . . . . . . . . . 23
Deleting a Time Macro . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Changing Volume Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Locking Volume Control to One Mode (Global Volume Lock). 24
Unlocking Volume Control for a Single Device (Individual
Volume Unlock) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Unlocking All Volume Control (Restoring Global Unlock) . . . 25
Using Text Edit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Resetting the Remote. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
RF Emissions Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Limited 90-Day Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
RadioShack 8-in-1 LCD ENG.fm Page 2 Friday, February 9, 2007 6:11 PM

3
Manufacturer’s Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Setup Codes for TVs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Setup Codes for Audio Amplifiers. . . . . . . . . . . . . . . . . . . . . . 41
Setup Codes for Audio Accessories . . . . . . . . . . . . . . . . . . . .42
Setup Codes for Audio Receivers. . . . . . . . . . . . . . . . . . . . . . 42
Setup Codes for Cable Set-top Boxes . . . . . . . . . . . . . . . . . . 46
Setup Codes for Cable/PVR Combos . . . . . . . . . . . . . . . . . . . 48
Setup Codes for CD Players . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Setup Codes for DBS/PVR Combo Boxes . . . . . . . . . . . . . . . .51
Setup Codes for DVD Players . . . . . . . . . . . . . . . . . . . . . . . . . 52
Setup Codes for DVD/PVR Combos. . . . . . . . . . . . . . . . . . . . .56
Setup Codes for Home Automation . . . . . . . . . . . . . . . . . . . . 56
Setup Codes for PVRs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Setup Codes for Satellite Set-top Boxes . . . . . . . . . . . . . . . . 58
Setup Codes for TV/DVD Combos . . . . . . . . . . . . . . . . . . . . . . 60
Setup Codes for TV/VCR Combos . . . . . . . . . . . . . . . . . . . . . . 60
Setup Codes for TV/VCR/DVD Combos . . . . . . . . . . . . . . . . . . 62
Setup Codes for Video Accessories . . . . . . . . . . . . . . . . . . . .63
Setup Codes for VCRs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
RadioShack 8-in-1 LCD ENG.fm Page 3 Friday, February 9, 2007 6:11 PM

4
INTRODUCTION
Thank you for purchasing a RadioShack 8-in-1 LCD
Remote. Your remote lets you control up to eight home
entertainment devices with one easy-to-use, compact
unit.
After installing batteries (see next section), you can
immediately use the RadioShack 8-in-1 LCD Remote to
control Sony home entertainment devices, and a Dish
Network satellite receiver. To control other brands,
perform the instructions in Programming a Device. For
best results, please read and perform all the remaining
instructions. Also, keep this guide for future reference.
•LCDScreen–A two-line LCD display
•My System Mode – a custom mode that
groups the most-often-used keys in different
modes together for operating convenience in
one mode
•Macros – for instant activation of favorite
key sequences
•Learning – to capture unique functions from
your devices’ original remote controls
•Direct Code Setup –for easy device
programming with setup codes
•Innovative Code Search –allows setup of
your devices without looking up codes
•Favorite Channel Scan –for easy channel
surfing of favorite channels
•Vo l u m e L o c k – to assign volume controls to
individual devices or to one global device
•Extensive Code Library – largest and most
efficient group of IR remote control codes for
virtually every current brand and make
•TextEdit–You can use the keypad on your
remote to edit and enter text that appears on
the LCD screen
• Language Selection – You can select
either English or Spanish as the remote’s
interface language
RadioShack 8-in-1 LCD ENG.fm Page 4 Friday, February 9, 2007 6:11 PM

5
INSTALLING BATTERIES
Yo u r RadioShack 8-in-1 LCD Remote requires four
AAA batteries (not supplied) for power.
Battery Use And Safety
• Use only fresh batteries of the required size and
recommended type.
• Do not mix old and new batteries, different types of
batteries (that is, standard, alkaline, or rechargeable),
or rechargeable batteries of different capacities.
CAUTION: If you do not plan to use the remote for an
extended period, remove the batteries. They can leak
chemicals that can damage electronic parts.
WARNING: Dispose of old batteries promptly and
properly. Do not burn or bury them.
To Install Batteries:
1. Open the battery compartment cover (located on
the back of the remote).
2. Place the AAA batteries in the compartment and
match the + and - polarity symbols inside.
3. Replace the cover.
NOTE: The RadioShack 8-in-1 LCD Remote will not
lose any setup configurations, even when it
loses power.
RadioShack 8-in-1 LCD ENG.fm Page 5 Friday, February 9, 2007 6:11 PM

