Raisecom ISCOM RAX711 Technical specifications

ISCOM RAX711 (B)
Product Description
(Rel_01)
www.raisecom.com

Raisecom Technology Co., Ltd. provides customers with comprehensive technical support and services. For any
assistance, please contact our local office or company headquarters.
Website: http://www.raisecom.com
Tel: [phone]
Fax: [phone]
Email: [e-mail]
Address: Raisecom Building, No. 11, EastArea, No. 10 Block, East Xibeiwang Road, Haidian District, Beijing,
P.R.China
Postal code: 100094
-----------------------------------------------------------------------------------------------------------------------------------------
Notice
Copyright © 2014
Raisecom
All rights reserved.
No part of this publication may be excerpted, reproduced, translated or utilized in any form or by any means,
electronic or mechanical, including photocopying and microfilm, without permission in Writing from Raisecom
Technology Co., Ltd.
is the trademark of Raisecom Technology Co., Ltd.
All other trademarks and trade names mentioned in this document are the property of their respective holders.
The information in this document is subject to change without notice. Every effort has been made in the
preparation of this document to ensure accuracy of the contents, but all statements, information, and
recommendations in this document do not constitute the warranty of any kind, express or implied.

Raisecom
ISCOM RAX711 (B) Product Description
Preface
Raisecom Technology Co., Ltd.
i
Preface
Objectives
This document describes product orientation, features, networking applications, system
structure, OAM, and technical specifications of the ISCOM RAX711.
The appendix describes cables and service interface module parameters, and lists terms,
acronyms, and abbreviations involved in this document.
Versions
The following table lists the product versions related to this document.
Product name
Product version
Hardware version
Software version
ISCOM RAX711
P200R003
B.02 or later
REAP 1.2 or later
Conventions
Symbol conventions
The symbols that may be found in this document are defined as follows.
Symbol
Description
Indicate a hazard with a medium or low level of risk which, if
not avoided, could result in minor or moderate injury.
Indicate a potentially hazardous situation that, if not avoided,
could cause equipment damage, data loss, and performance
degradation, or unexpected results.
Provide additional information to emphasize or supplement
important points of the main text.
Indicate a tip that may help you solve a problem or save time.

Raisecom
ISCOM RAX711 (B) Product Description
Preface
Raisecom Technology Co., Ltd.
ii
General conventions
Convention
Description
Times New Roman
Normal paragraphs are in Times New Roman.
Arial
Paragraphs in Warning, Caution, Notes, and Tip are in Arial.
Boldface
Names of files, directories, folders, and users are in boldface.
For example, log in as user root.
Italic
Book titles are in italics.
Lucida Console
Terminal display is in Lucida Console.
Change history
Updates between document versions are cumulative. Therefore, the latest document version
contains all updates made to previous versions.
Issue 01 (2014-06-20)
Initial commercial release

Raisecom
ISCOM RAX711 (B) Product Description
Contents
Raisecom Technology Co., Ltd.
iii
Contents
1Overview.........................................................................................................................................1
1.1 Introduction......................................................................................................................................................1
1.2 Characters.........................................................................................................................................................1
1.3 Features............................................................................................................................................................2
1.4 Ordering information........................................................................................................................................4
1.4.1 Naming convention.................................................................................................................................4
1.4.2 Ordering information about device .........................................................................................................4
1.4.3 Ordering information about auxiliary parts.............................................................................................5
2Networking applications.................................................................................................................7
2.1 SME access and mobile backhaul networking .................................................................................................7
2.2 Typical end-to-end ELPS networking ..............................................................................................................8
2.3 Typical ERPS networking ................................................................................................................................9
3System structure............................................................................................................................10
3.1 Appearance.....................................................................................................................................................10
3.2 Interfaces........................................................................................................................................................ 11
3.2.1 Service interfaces.................................................................................................................................. 11
3.2.2 Management interfaces .........................................................................................................................13
3.2.3 Power interfaces....................................................................................................................................14
3.3 LEDs ..............................................................................................................................................................15
3.4 Hardware logic structure ................................................................................................................................16
4Device installation.........................................................................................................................19
4.1 Installing hardware.........................................................................................................................................19
4.2 Safety precautions ..........................................................................................................................................19
4.2.2 Preparing for installation.......................................................................................................................20
4.2.3 Installing device....................................................................................................................................20
4.2.4 Connecting cables ................................................................................................................................. 22
4.3 Installing software..........................................................................................................................................26
5Technical specifications.................................................................................................................27
5.1 Integrated machine parameters.......................................................................................................................27
5.2 Laser security class ........................................................................................................................................28
5.3 Reliability specifications................................................................................................................................28

