Radiocrafts Tinymesh RC11 -TM Series User manual

RC11xx(HP)-TM
RC25xx(HP)-TM
RC17xx(HP)-TM
2016 Radiocrafts AS RC11xx(HP)/25xx(HP)/17xx(HP)-TM Data Sheet rev. 1.48 Page 1 of 86
2016 Tiny Mesh AS
Radiocrafts
Embedded Wireless Solutions
Tinymesh
TM
RF Transceiver Modules
Product Description
The RC11XX(HP) / RC25XX(HP) / RC17xx(HP)-TM RF Transceiver Modules are compact surface-
mounted high performance modules for wireless mesh networking applications. The modules feature a
fully embedded Tinymesh™ application and multi-hop protocol stack with automatic network forming
and self-healing features. The embedded Tinymesh™ application layer supports a full duplex UART,
Analogue- Pulse- and Digital inputs, as well as PWM and Digital outputs. Serial application data entered
on the UART port is transported automatically to the desired destination node without further interaction
from any external processor. The modules are completely shielded, available as Low Power, High
Power and Long Range Ultra Narrow Band versions, and pre-certified for operation in license free bands
from 169 MHz to 2.4 GHz.
Typical Applications
•Wireless Sensor Networks
•Automatic Meter Reading
•Alarm- and Security Systems
•Building Management
•Telemetry Stations
•Fleet Management
•Asset Tracking
•Street Light Control and Monitoring
Key Features
•Embedded application layer for I/O control and data collection
•Self-forming, self-healing and self-optimizing bi-directional mesh network stack
•AES 128 encryption
•Selectable Gateway, Router and low power End Device configuration
•Configurable digital I/O, PWM (Dimmer) output and analogue inputs
•Full Duplex Serial Port with handshake, streaming support and 256 byte buffer for easy
RS232/422/485 wire replacement and MODBUS RTU compatibility
•Pulse counter with configurable de-bounce time and detection feedback output
•'Walk-by' mode for low power data logging and metering applications
•RSSI and Network connect LED output control for simplified field installation
•Group-, Broadcast- or Individual addressing modes
•Clustered Node Detection and Network Congestion Avoidance (CND/NCA™)
•RF Jamming Detection and Alarm, with alarm output and network alarm messaging
•Analogue- and Digital level triggered event messages.
•Time-generated and event-triggered status messages
•Locator Function for asset tracking applications
•Network Busy Detection for ad hoc networks with multiple, roaming Gateway Devices
•Multiple Gateway support for redundancy and automatic network load sharing
•Small size (12.7 x 25.4 x 3.3 mm), shielded and optimized for SMD mounting
•No external components
•Wide supply voltage range
•RC1x40/80(HP)-TM conforms with EU R&TTE directive (EN 300 220, EN 301 489, EN 60950)
•RC119x-TM conforms with regulations for operation under FCC CFR 47 part 15
•RC117x(HP)-TM complies with G.S.R.564(E) (G.S.R.168(E)).
•RC2500(HP)-TM complies with EN 300 328 (Europe), FCC CFR 47 part 15 (US) and ARIB STD-
T66 (Japan)
•RC117x-TM and RC117xHP-TM comply to IEEE 802.15.4.g PHY mode 0 encoding when
configured for RF Data Rate 8.

RC11xx(HP)-TM
RC25xx(HP)-TM
RC17xx(HP)-TM
2016 Radiocrafts AS RC11xx(HP)/25xx(HP)/17xx(HP)-TM Data Sheet rev. 1.48 Page 2 of 86
2016 Tiny Mesh AS
Radiocrafts
Embedded Wireless Solutions
Quick Reference Data
Module version
LP
HP
Long Range,
UNB-HP
Parameter
RC1701HP-TM
RC114x
1
-TM
RC1740HP-TM RC1760HP-TM
RC117x
1
-TM
RC117xHP
1
-TM
RC118x-TM
1
RC118xHP-TM
1
RC1780HP-TM
RC119x-TM
1
RC119xHP-TM
1
RC2500-TM
RC2500HP-TM
Unit
Frequency
LP
HP
UNB-HP
169
433 - 434
424 - 447
458-468
865 – 867
865 – 867
868 - 870
868 - 870
865 - 870
902– 927
902– 927
2400 - 2483
2400 - 2483 MHz
Channels
LP
HP
UNB-HP
13
17
173 239
15
15
18
18
94
50
50
83
83
Data rate
LP
HP
UNB-HP
0.3-100
1.2 – 100
0.3-100 0.3-100
1.2 – 100
1.2 – 100
1.2 – 100
1.2 – 100
0.3 – 100
1.2 – 250
1.2 – 250
1.2 – 100
1.2 - 100 kbit/s
Max TX power
LP
HP
UNB/UNB-HP
27
11
14/27
14/27
11
27
11
27
14/27
11
27
1
18 dBm
Sensitivity
1.2/ 100 kbit/s
LP
HP
UNB-HP
-
118 /
-
102
-110 / -97
-
118 /
-
102
-
118 /
-
102
-110 / -97
-109 / -96
-110 / -97
-109 / -96
-
118 /
-
102
-110 / -97
-109 / -96
-105 / -89
-108/ -91
dBm
Supply voltage
LP
HP
UNB-HP
2.8 - 3.6
2.0 – 3.6
2.8 - 3.6 2.8 - 3.6
2.0 – 3.6
3.0 – 3.3
2.0 – 3.6
3.0 – 3.3
2.8 - 3.6
2.0 – 3.6
3.0 – 3.3
2.0 - 3.6
2.7 - 3.6 Volt
RX/ TX Current
LP
HP
UNB-HP
31/ 407
24 / 35
31/ 318+63 31/ 297+72
24 / 37
24 / 560
24 / 37
24 / 560
31/ 297+72
24 / 37
24 / 560
25 / 27
30 / 155 mA
SLEEP Current
LP
HP
UNB-HP
0.6
0.3
0.6 0.6
0.3
3.4
0.3
3.4
0.6
0.3
3.4
0.4
1.3
uA
Temp. range
LP
HP
UNB-HP
-30 to +85
-40 to +85
-30 to +85 -30 to +85
-40 to +85
-40 to +85
-40 to +85
-40 to +85
-30 to +85
-40 to +85
-40 to +85
-40 to +85
-20 to +85
°C
Typical Application Circuit
Please see additional schematic information regarding recommended Reset and Power supply filtering,
LED outputs, configurable I/O pins and how to include a firmware upgrade connector later in this
document.
1
Radiocrafts will deliver RC11x0-TM or RC11x1-TM and RC11x0HP-TM or RC11x1HP-TM depending on availability.
The versions performance is identical.