6
FEATURES AND FUNCTIONS
Use the illustration below to locate features on the
RadioShack 8-in-1 LCD Remote and then study the Key
Charts (on the next three pages) to learn how they
function.
To find out what type of devices can be controlled by
each device key after programming, see “Device Table”
on page 9.
RadioShack 8-in-1 LCD ENG.fm Page 6 Friday, February 9, 2007 6:11 PM

7
Key Charts
Press this key… To…
Enter programming mode.
Turn the selected device on or off, or
run the macro you programmed for
the Power button (see “Setting the
Power Macro” on page 20 for more
information).
Select a device to control.
Display the menu for the selected
device.
Display the menu for the PVR.
Display the program guide for the
selected device.
Move the cursor in the program
guide and menu screens.
To choose options in the LCD menu
screens and to tune programs from
the program guide.
Scroll up or down the menu of your
PVR or cable/satellite box one page
at a time.
Choose options from the selected
device's menu or guide.
Return to live TV on your PVR.
RadioShack 8-in-1 LCD ENG.fm Page 7 Friday, February 9, 2007 6:11 PM

8
Exit the selected device's menu,
guide, or program.
Select the next or previous channel.
Select the next or previous chapter
on some DVD player models.
Increase or decrease the sound level.
NOTE: When the device that is set up
does not support volume functions,
the remote will send volume for TV.
Turn the sound off or on.
Switch the TV's, VCR's, CBL/SAT’s,
or DVD’s input to view TV or video
programs, or to act as your cable
box's A/B switch.
Recall the last-viewed channel.
Scan favorite channels (and/or all
channels). See “Programming
Favorite Channel Scan” on page 20
and “Using Channel Scan” on
page 20.
Use MY SYSTEM to create a custom
mode with favorite remote control
keys from different devices in your
home theater system. See “Using My
System Mode” on page 15.
Directly enter channels (for example,
09 or 31). You can also use the
keypad for text editing and entering
the manufacturer’s codes for your
home entertainment device. See
“Using Text Edit” on page 25 and
“Programming a Device” on
page 11.
Input channel number entries on
some TV models or make a selection
on a device's menu.
Press this key… To…
RadioShack 8-in-1 LCD ENG.fm Page 8 Friday, February 9, 2007 6:11 PM

9
Device Table
NOTE: Please refer to the table below when
performing the instructions in
“Programming a Device” on page 11.
After programming, the RadioShack 8-in-1 LCD
Remote will be able to control the following types of
devices:
Control your VCR, DVD player, or
Video On Demand (VOD) if available
on your cable/satellite service.
Control the functions of your PVR.
Control the Picture in Picture (PIP)
functions of your TV or VCR.
Record a video program on a record-
capable device (press twice).
Use the light bulb key to turn LED
backlighting on or off. Press and
hold this key to display the time and
date on the LCD. The time and date
will display only if the clock has
previously been set.
Set the sleep timer of your selected
device. This is only available if your
device has a sleep function.
Program macros. You can program
macro sequences on any of these
three keys.
Device Key Controls these types of devices
Any device type can be assigned via the
LCD menu. Device types include: TV,
VCR, DVD, AUX, Cable, Satellite, DSS,
Receiver, PVR, Amp, Misc. Audio, CD,
Home Automation, Video Accessories,
and Tuner.
Press this key… To…
RadioShack 8-in-1 LCD ENG.fm Page 9 Friday, February 9, 2007 6:11 PM

10
SETTING THE LANGUAGE
Before using your RadioShack 8-in-1 LCD Remote, you
must set the default language (either English or
Spanish). You cannot use your remote control until you
have set the language. To set the language for your
remote control for the first time, perform the following
steps:
1. After the remote powers up, the LCD displays
English OK or .
2. Press OK for English or press until Spanish is
displayed. Press OK.
3. The LCD displays Success and returns to normal
operation.
To change the language after the initial setup, perform
the following steps:
1. Press and hold Puntil the LCD displays
Code Set OK or . The remote is
now in the programming mode.
2. Use the or keys to scroll through the LCD
display until Language is displayed.
3. Press OK once.
4. To set the language to English, press OK once. To set
the language to Spanish, use the to scroll to
Spanish. Press OK to select Spanish as the remote
control’s language.
5. To exit this menu, press EXIT once, or use the 
key to return to the previous menu.
SETTING THE CLOCK
To set the clock on your remote control, perform the
following steps:
1. Press and hold Puntil the LCD displays
Code Set OK or . The remote is
now in the programming mode.
2. Use the or keys to scroll through the LCD
until Clock set is displayed.
3. Press OK once.
4. The LCD displays the time as previously set, if any.
The first set is the hour. The second set is the
minutes. In the position following the numbers,
the LCD displays Aor Pfor A.M. or P.M.
5. While the number for the first digit is flashing, use
the or keys to select the correct digit. You can
also change the time by pressing the number keys
on your remote control’s keypad.
6. Use the key to change to the next digit, until the
last digit is set. Use to go back to the previous
digit.
7. After you have set the correct time, use the key to
cursor over to Aor P.
RadioShack 8-in-1 LCD ENG.fm Page 10 Friday, February 9, 2007 6:11 PM

