RADLEY 1262-300 User manual

3 Year Limited Warranty on tool
JD2441U

1
2.2 AMP 1/4 SHEET PALM SANDER
Rating 120V, 60 Hz AC
Amperes 2.2 A
Speed 15,000 OPM (no load)
Sanding pad size 1/4 sheet
Sanding pad size 2.50 lbs.(1.18kg)
NEED ASSISTANCE?
Call us on our toll-free customer support line:
(Monday through Friday 9am – 5pm Eastern Standard Time)
•Technical questions
•Replacement parts
•Parts missing from package

1262-300
2.2 AMP 1/4 SHEET PALM SANDER
2
...........................................................................................................1
Table Of Content.................................................................................................................... 2
General Safety Warning ...................................................................................................
Eye, Ear & Lung Protection ................................................................................................... 3
Electrical Safety..................................................................................................................... 4
Power Tool Safety...............................................................................................................
General Safety Rules.............................................................................................................. 5
Work Area ............................................................................................................................... 5
Electrical Safety...................................................................................................................... 5
Personal Safety...................................................................................................................
Power Tool Use And Care.................................................................................................
Service ..................................................................................................................................... 6
............................................................................................................... 7
Guidelines For Extension Cords .......................................................................................... 8
Symbols ................................................................................................................................... 9
Know Your Palm Sander ...................................................................................................... 10
Assembly And Operating................................................................................................
Installing The Dust Bag Assembly ...................................................................................... 11
Removing & Cleaning The Dust Box .................................................................................. 11
Installing Sandpaper........................................................................................................
Punching Holes In Sandpaper.............................................................................................12
Sandpaper Selection ............................................................................................................12
........................................................................................................................13
Sanding.............................................................................................................................
Maintenance ..........................................................................................................................15
Exploded View.......................................................................................................................16
Parts List .................................................................................................................................17
Warranty .................................................................................................................................18

WARNING
Before using this tool or any of its accessories, read this manual and follow all
Safety Rules and Operating Instructions. The important precautions, safeguards
and instructions appearing in this manual are not meant to cover all possible situations.
It must be understood that common sense and caution are factors which cannot
be built into the product.
SYMBOL MEANING
ALWAYS WEAR EYE PROTECTION THAT CONFORMS WITH
CSA Z94.3 or ANSI SAFETY STANDARD Z87.1
FLYING DEBRIS can cause permanent eye damage. Prescription
eyeglasses ARE NOT a replacement for proper eye protection.
Non-compliant eyewear can cause serious injury if broken
during the operation of a power tool.
Use hearing protection, particularly during extended periods of
operation of the tool, or if the operation is noisy.
WEAR A DUST MASK THAT IS DESIGNED TO BE USED WHEN OP-
ERATING A POWER TOOL IN A DUSTY ENVIRONMENT.
Dust that is created by power sanding, sawing, grinding, drilling,
and other construction activities may contain chemicals that are
known to cause cancer, birth defects, or other genetic abnormalities.
These chemicals include:
•Lead from lead-based paints
•Crystalline silica from bricks, cement, and other masonry products
•Arsenic and chromium from chemically treated lumber .
The level of risk from exposure to these chemicals varies, according
to how often this type of work is performed. In order to reduce
exposure to these chemicals, work in a well-ventilated area, and use
To avoid electrical hazards, fire hazards or damage to the tool,
use proper circuit protection.
This tool is wired at the factory for 120 Volts AC operation.
It must be connected to a 120 Volts AC, 15 Amps circuit that is pro-
tected by a time-delayed fuse or circuit breaker. To avoid shock or
or damaged in any way.
SAVE THESE INSTRUCTIONS FOR REFERENCE
3