RC11xx(HP)-TM
RC25xx(HP)-TM
RC17xx(HP)-TM
2016 Radiocrafts AS RC11xx(HP)/25xx(HP)/17xx(HP)-TM Data Sheet rev. 1.48 Page 3 of 86
2016 Tiny Mesh AS
Radiocrafts
Embedded Wireless Solutions
Table of Contents
Product Description 1
Typical Applications 1
Key Features 1
Quick Reference Data 2
Typical Application Circuit 2
Table of Contents 3
Tinymesh™ Application and Protocol Stack 6
Tinymesh™ Devices 6
Gateway Device 6
Router Device 6
End Device 7
Data Integrity 7
Network Formation 7
Self-healing 7
Self-optimizing 8
Network Addressing 8
Multiple Gateway Support 8
Ad Hoc Networks and Hand Held Gateway Devices 8
Alerts and Device Triggered Events 9
Over the Air Configuration 9
Getting Started 10
How do I Form a Network? 10
How do I Transmit Data? 10
How do I Receive Data? 10
What about the Antenna? 11
How do I change the RF Channel or any other Parameter? 11
Module Pin Assignment 12
Pin Description, 11xx(HP)/ 25xx(HP) Devices 12
Pin Description, 17xx UNB devices 14
Circuit Description 16
Selecting the Right Module for Your Application 16
Indicative Module Selection Guide 16
RCTools 17
Transparent Mode Operation 18
Transparent- Versus Packet- Mode Operation 18
Transparent- and Packet Mode Functions 19
Serial Data Streaming 19
Serial Port Handshake 19
AES Encryption 20
Co-Existence with AES Encrypted and Un-Encrypted Devices 20
Sleep Mode 21
RF Jamming Detection and Alarm 21
RF Jamming Detection in Packet Mode Systems 21
Clustered Node Detection and Network Congestion Avoidance (CND/NCA™) 22
Optimizing Polled Systems 22
LED Indicators 23
LED Indicator Time-Out 23
Pulse Counter Feedback Indicator 23
RSSI Indicator LED 23
Connection Indicator LED 23
Radio RX /TX Indicator LED 24
Configuration mode indicator 24
Packet Mode Operation 25
Gateway in Packet Mode 25
Router in Packet Mode 25
Transmitting Command and Configuration Packets from Gateway 25
Group and Broadcast Addressing 25
Command Acknowledge 26
Command Packet Format 26
Transmit Serial Data Packet from Gateway 27

RC11xx(HP)-TM
RC25xx(HP)-TM
RC17xx(HP)-TM
2016 Radiocrafts AS RC11xx(HP)/25xx(HP)/17xx(HP)-TM Data Sheet rev. 1.48 Page 4 of 86
2016 Tiny Mesh AS
Radiocrafts
Embedded Wireless Solutions
Received Packet Formats 27
Practical Use of Packet Header Data 30
Device and Network Status Interrogation 30
Serial Data Block Counter 31
Locator Function 31
Network Busy Detection 31
Network ID 32
IMA On Connect Function 32
Automatic Status Reporting 32
Receive Neighbour Function 33
Input / Output Functions 34
Digital Input 34
Digital Input De-bouncing 34
Digital Input ‘Trig Hold’ 34
Pulse Counter 34
Pulse Counter De-bounce 35
Pulse Count Verification 35
Digital Output control 36
Digital Output Drive 37
PWM (Dimmer) Output 37
Analogue Input 37
Analogue Input Event Triggering 38
Setting the Analogue Input Trigger Level 38
Setting the Analogue Input Sampling Interval. 38
End Device 39
Wake Up from Pulse Counter 39
Wake Up from Digital Input 40
Wake Up from Serial Port UART 40
Wake Up from IMA Timer 40
Battery Lifetime Considerations 40
Analogue Port Sampling by End Devices 41
Module Awake Output Function 41
Fixed Destination and “Walk By” Mode 41
Receive and Transmit Timing 42
Receive RF Packet Timing 42
UART Receive and CTS Timing 43
Memory Configuration Timing 44
RF Frequencies, Output Power and Data Rates 45
Module Configuration 50
Configuration Commands 50
Configuration Mode 50
RSSI Reading (S- Command) 51
Temperature Reading (U- Command) 52
Power Supply Voltage Reading (V- Command) 52
Set Configuration Memory (M- Command) 52
Set Sleep Mode (Z-Command) 53
Alternate Set Sleep Mode (z-Command) 53
Setting and Changing the AES key (K7- Command) 53
Change Calibration Memory Command (HW- Command) 53
Calibrating the Temperature Sensor 53
Setting and Changing the Network ID (NID) 54
Setting and Changing the Fixed Destination ID (FDID) 55
RSSI Sniffer (Test Mode 5) 55
Simple Packet Sniffer (Test Mode 6) 55
Configuration Memory 57
Calibration Memory 63
Demo Board Exercises 64
Transparent Mode Communication 64
Packet Mode Serial Communication, Test and Demo 65
Packet Mode Demo: Digital Output Control, PWM Dimming and Input Trigger 66
End Device Test and Demo, Pulse Counter with Feedback 68
Antenna Connection 69
PCB Layout Recommendations 70
Mechanical Drawing 71
Mechanical Dimensions 71

