Radio Systems StudioHub+ User manual

Small Products Technical Manual
for Powered and Passive Panels

2
Active (Powered) Panels Part # Page
4 Source Switcher Panel SH-4SWSS 25
Mic Preamp Panel SH-MIC 26
Mic Preamp w/PTT Panel SH-MICPTT 27
Mic Preamp w/PTT Panel* SH-MICPTT 28
Headphone Amplifier Panel SH-HPB 29
Dual Headphone Amp. Panel SH-HPDUAL 30
Monitor Level Control Panel SH-LEVEL 31
Monitor Amp Panel SH-AMP w/o Speaker 32
SH-AMPSPKR w/Speaker 32
Amp w/Headphone SH-AMPHPN 33
Dual VU Meter Panel SH-VUV(Vertical) 34
SH-VUH (Horizontal) 34
3 Mixer Panel (Input) SH-MIXER 35
3 Mixer Panel (Output) SH-MIXER 36
LCD Display Panel SH-LCDV(Vertical) 37
SH-LCDH(Horizontal) 37
In/Out Balanced MatchJack SH-DUALMATCH 38
In/Out Balanced MatchJack SH-MATCHPANEL 39
On/Off/Cough Panel SH-ONOFFCOUGH 40
Warranty/Repair Policy/Returns
Table of Contents
* Obsolete Part
Part # Page
StudioHub+ Standard Pinout
& Power Consumptions Illustration 3
How to Power StudioHub+ - via PS-Cube 4
How to Power StudioHub+ - via a Hub or Wall-Wart 5
Active (Powered) MatchJacks
MatchJack Preamp, Input MJ-IN 6
MatchJack Preamp, Output MJ-OUT 7
AES/EBU to S/PDIF Converter MJ-SPDIFIN 8
S/PDIF to AES/EBU Converter MJ-SPDIFOUT 9
Analog to Digital Converter MJ-AD 10
Digital to Analog Converter MJ-DA 11
Digital Distribution Amplifier MJ-DDA 12
Passive Panels
Dual XLR Female Adapter Mono/Stereo SH-2XLRF 13
Dual XLR Male Adapter Mono/Stereo SH-2XLRM 14
Dual XLR Male-Female Panel SH-2XLRMF 15
Single XLR Female Panel SH-1XLRF 16
Single XLR Male Panel SH-1XLRM 17
Single XLR 5-Pin Female Panel SH-1XLRF5PIN 18
1/4” & Mini TRS Panel
(Unbalanced) SH-1/4UNBAL 19
1/4” & Mini TRS Panel
(Balanced) SH-1/4BAL 20
4 Source Switcher Panel SH-4SW* 21
Breakout Adapter ADAPT-BO 22
Breakout Adapter ADAPT-GPI 23
PS-CUBE “DC-Link” Power Inserter PS-CUBE 24
Mic Single XLR Female w/PTT Panel SH-MICPTTPAS 27

3
[phone] • Fax [phone] • www.studiohub.com
StudioHub+
Standard Pinout
(T568B Standard)
Current consumption for each StudioHub+ active device. Refer to this list
when calculating the total number of devices that can be run together
on any individual power supply.
Part # Description Current
MJ-OUT Analog MatchJack Out (IHF to Pro) 75ma
MJ-IN Analog MatchJack In (Pro to IHF) 35ma
MJ-SPDIFOUT SPDIF OUT (S/PDIF and Optical to AES) 100ma
MJ-SPDIFIN SPDIF IN (AES to S/PDIF) 0 (passive)
MJ-AD Digital MatchJack A to D 150ma
MJ-DA Digital MatchJack D to A 150ma
MJ-DDA Digital MatchJack Distribution Amplifier 165ma*
SH-DUALMATCH Dual Match Panel 100ma
SH-HP Headphone Panel 100ma
SH-MIC Mic Pre-Amp Panel 55ma
SH-MIXER 3 Input Stereo Mixer with mix-minus 125ma
SH-AMPSPKR Monitor Amp Panel (w/ Speaker) 1400ma
SH-LEVEL Monitor Panel 145ma
SH-VUV Dual VU Meter Panel 150ma
SH-LCDV LCD Display Panel 75ma
DA6-DC DA Hub (Single) 575ma
SUM4-DC Combiner Hub (Single) 175ma
+-G-+
LEFT RIGHT
Stand-Alone Versions
Some active StudioHub+ products were
previously available in “Stand-Alone”
versions with barrier strip connectivity for
audio I/O. The following illustrates the
pinout for this barrier strip.
* Powered via 9v DC (single ended) wall wart
or +/-15vDC StudioHub+ power supply

