RAM AIR GEAR DRYERS
ASSEMBLY INSTRUCTIONS
MODELS T4-MU, T4-HMU, T6-MU AND T6-HMU
TOOLS NEEDED
FOR ASSEMBLY:
9/16” SOCKET 9/16” WRENCH
STEP ONE
Remove all bolts from deck.
STEP TWO
Install left vertical pipe with
opening for motor facing away
from center. Tighten bolts.
STEP THREE
Install right vertical accessory
pipe aligning straight edge with
edge of base. Tighten bolts.

855-393-3379 (USA) | 888-393-3379 (Canada)
www.ramairgeardryer.com
STEP FOUR
Thread the outside stickmen on
the horizontal top pipe. Be careful
not to cross thread.
STEP FIVE
Install horizontal pipe with
valves facing the front.
STEP SIX
Apply aluminum sealing tape
on pipe joints.
STEP SEVEN
Attach stainless steel clamps with
bolt head facing the front.
STEP EIGHT
Attach remaining stickmen.
Be careful not to cross thread.
STEP NINE
Attach the blower to the vertical
pipe. Adjust clamp as needed.
QUESTIONS? CONTACT US.
STEP TEN
Thread all accessory valves
onto right accessory pipe.