RC11xx(HP)-TM
RC25xx(HP)-TM
RC17xx(HP)-TM
2016 Radiocrafts AS RC11xx(HP)/25xx(HP)/17xx(HP)-TM Data Sheet rev. 1.48 Page 5 of 86
2016 Tiny Mesh AS
Radiocrafts
Embedded Wireless Solutions
Carrier Tape and Reel Specification 71
Soldering Profile Recommendation 71
Cleaning and welding Recommendation 71
Absolute Maximum Ratings 72
Electrical Specifications 74
Regulatory Compliance Information 79
R&TTE directive (EU) 79
FCC Compliance (US, Canada) 79
WPC Compliance (India) 80
ARIB Compliance 80
Regulatory Compliance Disclaimer 80
Typical Application Circuit 81
Power Supply 83
Appendix: ASCII Table 84
Document Revision History 85
Product Status and Definitions 85
Disclaimer 85
Trademarks 86
Life Support Policy 86
Contact Information 86

RC11xx(HP)-TM
RC25xx(HP)-TM
RC17xx(HP)-TM
2016 Radiocrafts AS RC11xx(HP)/25xx(HP)/17xx(HP)-TM Data Sheet rev. 1.48 Page 6 of 86
2016 Tiny Mesh AS
Radiocrafts
Embedded Wireless Solutions
Tinymesh™ Application and Protocol Stack
The Tinymesh™ Multi-hop Wireless Mesh Network Protocol Stack is a unique set of multi-hop wireless
mesh network protocols that enable devices to send messages or transfer data to and from each other.
The embedded Application Layer contains an advanced set of configurable I/O handling mechanisms
that enable Tinymesh™ devices to be implemented in most application circuits without need for an
external MCU.
The Tinymesh™ Stack requires no external processor for establishing and maintaining the optimum
network routing path at all times.
Internet applications may connect to Tinymesh™ Wireless Mesh Network through the equally
uncomplicated Tinymesh™ Cloud Services.
Tinymesh™ Multi-hop Wireless Mesh Networks may consist of large numbers of Tinymesh™ enabled
devices or nodes where a node is one out of three types as described below. The wireless traffic
between the Tinymesh™ enabled devices follows a tree-type topology, where data transfer is up or
down in the tree structure.
A Tinymesh™ Multi-hop Wireless Mesh Network in its simplest form consists of a single Gateway and a
Router. End Devices will not perform packet routing and must connect to a Router or directly to a
Gateway. A network may be comprised of thousands of Tinymesh™ enabled devices. There may be
several Gateway devices within a network, for redundancy and automatic workload sharing.
The network addressing structure uses four-byte addressing, for a total of 4.3 billion possible unique
devices per network. The network tree structure may have a total depth 255 hops.
Tinymesh™ Devices
Any Tinymesh™ enabled device may be configured to function as Gateway, a Router or as an End
Device. Single byte configuration commands will set all relevant configuration parameters when
changing operating mode.
Gateway Device
A Tinymesh™ network must have at least one Gateway Device. The Gateway Device initiates the
network formation, and is required to keep the network alive. Gateway Devices provide the connection
between the Tinymesh™ Routers and End Devices, and an external host processor, or to a local- or
wide area network, such as the Internet.
The Tinymesh™ stack supports implementations with multiple Gateways, where additional Gateway
devices provide redundancy and data traffic load sharing.
Gateway devices support full Input / Output control capabilities, similar to Routers and End Devices.
Router Device
Router Devices are full-functioning devices with serial data UART and Input / Output capabilities. Router
Devices provide the communication path between individual Router- or End-devices, and the network

RC11xx(HP)-TM
RC25xx(HP)-TM
RC17xx(HP)-TM
2016 Radiocrafts AS RC11xx(HP)/25xx(HP)/17xx(HP)-TM Data Sheet rev. 1.48 Page 7 of 86
2016 Tiny Mesh AS
Radiocrafts
Embedded Wireless Solutions
Gateway.
Router devices must always be powered, to support routing of packets received from other devices.
End Device
A Tinymesh™END DEVICE will normally be in low power sleep mode for battery operation. End Devices
have full input- and output control capabilities, but will not accept messages for re-distribution from other
devices.
An End Device will wake up to full power mode by external stimuli, such as a digital input level shift,
serial data input, pulse counter activity or by internal clock. Wakeup conditions are selectable through
configuration settings. After waking up, the End Device will generate an Event Message or a Serial in
Message, depending on the wake-up condition. After delivering the message, the End Device will either
return directly to sleep condition, or stay awake for a settable time period, to wait for response
commands from a server or application outside the Tinymesh™ network.
Data Integrity
The Tinymesh™ stack uses several mechanisms to ensure safe and reliable data delivery with minimal
latency.
•Listen Before Talk in accordance with the harmonized EN 300 220-2 standard, to reduce
likelihood of RF traffic collision.
•Link level acknowledge on all packet deliveries for positive confirmation of data reception.
•Packet retransmission on missing acknowledge
•Format, data validity and CRC control on check on packet reception
•AES 128 encryption
•Packet duplicate check
•Housekeeping mechanisms to eliminate stray packets that are either too old or have hopped to
many times
•Unique numbering of packets to allow duplicate and sequence control by external applications
•Application level command acknowledge to verify and validate command reception.
•Unique timing mechanisms to handle network congestion
Network Formation
A Tinymesh™ Multi-hop Wireless Mesh Network is self-forming, created by Gateway units starting to
invite Routers and End Devices within RF range to join in the network. A Router joins the network after
verifying the invitation, and immediately starts inviting new nodes to join. Within seconds of powering up
the Gateway, a large network may be created automatically.
Gateway and connected Router devices send periodic beacon packets to indicate presence and
availability for connection. Tinymesh™ beacon packets, referenced as HIAM packets, contain
information of device address (UID), System Identity (SID), Radio Frequency Channel and device
Network Level (Hop Level).
Routers and End Devices receive and evaluate connection alternatives by comparing hop level- and
received signal strength of HIAM packets on selectable time intervals (Connect Check Time)
Self-healing
Devices in Tinymesh™ networks continuously evaluate alternate connections by comparing the hop
level and signal strength of received HIAM packets. In cases where the primary communication link
becomes unresponsive, the device will automatically change to the alternate routing if such routing is
available.
If the alternate routing is also unresponsive, the device will enter a state where it searches for new
routing possibilities.
Data received by the device, and event data generated by the device will be stored in the internal device
buffers until a valid connection has been established.