Revised 4-21-10
4
Powering StudioHub+ Active Device
s
Many StudioHub+devices areactiveand are poweredby+/- 15vDC. Powercan be supplied viathe StudioHub+ “DC-Link”
system that uses CAT-5pair#4(White/Brown)for power, or powercan be supplied viaaseparate powersupply.
Seethe current consumption charttodetermine howmanydevices canbepoweredwithdifferent systems.
II -PoweringViaaHub (for up to 16 devices)
I-Powering viaPS-Cube (for up to 4devices)
Useany Hubinwhich themodelnumber endsin“DC”
(HUB18-DCorHUB36-DCorHUB8-DC or HUB16-DC
PS-EXTU
Headphoneampslink
together foraudio &DC
SH-HP SH-HP
SH-MIC MatchJack
DtoA
Converter
From 4separate
a
udio sendsorfeed
s
Headphoneampslink
together foraudio &DC
SH-HP
SH-MIC
MatchJack
SH-HP
PS-Cube
PoweraPS-CUBEfroma
RadioSystems Console
U
se
cable#16998(6') / 15884(1')
(3-pin MTAto3-pin MTE)
MatchJack
III-Powering viaa“WallWart” or Desk-Top PowerSupply
SH-HP
SH-HP
Headphoneampslinktogether foraudio &DC.
Powerup to4headphone amps from onePS-WWU
andupto2headphoneamps from 1PSWW
D to A
Converter
3amp bi-polar
15vDC powersupply
PoweraPS-CUBEfroma
RS ConsolePower Supply
Usecable#16600
(16-pinMR-16 to 5-pinMTA)
PoweraPS-CUBEfrom a
PS-EXTU PowerSupply
(the cableisincluded)
(4-pin MR-4 to 5-pinMTA)
1Amp
1Amp
3Amps400ma
PoweraPS-CUBE from a
PS-WWCUBEPower Supply
(the captivecable is included)
(captive to 3-pinMTE)
200ma
NOTE –All powersuppliesshown areUniversal Voltage
switchingsuppliesand accept from 100 to 240VAC input
powerEXCEPTthe “non UniversalWall-Wart”
PS-WWCUBE andPS-WWSH supplies
whichare 110VAC inputpower only.
P
ower an individual MatchJackorPanel
from aPSWW-SH PowerSupply
(the captive3-pin to MTAcable
is included)
PowermultiplePanels
from aPSWWU-SHPower Supply
(the captive3-pin to MTAcable
is included)
PoweraPS-CUBE from a
PS-WWUCUBE PowerSupply
(the captivecable is included)
(captive to 3-pinMTE)
5-pinMTA &3-pin MTE
powerconnectors(in parallel)
How to Power StudioHub+ - via PS-Cube

