Key features
• External RAID system for 2x 3.5" SATA HDDs
• Compact aluminium premium design
• RAID level: RAID 0, RAID 1
• Multi Host interfaces:1x USB 3.0, 1x eSATA,
2x Firewire 800, 1x Firewire 400
• Transfer rates: USB 3.0 up to 5 Gbit/s, eSATA up to 3 Gbit/s,
FireWire 800 up to 800 Mbit/s, FireWire 400 up to 400 Mbit/s
• Plug & Play and Hot Swap
• All settings via LCD display and front buttons
IB-RD3252-U3SE2
External RAID sub system
for 2x 3.5" SATA HDD
Technical data
Model IB-RD3252-U3SE2
Article No. 22202
EAN code 4250078187967
Brand ICY BOX
Article text External RAID sub system for
2x 3.5" SATA HDDs
Colour Silver
Material Aluminium
HDD interface 2x 3.5" SATA
HDD capacity unlimited
Hot Swap Yes
Plug & Play Yes
External data interface 1x USB 3.0, 1x eSATA,
2x Firewire 800, 1x Firewire 400
RAID Level RAID 0, 1
LED RAID and HDD status
Display/Front panel Button: Select, OK
Display: Information about hardware and device
configuration, system start, HDD failure, RAID failure,
Interface, Rebuilding
Alarm Yes
User interface No
Operating system Windows, Mac OS, Linux
Transfer rate USB 3.0 up to 5 Gbit/s, eSATA up to 3 Gbit/s,
FireWire 800 up to 800 Mbit/s, Firewire a up to 400 Mbit/s
Fan Yes
Power switch Yes
Auto rebuilding Yes
Power connector Wall power supply: 100-240 V 50/60 Hz;
DC: 12 V, 4 A

On/Off Switch:
Switches the
device on or off
OK/Select button:
Button for
navigation and
selection in the
setup menu
LED HDD 1 + 2:
HDD access/
HDD failure
LED:
HDD status/
Rebuilding
Power connector
USB 3.0
FireWire 800
eSATA
Firewire 400
RaidSonic Technology GmbH • Kurt-Fischer-Straße 50 • 22926 Ahrensburg / Germany
Telefon: [phone] – 468 900 (Vertrieb) • Fax: [phone] – 468 901 • www.raidsonic.de
Offers and deliveries are only done under our General Terms and Conditions. Errors and omissions excepted. RaidSonic
STORAGE SOLUTIONS WITHOUT LIMITS
Packing content
1x IB-RD3252, 1x USB 3.0 cable, 1x eSATA cable, 1x Firewire 800 cable, 1x Firewire 400 cable, power supply, manual (German/English)
Pretty Performance Package
Compact and space-saving. But it still offers space for two 3.5" HDDs.
Two Firewire 800, one Firewire 400, an eSATA plus a USB 3.0 ports provide great performance and flexibility in data transfer.
Logistical data
Packing unit: 6 pcs./carton Dimension/Carton: 490x420x380 mm Import tax: 84733080
Total weight: 14.7 kg/carton Dimension (with packing): 130x350x235 mm
Gross weight: 2.26 kg Dimension of article: 244x125x82 mm
Net weight: 0.478 kg Country of Origin: China