11
8. Use the or keys to select either Aor P.
9. Press OK once.
10. The LCD displays Success.
11. The LCD displays a day of the week. Use the or
keys to change the day if it is not correct.
12. Press OK once. The day is now set.
13. The LCD displays Success.
NOTE: The LCD does not display the clock on the
screen during normal operation. To view the
current time, press and hold the Light bulb
key until the LCD displays the time. The clock
is used for timed macros. For more
information on timed macros, see “Setting
Time Macros” on page 22.
PROGRAMMING A DEVICE
The RadioShack 8-in-1 LCD Remote comes pre-
programmed to operate Sony TVs, VCRs, DVD players,
and audio devices, as well as a Dish Network satellite
receiver. To control devices other than these default
brands, follow these steps; otherwise, skip this section.
Before proceeding, find the codes for the devices you
want to program in Manufacturer's Codes and write
them down or highlight them.
The RadioShack 8-in-1 LCD Remote offers three
methods for programming a device. You can program a
device by selecting its brand (for the top 25 brands
only), by manually entering its ID code into the remote
control, or by searching for the code.
Programming a Device by Selecting Its Brand
1. Turn on the device (for example, DVD player) and,
if needed, load media (for example, a DVD).
2. Press and hold Puntil the LCD displays
Code Set OK or .
3. Press OK.
4. The LCD displays Brand.
5. Press OK. The LCD displays Press Mode or 
.
6. Select the mode on the remote that you would like
to set (for example, TV).
7. The LCD displays Setup CBL. Use the keys
to scroll through the different types of devices to
set up. Press OK.
8. Select the brand of device you want to control (for
example, Sony), by using the keys to scroll
through the brand list. You can also select your
brand by using your keypad like the keys on a cell
phone, to jump from letter to letter (for example,
press 2repeatedly to select either A, B, or C). Press
OK.
RadioShack 8-in-1 LCD ENG.fm Page 11 Friday, February 9, 2007 6:11 PM

12
9. Aim the remote control at your device (for
example, TV). Press any key but OK , , , or
EXIT to test that the remote control works with your
device. Use the keys to select a different code
within the same brand, if any. Press OK to save.
10. The LCD displays Success.
11. The LCD displays Edit Text. This option allows
you to change the default display for this mode
from the brand of the device (for example, Sony) to
a personalized display (for example, My TV). Press
OK to edit text, or press to exit without text
editing. See steps 4-5 of “Using Text Edit” on
page 25.
Programming a Device by Manually Entering Its Code
1. Turn on the device (for example, DVD player) and,
if needed, load media (for example, a DVD).
2. Press and hold Puntil the LCD displays
Code Set OK or .
3. Press OK once. The LCD displays Brand.
4. Use the keys to scroll through the
LCD display until it displays ID Set.
5. Press OK.
6. The LCD displays Press Mode OK or .
Press the mode on the remote for the device you
want to program (for example, TV).
7. The LCD displays Enter ID. Press OK. Enter the
first five-digit code for your device. As you enter
the code numbers, each number displays on the
LCD from right to left.
8. Press OK to confirm the code.
NOTE: If you do not press OK, the remote does not
save the code you entered.
9. The LCD displays Test followed by the code you
entered (for example, Test 10000).
NOTE: At this point, you can use function keys other
than OK, and EXIT (for example, POWER) to
test the code.
10. Press OK once. The LCD displays Success.
NOTE: If you cannot find a code that works, see
“Programming a Device by Searching for Its
Code” on page 14.
11. The LCD displays Edit Text. This option allows
you to change the default display for this mode
from the code of the device (for example, 10000) to
a personalized display (for example, My TV). Press
OK to edit text, or press to exit without text
editing. See steps 4-5 of “Using Text Edit” on
page 25.
12. Repeat steps 1 to 11 for each device you want to
control. For future reference, write down each
working device code in a safe place.
RadioShack 8-in-1 LCD ENG.fm Page 12 Friday, February 9, 2007 6:11 PM