Revised 4-21-10
5
Powering StudioHub+ Active Device
s
Many StudioHub+devices areactiveand are poweredby+/- 15vDC. Powercan be supplied viathe StudioHub+ “DC-Link”
system that uses CAT-5pair#4(White/Brown)for power, or powercan be supplied viaaseparate powersupply.
Seethe current consumption charttodetermine howmanydevices canbepoweredwithdifferent systems.
II -PoweringViaaHub (for up to 16 devices)
I-Powering viaPS-Cube (for up to 4devices)
Useany Hubinwhich themodelnumber endsin“DC”
(HUB18-DCorHUB36-DCorHUB8-DC or HUB16-DC
PS-EXTU
Headphoneampslink
together foraudio &DC
SH-HP SH-HP
SH-MIC MatchJack
DtoA
Converter
From 4separate
a
udio sendsorfeed
s
Headphoneampslink
together foraudio &DC
SH-HP
SH-MIC
MatchJack
SH-HP
PS-Cube
PoweraPS-CUBEfroma
RadioSystems Console
U
se cable#16998(6') / 15884(1')
(3-pin MTAto3-pin MTE)
MatchJack
III-Powering viaa“WallWart” or Desk-Top PowerSupply
SH-HP
SH-HP
Headphoneampslinktogether foraudio &DC.
Powerup to4headphone amps from onePS-WWU
andupto2headphoneamps from 1PSWW
D to A
Converter
3amp bi-polar
15vDC powersupply
PoweraPS-CUBEfroma
RS ConsolePower Supply
Usecable#16600
(16-pinMR-16 to 5-pinMTA)
PoweraPS-CUBEfrom a
PS-EXTU PowerSupply
(the cableisincluded)
(4-pin MR-4 to 5-pinMTA)
1Amp
1Amp
3Amps400ma
PoweraPS-CUBE from a
PS-WWCUBEPower Supply
(the captivecable is included)
(captive to 3-pinMTE)
200ma
NOTE –All powersuppliesshown areUniversal Voltage
switchingsuppliesand accept from 100 to 240VAC input
powerEXCEPTthe “non UniversalWall-Wart”
PS-WWCUBE andPS-WWSH supplies
whichare 110VAC inputpower only.
P
ower an individual MatchJackorPanel
from aPSWW-SH PowerSupply
(the captive3-pin to MTAcable
is included)
PowermultiplePanels
from aPSWWU-SHPower Supply
(the captive3-pin to MTAcable
is included)
PoweraPS-CUBE from a
PS-WWUCUBE PowerSupply
(the captivecable is included)
(captive to 3-pinMTE)
5-pinMTA &3-pin MTE
powerconnectors(in parallel)
How to Power StudioHub+ - via a Hub or Wall-Wart

6
Revised 4-21-10
Part # MJ-IN StudioHub+ MatchJack Preamp, Input
[phone] • Fax [phone] • www.studiohub.com
JU1
Install to connect shield ground
to power ground
Left level adjust
Right level adjust
Audio and power input
provided on RJ-45
Direct power input
+/- 15 volts DC
Right output RCA
Power
LED
Left output RCA

7
Revised 4-21-10
Part # MJ-OUT StudioHub+ MatchJack Preamp, Output
[phone] • Fax [phone] • www.studiohub.com
JU1
Install to connect
shield ground to
power ground
Left level adjust
Right level adjust
Direct power input
+/- 15 volts DC
Right input RCALeft input RCA
Audio and power input
provided on RJ-45
Power
LED

8
Revised 4-21-10
ASM STAND ALONE 12342
ASM STUDIOHUB+ 12341
J1
J2
J3
R2
ASM
JU1
R1 R1
T1
Part # MJ-SPDIFIN StudioHub+ S/PDIF to AES/EBU Converter
[phone] • Fax [phone] • www.studiohub.com
* RCA S/PDIF output
StudioHub+ AES/EBU RJ-45 input
JU1
Install to connect
shield ground to
power ground

9
Revised 4-21-10
Part # MJ-SPDIFOUT StudioHub+ S/PDIF to AES/EBU Converter
[phone] • Fax [phone] • www.studiohub.com
Direct power in
+/- 15 volts DC
* RCA S/PDIF input *Optical Input
StudioHub+ AES/EBU
output and power in
JU1
Install to connect
shield ground to
power ground
* Use only one

10
Revised 10-30-15
Part # MJ-AD StudioHub+ Analog to Digital Converter
[phone] • Fax [phone] • www.studiohub.com
DC power in +/- 15 volts DC included
(Radio Systems Part # PS-UCUBE)
Unit can also be powered by
StudioHub+ “DC-Link” via RJ-45’s.
JU7, JU8
Install to connect RJ-45 shield
to ground to power ground
Unbalanced Inputs
Balanced
Input AES/EBU Output
Left Right
JU3 JU4 JU5 JU6
Set Input Level
Pro Level Input
IHF
C
DC DC D
PRO
Set Nominal Input Sensitivity*
Short all lower pins
0dBu
Short Upper Pins Short Lower Pins Short No Pins
+4dBu +8dBu
JU1 JU2 JU1 JU2 JU1 JU2
JU3 JU4 JU5 JU6
Set Input Level
Consumer Level Input
IHF
C
DC DC D
PRO
Set Nominal Input Sensitivity*
Short all upper pins
-15dBv
Short Upper Pins Short Lower Pins
* Set for station standard
reference level to provide unit
output headroom of 20dB.
Short No Pins
-10dBv -6dBv
JU1 JU2 JU1 JU2 JU1 JU2
+15vG-15v
REDBLUWHT
Power Supply Connector

