Raloy RW119 Series User manual

www.raloy.com
User Manual
RW119 –Series
1U widescreen 19” LCD keyboard drawer
Combo interface PS/2 or USB input
Keyboard available in 13 international
languages
Resolution up to 1440 x 900
Full range of KVM options
RWS119 –Series
1U widescreen 19” LCD keyboard drawer
Direct support for SUN Micro 1152 x 900
native resolution
Combo interface PS/2 or USB input
SUN key support including Stop, Cut, Paste,
Compose etc
Full range of KVM options
Raloy LCD Rack Console with Integrated Matrix IP CAT5/6 KVM
16 or 32 Ports
RW119- Widescreen
Series
RW119- MUIP1613 / MUIP1614 / MUIP1624
RW119- MUIP3213 / MUIP3214 / MUIP3224
RWS119- Sun
Solaris Series
RWS119- MUIP1613 / MUIP1614 / MUIP1624
RWS119- MUIP3213 / MUIP3214 / MUIP3224

www.raloy.com
Contents
Chapter 1 Getting Started..............................................................................................................................1
1.1 Important Safeguards .......................................................................................................................................... 1
1.2 Regulatory Notice ................................................................................................................................................ 2
Legal Information ......................................................................................................................................................................................... 2
Safety Instructions........................................................................................................................................................................................ 2
Regulatory Notices Federal Communications Commission (FCC) ................................................................................................................ 2
1.3 Package Contents................................................................................................................................................. 3
1.4 Before Installation ............................................................................................................................................... 4
1.5 Unpacking ........................................................................................................................................................... 4
1.6 Optional Accessories............................................................................................................................................ 5
1.7 LCD Rackmount Structure Diagram....................................................................................................................... 6
1.8 Installation .......................................................................................................................................................... 7
1.9 Installation (continued)........................................................................................................................................ 8
1.10 How to use the slides........................................................................................................................................... 9
1.11 How to use the LCD Keyboard Drawer .................................................................................................................10
1.12 KVM Model Connection Diagrams .......................................................................................................................11
1.13 KVM Diagrams....................................................................................................................................................12
Models: .........................................................................................................................................................................12
RW119-MUIP1613 .........................................................................................................................................................12
RWS119-MUIP1613........................................................................................................................................................12
RW119-MUIP1614 .........................................................................................................................................................12
RWS119-MUIP1614........................................................................................................................................................12
RW119-MUIP1624 .........................................................................................................................................................12
RWS119-MUIP1624........................................................................................................................................................12
KVM Server Connection ............................................................................................................................................................................. 12
KVM Cascade.............................................................................................................................................................................................. 12
1.14 KVM Diagrams..................................................................................................................................................... 2
Models: .......................................................................................................................................................................... 2
RW119-MUIP3213 RWS119-MUIP3213............................................................................................................................ 2
RW119-MUIP3214 .......................................................................................................................................................... 2
RWS119-MUIP3214......................................................................................................................................................... 2
RW119-MUIP3224 RWS119-MUIP3224............................................................................................................................ 2
KVM Server Connection ............................................................................................................................................................................... 2
KVM Cascade................................................................................................................................................................................................ 2

www.raloy.com
1.15 KVM Connection KVM Cable Connection & Receiver Diagrams (All Models) .......................................................... 2
Receiver........................................................................................................................................................................................................ 2
Receiver Connection .................................................................................................................................................................................... 2
Chapter 2 Operation.......................................................................................................................................3
2.1 On-screen Display Operation................................................................................................................................ 3
2.2 On-screen Menu .................................................................................................................................................. 4
Chapter 3 LCD Specifications.......................................................................................................................5
3.1 LCD Rackmount Widescreen Series Specifications................................................................................................. 5
3.2 Keyboard & Mouse .............................................................................................................................................. 6
For RW119 series.......................................................................................................................................................................................... 6
3.2 Keyboard & Mouse (Continued) ........................................................................................................................... 7
For RWS119 series........................................................................................................................................................................................ 7
3.3 How to use “NS” keyboard................................................................................................................................... 8
Chapter 4 KVM Specifications......................................................................................................................9
4.1 Matrix-Multi-User CAT 5/6 KVM Over IP............................................................................................................... 9
4.2 DVI-D Option ......................................................................................................................................................10
4.3 BNC + S-Video Option .........................................................................................................................................10
4.4 Audio Option ......................................................................................................................................................10
4.5 DC Power Options...............................................................................................................................................11
Chapter 5 Troubleshooting......................................................................................................................... 12
For RWS119 Series .........................................................................................................................................................12
Chapter 6 Dimensions ................................................................................................................................. 13

