RADLEY 1270-080 User manual
1270080
3042597
JD3507U
Onr's Mna
1
6 Ap Rcpotn Sw - Onr's Mna
PRODUCT SPECIFICATIONS
Need Assistance?
Call us on our toll free customer support line:
•
• Replacement parts
•
6 AMP RECIPROCATING SAW
1/2
1 1/
2
1270-080
TABLE OF CONTENTS
6 Ap Rcpotn Sw - Onr's Mna
GENERAL SAFETY WARNINGS
WARNING:
This instruction manual includes the following:
EYE, EAR & LUNG PROTECTION
ALWAYS WEAR EYE PROTECTION THAT CONFORMS WITH CSA
REQUIREMENTS or ANSI SAFETY STANDARD Z87.1
WARNING:
ALWAYS WEAR EAR PROTECTION
WARNING:
WEAR A DUST MASK THAT IS DESIGNED TO BE USED WHEN OPERATING A
POWER TOOL IN A DUSTY ENVIRONMENT.
WARNING:
•
•
•
•
•
•
•
1270-080
ELECTRICAL SAFETY
WARNING:
Power tool plugs must match the outlet. Never modify the plug in any
way. Do not use any adapter plugs with earthed (grounded) power tools.
Avoid body contact with earthed or grounded surfaces such as pipes,
radiators, ranges and refrigerators.
Do not expose power tools to rain or wet conditions.
Do not abuse the cord. Never use the cord for carrying, pulling or unplugging
the power tool. Keep cord away from heat, oil, sharp edges or moving parts.
When operating a power tool outdoors, use an extension cord suitable for outdoor
use.
If operating a power tool in a damp location is unavoidable, use a residual
current device (RCD) protected supply.
POWER TOOL SAFETY
WARNING:
Save all warnings and instructions for future reference.
WORK AREA SAFETY
Keep work area clean and well lit.
Do not operate power tools in explosive atmospheres, such as in the presence
of flammable liquids, gases or dust.
Keep children and bystanders away while operating a power tool.
6 Ap Rcpotn Sw - Onr's Mna
PERSONAL SAFETY
Stay alert, watch what you are doing and use common sense when operating a
power tool. Do not use a power tool while you are tired or under the influence
of drugs, alcohol or medication.
Use personal protective equipment. Always wear eye protection. Protective
Prevent unintentional starting. Ensure the switch is in the o-position before
connecting to power source and/or battery pack, picking up or carrying the
tool.
Remove any adjusting key or wrench before turning the power tool on.
Do not overreach. Keep proper footing and balance at all times.
Dress properly. Do not wear loose clothing or jewellery. Keep your hair,
clothing and gloves away from moving parts.
If devices are provided for the connection of dust extraction and collection
facilities, ensure these are connected and properly used.
POWER TOOL USE AND CARE
Do not force the power tool. Use the correct power tool for your application.
Do not use the power tool if the switch does not turn it on and o.
Disconnect the plug from the power source and/or the battery pack from
the power tool before making any adjustments, changing accessories, or
storing power tools.
1270-080
Store idle power tools out of the reach of children and do not allow persons
unfamiliar with the power tool or these instructions to operate the power
tool.
Maintain power tools. Check for misalignment or binding of moving parts,
breakage of parts and any other condition that may aect the power tool’s
operation. If damaged, have the power tool repaired before use.
Keep cutting tools sharp and clean.
SERVICE
Have your power tool serviced by a qualified repair person using only
identical replacement parts.
6 Ap Rcpotn Sw - Onr's Mna
SPECIFIC SAFETY RULES
WARNING:
WARNING:
WARNING:
WARNING:
WARNING:
1270-080
GUIDELINES FOR EXTENSION CORDS
WARNING: Keep the extension cord clear of the working area.
WARNING: Repair or replace damaged or worn extension cords immediately.
WARNING: Keep the extension
cord clear of the working area.
Position the cord so it will not get
caught on the workpiece, tools or
any other obstructions while you
are working with the power tool.
MINIMUM GAUGE (AWG) EXTENSION
CORDS(120 V use only)
Ampere rating
Total length infeet
More
than
Not
more
than
7.5 m
(25')
15 m
(50')
30 m
(100')
45 m
(150')
0
6
18
16
16
14
6
10
18
16
14
12
10
12
16
16
14
12
12
16
14
12
Not Applicable
6 Ap Rcpotn Sw - Onr's Mna
SYMBOLS
WARNING:
Volts
Watts
Pascals
Class II construction
tools
Revolutions or reciprocations
per minute
3042597
JD3507U
10
1270-080
KNOW YOUR RECIPROCATING SAW
Wood cutting
blade
Hex key
Motor
vent
Variable speed
trigger switch
Motor
vent
Pivoting shoe
adjusting
screws
Pivoting
shoe
Toolfree
blade holder
Variable speed
adjusting knob
Lock-on
button
11
6 Ap Rcpotn Sw - Onr's Mna
INSTALLING A BLADE
WARNING: Always remove the plug from
the power source before installing or
removing a blade or adjusting the saw in
any way.
