HS Series
Installation & Operating
Instructions

IN007 Rev N 0419 23 Saber Way, Ward Hill, MA 01835 | radonaway.com
HS Series Fan Installation & Operating Instructions
Please Read and Save These Instructions.
DO NOT CONNECT POWER SUPPLY UNTIL FAN IS COMPLETELY INSTALLED. MAKE SURE ELECTRICAL
SERVICE TO FAN IS LOCKED IN “OFF” POSITION. DISCONNECT POWER BEFORE SERVICING FAN.
1. WARNING! Do not use fan in hazardous environments where fan electrical system could provide ignition to
combustible or ammable materials.
2. WARNING! Check voltage at the fan to ensure it corresponds with nameplate. See Vapor Intrusion Application
Note #AN001 for important information on VI Applications. RadonAway.com/vapor-intrusion
3. WARNING! Normal operation of this device may affect the combustion airow needed for safe operation of fuel
burning equipment. Check for possible backdraft conditions on all combustion devices after installation.
4. NOTICE! There are no user serviceable parts located inside the fan unit.
Do NOT attempt to open. Return unit to the factory for service.
5. All wiring must be performed in accordance with the National Fire Protection Association’s (NFPA) “National
Electrical Code, Standard #70”-current edition for all commercial and industrial work, and state and local
building codes. All wiring must be performed by a qualied and licensed electrician.
6. WARNING! In the event that the fan is immersed in water, return unit to factory for service before operating.
7. WARNING! Do not twist or torque fan inlet or outlet piping as leakage may result.
8. WARNING! Do not leave fan unit installed on system piping without electrical power for more than 48 hours.
Fan failure could result from this non-operational storage.
9. WARNING! TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE
FOLLOWING:
a) Use this unit only in the manner intended by the manufacturer. If you have questions, contact the
manufacturer.
b) Before servicing or cleaning unit, switch power off at service panel and lock the service disconnecting
means to prevent power from being switched on accidentally. When the service disconnecting means
cannot be locked, securely fasten a prominent warning device, such as a tag, to the service panel.

IN007 Rev N 0419 33 Saber Way, Ward Hill, MA 01835 | radonaway.com
1.0 SYSTEM DESIGN CONSIDERATIONS
1.1 INTRODUCTION
The HS Series Fan is intended for use by trained, certied/licensed, professional radon mitigators. The purpose of
this instruction is to provide additional guidance for the most effective use of the HS Series Fan. This instruction
should be considered as a supplement to EPA/Radon Industry standard practices, state and local building codes
and state regulations. In the event of a conict, those codes, practices and regulations take precedence over this
instruction.
1.2 ENVIRONMENTALS
The HS Series Fan is designed to perform year-round in all but the harshest climates without additional concern
for temperature or weather. For installations in an area of severe cold weather, please contact RadonAway for
assistance. When not in operation, the HS Series Fan should be stored in an area where the temperature is always
greater than 32°F or less than 100°F. The HS Series Fan is thermally protected such that it will shut off when the
internal temperature is above 194°F +/- 9°F (90°C +/- 5°C). If the HS Series Fan is idle in an area where the
ambient temperature exceeds this shut off, it will not restart until the internal temperature falls below 104°F.
1.3 ACOUSTICS
The HS Series Fan, when installed properly, operates with little or no noticeable noise to the building occupants.
Recommended system design and installation considerations to minimize noise: When installing the HS Series Fan
above sleeping areas, select a location for mounting at the farthest possible distance. Avoid mounting near doors,
fold-down stairs or other uninsulated structures which may transmit sound. Ensure a solid mounting for the HS
Series Fan to avoid structure-borne vibration or noise.
The velocity of the outgoing air must also be considered in the overall system design. With small diameter piping,
the “rushing” sound of the outlet air can be disturbing. The system design should incorporate a means to slow and
quiet the outlet air. The use of the RadonAway Exhaust Mufer, p/n 24002, is strongly recommended.
1.4 GROUND WATER
Under no circumstances should water be allowed to be drawn into the inlet of the HS Series Fan as this may result
in damage to the unit. The HS Series Fan should be mounted at least 5 feet above the slab penetration to minimize
the risk of lling the HS Series Fan with water in installations with occasional high water tables.
In the event that a temporary high water table results in water at or above slab level, water will be drawn into
the riser pipes thus blocking air ow to the HS Series Fan. The lack of cooling air will result in the HS Series Fan
cycling on and off as the internal temperature rises above the thermal cutoff and falls upon shutoff. Should this
condition arise, power down and disconnect the HS Series Fan until the water recedes allowing for return to normal
operation; then reconnect and power on to turn the fan back on.
1.5 CONDENSATION & DRAINAGE
WARNING!: Failure to provide adequate drainage for condensation can result in system failure and damage the HS Series Fan.
Condensation is formed in the piping of a mitigation system when the air in the piping is chilled below its dew
point. This can occur at points where the system piping goes through unheated space such as an attic, garage
or outside. The system design must provide a means for water to drain back to a slab hole to remove the
condensation.
HS Series Fan Installation & Operating Instructions
High Suction Series
HS2000 p/n 23004-1
HS3000 p/n 23004-2
HS5000 p/n 23004-3
HS2000E p/n 23004-4
HS3000E p/n 23004-5
HS5000E p/n 23004-6

