Raloy DVIKVM112 series User manual

User Manual
1U KVM Switch with DVI-D Connections
Features:
»12 Port
»Single User
DVI-D KVM Switch

II
Contents
Safety Notice iii
1 Product Overview 1
1-1 Package Content (Standalone KVM) 1
1-2 Package Content (Integrated KVM) 1
1-3 DVI-D KVM Table 2
2 Installation 3
2-1 Before Installation 3
2-2 Unpacking the Unit 3
2-3 Installation Instructions (Standalone KVM) 3
2-4 KVM Port & CATx Dongle Connection 4
3 Operation 5
3-1 KVM Button 5
3-5 Hotkeys for KVM 6
4 Product Specications 7
4-1 Specications Table 7
5 Important Information 8
Warranty Information 8
What the Warranty Does Not Cover 9
Regulatory Notices Federal Communications Commission (FCC) 9
Legal Information 9

iii
Please read the following before using your Raloy unit:
■Unplug equipment before cleaning. Don’t use liquid or spray detergent; use a moist cloth.
■Keep equipment away from excessive humidity and heat. Preferably, keep it in an air-conditioned
environment with temperatures not exceeding 40º Celsius (104º Fahrenheit).
■When installing, place the equipment on a sturdy, level surface to prevent it from accidentally falling and
causing damage to other equipment or injury to persons nearby.
■When the equipment is in an open position, do not cover, block or in any way obstruct the gap between it
and the power supply. Proper air convection is necessary to keep it from overheating.
■Arrange the equipment’s power cord in such a way that others won’t trip or fall over it.
■If you are using a power cord that didn’t ship with the equipment, ensure that it is rated for the voltage and
current labeled on the equipment’s electrical ratings label. The voltage rating on the cord should be higher
than the one listed on the equipment’s ratings label.
■Observe all precautions and warnings attached to the equipment.
■If you don’t intend on using the equipment for a long time, disconnect it from the power outlet to prevent
being damaged by transient over-voltage.
■Keep all liquids away from the equipment to minimize the risk of accidental spillage. Liquid spilled on to the
power supply or on other hardware may cause damage, re or electrical shock.
■ Only qualied service personnel should open the chassis. Opening it yourself could damage the equipment
and invalidate its warranty.
Safety Notice

1
1 Product Overview
1-1 Package Content (Standalone KVM)
1-2 Package Content (Integrated KVM)
KVM unit
KVM unit
■1 x KVM Unit
■1 x KVM Unit
■1 x Mounting set w/ bracket & screws
■1 x Power cord (for KVM)

2
Multi-User Matrix Part Numbers Concurrent Users Local Remote IP Ports
DVIKVM112* 1 1 0 0 12
1-3 DVI-D KVM Table
www.Raloy.com/support/downloads.html

3
2 Installation
2-1 Before Installation
2-2 Unpacking the Unit
2-3 Installation Instructions (Standalone KVM)
■It is very important to mount the equipment in a suitable cabinet or on a stable surface.
■Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive
dust, dirt, heat, water, moisture and vibration.
The equipment comes with the standard parts shown in package content. Check and make sure they are
included and in good condition. If anything is missing, or damaged, contact Raloy immediately.
AB
M3.2 x 4.5 mm M4 x 10 mm
Screw A: 2 pcs Screw B: 8 pcs
■Install each bracket using the screws provided.
■Mount the KVM into the rack.
Step 1
Step 2

4
RCI-6 / RCI-10 / RCI-15 Combo KVM Cable
■6 / 10 / 15 ft. DVI KVM cable
■Server end: DVI-D, USB, & Audio
■KVM port: DVI-D & USB3.0
2-4 KVM Port & CATx Dongle Connection
1
7
12
326 5 4
9 811 10
DVI-D KVM port
USB Servers
USB Servers
Power Audio
IP console, remote console, daisy-chain and OSD menu are NOT available for this model.

5
Front Panel - Port LED Indications
Power ON
■Turn off all servers and KVM switches
■Make sure all cables / connectors are properly connected
■Power ON sequence
1. Turn on Rack Monitor (if applicable)
2. Turn on KVM switch
3. Turn on Servers
3 Operation
3-1 KVM Button
Channel
button
Button B is
non-functional
DVI-D KVM 12 ports
PC port LEDs
PC port LEDs Online : Blue LED on indicating a PC is connecting to the port
Active : Green LED on indicating a selected channel
Channel button Press to select channel from 01 to 12

6
3-5 Hotkeys for KVM
Remarks:
■Example of “Scroll Lock + Scroll Lock + Port no.”
- Port No. : 01 to 12
- e.g. Port 4 : Scroll Lock + Scroll Lock + 0+ 4
- e.g. Port 12 : Scroll Lock + Scroll Lock + 1+ 2
■You must press the hotkey within 2 seconds
■A beep sound will be heard for successful entering
Hotkey Function
Scroll Lock + Scroll Lock + Switch to previous port
Scroll Lock + Scroll Lock + Switch to next port
Scroll Lock + Scroll Lock + Port no. Switch to specic port
Scroll Lock + Scroll Lock + SAuto scan for powered on PC
Scroll Lock + Scroll Lock + BEnable / Disable beeper sound
Hotkey Label