11
Revised 10-30-15
Part # MJ-DA StudioHub+ Digital to Analog Converter
[phone] • Fax [phone] • www.studiohub.com
AES/EBU InputTOSlink InputCoaxial Input
Analog Output
+15vG-15v
REDBLUWHT
Power Supply Connector
JU1 and Ju2
Install to connect
RJ-45 shield
to ground
DC power in +/- 15 volts DC
included
(Radio Systems Part # PS-UCUBE)
Unit can also be powered by
StudioHub+ “DC-Link” via RJ-45’s.

12
Revised 10-30-15
[phone] • Fax [phone] • www.studiohub.com
AES Output #1 AES Output #2 AES Output #3
AES Input
AES Output #4
JU1 - Ju5
Install to connect
RJ-45 shield
to ground
DC power in +9 volts DC included.
(Radio Systems Part # 16213).
Unit can also be powered by
StudioHub+ “DC-Link” via RJ-45’s
Part # MJ-DDA StudioHub+ Digital Distribution Amplifier

13
Revised 4-21-10
Part # SH-2XLRF StudioHub+ Dual XLR Female Adapter Mono/Stereo
[phone] • Fax [phone] • www.studiohub.com
Install JU3 to connect
Left XLR pin 1 to chassis ground
Install JU4 to connect
Right XLR pin 1 to chassis ground
JU1 JU2
Left Right
Install to connect
XLR Pin 1 to RJ-45 shield
StudioHub+ RJ45 “A” for mono only
or stereo operation
When programmed for stereo operation:
L & R XLR feed both RJ45’s in stereo.
When programmed for Mono Operation:
Left XLR feeds RJ45-1, pins 1 & 2 only.
Right XLR feeds RJ45-2, pins 1 & 2 only.
StudioHub+ RJ45 “B”
for stereo operation
To configure for stereo operation
JU5
JU6
JU7, JU8, JU9, JU10
To configure for mono operation
JU5
JU6
JU7, JU8, JU9, JU10
JU1 JU2 Install to connect
XLR Pin 1 to RJ-45
power ground (RJ-45 pin 4)
RJ45 shield and ground select jumpers
XLR PIN1 select jumper
8
7
6
5
4
3
2
1
21
3
21
3
8
7
6
5
4
3
2
1
21
3
8
7
6
5
4
3
2
1
Left
XLR
Right
XLR
Left
XLR
RJ-45 #1
CHASSIS
GROUND
RJ-45 #2
JU1
JU2
RJ-45 #1
8
7
6
5
4
3
2
1
21
3
Right
XLR
RJ-45 #2
8
7
6
5
4
3
2
1
21
3
21
3
8
7
6
5
4
3
2
1
Left
XLR
Right
XLR
CHASSIS
GROUND
RJ-45 #2
JU3
JU1
RJ-45 #1
JU2
JU4
CHASSIS
GROUND
CHASSIS
GROUND
JU3
JU1
JU4
JU2
CHASSIS
GROUND
CHASSIS
GROUND
CHASSIS
GROUND
CHASSIS
GROUND
CHASSIS
GROUND
8
7
6
5
4
3
2
1
21
3
21
3
8
7
6
5
4
3
2
1
21
3
8
7
6
5
4
3
2
1
Left
XLR
Right
XLR
Left
XLR
RJ-45 #1
CHASSIS
GROUND
RJ-45 #2
JU1
JU2
RJ-45 #1
8
7
6
5
4
3
2
1
21
3
Right
XLR
RJ-45 #2
8
7
6
5
4
3
2
1
21
3
21
3
8
7
6
5
4
3
2
1
Left
XLR
Right
XLR
CHASSIS
GROUND
RJ-45 #2
JU3
JU1
RJ-45 #1
JU2
JU4
CHASSIS
GROUND
CHASSIS
GROUND
JU3
JU1
JU4
JU2
CHASSIS
GROUND
CHASSIS
GROUND
CHASSIS
GROUND
CHASSIS
GROUND
CHASSIS
GROUND