IN007 Rev N 0419 43 Saber Way, Ward Hill, MA 01835 | radonaway.com
The use of small diameter piping in a system increases the speed at which the air moves. The speed of the air can
pull water uphill and, at sufcient velocity, it can actually move water vertically up the side walls of the pipe. This
has the potential of creating a problem in the negative pressure (inlet) side piping. For HS Series Fan inlet piping,
the following table provides the minimum recommended pipe diameters as well as minimum pitch under several
system conditions. Use this chart to size piping for a system.
*Typical operational ow rates:
HS2000 12 - 63 CFM
HS3000 19 - 39 CFM
HS5000 16 - 44 CFM
All exhaust piping should be 2” PVC.
1.6 SYSTEM MONITOR & LABEL
A properly designed system should incorporate a “System On” indicator for afrmation of system operation. A
Magnehelic pressure gauge is recommended for this purpose. The indicator should be mounted at least 5 feet
above the slab penetration to minimize the risk of lling the gauge with water in installations with occasional high
water tables. A System Label (P/N 15022) with instructions for contacting the installing contractor for service
and also identifying the necessity for regular radon tests to be conducted by the building occupants, must be
conspicuously placed where the occupants frequent and can see the label.
1.7 SLAB COVERAGE
The HS Series Fan can provide coverage of well over 1000 sq. ft. per slab penetration. This will, of course, depend
on the sub-slab aggregate in any particular installation and the diagnostic results. In general, sand and gravel are
much looser aggregates than dirt and clay. Additional suction points can be added as required. It is recommended
that a small pit (5 to 10 gallons in size; larger as needed) be created below the slab at each suction hole. When
ne sand or dirt is present it is recommended that the pit be lined with a material such as clean gravel, size 4, 5,
56, or 6 as classied (ASTM C33).
1.8 ELECTRICAL WIRING
For models with a cord, the HS Series Fan plugs into a standard 120V outlet. The switch box models are
hardwired. All wiring must be performed in accordance with the National Fire Protection Association’s
(NFPA)”National Electrical Code, Standard #70”-current edition for all commercial and industrial work, and state
and local building codes. All wiring must be performed by a qualied and licensed electrician. Outdoor installations
require the use of a UL listed watertight conduit. Ensure that all exterior electrical boxes are outdoor rated and
properly caulked to prevent water penetration into the box. A means, such as a weep hole, is recommended to
drain the box.
1.9 SPEED CONTROLS
Electronic speed controls can NOT be used on HS Series units.
Pipe
Diameter
Minimum Rise per 1 Foot of Run*
@ 25 CFM @ 50 CFM @ 100 CFM
4” 1/32” 3/32” 3/8”
3” 1/8” 3/8” 1 1/2”
RUN
RISE

IN007 Rev N 0419 53 Saber Way, Ward Hill, MA 01835 | radonaway.com
2.0 INSTALLATION
2.1 MOUNTING
Mount the HS Series Fan to the wall studs, or similar structure, in the selected location with (4) 1/4” x 1 1/2” lag
screws (not provided). Ensure the HS Series Fan is both plumb and level.
2.2 DUCTING CONNECTIONS
Make nal ducting connection to HS Series Fan with exible couplings. Ensure all connections are tight. Do not
twist or torque inlet and outlet piping on HS Series Fan or leaks may result.
NOTE: Do NOT solvent weld ttings to unit hubs.
2.3 VENT MUFFLER INSTALLATION
Install the mufer assembly in the selected location in the outlet ducting. Solvent weld all connections. The mufer
is normally installed above the rooine at the end of the vent pipe.
2.4 OPERATION CHECKS & ANNUAL SYSTEM MAINTENANCE
______ Verify all connections are tight and leak-free.
______ Ensure the HS Series Fan and all ducting is secure and vibration-free.
______ Verify system vacuum pressure with Magnehelic. Ensure vacuum pressure is within normal
operating range and less than the maximum recommended as shown below:
HS2000 14” WC
HS3000 21” WC
HS5000 35” WC
(Above are based on sea-level operation, at higher altitudes reduce above by about 4% per 1000 Feet.)
If these are exceeded, increase number of suction points.
______ Verify Radon levels by testing to EPA Protocol and applicable testing standards.