Raisecom
ISCOM RAX711 (B) Product Description
Contents
Raisecom Technology Co., Ltd.
iv
5.4 EMC indexes..................................................................................................................................................29
5.5 Security standards ..........................................................................................................................................29
5.6 Environmental requirements ..........................................................................................................................29
5.6.1 Storage environment .............................................................................................................................29
5.6.2 Transport environment..........................................................................................................................31
5.6.3 Operation environment .........................................................................................................................33
5.6.4 Biotic environment................................................................................................................................33
5.7 Compliant standards and protocols ................................................................................................................34
6Appendix........................................................................................................................................38
6.1 Cables.............................................................................................................................................................38
6.1.1 Grounding cable....................................................................................................................................38
6.1.2 DC power cable.....................................................................................................................................39
6.1.3 AC power cables ...................................................................................................................................40
6.1.4 Console cable........................................................................................................................................42
6.1.5 Fiber......................................................................................................................................................43
6.1.6 Ethernet cable........................................................................................................................................45
6.1.7 Clock cable............................................................................................................................................48
6.2 SFP modules...................................................................................................................................................49
6.2.1 100BASE-FX SFP optical module........................................................................................................49
6.2.2 SFP electrical module ...........................................................................................................................50
6.2.3 1000BASE-X SFP optical module........................................................................................................50
6.2.4 SFP electrical module ...........................................................................................................................52
6.3 Terms..............................................................................................................................................................52
6.4 Acronyms and abbreviations ..........................................................................................................................53

Raisecom
ISCOM RAX711 (B) Product Description
Figures
Raisecom Technology Co., Ltd.
v
Figures
Figure 1-1 Naming convention ..............................................................................................................................4
Figure 2-1 SME access and mobile backhaul networking .....................................................................................8
Figure 2-2 End-to-end ELPS networking...............................................................................................................9
Figure 2-3 Ring network protection application ....................................................................................................9
Figure 3-1 Appearance of the ISCOM RAX711-CLK.........................................................................................10
Figure 3-2 Appearance of the ISCOM RAX711 ..................................................................................................10
Figure 3-3 AC power interface.............................................................................................................................14
Figure 3-4 DC power interface.............................................................................................................................15
Figure 3-5 Hardware logical structure..................................................................................................................17
Figure 4-1 Installing customized brackets............................................................................................................21
Figure 4-2 Installing the device horizontally on the rack.....................................................................................21
Figure 4-3 Installing long wall-mount brackets ...................................................................................................21
Figure 4-4 Installing device vertically on wall.....................................................................................................22
Figure 4-5 Installing device on workbench..........................................................................................................22
Figure 4-6 Connecting grounding cable...............................................................................................................23
Figure 4-7 Connecting DC power cable...............................................................................................................23
Figure 4-8 Connecting AC power cable...............................................................................................................24
Figure 4-9 Connecting Console cable ..................................................................................................................24
Figure 4-10 Inserting SFP optical module............................................................................................................25
Figure 4-11 Connecting fiber ...............................................................................................................................25
Figure 4-12 Connecting Ethernet cable................................................................................................................25
Figure 4-13 Connecting clock cable.....................................................................................................................26
Figure 6-1 Grounding cable .................................................................................................................................38
Figure 6-2 DC power cable..................................................................................................................................39
Figure 6-3 British standard AC power cable........................................................................................................40
Figure 6-4 European standard AC power cable....................................................................................................40