1262-300
4
2.2 AMP 1/4 SHEET PALM SANDER
WARNING
Read all safety warnings and instructions. Failure to follow the warnings and
Save all warnings and instructions for future reference.
Work area safety
Keep work area clean and well lit. Cluttered or dark areas invite accidents.
Do not operate power tools in explosive atmospheres, such as in the presence
the dust or fumes.
Keep children and bystanders away while operating a power tool. Distractions can
cause you to lose control.
Electrical safety
Power tool plugs must match the outlet. Never modify the plug in any way.
Do not use any adapter plugs with earthed (grounded) power tools.
Avoid body contact with earthed or grounded surfaces such as pipes, radiators,
ranges and refrigerators. There is an increased risk of electric shock if your body
is earthed or grounded.
Do not expose power tools to rain or wet conditions. Water entering a power tool
will increase the risk of electric shock.
Do not abuse the cord. Never use the cord for carrying, pulling or unplugging
the power tool. Keep cord away from heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase the risk of electric shock.
When operating a power tool outdoors, use an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces the risk of electric shock.
If operating a power tool in a damp location is unavoidable, use a residual current
device (RCD) protected supply. Use of a ground fault circuit interrupter (GFCI)
reduces the risk of electric shock.
Stay alert, watch what you are doing and use common sense when operating a power
alcohol or medication. A moment of inattention while operating power tools may result
Use personal protective equipment. Always wear eye protection. Protective
equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection
connecting to power source and/or battery pack, picking up or carrying the tool.
that have the switch on invites accidents.

5
Power Tool Safety – cont’d
Do not overreach. Keep proper footing and balance at all times. This enables
better control of the power tool in unexpected situations.
can be caught in moving parts.
If devices are provided for the connection of dust extraction and collection facilities,
ensure these are connected and properly used. Use of dust collection can reduce dust-
related hazards.
Power tool use and care
Do not force the power tool. Use the correct power tool for your application.
designed.
that cannot be controlled with the switch is dangerous and must be repaired.
Disconnect the plug from the power source and/or the battery pack from the power tool
Such preventive safety measures reduce the risk of starting the power tool accidentally.
Store idle power tools out of the reach of children and do not allow persons unfamiliar
with the power tool or these instructions to operate the power tool. Power tools are
dangerous in the hands of untrained users.
Maintain power tools. Check for misalignment or binding of moving parts, breakage
have the power tool repaired before use. Many accidents are caused by poorly
maintained power tools.
Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp
cutting edges are less likely to bind and are easier to control.
Use the power tool, accessories and tool bits etc. in accordance with these instructions,
taking into account the working conditions and the work to be performed. Use of
situation.
Service
replacement parts. This will ensure that the safety of the power tool is maintained.
Save these instructions for reference

1262-300
6
2.2 AMP 1/4 SHEET PALM SANDER
WARNING
Know your ¼ sheet palm sander. Do not plug in the sander until you have read
and understand this Instruction Manual.
eyes and cause permanent eye damage.
ALWAYS wear safety goggles (not glasses) that comply with ANSI safety standard Z87.1.
Everyday glasses have only impact resistant lenses. They ARE NOT safety glasses.
WARNING
when they break.
WARNING
Always use a dust mask when sanding.
WARNING
Always use hearing protection when sanding, particularly during extended periods
of operation.
WARNING
Always unplug the tool from the power source before changing the sandpaper
and when cleaning the tool.
Do not wear gloves, neckties or loose clothing.
Secure the workpiece. Use clamps or a vise to hold the work when practical.
It is safer than using your hand and it frees both hands to operate the tool.
Do not sand material too small to be securely held.
to be sanded.
Always keep hands out of the path of the sanding pad. Avoid awkward hand
positions where a sudden slip could cause your hand to move into the path
of the sanding pad.
source before installing or removing sandpaper or the vacuum adaptor.
Save these instructions for reference

Make sure your extension cord is the proper size. When using an extension cord,
be sure to use one heavy enough to carry the current the tool will draw. An undersized
cord will cause a drop in line voltage resulting in loss of power and overheating.
The table on at right shows the correct size to use according to cord length and
nameplate ampere rating. If in doubt, use the next heavier gauge. The smaller the
gauge number the heavier the cord.
Be sure your extension cord is properly wired and in good condition. Always replace
or wet areas.
Use a separate electrical circuit for your power tools. This circuit must not be less
than 14 gauge wire and should be protected with either a 15A time delay fuse or circuit
breaker. Before connecting the power tool to the power source, make sure the switch
is in the OFF position and the power source is the same as indicated on the nameplate.
Running at lower voltage will damage the motor.
When operating a power tool outdoors, use an outdoor extension cord
marked “W -A” or “W”. These cords are rated for outdoor use and reduce the risk
of electric shock.
WARNING: Keep the extension cord clear of the working area. Position the cord
so it will not get caught on the workpiece, tools or any other obstructions while
you are working with the power tool.
7
MINIMUM GUAGE (AWG)
EXTENSION CORDS (120 V use only)
Ampere rating Total length in feet
More than Not more than 7.5 m (25 ft) 15 m (50 ft) 30 m (100 ft) 45 m (150ft)
0 6 18 16 16 14
6 10 18 16 14 12
10 12 16 16 14 12
12 16 14 12 Not applicable