NOTE:
REMOVING A BLADE
ADJUSTING THE PIVOTING SHOE
VARIABLE SPEED TRIGGER SWITCH
NOTE:
ASSEMBLY AND OPERATING
NOTE:
Fig. 1
1
2
3
Fig. 2
123
12
1270-080
VARIABLE SPEED TRIGGER SWITCH – cont’d
VARIABLE SPEED ADJUSTING KNOB
NOTE:
LOCKON BUTTON
NOTE:
MATERIALS YOU CAN CUT
NOTE:
ASSEMBLY AND OPERATING (continued)
Fig. 3
1
Fig. 4
2
3
4
5
Fig. 5
6 Ap Rcpotn Sw - Onr's Mna
WARNING:
GENERAL CUTTING
DANGER:
CAUTION:
PLUNGE CUTTING
NOTE:
ASSEMBLY AND OPERATING (continued)
Fig. 6
1270-080
PLUNGE CUTTING – cont’d
WARNING:
METAL CUTTING
DANGER:
ASSEMBLY AND OPERATING (continued)
Fig. 7
Fig. 8
6 Ap Rcpotn Sw - Onr's Mna
MAINTENANCE
GENERAL
WARNING: When servicing, use only
identical replacement parts. The use of
any other part may create a hazard or
cause product damage.
WARNING: Do not allow brake fluids,
gasoline, petroleum-based products,
penetrating oils, etc. to come into contact
with plastic parts. They contain chemicals
that can damage, weaken or destroy
plastic.
WARNING: DO NOT attempt to modify
tools or create accessories. Any such
alteration or modification is misuse and
could result in a hazardous condition leading
to possible serious injury. It will also void the
warranty.
WARNING: Always wear safety goggles or
safety glasses with side shields during all
cutting operations. It is critical that you also
wear safety goggles or safety glasses with
side shields and a dust mask while blowing
dust out of the reciprocating saw with an air
jet. Failure to take these safety precautions
could result in permanent eye or lung
damage.
LUBRICATION
1270-080
EXPLODED VIEW
1
2345678
9
10
11
12
13
14
15
16
17
18
19
20
212223
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
6 Ap Rcpotn Sw - Onr's Mna
PARTS LIST
WARNING:
Always order by PART NUMBER, not by key number.
Key #
Part #
Part Name
Quantity
1
1190030061
Cord set
1
2
6140020012
Hex key
1
3
3140010053
Cord sleeve
1
4
4030010099
Tapping screw ST3.9*14
2
5
2030050002
Strain relief
1
6
1061010013
Switch
1
7
3011110016
Housing
1
8
4030010106
Tapping Screw ST3.9*19
10
9
3150060001
Brush holder sleeve
2
10
2030070004
Brush holder
2
11
1230010122
Carbon brush
2
12
4010010053
Bearing 607 2RS
1
13
1010110015
Rotor
1
14
1020110013
Stator
1
15
3150010029
Fan
1
16
2030030260
Fixed plate
1
17
4010010054
Bearing 6000 2RS
1
18
4030010106
Tapping screw ST3.9*19
2
19
3150070096
Gear box
1
20
4030010116
Tapping screw ST3.9*30
1
21
4060010022
Nut
2
22
2010150055
Reciprocating lever support
1
23
2030160149
Clamping plate
1
24
3150240029
Bearing washer
2
25
4030010192
Tapping screw ST5*25
2
26
3140080045
Rubber boot
1
27
3150160209
Fixed frame
1
28
4020080011
Adjusting screw M5*14
2
29
1150020092
Pivoting shoe assembly
1
30
3011110016
Housing
1
31
4020080011
Adjusting screw M5*14
1
32
4040030003
Spring washer ø5
1
33
4040010009
Bearing washer
1
34
4010010054
Bearing 6000 2RS
1
35
4010010081
Bearing 6201 2RS
1
36
2040040089
Spindle
1
37
2040080028
Big gear
1
38
2040220035
Roller
1
39
1150010044
Plunger assembly
1
40
2030030262
Clamping plate
1
41
6060030005
Blade
1
42
2030030261
Top cover
1
43
4030010249
Tapping screw ST5*14
4
1270-080
WARRANTY
RADLEY 6 AMP RECIPROCATING SAW WARRANTY
1270080