Widescreen LCD Rack Console with Matrix IP CAT5/6 KVM
www.raloy.com 1
Chapter 1 Getting Started
1.1 Important Safeguards
Please read all of these instructions carefully before you use the device. Save this manual for future reference.
What the warranty does not cover
Any product, on which the serial number has been defaced, modified or removed.
Damage, deterioration or malfunction resulting from:
oAccident, misuse, neglect, fire, water, lightning, or other acts of nature, unauthorized product
modification, or failure to follow instructions supplied with the product.
oRepair or attempted repair by anyone not authorized by us.
oAny damage of the product due to shipment.
oRemoval or installation of the product.
oCauses external to the product, such as electric power fluctuation or failure.
oUse of supplies or parts not meeting our specifications.
oNormal wear and tear.
oAny other causes which does not relate to a product defect.
Removal, installation, and set-up service charges.

Widescreen LCD Rack Console with Matrix IP CAT5/6 KVM
www.raloy.com 2
1.2 Regulatory Notice
Legal Information
First English printing, October 2002
Information in this document has been carefully checked for accuracy; however, no guarantee is given to the
correctness of the contents. The information in this document is subject to change without notice. We are not
liable for any injury or loss that results from the use of this equipment.
Safety Instructions
Unplug equipment before cleaning. Don’t use liquid or spray detergent; use a moist cloth.
Keep equipment away from excessive humidity and heat. Preferably, keep it in an air-conditioned
environment with temperatures not exceeding 40º Celsius (104º Fahrenheit).
When installing, place the equipment on a sturdy, level surface to prevent it from accidentally falling
and causing damage to other equipment or injury to persons nearby.
When the drawer is in an open position, do not cover, block or in any way obstruct the gap between it
and the power supply. Proper air convection is necessary to keep it from overheating.
Arrange the equipment’s power cord in such a way that others won’t trip or fall over it.
If you are using a power cord that didn’t ship with the equipment, ensure that it is rated for the voltage
and current labeled on the equipment’s electrical ratings label. The voltage rating on the cord should be
higher than the one listed on the equipment’s ratings label.
Observe all precautions and warnings attached to the equipment.
If you don’t intend on using the equipment for a long time, disconnect it from the power outlet to prevent
being damaged by transient over-voltage.
Keep all liquids away from the equipment to minimize the risk of accidental spillage. Liquid spilled on to
the power supply or on other hardware may cause damage, fire or electrical shock.
Only qualified service personnel should open the chassis. Opening it yourself could damage the
equipment and invalidate its warranty.
If any part of the equipment becomes damaged or stops functioning, have it checked by qualified
service personnel.
CAUTION: Slide/rail mounted equipment is not to be used as a shelf or a work space.
Regulatory Notices Federal Communications Commission (FCC)
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation.
Any changes or modifications made to this equipment may void the user’s authority to operate this equipment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
Re-position or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

Widescreen LCD Rack Console with Matrix IP CAT5/6 KVM
www.raloy.com 3
1.3 Package Contents
1) LCD keyboard drawer w/ integrated KVM Switch x 1 pc
2) Screw M3.2 x 4 pcs
3) Screw M4 x 10mm x 8pcs
4) Bracket x 1 set
5) User Manual x 1 pc
6) 12V Power Adapter
7) Receiver x 1 set (for MUIP1613, MUIP1624, MUIP 3213 & MUIP3224)
Receiver x 2 set (for MUIP 1614 & MUIP 3214)
8) RDG-100S USB Dongle for CAT5/6 KVM x 16pcs
RCE-6 Combo 4-in-1 KVM cable x 1 pcs (for MUIP1613, MUIP1624, MUIP 3213 & MUIP3224)
RCE-6 Combo 4-in-1 KVM cable x 2 pcs (for MUIP 1614 & MUIP 3214)

Widescreen LCD Rack Console with Matrix IP CAT5/6 KVM
www.raloy.com 4
1.4 Before Installation
It is very important to place the LCD Keyboard Drawer in a suitable environment.
The surface for placing and fixing the LCD Keyboard Drawer should be stable and level or mounted into
a suitable cabinet.
Make sure the location is well ventilated, out of direct sunlight, away from sources of excessive dust,
dirt, heat, water, moisture and vibration.
Position LCD Keyboard Drawer with respect to related facilities.
1.5 Unpacking
The LCD keyboard drawer comes with the standard parts as shown in the package contents. Check and make
sure they are included and in good condition. If anything is missing, or damage, contact the supplier
immediately.