1262-300
8
2.2 AMP 1/4 SHEET PALM SANDER
WARNING
Some of the following symbols may appear on the palm sander.
Study these symbols and learn their meaning. Proper interpretation of these
using your hand and it frees both hands to operate the tool.
Volts
Amperes
Hertz
Watts
Kilowatts
Microfarads
Litres
Kilograms
Hours
Newtons per
square centimetre
Pascals
Oscillations per minute
Minutes
Seconds
Alternating current
Three-phase
alternating current
Three-phase alternating
current with neutral
Direct current
No load speed
Alternating or direct current
Class II construction
Splash-proof construction
Watertight construction
Protective grounding a
grounding terminal, Class I tools
Revolutions or reciprocations
per minute
Diameter
Directional arrow
Warning symbol
Wear your safety glasses
This symbol designates that this tool is listed with U.S. and Canadian
requirements by UL Testing Laboratories, Inc.
UL60745-1，UL60745-2-4;
CSA C22.2#60745-1，CSA C22.2#60745-2-4.
JD2441U

9
ON/OFF switch Palm grip
Dust box
vent
Dust box
assembly
Sandpaper
clamping lever
Sandpaper
hole punch
Backing
pad
Cooling
vents
Sandpaper
clamp

1262-300
10
2.2 AMP 1/4 SHEET PALM SANDER
INSTALLING THE DUST BOX ASSEMBLY
1. Insert the dust duct box assembly sleeve (1) onto the dust chute (2) (Fig. 1).
NOTE: Make sure the locking tabs (3) insert into the matching slots (4) in the rear of
the sander housing.
2. Push the dust box assembly sleeve fully onto the dust chute until the locking tabs
NOTE: Remove and clean the dust box assembly periodically to remove accumulated
dust from the dust box.
CLEANING THE DUST BOX
The dust box will collect much of the sanding dust that is generated during sanding operations.
1. Squeeze the sides of the dust box (1) and pull it away from the rear of the sander (2) (Fig. 2).
2. Pry the top of the dust box (3) away from the bottom of the dust box (4) (Fig. 3).
NOTE: It is best to perform this function either outside or over a trash can, as loose
dust will come out of the dust box very easily.
3. Shake all the dust out of the dust box.
4.
5. Once all the sanding dust is removed from the dust box, press the upper and lower
sections together. They will “snap” into place when properly assembled.
6. Reinstall the dust box onto the rear of the sander.
NOTE: The locking tabs (5) will “snap” into place when the dust box is fully pushed
onto the rear of the sander.
INSTALLING SANDPAPER
WARNING
Unplug the sander from the power source before installing or changing the sandpaper.
NOTE: Cut a standard 9" x 11" sheet of sandpaper into quarters (4½" x 5½").
1. Lift up and outward on the front and rear sandpaper clamp levers (1) at the front
and rear of the backing pad (Fig. 4).
2. Insert one end of the ¼ sheet sandpaper (3) with grit side up into the open front
sandpaper clamp (4), making sure it is aligned with the backing pad. Lift the sandpaper
clamp lever up and inward to lock the sandpaper into the clamp.
Fig. 2Fig. 1 Fig. 3