Raisecom
ISCOM RAX711 (B) Product Description
Figures
Raisecom Technology Co., Ltd.
vi
Figure 6-5 American standard AC power cable ...................................................................................................41
Figure 6-6 RJ45 Console cable ............................................................................................................................42
Figure 6-7 Wiring between PINs on device and PINs on PC...............................................................................43
Figure 6-8 LC/PC fiber connector........................................................................................................................44
Figure 6-9 SC/PC fiber connector........................................................................................................................44
Figure 6-10 FC/PC fiber connector......................................................................................................................45
Figure 6-11 Ethernet cable ...................................................................................................................................45
Figure 6-12 Wiring of straight-through cable.......................................................................................................47
Figure 6-13 Wiring of 100 Mbit/s crossover cable...............................................................................................47
Figure 6-14 Wiring of 1000 Mbit/s crossover cable.............................................................................................48
Figure 6-15 Clock cable for 2 Mbit/s or MHz interface.......................................................................................48

Raisecom
ISCOM RAX711 (B) Product Description
Tables
Raisecom Technology Co., Ltd.
vii
Tables
Table 1-1 Features..................................................................................................................................................2
Table 1-2 Naming convention................................................................................................................................4
Table 1-3 Ordering information about device ........................................................................................................4
Table 1-4 Models and parameters of power modules.............................................................................................5
Table 3-1 Prints .................................................................................................................................................... 11
Table 3-2 Service interfaces ................................................................................................................................. 11
Table 3-3 Parameters of 100BASE-FX/1000BASE-X SFP optical interface.......................................................12
Table 3-4 Parameters of 1000BASE-T Combo electrical interface......................................................................12
Table 3-5 Parameters of 2 Mbit/s or 2 MHz interface..........................................................................................13
Table 3-6 Management interfaces ........................................................................................................................13
Table 3-7 Parameters of SNMP interface.............................................................................................................13
Table 3-8 Parameters of Console interface...........................................................................................................14
Table 3-9 Power interfaces...................................................................................................................................14
Table 3-10 Parameters of AC power module .......................................................................................................15
Table 3-11 Parameters of the DC power interface................................................................................................15
Table 3-12 LEDs ..................................................................................................................................................15
Table 4-1 Power supply conditions ......................................................................................................................20
Table 5-1 Integrated machine parameters.............................................................................................................27
Table 5-2 Reliability specifications......................................................................................................................29
Table 5-3 Atmosphere requirements for device during storage............................................................................30
Table 5-4 Mechanical active substance requirements during storage...................................................................30
Table 5-5 Chemical active substance requirements during storage......................................................................31
Table 5-6 Atmosphere requirements for device during transport .........................................................................31
Table 5-7 Mechanical active substance requirements during transportation........................................................32
Table 5-8 Chemical active substance requirements during transport ...................................................................32
Table 5-9 Atmosphere requirements during operation .........................................................................................33

Raisecom
ISCOM RAX711 (B) Product Description
Tables
Raisecom Technology Co., Ltd.
viii
Table 5-10 Mechanical active substance requirements during operation.............................................................34
Table 5-11 Chemical active substance requirements during operation.................................................................34
Table 5-12 Compliant standards and protocols ....................................................................................................34
Table 6-1 Specifications of the grounding cable ..................................................................................................39
Table 6-2 Technical specifications of the DC power cable ..................................................................................39
Table 6-3 AC power cables ..................................................................................................................................40
Table 6-4 Specifications of British standard AC power cable..............................................................................41
Table 6-5 Specifications of European standard AC power cable..........................................................................41
Table 6-6 Specifications of American standard AC power cable .........................................................................41
Table 6-7 Technical specifications of Console cable............................................................................................42
Table 6-8 PIN definitions on Console interface on device...................................................................................42
Table 6-9 PIN definitions on serial interface on PC.............................................................................................43
Table 6-10 Fiber connectors................................................................................................................................. 43
Table 6-11 Wiring of EIA/TIA 568A and EIA/TIA 568B standards ....................................................................46
Table 6-12 Technical specifications of Ethernet cable .........................................................................................46
Table 6-13 Technical specifications of RJ45/RJ45 clock cable............................................................................48
Table 6-14 PINs definitions of clock cable for 2 Mbit/s or MHz interface..........................................................49
Table 6-15 Parameters of 100BASE-FX SFP optical module..............................................................................49
Table 6-16 Parameters of SFP electrical module..................................................................................................50
Table 6-17 Parameters of 1000BASE-X SFP optical module..............................................................................51
Table 6-18 Parameters of SFP electrical module..................................................................................................52