13
AUX Code
Device Type:___________________
CD Code
Device Type:___________________
DVD Code
Device Type:___________________
AUD Code
Device Type:___________________
SAT/CBL Code
Device Type:___________________
TV Code
Device Type:___________________
PVR Code
Device Type:___________________
VCR Code
Device Type:___________________
RadioShack 8-in-1 LCD ENG.fm Page 13 Friday, February 9, 2007 6:11 PM

14
Programming a Device by Searching for Its Code
If your device does not respond to the remote after
trying all codes listed for your brand, or if your brand is
not listed, try searching for your code. For example, to
search for a code for your TV:
1. Press and hold Puntil the LCD displays
Code Set OK or .
2. Press OK.
3. Use the key to scroll through the LCD display
until the LCD displays Search.
4. Press OK once.
5. Press the mode key on the remote for the device
you want to program (for example, TV).
6. The LCD displays Setup CBL. Use the keys
to select the device type you want to set up.
7. Press OK.
8. The LCD displays Press Test Key. At this point,
press the test key you would like the remote to
transmit every time it moves to the next code
during the search.
9. The remote displays the next code in the list. Use
the keys to scroll through the codes. The LCD
displays the code for the current devices (for
example, 10000) and transmits your test function.
10. If the TV responds to your test function (for
example, POWER), press OK. The LCD displays
Success.
NOTE: The remote transmits the test key you pressed
in step 8 every time the or key is
pressed. If desired, within each code, any
function key except the arrows, OK, and EXIT
can be used for testing also.
11. The LCD displays Edit Text. This option allows
you to change the default display for this mode
from the code of the device (for example, 10000) to
a personalized display (for example, My TV).Press
OK to edit text, or press to exit without text
editing. See steps 4-5 of “Using Text Edit” on
page 25.
12. To search for other device codes, repeat steps 1 to
12, substituting the appropriate device key.
RadioShack 8-in-1 LCD ENG.fm Page 14 Friday, February 9, 2007 6:11 PM

15
USING MY SYSTEM MODE
The RadioShack 8-in-1 LCD Remote includes a custom
Home Theater mode. After the My System key is
programmed, it will allow you to access four groups of
remote control keys without having to change device
modes.
Control Organization
About Control Groups
For Home Theater programming, the remote control’s
keys are grouped by type of control into the following
four control groups:
About Device Modes
Moreover, the above Control Groups can be used in all
modes.
Factory Default Settings
At the factory, the Control Groups are assigned the
following modes as default settings:
Playback Group: Transport Controls
(Rewind, Play, Fast
Forward, Stop,
Pause, Record, Skip
Forward, and Skip
Back)
Audio Group: VOL, VOL, and
MUTE
Channel Group: CH, CH, TV/
VCR, Keypad (0 – 9),
FAV Scan, ENTER,
LAST, SLEEP, and
INFO
Menu Group: Cursor Controls (Up,
Down, Left, and
Right), SELECT,
PAGE+, PAGE-,
MENU, INFO, GUIDE,
and EXIT
Playback Group: VCR
Audio Group: TV
Channel Group: CBL
Menu Group: CBL
RadioShack 8-in-1 LCD ENG.fm Page 15 Friday, February 9, 2007 6:11 PM

16
If the default settings fit your needs, you can skip
programming this mode. Otherwise, perform the steps
in the following section to assign device modes to the
Control Groups.
PROGRAMMING MY SYSTEM MODE
1. Press and hold Puntil the LCD displays
Code Set OK or . Use the 
keys to scroll through the LCD until My
System OK or  is displayed.
Press OK.
2. The LCD displays Channel OK or . Press OK.
3. The LCD displays Press Mode or .
4. Press the mode key for the device you want to
control the channel (for example, TV). The LCD
displays Success TV.
5. The LCD displays Volume OK or . Press OK.
Press the mode key for the device that you want to
control volume (for example, AUDIO). The LCD
displays Success.
6. The LCD displays Transport OK or . Press OK.
7. Press the mode key for the device you want to
control transport (for example, VCR). The LCD
displays Success VCR.
8. The LCD displays Menu Nav OK or . Press OK.
9. Press the mode key for the device you want to
control menu navigation (for example, CBL/SAT).
The LCD displays Success SAT.
10. When programming is complete, the LCD displays
Complete and exits the My System setup.
USING LEARNING
The RadioShack 8-in-1 LCD Remote includes a
Learning feature so you can add functions that are
unique to your home entertainment devices (e.g.,VCR
T
racking Up or Down). However, there are some
considerations
.
Learning Precautions
• Your original remote controls must be in working
order for learning to work properly.
• Learned keys are mode-specific, so each one can
store a unique function for each mode.
• Learning capacity is approximately 34 to 50 keys,
depending on the code being learned.
• Some keys cannot be learned: Mode keys (for
example, TV), P, and the Light bulb key.
• Certain device functions are not learnable,
including multi-frequency types, some high
frequency ones, and other unusual formats.
RadioShack 8-in-1 LCD ENG.fm Page 16 Friday, February 9, 2007 6:11 PM

