INTRODUCTION
Welcome to wireless networking. The RadioLAN PCI CardLINK™adapter allows you to connect a PC
with a 32-bit PCI slot to a RadioLAN wireless network. RadioLAN wireless networks allow network
stations to access shared network resources using a full 10Mbps connection, without typical
cabling requirements.
The RadioLAN PCI CardLINK comes with NDIS 4 and NDIS 5 drivers to support the following
Microsoft Operating Systems:
• Windows 95™B or later
• Windows NT™4.0 SP3 or later
• Windows 98™
• Windows 2000™
Installation procedures for each of the above operating systems are explained later.
The PCI CardLINK also comes with RadioNET™Manager, RadioLAN’s powerful network connection
application.
RadioNET Manager manages network stations, enabling them to function at an optimum level. You
can also track and test the quality of communications within a network. With RadioNET Manager
you can:
• View detailed information for a specific station
• View several stations at once
• Modify station name
• Modify station Subnet ID
• Enable optional features, like encryption
• Identify access type for each station
• Test individual stations to determine success/failure rate of transmissions
• Test the communication connection between stations
CAUTIONS
•This adapter requires PCI 2.2 BIOS support. Many of the latest PCI 2.1 BIOS PCs support PCI 2.2
functions. If the adapter is not working, you may need a BIOS update from your PC
Manufacturer.
• Do not try to use this adapter across a PCI to PCI Bridge. This is not supported and will not
work. Only use the PCI CardLINK in a primary bus PCI slot. Consult your PC’s documentation to
determine if any slots are across a bridge. Generally, if there are 4 PCI slots or less, then all are
primary slots.
• Do not remove the PCMCIA card from the PCI CardLINK adapter and try to use it in a laptop. This
configuration is not supported and voids the warranty.
SYSTEM REQUIREMENTS
To use RadioNET Manager on a station, computers must meet or exceed the following requirements:
• IBM™-compatible 486 or greater
• 16Mb of RAM
• CD-ROM drive
• Hard disk drive with 2Mb of available space
WHAT TOKNOW FIRST
SECTION 1:
2

RANGE OF OPERATION
Within the data range, a station can exchange information at full Ethernet speeds. For best opera-
tion, RadioLAN recommends that you locate all stations within a 120-foot circular area (see Figure