RC11xx(HP)-TM
RC25xx(HP)-TM
RC17xx(HP)-TM
2016 Radiocrafts AS RC11xx(HP)/25xx(HP)/17xx(HP)-TM Data Sheet rev. 1.48 Page 8 of 86
2016 Tiny Mesh AS
Radiocrafts
Embedded Wireless Solutions
Self-optimizing
The communication path offering the least number of hops and the highest link quality is always
selected as the primary connection for data delivery. A network optimization process runs continuously
as a background task in all Tinymesh™ devices.
In changing environments with changing link quality, Tinymesh™ networks dynamically adapt to find
optimum routing.
Network Addressing
Tinymesh™ networks utilize a flexible addressing scheme with 4 bytes System address (SID) and 4
bytes for unique device addressing (UID).
The four byte System ID identifies a local network in the same way as a PAN address. All devices in a
local mesh must share the same four-byte SID.
Every Gateway, Router, and End Device belonging to a local mesh network must have unique UIDs.
Duplicate UIDs will cause network instability, lost packets and connection issues.
A separate 4-byte Network Address is applied to uniquely distinguish local mesh networks sharing a
common platform in a cloud- or server controlled environment where local mesh networks may be
deployed with similar SID.
The Tinymesh™ Stack supports unique, group and broadcast addressing of individual devices. Routers
and End Devices may be assigned to addressing groups, by entering up to eight different single-byte
group identifier addresses.
Multiple Gateway Support
Tinymesh™ networks support multiple Gateway devices operating within the same local mesh. In mesh
networks with a single Gateway, the Gateway becomes a critical point for system reliability. In a
Tinymesh™ network, additional Gateways may be added at any point in time to provide redundancy on
the Gateway level.
Adding Gateway devices to a local mesh also improves data throughput and network capacity, as the
additional Gateway devices will automatically load share the upstream data traffic from for instance a
large data collection or sensor network.
Systems with multiple gateways must be controlled by a common server or cloud platform, such as
Tinymesh™ Cloud Services. Data originating from Router- or End Devices will automatically be routed
through the mesh to the Gateway device that provides the least number of hops and the best signal
strength. If two or more Gateway devices offer the same number of hops and equally good signal
strength, for instance if the two Gateway devices are located near to each other, the packet will be
delivered to the Gateway device that is currently available. The server platform will use the device UID
to identify the packet origin, and the packet number contained in the packet header to verify uniqueness.
Commands (downstream data traffic) in multiple Gateway systems should as a rule be entered to all
Gateway devices, to ensure reliable delivery.
Systems where the Gateway devices are located close by each other, offer an exception to this rule.
This will be systems where two or more Gateway devices provide redundancy and added throughput,
and where the distance between the individual Gateway devices is less than the distance to the closest
Router device. A single Gateway may be selected to dispatch commands in such configurations.
Ad Hoc Networks and Hand Held Gateway Devices
Local mesh systems that are created ‘ad hoc’ by turning on a portable Gateway device such as a
portable CMRI used for data collection in automated metering systems will be formed as a web with the
portable Gateway in the centre of the mesh network.
Because there is no fixed rule to where a Gateway device is located, or when the mesh is created, there
needs to be mechanisms in place to ensure there is only one Gateway device downloading from the
mesh at a given time.
A configurable parameter in a Tinymesh™ Gateway device provides a mechanism for the Gateway to
detect if a network is already present when the portable Gateway is powered up. Depending on the
device configuration, the Gateway device will either refuse connection, provide an alert, or ignore the

RC11xx(HP)-TM
RC25xx(HP)-TM
RC17xx(HP)-TM
2016 Radiocrafts AS RC11xx(HP)/25xx(HP)/17xx(HP)-TM Data Sheet rev. 1.48 Page 9 of 86
2016 Tiny Mesh AS
Radiocrafts
Embedded Wireless Solutions
presence of the other Gateway that is controlling the mesh.
If a portable Gateway device is configured to ignore the presence of an existing mesh, a portable device
may be used to temporarily connect to a device that is already connected to a stationary Gateway
device. This function could be used in automatic metering systems with permanently installed data
collection units (DCU), for individual interrogation or downloading of data directly to a portable device.
The portable device must share the same System ID as the permanent Gateway, and must have unique
UID. When turning on the portable device, the portable Gateway will connect to the closest Router
devices and act as a secondary gateway in the system.
The portable device may interrogate the connected mesh to detect which Router devices have made
connection.
After switching off the portable device, the mesh will automatically reconfigure with the permanent DCU
as the preferred Gateway.
Alerts and Device Triggered Events
The application layer in the Tinymesh™ stack supports automatic alerts and triggered events from
multiple, configurable sources, eliminating the need for traditional status polling as known from wired
multi-drop systems.
•Timer triggered status reporting, with time intervals from seconds to days
•Digital input status change, with configurable de-bounce and edge detection
•Analogue level change, with configurable hysteresis, trigger conditions and sample interval
•Power On detection
•Serial data input
•Radio Frequency Jamming detection
Over the Air Configuration
Gateway, Router, and End devices may be reconfigured at any time, even after system deployment. The
flexible format configuration command allows setting of any addressable location in the device
configuration memory.
Remote reconfiguration capability is a valuable feature for system maintenance and service. Any
configurable function, from changing the de-bounce time for digital input detection, to altering the radio
frequency channel may be changed over the air.
A special two-step mechanism protects the most sensitive configuration parameters that may cause a
device to lose network connection.

