RAM 1500 2021 User manual

THIRD EDITION V2
21_DT_OM_EN_USC
©2021 FCA US LLC. All Rights Reserved. Tous droits réservés. Ram is a registered trademark of FCA US LLC.
Ram est une marque déposée de FCA US LLC. App Store is a registered trademark of Apple Inc. Google Play Store is a registered trademark of Google.
DOWNLOAD THE MOST UP-TO-DATE OWNER’S MANUAL,
RADIO AND WARRANTY BOOKS
Whether it is providing information about specific product features, taking a tour through your vehicle’s heritage, knowing
what steps to take following an accident or scheduling your next appointment, we know you will find the app an important
extension of your Ram vehicle. Simply download the app, select your make and model and enjoy the ride. To get this app,
go directly to the App Store®or Google Play®Store and enter the search keyword “ram toolbox” (U.S. residents only).
OWNERS.MOPAR.CA
CANADA
MOPAR.COM/OM
U.S.
2021 RAM 1500
OWNER’S MANUAL
2021 RAM 1500

The driver’s primary responsibility is the safe operation of the vehicle. Driving while distracted can result in loss of vehicle control, resulting in an accident and
personal injury. FCA US LLC strongly recommends that the driver use extreme caution when using any device or feature that may take their attention off the road.
Use of any electrical devices, such as cellular telephones, computers, portable radios, vehicle navigation or other devices, by the driver while the vehicle is moving
is dangerous and could lead to a serious accident. Texting while driving is also dangerous and should never be done while the vehicle is moving. If you find yourself
unable to devote your full attention to vehicle operation, pull off the road to a safe location and stop your vehicle. Some states or provinces prohibit the use of cellular
telephones or texting while driving. It is always the driver’s responsibility to comply with all local laws.
This Owner’s Manual has been prepared to help you get acquainted with your new Ram brand vehicle and to provide a convenient reference for common
questions.
Not all features shown in this manual may apply to your vehicle. For additional information on accessories to help personalize your vehicle, visit
mopar.com/om (U.S.), owners.mopar.ca (Canada) or your local Ram brand dealer.
DRIVING AND ALCOHOL
Drunk driving is one of the most frequent causes of accidents. Your driving ability can be seriously impaired
with blood alcohol levels far below the legal minimum. If you are drinking, don’t drive. Ride with a designated
non-drinking driver, call a cab, a friend or use public transportation.
WARNING
Driving after drinking can lead to an accident. Your perceptions are less sharp, your reflexes are slower and
your judgment is impaired when you have been drinking. Never drink and then drive.
WARNING: Operating, servicing and maintaining a passenger vehicle or off-highway
motor vehicle can expose you to chemicals including engine exhaust, carbon monoxide,
phthalates, and lead, which are known to the State of California to cause cancer and birth defects
or other reproductive harm. To minimize exposure, avoid breathing exhaust, do not idle the
engine except as necessary, service your vehicle in a well-ventilated area and wear gloves or wash
your hands frequently when servicing your vehicle. For more information go to
www.P65Warnings.ca.gov/passenger-vehicle.
This Owner’s Manual illustrates and describes the operation of features and equipment that are either standard or optional on this vehicle. This manual may
also include a description of features and equipment that are no longer available or were not ordered on this vehicle. Please disregard any features and equip-
ment described in this manual that are not on this vehicle. FCA US LLC reserves the right to make changes in design and specifications, and/or make additions
to or improvements to its products without imposing any obligation upon itself to install them on products previously manufactured.
With respect to any vehicles sold in Canada, the name FCA US LLC shall be deemed to be deleted and the name FCA Canada Inc. used in substitution therefore.
This Owner’s Manual is intended to familiarize you with the important features of your vehicle. Your most up-to-date Owner’s Manual, Navigation/
Uconnect manuals and Warranty Booklet can be found by visiting the website on the back cover.
U.S. Residents: If you are the first registered retail owner of your vehicle, you may obtain a complimentary printed copy of the Warranty Booklet by calling
1-866-726-4636 or by contacting your dealer. Replacement kits can be purchased by visiting www.techauthority.com.
Canadian Residents: If you are the first registered retail owner of your vehicle, you may obtain a complimentary printed copy of the
Warranty Booklet or purchase a replacement kit by calling 1-800-387-1143 or by contacting your dealer.