17
• For optimum learning, avoid high levels of ambient
light such as natural sunlight or energy-efficient
fluorescent lights.
NOTE: Please have your original remote controls
handy before programming learning.
Programming a Learned Key
1. Press and hold Puntil the LCD displays
Code Set OK or . Use the 
keys to scroll through the LCD display
until Learn is displayed. Press OK.
2. The LCD displays Add Learn OK or . Press OK.
3. The LCD displays Press Mode or .
4. Press a mode key once (i.e., TV, VCR , PVR, CBL/SAT,
CD, DVD, AUX, or AUDIO) to assign a mode to learn
onto.
5. Place the RadioShack 8-in-1 LCD Remote head-to-
head (about 2" apart) from your original remote
control. Also locate the key (on your original
remote control) that you want the RadioShack 8-
in-1 LCD Remote to learn.
6. Press the key on your RadioShack 8-in-1 LCD
Remote that wish to assign learning.
7. On the original remote, press and hold the key.
Continue holding the key on the original remote
until the RadioShack 8-in-1 LCD Remote’s LCD
displays either Success or Learn Fail.
NOTE: Immediately after you have pressed the key
that will learn, the LED flashes rapidly and the
LCD displays Learning. The remote times
out after five seconds and returns to step 6.
8. Repeat steps 4 through 7 for another mode and/or
key or press EXIT to exit programming. Repeat
steps 5 through 7 if learning failed.
Deleting a Single Learning Key
T
his process returns the key to its original programmin g
for the mode you select. You can also delete learned
programming by teaching a different function to the key
(see “Programming a Learned Key” on page 17).
1. Press and hold Puntil the LCD displays
Code Set OK or . Use the 
keys to scroll through the LCD display
until Learn is displayed. Press OK.
2. Use the keys to scroll through the
LCD display until Dlt Learn is displayed. Press
OK.
2"
RadioShack 8-in-1 LCD ENG.fm Page 17 Friday, February 9, 2007 6:11 PM

18
3. The LCD displays Press Mode or .
4. Press the mode key once (i.e., TV, VCR , PVR, CBL/
SAT, CD, DVD, AUX, or AUDIO) for the mode you want
to delete the learned key from.
5. The LCD displays DLT Key or  . Press OK.
6. The LCD displays Select Key or .
7. Press the key containing the learned function to be
deleted. The LCD displays Are U Sure OK or .
8. Press OK. The LCD displays Success.
9. Repeat steps 5 through 7 for another key.
Deleting All Learned Keys in a Specific Mode
1. Press and hold Puntil the LCD displays
Code Set OK or . Use the 
keys to scroll through the LCD display
until Learn is displayed. Press OK.
2. Use the keys to scroll through the LCD
display until Dlt Learn is displayed. Press OK.
3. The LCD displays Press Mode or .
4. Press the mode key once (i.e., TV, VCR , PVR, CBL/
SAT, CD, DVD, AUX, or AUDIO), to clear all learned
keys for that mode.
5. The LCD displays DLT Key. Press until the
LCD displays DLT All. Press OK.
6. The LCD displays Are U Sure OK or . Press OK.
7. The LCD displays Success and exits
programming.
8. Repeat steps 3 to 7 for another mode.
USING KEYMOVER
The RadioShack 8-in-1 LCD Remote includes a
Keymover feature that allows you to map (or copy) keys
from one mode (i.e., source mode) to another mode
(i.e., destination mode).
PROGRAMMING KEYMOVER
For example, if your DVD player does not have volume
control, you can map those keys (i.e., VOL, VOL,
and MUTE) from the TV mode to DVD mode as follows:
1. Press and hold Puntil the LCD displays
Code Set OK or . The remote is
now in the programming mode.
2. Use the or keys to scroll through the
LCD display until Key Mover is displayed. Press
OK.
3. The LCD displays Move Key. Press OK.
4. The LCD displays Press from Mode.
5. For the source mode, press a desired device key
once (i.e., AUX, CBL/SAT, CD, TV, DVD, AUDIO, VCR,
or PVR). For this example, press TV once.
6. The LCD displays Press From Key. For the source
key, press a key to be moved once. For this example
press VOLonce.
RadioShack 8-in-1 LCD ENG.fm Page 18 Friday, February 9, 2007 6:11 PM