RC11xx(HP)-TM
RC25xx(HP)-TM
RC17xx(HP)-TM
2016 Radiocrafts AS RC11xx(HP)/25xx(HP)/17xx(HP)-TM Data Sheet rev. 1.48 Page 10 of 86
2016 Tiny Mesh AS
Radiocrafts
Embedded Wireless Solutions
Getting Started
A simple Tinymesh™ network may be formed by configuring at least one module as a Gateway (SET
GATEWAY MODE command).
Make sure the Gateway and all Routers have different Unique ID, but same System ID. This is
mandatory for successful self-forming of the network.
Modules are delivered with default setting 'Router', and with non- identical Unique IDs.
How do I Form a Network?
Power up the nodes in any random sequence.
The Gateway Device starts inviting neighbouring nodes to become members of the network. The
Gateway Device will flash the RSSI/ TX LED (Red LED on Demo Board) every time a network invite
beacon (HIAM) is transmitted.
The RSSI/ TX LED on nodes configured as Router devices (default configuration) will start flashing in a
slow pattern, indicating the node is alive and listening, but not connected to the network.
Router devices within acceptable radio range of the Gateway, will detect the invite beacons from the
Gateway. If the received signal strength (RSSI) is within predetermined limits of acceptable signal
strength, the Router Device will attempt connecting to the Gateway by sending an invite response. If the
Gateway properly accepts the invite response, the Router has successfully joined the network, and will
signal its new status by changing the LED flash pattern. The red RSSI Indicator LED now reflects the
RSSI level of the established connection, and the yellow CONNECTION/ RX LED indicator starts flashing
to indicate successful connection.
All Routers that successfully connect to the network will immediately start inviting new Routers to join
the network, forming the next level of connected nodes. New Routers will again start inviting the next
level of Routers, automatically propagating the network to encompass all Routers with identical System
ID that are within radio range of at least one other Router or Gateway in the same network.
No external processing effort in the terms of a network organizer, controller PC or micro controller is
required, as each node actively and autonomously participates in the forming of the RF network.
How do I Transmit Data?
This chapter refers to the most easy-to-use mode, the default mode named “transparent” for
transparent, bidirectional data transfer.
Send your data to the RXD pin on the module. Use the UART format with default settings (19200, 8, 1,
N, no flow control). Up to 120 payload bytes are buffered in the module. The module will transmit the
data when
•the maximum packet length is reached (120 bytes)
•the modem time-out limit is reached (default 20 ms)
Modules will by default use the UART CTS signal to indicate when data may be entered. Routers will
hold CTS high when the UART receive buffer is full. After successful connection to a network and
delivery of the current contents of the UART buffer, CTS will go low, indicating the node is ready to
receive data. CTS will remain low until the data buffer is full, or a byte-to-byte time out has occurred.
CTS will then go high, indicating no more data may be entered. As soon as the data packet has been
successfully transmitted and the data buffer is emptied, CTS will return low, to indicate new data may be
entered.
Data may be entered in binary format, any byte value with proper start- and stop bit is accepted. The
time-out limit is configurable in-circuit by changing the SERIAL PORT TIME OUT parameter in
Configuration memory. Default setting is 20 ms.
How do I Receive Data?
Any data entered at the Gateway (while CTS is low), will be delivered to all Routers that are connected
to the network. Received RF data with correct check sum will be presented on the TXD pin of all
Router(s).
Data entered at any Router Device (while CTS is low), will be delivered to the Gateway and presented
on the Gateway TXD pin.

RC11xx(HP)-TM
RC25xx(HP)-TM
RC17xx(HP)-TM
2016 Radiocrafts AS RC11xx(HP)/25xx(HP)/17xx(HP)-TM Data Sheet rev. 1.48 Page 11 of 86
2016 Tiny Mesh AS
Radiocrafts
Embedded Wireless Solutions
What about the Antenna?
In most cases, a simple quarter wavelength wire or a PCB track will do. Connect a piece of wire to the
RF pin with length corresponding to the quarter of a wavelength. When space is limited, contact
Radiocrafts for recommendations for the best antenna solution for your application.
How do I change the RF Channel or any other Parameter?
Configurable parameters such as RF Channel, RF Power or RF Data Rate, are stored in non-volatile
memory in the module. There are principally two different ways for changing these parameters. The
module must either be entered into CONFIGURATION MODE, for direct input of new parameters on the
serial port, or new parameter values may be dispatched to a module in a live mesh network by issuing
the SET CONFIGURATION command.
Please see MODULE CONFIGURATION for details.

RC11xx(HP)-TM
RC25xx(HP)-TM
RC17xx(HP)-TM
2016 Radiocrafts AS RC11xx(HP)/25xx(HP)/17xx(HP)-TM Data Sheet rev. 1.48 Page 12 of 86
2016 Tiny Mesh AS
Radiocrafts
Embedded Wireless Solutions
Module Pin Assignment
Pin Description, RC11xx(HP)/ RC25xx(HP) Devices
Pin no Pin name Pin type Description Equivalent circuit
1 GND System ground
2 CTS / RXTX Output UART CTS or RTX Active Low
3 RTS / SLEEP Input UART RTS or Module Sleep
2
4 CONFIG Input Configuration Enable. Active low.
Should normally be set high
3
.
5 TXD Output UART TX Data
6 RXD Input UART RX Data.
Use external max 8k2 pull-up resistor
if connected to an open collector
output from a host MCU or other high
impedance circuitry like level
shifters.
4
Never leave RXD-pin floating.
7 GND System ground
8 GND System ground
9 RF RF I/O connection to antenna
10 GND System ground
11 NC Not connected
2
The internal pull-up is disabled when configured for SLEEP function.
3
The internal pull-up is disabled when the SET SLEEP MODE (Z-COMMAND) command has been used to enter
sleep mode
4
For UART communication, the TXD and RXD are used for serial data, and CTS for flow control.
RXD must be high when not sending data to the module.