Widescreen LCD Rack Console with Matrix IP CAT5/6 KVM
www.raloy.com 5
1.6 Optional Accessories
1. Combo 4-in-1 KVM Cable (For RW-Series)
1.1 RCE-6 6 feet
1.2 RCE-10 10 feet
1.3 RCE-15 15 feet
2. USB 2-in-1 KVM cable (For RWS-Series)
2.1 RCB-6 6 feet
2.2 RCB-10 10 feet
2.3 RCB-15 15 feet
3. CAT5 cable
3.1 RCU-3 3 feet
3.2 RCU-6 6 feet
3.3 RCU-10 10 feet
3.4 RCU-15 15 feet
3.5 RCU-33 33 feet
3.6 RCU-66 66 feet
4. Combo KVM cascade cable
4.1 RCBC-6 6 feet
5. DVI-USB dongle for CAT5/6 KVM
5.1 RDG-100SD
6. VGA-USB dongle for CAT5/6 KVM
6.1RDG-100S
7. VGA-PS/2 dongle for CAT5/6 KVM
7.1 RDG-100
8. Power cord
8.1 IEC power cord
8.2 NEMA5-15 power cord

Widescreen LCD Rack Console with Matrix IP CAT5/6 KVM
www.raloy.com 6
1.7 LCD Rackmount Structure Diagram
1. Carry handle to release the two-point lock
2. Two-point lock
3. LCD interchangeable module kit
4. LCD membrane
5. “One Man” Installation Slide
6. Micro switch for screen auto power off
7. Keyboard interchangeable module kit
8. Membrane switch (KVM option)
9. Mouse interchangeable module kit

Widescreen LCD Rack Console with Matrix IP CAT5/6 KVM
www.raloy.com 7
1.8 Installation
Attach the left and right mounting bracket to rack 19” mounting rails
Adjust the mounting bracket to fit your rack
M6 screw x 8pcs included
Caution: Leaving all M6 screw slightly loose, until you complete the installation in step
Pull out left & right inner slide members
1
5
2

Widescreen LCD Rack Console with Matrix IP CAT5/6 KVM
www.raloy.com 8
1.9 Installation (continued)
Pick up the LCD tray.
Insert the LCD tray into the mounting bracket.
Pull and hold the left & right black arrow buttons
on the rails. Return the LCD tray to park position.
Fix the rear kit to the mounting bracket by M3.2 screw x 4 pcs included.
Caution: This step is necessary. Failure to complete this will cause damage.
Complete the installation
Tighten all 8 pcs of M6 screw to complete the installation.
3
4
5

Widescreen LCD Rack Console with Matrix IP CAT5/6 KVM
www.raloy.com 9
1.10 How to use the slides
Figure 1.
A black arrow release button is
located on the outside of each
slide. (Shown in Figure 1).
Figure 2.
Pull and hold the black arrow
button on either side of the LCD
keyboard drawer to unlock. (Shown
in Figure 2).
Figure 3.
Push the LCD keyboard drawer
into the rack. (Shown in Figure 3).
Caution : Keep your fingers away from the
slide stop

Widescreen LCD Rack Console with Matrix IP CAT5/6 KVM
www.raloy.com 10
1.11 How to use the LCD Keyboard Drawer
Figure 4. Sliding out the LCD keyboard drawer by
pressing the carry handle button first.
Press the carry handle button. Gently pull the
carry handle toward the front of the LCD.
(shown in Figure 4)
Figure 5. Flipping up the LCD to a suitable angle.
Flip up the LCD to a suitable angle. (shown in
Figure5)
Figure 6. Operating the LCD keyboard drawer
Operate the LCD keyboard drawer. (shown in
Figure 6)

Widescreen LCD Rack Console with Matrix IP CAT5/6 KVM
www.raloy.com 11
1.12 KVM Model Connection Diagrams
RW / RWS119-
MUIP 1613
16 –Port KVM
(1 local +
1 CAT5/6 remote +
1 IP remote users)
RW / RWS119-
MUIP 1614
16 –Port KVM
(1 local +
2 CAT5/6 remote +
1 IP remote users)
RW / RWS119-
MUIP 1624
16 –Port KVM
(1 local +
1 CAT5/6 remote +
2 IP remote users)
RW / RWS119-
MUIP 3213
32 –Port KVM
(1 local +
1 CAT5/6 remote +
1 IP remote users)
RW / RWS119-
MUIP 3214
32 –Port KVM
(1 local +
2 CAT5/6 remote +
1 IP remote users)
RW / RWS119-
MUIP 3224
32 –Port KVM
(1 local +
1 CAT5/6 remote +
2 IP remote users)