Raisecom
ISCOM RAX711 (B)Product Description
Raisecom Technology Co., Ltd.
1
1 Overview
This chapter is an overview of the ISCOM RAX711, including the following sections:
Introduction
Characters
Features
1.1 Introduction
The full 1000 Mbit/s Ethernet Demarcation Device (EDD) ISCOM RAX711 (hereinafter
referred to as the ISCOM RAX711), developed by Raisecom, is designed for the remote
access for the Metropolitan Access Network (MAN), Small and Medium Enterprise (SME)
access, and mobile backhaul network access. By cooperating with the ISCOM2924GF-
4GE/4C at the Central Office (CO), it provides a MAN Ethernet access solution that is of easy
service activation and deployment for carriers.
The ISCOM RAX711 has the following interfaces:
Two uplink Small Factor Pluggable (SFP) optical interfaces, which support 100BASE-
FX/1000BASE-X SFP and 10/100/1000BASE-T SFP.
Four downlink pairs of Combo interfaces, of which:
Four Combo optical interfaces support the 100BASE-FX/1000BASE-X SFP.
Four Combo electrical interfaces support the 10/100/1000BASE-T SFP.
The ISCOM RAX711-CLK provides an external clock synchronization interface, supporting
inputting or outputting 2 Mbit/s or 2 MHz external clock synchronization signals.
1.2 Characters
The ISCOM RAX711 has the following characters:
Comply with MEF 9 and MEF 14 standards, and be compatible with MEF CE2.0
standard.
Provide GE access ability on the interface.

Raisecom
ISCOM RAX711 (B)Product Description
Raisecom Technology Co., Ltd.
2
Support ITU-T G.8031 Ethernet Linear Protection Switching (ELPS) and ITU-T G.8032
Ethernet Ring Protection Switching (ERPS). The Automatic Protection Switching (APS)
time is less than 50ms.
Support hardware-based IEEE 802.1ag end-to-end link fault management.
Support hardware-based end-to-end Service LevelAgreement (SLA) features, such as
testing delay, jitter, and packet loss rate.
Support Y.1564.
SupportAuto-Provisioning.
Support strict QoS guarantee.
Support Layer 2 loopback protocols.
Support hierarchical rate limiting in the ingress interface direction.
Provide the SNMP interface.
Support monitoring multiple ways of voltage and temperature.
Support power failure alarms, namely, Layer 2 Dying Gasp.
Support 1+1 power protection and hybrid input of AC power and DC power.
Support EMI Class B.
SupportAnti-Static Discharge (ASD) interference.
1.3 Features
Table 1-1 lists features of the ISCOM RAX711.
Table 1-1 Features
Feature
Description
Basic features
Accessing the device (RJ45 Console/Telnet/SSHv2)
CLI
Managing files (BootROM/system files/configuration files)
Load and upgrade (TFTP auto-loading, upgrade from BootRom, and
upgrade from FTP/TFTP)
Time management
Managing interfaces
Basic information (device name, language mode, saving/deleting
configurations, and restarting the device)
Task scheduling
Ethernet
MAC address (32K addresses)
Jumbo frame
Maximum frame length (12 KBytes)
VLAN (4094 VLANs)
User VLAN
QinQ
1:1 VLAN mapping
Loopback detection
Interface protection
Port mirroring
L2CP