RC11xx(HP)-TM
RC25xx(HP)-TM
RC17xx(HP)-TM
2016 Radiocrafts AS RC11xx(HP)/25xx(HP)/17xx(HP)-TM Data Sheet rev. 1.48 Page 13 of 86
2016 Tiny Mesh AS
Radiocrafts
Embedded Wireless Solutions
12 RESET Input Main reset (active low). Should
normally be left open. Internal 12 k
pull-up resistor.
13 VCC Supply voltage input. Internally
regulated.
14 GND System ground
15,16 GPIO 0-GPIO 1 Digital In / out
Analogue In
Individually configurable as digital
input / output or
analogue Input (Internal pull-up
disabled)
Digital Input/ output, Ref pins 2-
6
20 GPIO 2-GPIO 6 Digital In / out Individually configurable as digital
input / output
Ref pins 2-6
21 Pulse Counter Input Pulse Counter Ref pins 2-6
22,26,
25,24
GPIO 3-GPIO 6 Digital In / out Individually configurable as digital
input / output
Ref pins 2-6
23 GPIO 7 Digital In / out
PWM out
Configurable as digital input / output
or PWM output
Ref pins 2-6
17-19,
21, 27,
28
RESERVED Test pins or pins reserved for future
use. Do not connect!
29 RSSI/ TX LED Output Direct LED drive output.
Flash pattern given for current
sourcing:
Flash frequency indicates network
connection RSSI level for Routers
and End Devices.
Flash indicates RF TX activity for
Gateway Devices.
30 Connection/ RX
LED
Output Direct LED drive output.
Flash pattern given for current
sourcing:
Flash frequency indicates network
connection redundancy for Routers
and End Devices.
Flash indicates RF RX (received
packets) for Gateway Devices

RC11xx(HP)-TM
RC25xx(HP)-TM
RC17xx(HP)-TM
2016 Radiocrafts AS RC11xx(HP)/25xx(HP)/17xx(HP)-TM Data Sheet rev. 1.48 Page 14 of 86
2016 Tiny Mesh AS
Radiocrafts
Embedded Wireless Solutions
Pin Description, RC17xx Devices
Pin no Pin name Pin type Description Equivalent circuit
1 GND System ground
2 CTS / RXTX Output UART CTS or RTX Active Low
3 RTS / SLEEP Input UART RTS or Module Sleep
5
4 CONFIG Input Configuration Enable. Active low.
Should normally be set high
6
.
5 TXD Output UART TX Data
6 RXD Input UART RX Data.
Use external max 8k2 pull-up resistor
if connected to an open collector
output from a host MCU or other high
impedance circuitry like level
shifters.
7
Never leave RXD-pin floating.
7 GND System ground
8 GND System ground
9 RF RF I/O connection to antenna
10 GND System ground
11 NC Not connected
12 RESET Input Main reset (active low). Should
normally be left open. Internal 12 k
pull-up resistor.
5
The internal pull-up is disabled when configured for SLEEP function.
6
The internal pull-up is disabled when the SET SLEEP MODE (Z-COMMAND) command has been used to enter
sleep mode
7
For UART communication, the TXD and RXD are used for serial data, and CTS for flow control.
RXD must be high when not sending data to the module.

RC11xx(HP)-TM
RC25xx(HP)-TM
RC17xx(HP)-TM
2016 Radiocrafts AS RC11xx(HP)/25xx(HP)/17xx(HP)-TM Data Sheet rev. 1.48 Page 15 of 86
2016 Tiny Mesh AS
Radiocrafts
Embedded Wireless Solutions
13 VCC Supply voltage input. Internally
regulated.
14 GND System ground
15,16 GPIO 0-GPIO 1 Digital In / out
Analogue In
Individually configurable as digital
input / output or
analogue Input (Internal pull-up
disabled)
Digital Input/ output, Ref pins 2-
6
17,
18,19,
20,22,
26
GPIO 2-GPIO 7, Digital In / out Individually configurable as digital
input / output
Ref pins 2-6
21 Pulse Counter Digital Input Pulse Counter Ref pins 2-6
29 RSSI/ TX LED Output Direct LED drive output.
Flash pattern given for current
sourcing:
Flash frequency indicates network
connection RSSI level for Routers
and End Devices
Flash indicates RF TX activity for
Gateway Devices
30 Connection/ RX
LED Output
Direct LED drive output (source).
Flash pattern given for current
sourcing:
Flash frequency indicates network
connection redundancy for Routers
and End Devices.
Flash indicates RF RX (received
packets) for Gateway Devices
41 VCC_PA Supply voltage
input for Power
Amplifier stage
Connect to 5V or VCC for
RC17x0HP, and leave open for
RC17xx.
When VCC_PA is connected to VCC
(3.3V) for RC17x0HP, the max output
power is limited to +24 dBm.
For RC1701HP, the VCC_PA has the
same voltage range as VCC, and
supports +27 dBm at 3.3 V.
23,24,
25,27,
28,31,
32,33,
34,35,
36,37,
38,39,
40,42
RESERVED Test pins or pins reserved for future
use. Do not connect!