Widescreen LCD Rack Console with Matrix IP CAT5/6 KVM
www.raloy.com 12
1.13 KVM Diagrams
Models:
RW119-MUIP1613
RWS119-MUIP1613 RW119-MUIP1614
RWS119-MUIP1614 RW119-MUIP1624
RWS119-MUIP1624
KVM Server Connection
KVM Cascade

Widescreen LCD Rack Console with Matrix IP CAT5/6 KVM
www.raloy.com 2
1.14 KVM Diagrams
Models:
RW119-MUIP3213
RWS119-MUIP3213
RW119-MUIP3214
RWS119-MUIP3214 RW119-MUIP3224
RWS119-MUIP3224
KVM Server Connection
KVM Cascade

Widescreen LCD Rack Console with Matrix IP CAT5/6 KVM
www.raloy.com 2
1.15 KVM Connection KVM Cable Connection & Receiver Diagrams (All Models)
Receiver
Receiver Connection

Widescreen LCD Rack Console with Matrix IP CAT5/6 KVM
www.raloy.com 3
Chapter 2 Operation
2.1 On-screen Display Operation
LCD membrane
Membrane Switch
Function
Power light
Green = On
Orange = Power saving
Power on / off LCD
Display the OSD menu
Scrolls through menu options and adjusts the displayed control
(To auto adjustment by pressing the button for 5 seconds)
Exit the OSD screen
Toggle analog, digital & video connection (DVI-D and video options only)
Caution: The LCD keyboard drawer is hot-pluggable, but components of connected devices, such as
the servers and KVM switch, may not be hot-pluggable. Plugging and unplugging cables while servers
and KVM are powered on may cause irreversible damage to the servers, KVM and LCD keyboard
drawer. Before attempting to connect anything to the LCD keyboard drawer, we suggest turning off the
power to all devices before connecting them. Apply power to connected devices again only after the
LCD keyboard is receiving power. The company is not responsible for damage caused in this way.

Widescreen LCD Rack Console with Matrix IP CAT5/6 KVM
www.raloy.com 4
2.2 On-screen Menu
OSD Configuration Page
Image:
To enter into the brightness, contrast, colour temp, red, green, and blue
Geometry:
To enter into the auto adjust, H position, V position, phase and clock
Video:
To enter into the colour, tint, sharpness, noise reduction, DCDi and TV Setup
Audio:
To enter into volume, bass, treble, balance, AVL and mute
Misc:
To enter into the language, OSD position, graphic mode, OSD time, ratio, reset and timer

Widescreen LCD Rack Console with Matrix IP CAT5/6 KVM
www.raloy.com 5
Chapter 3 LCD Specifications
3.1 LCD Rackmount Widescreen Series Specifications
Item
Description
Form Factor
1U rack mounting on slide-out rails
LCD Manufacturer
-
Series
RW
RWS
Diagonal Size
Wide 19" TFT
Wide 19" TFT
Max. Resolution
1440 x 900
1152 x 900 (Direct)
1440 x 900 (Native)
Brightness (cd/m²)
300
300
Color Support
16.7 M
16.7 M
Contrast Ratio (typ.)
1000:1
1000:1
Viewing Angle (H/V)
160˚ x 160˚
160˚ x 160˚
Display Area (mm)
408 x 255
408 x 255
Try Response Time (ms)
1.3
1.3
LCD Panel MTBF (hrs)
50,000
50,000
VGA Signal Input
Analog RGB, 0.7Vp-p
Sync. Type
Separate H/V, Composite, SOG
Resolution
720 x 400, 70 Hz
640 x 480, 60/ 70/ 72/ 75 Hz
800 x 600, 60/ 70/ 72/ 75 Hz
1024 x 768, 60/ 70/ 75 Hz
1152 x 864, 60/ 70/ 75 Hz
1280 x 720, 60/ 70/ 75 Hz
1280 x 720, 60/ 75 Hz
1280 x 1024, 60/ 70/ 75 Hz
1280 x 1024, 60/ 75 Hz
1440 x 900, 60 Hz
--
1152 x 900, 66 Hz
Plug & Play DDC
EDID 1.3
Console Port (Combo)
DB-15 connector for VGA / keyboard / mouse
(Combo interface)
DB-15 connector for VGA / keyboard / mouse
Support USB servers or Combo KVM switches
Power Input
Auto-sensing 100 to 240VAC, 50 / 60Hz
Power Consumption
Max. 48 Watt, Standby 5 Watt
Compatibility
Multi-platform - Mix PCs, SUNs, IBMs, HPs & DELLs.
Regulation Approval
FCC, CE, UL*
Other manuals for RW119 Series
1
This manual suits for next models
1
Table of contents
Other Raloy LCD Drawer manuals