11
INSTALLING SANDPAPER – cont’d
1. Place the hole punch (1)
2. Wrap the sandpaper sheet (3) over the backing pad (2) and insert it into the
open rear sandpaper clamp (5) (Fig. 5).
NOTE: Make sure the sandpaper is pulled tight over the backing pad for proper
sanding operation.
3. Wrap the sandpaper sheet (3) over the backing pad (2) and insert it into the open
rear sandpaper clamp (5) (Fig. 5).
4. Lift the sandpaper clamp lever up and inward to lock the sandpaper into the clam
NOTE: Make sure the sandpaper is pulled tight over the backing pad for proper
sanding operation.
PUNCHING HOLES IN SANDPAPER
The sandpaper must have 8 holes punched in it to allow the sanding dust to escape
from the working surface. The pattern of these holes must match the hole pattern on the
sanding pad. If the sandpaper you are using does not have the holes punched, use the
hole punch supplied with the tool to pierce the sandpaper in the correct locations.
2. Align the corner of the sanding pad (2) with the corner of the hole punch (3).
This will ensure the holes are punched in the correct location.
3. When the sanding pad is correctly aligned on the hole punch, press the sanding
NOTE: The sharp pegs (4) in the hole punch will pierce the sandpaper in the
correct location.
SANDPAPER SELECTION
Selecting the correct grit and type of sandpaper is extremely important in achieving
abrasives are best for power sanding. Natural abrasives such as flint and garnet
are too soft for economical use in power sanding.
until the surface is uniform. Medium grit may then be used to remove scratches left by
Always continue sanding with each grit until the surface is uniform.
Fig. 6Fig. 5Fig. 4

1262-300
12
2.2 AMP 1/4 SHEET PALM SANDER
WARNING
For safety reasons, the operator must read the sections of this Owner’s Manual entitled
“GENERAL SAFETY WARNINGS”, “POWER TOOL SAFETY”, “SPECIFIC SAFETY RULES”,
“GUIDELINES FOR EXTENSION CORDS” and “SYMBOLS” before using this pad sander.
Verify the following every time the pad sander is used:
1. Sander cord is not damaged.
2. Safety glasses and dust mask are being worn.
3. Hearing protection is being worn.
4. Sandpaper is the correct type for the job.
5. Sandpaper is in good condition and is properly installed.
Failure to observe these safety rules will significantly increase the risk of injury.
WARNING
Always wear safety goggles or safety glasses with side shields when operating your
resulting in possible serious eye damage.
Always wear an appropriate dust mask and hearing protection when using your sander.
ON/OFF SWITCH
To turn the switch ON, press the right hand side of the ON/OFF switch (1) (Fig. 7).
To turn the switch OFF, press the left hand side of the ON/OFF switch (2).
SANDING
Clamp or otherwise secure your workpiece to prevent it from moving under
the sander while being sanded.
WARNING
Place the sander on the workpiece so that the complete sandpaper surface is in contact
with the workpiece. Turn the sander ON by pressing on the side of the ON/OFF switch.
Move the sander slowly over workpiece making successive passes in parallel lines,
circles or crosswise movements.
Fig. 7

13
SANDING – cont’d
Upon completion of the sanding operation, turn the sander OFF by pressing on the
opposite side of the ON/OFF switch. Wait until the sanding pad comes to a complete
stop before removing it from the workpiece.
WARNING
Your sander should only be turned ON when the entire surface of the sanding pad
is in contact with the workpiece. Failure to follow this sanding procedure could result
NOTE: Hold the sander using the grip on top of the sander. Be careful NOT to cover
the motor cooling vents with your hand. Motor damage may occur from over heating
if the cooling vents are covered.
DO NOT FORCE THE SANDER. The weight of the sander usually provides adequate
pressure. Let the sander and the sandpaper do the work. Applying added pressure
will slow the motor, increase the wear on the sandpaper and greatly reduce the sander
speed. Motor damage may occur if excessive downward pressure is applied. It will also
the frictional heat, causing the sandpaper to become clogged very quickly. Do not sand
the surface uneven.
Extended periods of sanding may tend to overheat the motor. If this occurs, turn sander
OFF, wait until the sanding pad comes to a complete stop and remove it from the
workpiece. Check to make sure your hand has not been covering the cooling vents.
Let the motor cool before continuing the sanding operation.