19
7. The LCD displays Press To Mode. For the
destination mode, press a desired device key once
(i.e., AUX, CBL/SAT, CD, TV, DVD, AUDIO, VCR, or
PVR). For this example, press DVD once.
8. The LCD displays Press To Key. For the
destination key, press a key to be moved once. For
this example press VOLonce.Upon keymoving,
the LCD displays Success.
9. Repeat steps 3 to 8 to move additional keys. For this
example, repeat steps 3 to 8 two more times to map
the remaining volume control keys, substituting
VOLand MUTE as source and destination keys in
steps 6 and 7.
Upon completion of the above procedure, you can now
use your RadioShack 8-in-1 LCD Remote to control the
TV’s volume and mute in the DVD mode, as well as in
the TV mode.
Restoring a Single Keymover Key
1. Press and hold Puntil the LCD displays
Code Set.
2. Use the or keys to scroll through the
LCD display until Key Mover is displayed. Press
OK.
3. The LCD displays Move key.
4. Use the or keys to scroll to Clear Move and
press OK.
5. The LCD displays Press from Mode.
6. Press the source mode once where the keymoved
key is stored.
7. The LCD displays Press From Key. Then press
the source key once. Upon key restoration, the LCD
displays Success.
8. If desired, repeat steps 4 through 6 to restore
another key.
Restoring All Keymover Keys in a Single Mode
1. Press and hold Puntil the LCD displays
Code Set.
2. Use the or keys to scroll through the
screen until Keymover is displayed. Press OK.
3. Use the or keys to scroll to Clear All. Press
OK.
4. The LCD displays Press Mode or . Press the
mode you want to delete all keymoved keys from.
5. The LCD displays Are U Sure. Press OK.
6. The LCD displays Success and exits.
RadioShack 8-in-1 LCD ENG.fm Page 19 Friday, February 9, 2007 6:11 PM

20
PROGRAMMING FAVORITE CHANNEL SCAN
The remote allows you to store a list of up to 10 favorite
channels, in any order, that are immediately scanned
when you press FAV (SCAN).
NOTE: You can only store channels from one device
for Favorite Channel Scan.
1. Press and hold Puntil the LCD displays
Code Set OK or .
2. Use the use the or keys to scroll
through the LCD display until Fav Ch is
displayed. Press OK.
3. The LCD displays Select Mode or .
4. Select the mode you want to program for Favorite
Channel Scan (for example, TV).
5. The LCD displays 1st Fav OK or . Press OK.
6. The LCD displays Enter Chan OK or . Enter a
channel number (for example, 039). Press OK.
NOTE: If you press after programming your first
Favorite Channel, the remote saves the last
Favorite Channel selection and exits back to
the main Favorite Channel screen.
7. The LCD displays 2nd Fav CH OK or . Press OK.
Enter the next channel number (for example, 055).
Press OK.
8. Continue entering channel numbers until you get
up to 10 channels programmed.
9. As soon as you enter the 10th channel, the LCD
displays Success and exits (if you decide you
need fewer than 10 channels, then press EXIT or
).
NOTE: Whenever you want to add or replace one or
more favorite channels, all previously entered
favorite channels are cleared.
USING CHANNEL SCAN
Use FAV (SCAN) to start a three-second scan of all
favorite channels (if programmed; see “Programming
Favorite Channel Scan” on page 20) or all channels (if
Favorite Channel Scan is not programmed).
1. Press a device key.
2. Press SCAN once.
3. To stop scanning channels at any time, press any
key once.
SETTING THE POWER MACRO
You can use your new RadioShack 8-in-1 LCD Remote
to program a power macro that turns your devices off or
on in the sequence you choose.
RadioShack 8-in-1 LCD ENG.fm Page 20 Friday, February 9, 2007 6:11 PM