14
Revised 4-21-10
Part # SH-2XLRM StudioHub+ Dual XLR Male Adapter Mono/Stereo
[phone] • Fax [phone] • www.studiohub.com
StudioHub+ RJ45 “A” for mono only
or stereo operation
When programmed for stereo operation:
L & R XLR feed both RJ45’s in stereo.
When programmed for mono operation:
Left XLR feeds RJ45-1, pins 1 & 2 only.
Right XLR feeds RJ45-2, pins 1 & 2 only.
StudioHub+ RJ45 “B”
for stereo operation
To configure for stereo operation
JU5
JU6
JU7, JU8, JU9, JU10
To configure for mono operation
JU5
JU6
JU7, JU8, JU9, JU10
8
7
6
5
4
3
2
1
21
3
21
3
8
7
6
5
4
3
2
1
21
3
8
7
6
5
4
3
2
1
Left
XLR
Right
XLR
Left
XLR
RJ-45 #1
CHASSIS
GROUND
RJ-45 #2
JU1
JU2
RJ-45 #1
8
7
6
5
4
3
2
1
21
3
Right
XLR
RJ-45 #2
8
7
6
5
4
3
2
1
21
3
21
3
8
7
6
5
4
3
2
1
Left
XLR
Right
XLR
CHASSIS
GROUND
RJ-45 #2
JU3
JU1
RJ-45 #1
JU2
JU4
CHASSIS
GROUND
CHASSIS
GROUND
JU3
JU1
JU4
JU2
CHASSIS
GROUND
CHASSIS
GROUND
CHASSIS
GROUND
CHASSIS
GROUND
CHASSIS
GROUND
8
7
6
5
4
3
2
1
21
3
21
3
8
7
6
5
4
3
2
1
21
3
8
7
6
5
4
3
2
1
Left
XLR
Right
XLR
Left
XLR
RJ-45 #1
CHASSIS
GROUND
RJ-45 #2
JU1
JU2
RJ-45 #1
8
7
6
5
4
3
2
1
21
3
Right
XLR
RJ-45 #2
8
7
6
5
4
3
2
1
21
3
21
3
8
7
6
5
4
3
2
1
Left
XLR
Right
XLR
CHASSIS
GROUND
RJ-45 #2
JU3
JU1
RJ-45 #1
JU2
JU4
CHASSIS
GROUND
CHASSIS
GROUND
JU3
JU1
JU4
JU2
CHASSIS
GROUND
CHASSIS
GROUND
CHASSIS
GROUND
CHASSIS
GROUND
CHASSIS
GROUND
JU1 JU2
JU1 JU2
Left Right
JU1 JU2
Install to connect
XLR Pin 1 to RJ-45 shield
Install to connect XLR Pin 1
to RJ-45 power ground
(RJ-45 pin 4)
RJ45 shield and ground select jumpers
Install JU3 to connect
Left XLR pin 1 to chassis ground
Install JU4 to connect
Right XLR pin 1 to chassis ground
XLR PIN1 select jumper

15
Revised 4-21-10
Part# SH-2XLRMF StudioHub+ Dual XLR Male/Female Panel
[phone] • Fax [phone] • www.studiohub.com
RJ45-1 RJ45-2
Female XLR Male XLR
Install JU1 to connect XLR(s)
pin 1 to chassis ground
JU2
Install to connect XLR(s) pin 1
to StudioHub+ RJ45 shield
JU2
Install to connect XLR(s) pin 1
to StudioHub+ RJ45
power ground (RJ-45 pin 4)
21
3
8
7
6
5
4
3
2
1
Female
XLR
RJ-45 #1
8
7
6
5
4
3
2
1
21
3
Male
XLR
RJ-45 #2
CHASSIS
GROUND
JU1
JU2
JU1
JU2
CHASSIS
GROUND
CHASSIS
GROUND
CHASSIS
GROUND