IN007 Rev N 0419 63 Saber Way, Ward Hill, MA 01835 | radonaway.com
*Power consumption varies with actual load conditions
Inlet: 3.0” PVC
Outlet: 2.0” PVC
Mounting: Brackets for vertical mount
Weight: Approximately 18 lbs
Size: Approximately 15”W x 13”H x 8”D
Minimum recommended inlet ducting (greater diameter may always be used):
HS3000, HS5000 --- 2.0” PVC Pipe
HS2000 --- Main feeder line of 3.0” or greater PVC Pipe
Branch lines (if 3 or more) may be 2.0” PVC Pipe
Outlet ducting: 2.0” PVC
Storage Temperature Range: 32°F-100°F
Thermal Cutout: 194°F +/- 9°F (90°C +/- 5°C)
Locked rotor protection
Internal condensate bypass
Addendum
Product Specications
Model Maximum Static
Suction
Recommended
Maximum Static
Suction
Typical CFM vs Static Suction WC
(Recommended Operating Range) Power* Watts
@ 115VAC
0” 10” 15” 20” 25” 35”
HS2000 16” 14” 62 40 23 - - - 153-314
HS3000 24” 21” 39 30 25 19 - - 120-250
HS5000 41” 35” 43 35 32 28 24 18 349-381
HS2000E 16” 14” 62 40 23 - - - 153-314
HS3000E 24” 21” 39 30 25 19 - - 120-250
HS5000E 41” 35” 43 35 32 28 24 18 349-381

IN007 Rev N 0419 73 Saber Way, Ward Hill, MA 01835 | radonaway.com
IMPORTANT INSTRUCTIONS TO INSTALLER
Inspect the RadonAway®HS Series Fan for shipping damage within 15 days of receipt. Notify RadonAway®of any damages
immediately. RadonAway®is not responsible for damages incurred during shipping.
There are no user serviceable parts inside the fan. Do not attempt to open the housing. Return unit to factory for service.
Install the HS Series Fan in accordance with all EPA standard practices, and state and local building codes and state regulations.
Provide a copy of this instruction or comparable radon system and testing information to the building occupants after
completing system installation.
Warranty
RadonAway®warrants that the HS Series Fan (the “Fan”) will be free from defects in materials and workmanship for a period of 90 days
from the date of purchase (the “Warranty Term”).
RadonAway®will repair or replace any Fan which fails due to defects in materials or workmanship during the Warranty Term. The Fan
must be returned (at Owner’s cost) to the RadonAway®factory. Any Fan returned to the factory will be discarded unless the Owner
provides specic instructions along with the Fan when it is returned regardless of whether or not the Fan is actually replaced under this
warranty. Proof of purchase must be supplied upon request for service under this Warranty.
This Warranty is contingent on installation of the Fan in accordance with the instructions provided. This Warranty does not apply where
any repairs or alterations have been made or attempted by others, or if the unit has been abused or misused. Warranty does not cover
damage in shipment unless the damage is due to the negligence of RadonAway®.
1 YEAR EXTENDED WARRANTY WITH PROFESSIONAL INSTALLATION
RadonAway® will extend the Warranty Term of the fan to twelve (12) months from date of installation or fteen (15) months from
the date of manufacture, whichever is sooner, if the Fan is installed in a professionally designed and professionally installed active
soil depressurization system or installed as a replacement fan in a professionally designed and professionally installed active soil
depressurization system. Proof of purchase and/or proof of professional installation may be required for service under this warranty.
RadonAway®is not responsible for installation, removal or delivery costs associated with this Warranty.
For service under this Warranty, contact RadonAway®for a Return Material Authorization (RMA) Number and shipping information. No
returns can be accepted without an RMA. If factory return is required, the customer assumes all shipping costs to and from factory.
RadonAway®
3 Saber Way
Ward Hill, MA 01835 USA
TEL [phone]
FAX [phone]
Email to: [e-mail]
Record the following information for your records:
Serial No. _________________________________________________
Purchase Date: _________________________________________________
EXCEPT AS STATED ABOVE, THE HS SERIES FAN IS PROVIDED WITHOUT WARRANTY OF ANY KIND, EITHER
EXPRESS OR IMPLIED, INCLUDING, WITHOUT LIMITATION, IMPLIED WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE.
IN NO EVENT SHALL RADONAWAY®BE LIABLE FOR ANY DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES ARISING OUT OF, OR RELATING TO, THE FAN OR THE PERFORMANCE THEREOF.
RADONAWAY’S AGGREGATE LIABILITY HEREUNDER SHALL NOT IN ANY EVENT EXCEED THE AMOUNT OF THE
PURCHASE PRICE OF SAID PRODUCT. THE SOLE AND EXCLUSIVE REMEDY UNDER THIS WARRANTY SHALL BE THE
REPAIR OR REPLACEMENT OF THE PRODUCT, TO THE EXTENT THE SAME DOES NOT MEET WITH RADONAWAY’S
WARRANTY AS PROVIDED ABOVE.