7
KVM Number of Ports 12
Connector DVI-D, USB 3.0
Connectivity Combo 4-in-1 KVM Cable
Up to 6 or 15 feet
Product Information Dimensions (W x D x H) 443 x 171 x 44 mm (17.4 x 6.7 x 1.73 in.)
Gross Weight 5.5 lbs / 2.5 kg
Packaging Information Dimensions (W x D x H) 500 x 400 x 90 mm (19.7 x 15.7 x 3.5 in.)
Gross Weight 11.9 lbs / 5.4 kg
Environmental Operating Temperature 0 to 50 °C (32 to 122 °F)
Storage Temperature -5 to 60 °C (23 to 140 °F)
Relative Humidity 90% non-condensing
Shock 50G peak acceleration (11ms, half-sine wave)
Vibration 58~100Hz / 0.98G (11ms / cycle)
Local Console Graphic Connector 1 x DVI-D
Resolution Up to 1920 x 1200
Input Device 2 x USB type A (keyboard & mouse)
Audio Out 1 x 3.5mm stereo audio
Power Input Auto sensing 11 to 240VAC, 50/60 Hz;
Consumption Max. 24W; Standby 5W
Regulatory Safety FCC, CE
Environment RoHS2, REACH
Compatibility Multi-Platform Mix PCs, SUN and Mac G3 / G4 Mac / iMac
Support Windows 7 / Vista / 2003 / XP, Linux, Unix
4 Product Specications
4-1 Specications Table

8
5 Important Information
Warranty Information
Raloy Customer Support warrants to the original retail purchaser that this product is and will be free from
defects in materials and workmanship for a period of twenty-four (24) months from date of purchase. During
the warranty period, the purchaser must promptly contact Raloy Tech Support for assistance to report a unit
failure.
Please see the Raloy website at www.raloy.com/support/raloy-product-warranty.html for detailed product return
information.
1. The standard warranty period is 24 months commencing from the date of your Raloy invoice.
2. For Touch Screen and High Brightness LCD custom units, the standard warranty period is 15 months
commencing from the date of your Raloy invoice.
3. Warranty will be void if any of these cases apply: physical damages by accident, natural disaster, neglect,
misuse or improper use of the equipment.
Raloy also provides the option to extend your warranty service up to 60 Months, please contact our sales at
[e-mail] for more warranty service and upgrade details.
EXCEPT AS SPECIFICALLY PROVIDED ABOVE AND TO THE MAXIMUM EXTENT ALLOWED BY LAW,
RALOY DISCLAIMS ALL WARRANTIES AND CONDITIONS WHETHER EXPRESSED, IMPLIED, OR
STATUTORY AS TO ANY MATTER WHATSOEVER INCLUDING, WITHOUT LIMITATION, TITLE, NON-
INFRINGEMENT, CONDITION, MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR OR INTENDED
PURPOSE. EXCEPT AS EXPRESSLY PROVIDED ABOVE AND TO THE MAXIMUM EXTENT ALLOWED BY
LAW, RALOY SHALL NOT BE LIABLE FOR ANY SPECIAL, INDIRECT OR CONSEQUENTIAL DAMAGES
(INCLUDING WITHOUT LIMITATION, LOSS OF PROFIT, LOSS OF BUSINESS, LOSS OF INFORMATION,
FINANCIAL LOSS, PERSONAL INJURY, LOSS OF PRIVACY OR NEGLIGENCE) WHICH MAY BE CAUSED
BY OR RELATED TO, DIRECTLY OR INDIRECTLY, THE USE OF A PRODUCT OR SERVICE, THE
INABILITY TO USE A PRODUCT OR SERVICE, INADEQUACY OF A PRODUCT OR SERVICE FOR ANY
PURPOSE OR USE THEREOF OR BY ANY DEFECT OR DEFICIENCY THEREIN EVEN IF RALOY OR AN
AUTHORIZED RALOY RESELLER HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR
LOSSES.
I. Raloy Limited Warranty
II. Warranty Period
III. Product Return Procedure
IV. Raloy Extended Warranty
Disclaimer of Warranty
Visit www.Raloy.com for full warranty information.

9
Legal Information
Regulatory Notices Federal Communications Commission (FCC)
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation.
Any changes or modications made to this equipment may void the user’s authority to operate this equipment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
■Re-position or relocate the receiving antenna.
■Increase the separation between the equipment and receiver.
■Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Information in this document has been carefully checked for accuracy; however, no guarantee is given to the
correctness of the contents. The information in this document is subject to change without notice. We are not
liable for any injury or loss that results from the use of this equipment.
The company reserves the right to modify product specications without prior notice and assumes no
responsibility for any error which may appear in this publication.
All brand names, logo and registered trademarks are properties of their respective owners.
Copyright 2014 Raloy. All rights reserved.
What the Warranty Does Not Cover
■ Any product, on which the serial number has been defaced, modied or removed.
■Damage, deterioration or malfunction resulting from:
■ Accident, misuse, neglect, re, water, lightning, or other acts of nature, unauthorized product
modication, or failure to follow instructions supplied with the product.
■Repair or attempted repair by anyone not authorized by us.
■Any damage of the product due to shipment.
■Removal or installation of the product.
■ Causes external to the product, such as electric power uctuation or failure.
■ Use of supplies or parts not meeting our specications.
■Normal wear and tear.
■Any other causes which does not relate to a product defect.
■Removal, installation, and set-up service charges.