Raisecom
ISCOM RAX711 (B)Product Description
Raisecom Technology Co., Ltd.
3
Feature
Description
IP services
ARP
Layer 3 interface
DHCP Client
DHCP Snooping
DHCP Option 82/DHCP Option 61
QoS
Trust priority
Traffic classification (IP priority, DSCP priority, and CoS priority) and
traffic policy (rate limiting based on traffic policy, re-direction, and re-
marking)
Local priority mapping and queue scheduling (SP, WRR, DRR,
SP+WRR, and SP+DRR)
Interface-based and VLAN-based rate limiting (the maximum rate limit
is 10 Gbit/s, and the smallest step is 8 Kbit/s)
QoS enhancement
Security
Secure MAC
ACL (400 ACLs)
RADIUS authentication
TACACS+
802.1x
PPPoE+
Storm control
Reliability
Link aggregation (4 link aggregation groups)
Interface backup
ELPS (ITU-TG.8031)
ERPS (ITU-TG.8032)
Failover
OAM
EFM (IEEE 802.3ah)
CFM (IEEE 802.1ag/ITU-Y.1731)
SLA
Y.1564
E-LMI
Service
System
management
SNMP
KeepAlive
RMON
LLDP
DDM
System log
Alarm management
Hardware monitoring
CPU monitoring
Caching CPU packets
Dual-system
Auto-Provisioning
Loopback
Ping and Traceroute
Performance statistics
For details about each feature, see ISCOM RAX711 Configuration Guide.

Raisecom
ISCOM RAX711 (B)Product Description
Raisecom Technology Co., Ltd.
4
1.4 Ordering information
1.4.1 Naming convention
Figure 1-1 shows the naming convention of the ISCOM RAX711.
Figure 1-1 Naming convention
Table 1-2 describes naming convention of the ISCOM RAX711.
Table 1-2 Naming convention
Domain
Indication
Value
Description
A
Product ID
ISCOM RAX
It is a carrier-grade Ethernet series device.
B
Product series
700
It is one of the 700 series, such as 711.
C
Main feature
CLK
It supports clock synchronization.
Optical modules specified in section 6.2 SFP modules are recommended for the
ISCOM RAX711. If you choose other ones, contact Raisecom technical support
engineers in advance.
1.4.2 Ordering information about device
Table 1-3 lists ordering information about the ISCOM RAX711.
Table 1-3 Ordering information about device
Model
Description
ISCOM RAX711-CLK
Support four 10/100/1000 Mbit/s Combo downlink
interfaces.
Support two 10/100/1000 Mbit/s SFP uplink interfaces.
Support the RJ45 Console interface.
Support the SNMP interface and out-of-band network
management.
Support hybrid power supply of 110/220 VAC and -48 VDC.
Support synchronous Ethernet.

Raisecom
ISCOM RAX711 (B)Product Description
Raisecom Technology Co., Ltd.
5
Model
Description
ISCOM RAX711
Support four 10/100/1000 Mbit/s Combo downlink
interfaces.
Support two 10/100/1000 Mbit/s SFP uplink interfaces.
Support the RJ45 Console interface.
Support the SNMP interface and out-of-band network
management.
Support hybrid power supply of 110/220 VAC and -48 VDC.
1.4.3 Ordering information about auxiliary parts
The ISCOM RAX711 can be equipped with the following auxiliary parts:
SFP modules
Power modules
For details about SFP models and parameters, see section 6.2 SFP modules.
Table 1-4 lists models and parameters of power modules.
Table 1-4 Models and parameters of power modules
Model
Description
RPA0361-SI-220S12
36 W AC power module
Lightning protection level: 6 kV in both common mode and
differential mode
Input voltage range: 100–240 VAC
Use one of the following power cables:
POL-AC-European standard-3-pin/plum blossom tail-18AWG-
1.5m/RoHS
POL-AC-American standard-3-pin/plum blossom tail-18AWG-
1.5m/RoHS
POL-AC-British standard-3-pin/plum blossom tail-0.75mm2-
1.5m/RoHS
RPD0361-SI-48S12
36 W DC power module
Lightning protection level: 4 kV in common mode and 2 kV in
differential mode
Input voltage range: -36 to -72 VDC
This model is delivered with the DC power cable and Phoenix
terminal.