TABLE OF CONTENTS
1
2
3
4
5
6
7
8
9
10
11
1 INTRODUCTION ..............................................................................................................................9
2 GETTING TO KNOW YOUR VEHICLE ..................................................................................17
3 GETTING TO KNOW YOUR INSTRUMENT PANEL ........................................................97
4 STARTING AND OPERATING ............................................................................................... 129
5 MULTIMEDIA ............................................................................................................................... 215
6 SAFETY ........................................................................................................................................286
7 IN CASE OF EMERGENCY ....................................................................................................342
8 SERVICING AND MAINTENANCE ......................................................................................363
9 TECHNICAL SPECIFICATIONS .............................................................................................431
10 CUSTOMER ASSISTANCE .....................................................................................................442
11 INDEX ............................................................................................................................................ 446

2
INTRODUCTION
SYMBOLS KEY........................................................ 10
VAN CONVERSIONS/CAMPERS........................... 10
CONSUMER INFORMATION — TRUCK-CAMPER
LOADING ................................................................. 10
VEHICLE MODIFICATIONS/ALTERATIONS.......... 12
SYMBOL GLOSSARY.............................................. 12
GETTING TO KNOW YOUR VEHICLE
KEYS ....................................................................... 17
Key Fob .............................................................17
SENTRY KEY ........................................................... 20
IGNITION SWITCH .................................................. 20
Keyless Enter ‘n Go™ Ignition .........................20
REMOTE START — IF EQUIPPED (GASOLINE) .... 22
How To Use Remote Start................................22
To Exit Remote Start Mode..............................23
Remote Start Front Defrost Activation —
If Equipped........................................................23
Remote Start Comfort Systems —
If Equipped........................................................23
Remote Start Windshield Wiper De-Icer
Activation — If Equipped ..................................24
Remote Start Abort Message ..........................24
REMOTE START — IF EQUIPPED (DIESEL) ......... 24
How To Use Remote Start................................24
VEHICLE SECURITY SYSTEM — IF EQUIPPED .... 25
To Arm The System ..........................................25
To Disarm The System.....................................25
Rearming Of The System .................................26
Security System Manual Override...................26
DOORS ....................................................................26
Manual Door Locks ..........................................26
Power Door Locks — If Equipped ....................27
Power Side Steps — If Equipped .....................27
Keyless Enter ‘n Go™ — Passive Entry............27
Automatic Unlock Doors On Exit —
If Equipped........................................................29
Automatic Door Locks — If Equipped..............29
Child-Protection Door Lock System —
Rear Doors........................................................29
STEERING WHEEL ..................................................30
Tilt/Telescoping Steering Column...................30
Heated Steering Wheel — If Equipped............31
DRIVER MEMORY SETTINGS — IF EQUIPPED.....31
Programming The Memory Feature ................32
Linking And Unlinking The Key Fob To
Memory .............................................................32
Memory Position Recall ...................................32
SEATS .....................................................................33
Manual Adjustment (Front Seats) —
If Equipped........................................................33
Manual Adjustment (Rear Seats)....................34
Power Adjustment (Front Seats) —
If Equipped .... ...................................................35
Heated Seats — If Equipped ...........................36
Ventilated Seats — If Equipped .......................37
Rear Ventilated Seats — If Equipped ..............38
Plastic Grocery Bag Retainers ........................38
Head Restraints ...............................................38
UCONNECT VOICE RECOGNITION ........................ 39
Introducing Voice Recognition ........................39
Basic Voice Commands ...................................40
Get Started .......................................................40
Additional Information .....................................41
DRIVER ADJUSTABLE PEDALS —
IF EQUIPPED........................................................... 41
MIRRORS................................................................ 42
Inside Rearview Mirror.....................................42
Illuminated Vanity Mirror .................................43
Outside Mirrors ................................................44
Outside Automatic Dimming Mirrors —
If Equipped .......................................................44
Power Mirrors ...................................................44
Power Folding Outside Mirrors For Standard
And Trailer Tow — If Equipped.........................45
Trailer Towing Mirrors — If Equipped .............45
Heated Mirrors — If Equipped .........................46
Tilt Side Mirrors In Reverse — If Equipped .....46