RC11xx(HP)-TM
RC25xx(HP)-TM
RC17xx(HP)-TM
2016 Radiocrafts AS RC11xx(HP)/25xx(HP)/17xx(HP)-TM Data Sheet rev. 1.48 Page 16 of 86
2016 Tiny Mesh AS
Radiocrafts
Embedded Wireless Solutions
Circuit Description
The Tinymesh™ module contains a communications controller with embedded Tinymesh™ protocol
stack firmware, a high performance RF transceiver and an internal voltage regulator.
The communications controller handles the radio packet protocol, the UART interface and controls the
RF transceiver. Data to be sent by the host is received at the RXD pin and buffered in the
communications controller. The data packet is then assembled with preamble, start-of-frame delimiter
(SOF), network routing information and CRC check sum before it is transmitted on RF.
The RF transceiver modulates the data to be transmitted on RF frequency, and demodulates data that
are received. Received data are checked for correct address and CRC by the communication controller.
If the address matches the module's own address, and no CRC errors were detected, the data packet is
acknowledged before re-transmitted.
The asynchronous UART interface consists of RXD, TXD, RTS and CTS. The CTS output will be TRUE
LOW when the module is ready to receive data. CTS must be monitored on a byte-by-byte basis to
avoid losing data when the default CTS handshake configuration is enabled.
When the CONFIG pin is pulled low, the communications controller interprets data received on the RXD
pin as configuration commands. There are commands to change the radio channel, the output power,
the RF Data Rate etc. Configuration parameters are stored in non-volatile memory. For a full overview of
configuration commands, please see MODULE CONFIGURATION
Selecting the Right Module for Your Application
Radiocrafts modules with embedded Tinymesh™ Protocol Stack are available for all the international
license free frequency bands, in two different selections of output power, and as high performance, long
range Ultra Narrow Band version. As new members are added to the Radiocrafts family of modules, the
Tinymesh™ Stack will be introduced on the new platforms.
All Radiocrafts modules are fully tested and footprint-compatible, allowing equipment manufacturers to
use the same electronics design for several markets and varying applications.
The inherent capability to select and configure communications parameters in the protocol stack
provides an unsurpassed level of flexibility in adapting the design to the application requirements.
The right module for your application may be selected from a decision matrix weighting the importance
of radio range coverage, RF compliance requirements, customer requirements, hardware cost and
available power supply limitations.
Note: High- and Low power modules should not be mixed in the same network, unless the output power
settings for all modules are limited to the same dBm level.
Transmission from the higher powered module may be received by the lower powered module, while the
high powered module will not be able to detect transmission from the low power device.
End Devices or Router Devices configured to transmit in
FIXED DESTINATION AN
D
“Walk By” Mode
represent an exception to the rule, as these devices will transmit without expecting a response (ACK)
and hence will not require a balanced connection link.
Indicative Module Selection Guide
Lower RF frequency Higher RF frequency

RC11xx(HP)-TM
RC25xx(HP)-TM
RC17xx(HP)-TM
2016 Radiocrafts AS RC11xx(HP)/25xx(HP)/17xx(HP)-TM Data Sheet rev. 1.48 Page 17 of 86
2016 Tiny Mesh AS
Radiocrafts
Embedded Wireless Solutions
Lower RF frequency Higher RF frequency
Improved communication range
Theoretical Range is approximately inversely
proportional to RF frequency. (Double frequency =
half range)
Lower dependency on direct Line of Sight
between devices
Shorter and less space demanding antenna
2.4 GHz is license free band in many countries
and regions.
Low Power (standard) Module High Power (HP) Module
Low Transmit power, simplified power supply
design.
Best price performance
Better range, theoretical range improvement
approximately double range per+6 dB increase in
output power.
Long Range Ultra Narrow Band (RC17xx) Wide Band (RC11xx/ RC25xx)
High performance, high selectivity radio
Excellent long range and performance
Good performance, good range
Best price
RCTools
RCTools is a powerful and easy to use PC suite that helps you during test, development and
deployment of the RC11XX(HP) / 25XX(HP)-TM. The tools may be used for both configuration and
communication testing. Visit www.radiocrafts.com for a free download and full documentation.

RC11xx(HP)-TM
RC25xx(HP)-TM
RC17xx(HP)-TM
2016 Radiocrafts AS RC11xx(HP)/25xx(HP)/17xx(HP)-TM Data Sheet rev. 1.48 Page 18 of 86
2016 Tiny Mesh AS
Radiocrafts
Embedded Wireless Solutions
Transparent Mode Operation
The default, factory setting for Tinymesh™ Gateway modules, is transparent mode, well suited for
applications requiring serial data transmission only. In transparent mode, UART data entered at the
Gateway, will be received by all Routers in the network, and will be output by the Router module UARTs
without any changes. The addressing must be handled by the host MCU application.
Data input to a Router or End Device UART will be transported 'transparently' to the network Gateway
Device and delivered unchanged by the Gateway Device UART.
Regardless of device type (Gateway or Router), the serial port UART is ready to receive data when the
CTS output is low, or when the Xon character has been received from the UART. RF transmission will
automatically be triggered on serial buffer full or character time-out on the serial port. The connected
host MCU should always observe the selected handshake status (CTS or Xon/Xoff) before sending any
data, to avoid losing data.
Transparent- Versus Packet- Mode Operation
When configured for PACKET MODE OPERATION, the Gateway Device may be used for controlling
Inputs- and Outputs in individual Routers and End- Devices.
Analogue and digital input monitoring, digital and PWM output control, and timed or event triggered
messages are available through Packet Mode operation.
Gateway Commands may be addressed to individual devices, to groups of devices, or may be
broadcast to all devices within a network.
Serial data entered and received at the Gateway will contain extra bytes for addressing, command and
control.