16
Revised 4-21-10
(Note - There is a stereo only version of this product.
See www.studiohub.com/legacy.php)
ASSEMBLY 12044B
STUDIOHUB+
F XLR TO RJ45
JU4JU3
JU1
JU2
J1
J2
Part # SH-1XLRF StudioHub+ Single XLR Female Panel
[phone] • Fax [phone] • www.studiohub.com
JU1
Install to connect XLR pins to chassis ground
JU2
Install to connect XLR pins to
power ground
Install to connect XLR pin 1 to
shield ground
JU3, JU4
Install for left and right in parallel
Remove for left only
XLR

17
Revised 4-21-10
(Note - There is a stereo only version of this product.
See www.studiohub.com/legacy.php)
ASSEMBLY 12044B
STUDIOHUB+
M XLRTO RJ45
JU4JU3
JU1
JU2
J1
J2
Part # SH-1XLRM StudioHub+ Single XLR Male Panel
[phone] • Fax [phone] • www.studiohub.com
JU1
Install to connect XLR pins to chassis ground
JU2
Install to connect XLR pins to
power ground
Install to connect XLR pin 1 to
shield ground
JU3, JU4
Install for left and right in parallel
Remove for left only
XLR

Modified 6-18-14
18
Part # SH-1XLRF5Pin StudioHub+ Single XLR 5Pin Female Panel
[phone] • Fax [phone] • www.studiohub.com
JU4
Install to connect XLR pins to
XLR chassis ground
Install to connect external power
to light mic boom LED (5-15VDC)
via pins 3 & 4 on barrier
strip connector
Install to connect external power
to light mic boom LED (15VDC)
via pin 8 of RJ-45 when connected
to a standard StudioHub+ powered
Cube or Hub.
JU1, JU2
Install both jumpers to apply left
and right mic audio in parallel on
RJ-45 connector (StudioHub+
standard pins 1 & 2 for left, and
pins 3 & 6 for right). Remove both
jumpers to apply mic audio to left
channel only.
5-Pin XLR
(Mating 5-pin male in-line male
XLR connector included)
5-Pin XLR Pin Out
1 - Ground
2 - Audio +
3 - Audio –
4 - LED –
5 - +DCV
NOTE: Unused StudioHub+ RJ-45 pin 5 (CAT-5 wht/blu wire) is
connected to light mic boom LED when connected to ground
(DC voltage must be provided either via barrier strip pin 4 or
StudioHub+ pin 8. Program JU3 accordingly).
JU3
+5-15VDC
Gnd
Pull-to-Gnd to light LED
Gnd
Made for Yellowtec Mic Arms

19
Revised 4-21-10
ASSEMBLY 12362
UNBAL WORLD
GND SHLD SHLD GND
SLV
L-
R-
STUDIOHUB+
JU6
JU4
JU5
JU3
JU1 JU2
J4J3
J6
J5
J2
J1
Part # SH-1/4UNBAL StudioHub+ 1/4” & Mini TRS Panel (Unbalanced)
[phone] • Fax [phone] • www.studiohub.com
JU1 and JU2*
Install to tie StudioHub+ RJ45 right - connection to StudioHub+ shield.
Install to tie StudioHub+ RJ45 right - connection to StudioHub+ power ground.
JU3 and JU4*
Install to tie StudioHub+ RJ45 left - connection to StudioHub+ shield.
Install to tie StudioHub+ RJ45 left - connection to StudioHub+ power ground.
JU5 and JU6*
Install to tie 1/4” and mini TRS sleeve to StudioHub+ RJ45 shield.
Install to tie 1/4” and mini TRS sleeve to StudioHub+ RJ45 power ground.
*Improper use of JU1, JU2, JU3, JU4 may result in no output, excessive noise,
crosstalk, oscillation, or circuit failure.
Stereo unbalanced StudioHub+
RJ45. Signal to/from J4 and J6
Stereo unbalanced StudioHub+
RJ45. Signal to/from J3 and J5
1/4” and mini TRS J3 and J5 are in
parallel. Use only one at a time.
Stereo unbalanced 1/4”
Stereo unbalanced mini TRS
Stereo unbalanced 1/4”
Stereo unbalanced mini TRS
1/4” and mini TRS wiring
Tip = Left + StudioHub+ RJ45 connection
Ring = Right StudioHub+ RJ45 connection
Sleeve = See JU5 and JU6
1/4” and mini TRS J4 and J6 are in
parallel. Use only one at a time.