Raisecom
ISCOM RAX711 (B)Product Description
Raisecom Technology Co., Ltd.
6
Model
Description
RPA0362-SI-220S12
NEBS-supportive 36 W AC power module
Lightning protection level: 6 kV in common mode and 6 kV in
differential mode
Input voltage range: 100–240 VAC
Supported power cables are as below:
POL-AC-European standard 3-pin/plum blossom tail-18AWG-
1.5m/RoHS
POL-AC-American standard 3-pin/plum blossom tail-18AWG-
1.5m/RoHS
POL-AC-British standard 3-pin/plum blossom tail-0.75mm2-
1.5m/RoHS
RPD0362-SI-48S12
NEBS-supportive 36 W DC power module
Lightning protection level: 4 kV in common mode and 2 kV in
differential mode
Input voltage range: -36 to -72 VDC
This model is delivered with the DC power cable and Phoenix
terminal.

Raisecom
ISCOM RAX711 (B)Product Description
Raisecom Technology Co., Ltd.
7
2 Networking applications
This chapter describes typical networking applications of the ISCOM RAX711, including the
following sections:
SME access and mobile backhaul
Typical end-to-end ELPS
Typical ERPS
2.1 SME access and mobile backhaul networking
As shown in Figure 2-1, in MAN access application, as an EDD, the ISCOM RAX711
connects to the ISCOM2924GF-4C in the uplink to implement SME leased line access and
mobile backhaul access.
An EDD can be connected to two ISCOM2924GF-4C devices to implement dual homing link
protection. Two or more ISCOM2924GF-4C devices can form a G.8032 ring network, and the
APS time is less than 50ms. In this application, network reliability is enhanced.
The SME user, eNodeB, or NodeB can be connected to the EDD flexibly for leased line
access or mobile backhaul through the FE or GE interface.

Raisecom
ISCOM RAX711 (B)Product Description
Raisecom Technology Co., Ltd.
8
Figure 2-1 SME access and mobile backhaul networking
2.2 Typical end-to-end ELPS networking
As shown in Figure 2-2, in the application of connecting the headquarter and the branch, as a
remote device, the ISCOM RAX711 reliably connects them.
This application has the following features:
Utilize existing Multi-Protocol Label Switching (MPLS) network as the core network.
Be connected to two ISCOM2924GF-4GE/4C devices. This implements dual homing.
Support end-to-end Operation,Administration, and Maintenance (OAM) and high-
precision SLA test.
Support end-to-end ELPS. This guarantees high reliability of network connections.
This application can use the MPLS-supportive ISCOM2924GF-4GE/4C as the Provider Edge
(PE) device.

Raisecom
ISCOM RAX711 (B)Product Description
Raisecom Technology Co., Ltd.
9
Figure 2-2 End-to-end ELPS networking
2.3 Typical ERPS networking
As shown in Figure 2-3, in MAN access application, as a remote device, the ISCOM RAX711
can network with the ISCOM2924GF-4GE/4C.
This application has the following features:
As the aggregation device, two or more ISCOM2924GF-4GE/4C devices can form a
G.8032 ring network. The APS time of the ring network is less than 50ms.
The ISCOM RAX711 and the ISCOM2924GF-4GE/4C can form a G.8032 ring network.
This guarantees reliable access for downstream users.
Figure 2-3 Ring network protection application

Raisecom
ISCOM RAX711 (B)Product Description
Raisecom Technology Co., Ltd.
10
3 System structure
This chapter describes system structure of the ISCOM RAX711, including the following
sections:
Appearance
Interfaces
LEDs
3.1 Appearance
Figure 3-1 Appearance of the ISCOM RAX711-CLK
Figure 3-2 Appearance of the ISCOM RAX711
Table 3-1 lists prints on the ISCOM RAX711-CLK.