1262-300
14
2.2 AMP 1/4 SHEET PALM SANDER
GENERAL
WARNING
When servicing, use only identical replacement parts. Use of any other
replacement parts may create a hazard or cause product damage.
DO NOT use solvents when cleaning plastic parts. Most plastics are susceptible
to damage from various types of commercial solvents and may be damaged
by their use. Use a clean cloth to remove dirt, dust, oil, grease etc.
WARNING
Do not at any time allow brake fluids, gasoline, petroleum-based products,
penetrating oils, etc. to come in contact with plastic parts. They contain
chemicals that can damage, weaken or destroy plastic.
DO NOT abuse power tools. Abusive practices can damage the tool as well
as the workpiece.
WARNING
DO NOT attempt to modify tools or create accessories not recommended.
wallboard, spackling compounds or plaster. The chips and grindings from
these materials are highly abrasive to electric tool parts such as bearings, brushes,
commutators, etc.
Consequently, it is not recommended that this tool be used for extended work
use on these materials it is extremely important that the tool is cleaned frequently
WARNING
Always wear safety goggles or safety glasses with side shields during
all sanding operations. It is critical that you also wear safety goggles or safety glasses
Failure to take these safety precautions could result in permanent eye or lung damage.
LUBRICATION
of high-grade lubricant for the life of the unit under normal conditions.
Therefore, no further lubrication is required.

15

1262-300
16
2.2 AMP 1/4 SHEET PALM SANDER
WARNING
When servicing, use only original equipment replacement parts. The use of
any other parts may create a safety hazard or cause damage to the sander.
Any attempt to repair or replace electrical parts on this sander may create a safety haz-
Always order by PART NUMBER, not by key number.
Key # Part # Part Name Quantity
1 3140080043 Switch dust excluding cap 1
2 1061250004 Switch 1
3 4030010026 Tapping screw 2
4 1130080019 PCB 1
5 3150210013 Supporting bearing block 1
6 3011080035 Housing 1
7 4030010106 Tapping screw 7
8 2030050009 Strain relief 1
9 4030010099 Tapping screw 2
10 3140010054 Cord sleeve 1
11 1190030016 Cord 1
12 1020080038 Stator 1
13 4010010053 Bearing 1
14 1010080039 Rotor 1
15 4010010106 Bearing 1
16 3150010109 Plastic fan 1
17 3180050023 Dust collection box cover 1
18 3190110005 1
19 3180060021 Filter clamp 1
20 3140020046 O ring 1
21 3180020038 Dust box 1
22 3150110038 2
23 3180050023 Air handling compartmentalization 1
24 2050080187 Sandpaper clamping wires 2
25 3190010047 Gasket 1
26 4020010005 Tapping screw 4
27 3190020060 Backing pad 1

17
Key # Part # Part Name Quantity
28 3150120090 Base plate 1
29 4010010105 Bearing 1
30 2030020331 Flat washer 1
31 2010130034 Eccentric 1
32 2030030259 Counter balance 1
33 3011080035 Housing 1
34 6150070008 Sandpaper punch template 1

1262-300
18
2.2 AMP 1/4 SHEET PALM SANDER
RADLEY 1/4 SHEET SANDER
If this Radley Tool fails due to a defect in material or workmanship within three years
from the date of purchase, return it to any Home Hardware store with the original bill of
sale for exchange.Two years for battery and charger. This warranty does not include
expendable parts including but not limited to blades, brushes, belts, and light bulbs.
This warranty coves defects in material or workmanship only. It does not cover normal
wear and tear, failure due to abuse/misuse, or defects caused by careless or accidental
mishandling. If this Radley product is used for commercial or rental purposes, this
warranty does not apply. For use at the consumer level. The warranty is not for industrial
or commercial applications.

Made in China
1262-300
RADLEY TOOLS
ST. JACOBS, ONTARIO N0B 2N0
© 2021 Home Hardware Stores Limited
1-866-349-8665
Customer Service/Tech Support
This Radley®product carries a three (3) year LIMITED
warranty against defects in workmanship and materials.
See Owner’s Manual for full details.
WEARCSAAPPROVED
EYEPROTECTION
WEAREAR
PROTECTION
WEARFACE
PROTECTION
READ ALL INSTRUCTIONS BEFORE FIRST USE.
KEEP THIS MANUAL FOR FUTURE REFERENCE.
KEEP AWAY FROM CHILDREN.
JD2441U