RC11xx(HP)-TM
RC25xx(HP)-TM
RC17xx(HP)-TM
2016 Radiocrafts AS RC11xx(HP)/25xx(HP)/17xx(HP)-TM Data Sheet rev. 1.48 Page 19 of 86
2016 Tiny Mesh AS
Radiocrafts
Embedded Wireless Solutions
Transparent- and Packet Mode Functions
Serial Data Streaming
When streaming serial data from a Router Device or from a Gateway Device in Transparent Mode, the
data stream will automatically be divided into correctly sized Tinymesh
TM
RF packets before data is
transmitted in the mesh network. The Serial Data Input Buffer has a capacity of 256 bytes, allowing for
e.g. a complete MODBUS RTU packet to be received.
The Tinymesh™ module will signal a full buffer condition by setting the CTS output high, or by issuing
an Xoff character, as configured by the UART FLOW CONTROL parameter. The SERIAL BUFFER FULL
MARGIN parameter provides for an adjustable margin from the buffer full condition is signalled, until the
Serial Data Input Buffer overflows. The default setting of the SERIAL BUFFER FULL MARGIN parameter is
18 bytes, allowing the host MCU a margin of some additional bytes that may be transmitted before the
Serial Data Input Buffer in the module runs full. The default value of 18 bytes has been chosen to
optimize packet sizes when streaming data. Most host systems and terminal emulators will be able to
respond to the 'CTS off' status within the time needed to transmit two bytes. At this point, there will be
240 bytes received in the Serial Data Input Buffer, which is the maximum size of two full Tinymesh™ RF
packets.
The host MCU should stop transmitting data as soon as possible after detecting CTS off, or after
receiving the Xoff character. After a time period of a few milliseconds, as determined by the SERIAL
PORT TIME OUT parameter, the Tinymesh™ module will start forming new RF packets from the received
data, and initiate RF transmission.
If the serial data stream does not stop after the module has signalled the 'buffer full' condition, The
Tinymesh
TM
protocol stack will prepare the data for RF transmission immediately after a data buffer
completely full condition is present (256 bytes).
Note: Subsequent data delivered to the UART will then be lost if the data stream continues before the
module Serial Data Input Buffer is again available.
After successful transmission of the received data, the module will signal to the external MCU that the
Serial Data Input Buffer is again available, by setting the hardware handshake CTS signal low, or by
transmitting an Xon character.
Serial Port Handshake
The Gateway and Router serial ports (UARTs) offer several optional handshake settings to support
reliable connections to an external host controller. The different settings are available by changing the
UART FLOW CONTROL parameter in CONFIGURATION MEMORY.
The UART FLOW CONTROL parameter is a bitmap of control mechanisms that may be individually
enabled by setting the corresponding bit. To combine settings, add the values in the 'Bit Value' column
and enter the sum value into the UART FLOW CONTROL parameter in CONFIGURATION MEMORY.
Bit
No
Bit
Val-
ue
De
-
fault
Name
Applies
to
Function
0 1 1 CTS Router
and
Gateway
The CTS control signal will be low when the module is ready to receive
data. The external host should monitor the CTS line before transmitting
any data, as the module will discard data received while CTS is high.
The SERIAL BUFFER FULL MARGIN parameter in Configuration Memory
may be used to set CTS off a number of bytes before the buffer is
completely full, thereby allowing the host system time to respond to the
CTS off situation. This function is important when for instance using
hardware handshake on a system with USB serial ports.
1 2 0 RTS Gateway The RTS control signal may be used by an external host to signal that the
host is ready to receive data. When enabled, the module will observe the
RTS line before transmitting any byte. No data will be transmitted while
RTS is high.
Note: If RTS is enabled, and the host does not set RTS TRUE (Low), a
connected Gateway Device will not be able to deliver data, and
consequently the Gateway will not receive data from the mesh network.
The mesh network will disconnect.
2 4 0 RXTX Router
and
The RXTX mode is provided for direction control of RS485 drivers. When
RXTX is enabled, the module UART will set CTS HIGH during data

RC11xx(HP)-TM
RC25xx(HP)-TM
RC17xx(HP)-TM
2016 Radiocrafts AS RC11xx(HP)/25xx(HP)/17xx(HP)-TM Data Sheet rev. 1.48 Page 20 of 86
2016 Tiny Mesh AS
Radiocrafts
Embedded Wireless Solutions
Bit
No
Bit
Val-
ue
De
-
fault
Name
Applies
to
Function
Gateway transmission.
CTS will be driven high immediately before the first start-bit is transmitted,
and will return low immediately following the last stop bit from the UART.
3 8 0 Xon/Xoff Router
and
Gateway
When the Xon/ Xoff function is enabled, the module UART will transmit an
Xoff character (Value 0x13, ASCII DC3) a settable number of bytes
(SERIAL BUFFER FULL MARGIN) before the buffer runs full. The external
host MCU should then halt further data transfer until an Xon (0x11, ASCII
DC1) character has been received. An Xon character will be transmitted
continuously at 1 second intervals while the module is ready to receive
data.
The Gateway Device will only support Xon/ Xoff when in transparent
mode. Please also note that binary data transfer will not work with Xon/
Xoff, as the binary data may contain the Xon / Xoff characters.
4 16 0 ACK/
NAK
Gateway When enabled, the Gateway Device will answer any received data on the
serial port with a COMMAND RECEIVED AND EXECUTED or a
COMMAND REJECTED, NOT EXECUTED message. In this mode, the
Gateway will do a format- and validity control of received commands
before transmitting in the RF mesh network.
The MESSAGE DATA MSB will contain the user selected Command
Number.
If the packet is not accepted by the Gateway Device, the MESSAGE DATA
LSB in the returned COMMAND REJECTED, NOT EXECUTED message
will indicate why the packet was not accepted.
5 32 0 Wait For
ACK
Gateway When enabled, the Gateway Device will expect an ACK character (0x06,
ASCII ACK) response to any packet delivered to the host. If the ACK is not
received within a 1second time frame, the packet will be repeated until a
valid response has been received.
6 64 Reserved
7
128
Reserved
AES Encryption
Changing the SECURITY LEVEL parameter in CONFIGURATION MEMORY will enable automatic AES data
encryption. When AES encryption is enabled, the payload portion of all RF data packets are encrypted
using the 128 bit AES encryption algorithm.
The Gateway and Router Device must share a common AES key, settable by the SETTING AND
CHANGING THE AES KEY (K7- COMMAND).
The encryption key is stored in a hidden and secure memory location.
The AES key is retained even after an @TM factory reset command.
Encrypted and unencrypted Router Devices may co-exist and will connect to a common network. A
Gateway Device will be able to receive data from encrypted, as well as unencrypted, Router Devices,
but an unencrypted Router Device will not be able to receive and interpret encrypted commands.
Co-Existence with AES Encrypted and Un-Encrypted Devices
Nodes with encryption enabled, may co-exist with unencrypted nodes in a common system. Encrypted
data packets are slightly larger than unencrypted packets. SECURITY LEVEL 2 (Compatible mode) is
provided for backwards compatibility to field deployed systems where encryption has not been enabled.
In systems with a mixture of encrypted and unencrypted nodes, the following rules will apply:
•Encrypted packets will be transported by unencrypted nodes to their final destination.
•Un-encrypted packets will be transported by encrypted nodes to their final destination.
•Encrypted nodes will not accept receipt of unencrypted packets (commands or serial out
packets)
•Un-encrypted nodes will not accept receipt of encrypted packets (commands or serial out
packets)
•An encrypted Gateway will accept and decrypt messages from encrypted nodes, as well as
accept data packets from unencrypted nodes.
•An un-encrypted Gateway will only accept messages from un-encrypted nodes.