3
UNIVERSAL GARAGE DOOR OPENER
(HOMELINK®) — IF EQUIPPED ............................ 46
Before You Begin Programming
HomeLink®.......................................................46
Erasing All The HomeLink® Channels ............47
Identifying Whether You Have A Rolling
Code Or Non-Rolling Code Device...................47
Programming HomeLink® To A Garage Door
Opener ..............................................................47
Programming HomeLink® To A
Miscellaneous Device ......................................48
Reprogramming A Single HomeLink®
Button ...............................................................48
Canadian/Gate Operator Programming .........48
EXTERIOR LIGHTS.................................................. 49
Headlight Switch...............................................49
Multifunction Lever .........................................50
Daytime Running Lights (DRLs) ......................50
High/Low Beam Switch....................................50
Automatic High Beam Headlamp Control —
If Equipped .......................................................50
Flash-To-Pass....................................................51
Automatic Headlights — If Equipped ..............51
Parking Lights And Panel Lights......................51
Automatic Headlights With Wipers..................51
Headlight Delay ................................................51
Lights-On Reminder..........................................51
Fog Lights — If Equipped .................................52
Turn Signals......................................................52
Lane Change Assist — If Equipped..................52
Cargo Lights/Trailer Spotter Lights With
Bed Lights — If Equipped .... .............................52
Battery Saver....................................................53
INTERIOR LIGHTS ..................................................53
Courtesy Lights.................................................53
Illuminated Entry .............................................54
WINDSHIELD WIPERS AND WASHERS...............55
Windshield Wiper Operation............................55
Rain Sensing Wipers — If Equipped ................55
CLIMATE CONTROLS .............................................56
Automatic Climate Control Descriptions
And Functions ..................................................56
Manual Climate Control Descriptions And
Functions .........................................................59
Automatic Temperature Control (ATC) —
If Equipped........................................................61
Climate Voice Recognition...............................61
Operating Tips .................................................62
INTERIOR STORAGE AND EQUIPMENT ...............63
Storage..............................................................63
USB/AUX Control .............................................68
Electrical Power Outlets...................................70
Power Inverter — If Equipped .........................71
Wireless Charging Pad — If Equipped ............72
WINDOWS ..............................................................73
Power Windows ................................................73
Automatic Window Features ...........................73
Reset Auto-Up ..................................................74
Window Lockout Switch...................................74
Power Sliding Rear Window — If Equipped .... 74
Manual Sliding Rear Window — If Equipped ..75
Wind Buffeting .................................................75
POWER SUNROOF — IF EQUIPPED ..................... 75
Single Pane Power Sunroof — If Equipped .....75
Dual Pane Power Sunroof — If Equipped........76
HOOD....................................................................... 78
To Open The Hood............................................78
To Close The Hood ...........................................79
TAILGATE ................................................................ 79
Opening.............................................................79
Closing ..............................................................79
Locking Tailgate ...............................................79
Multifunction Tailgate — If Equipped .............79
Tailgate Removal .............................................80
Bed Step — If Equipped ...................................83
PICKUP BOX .......................................................... 83
Bed Rail Tie-Down System — If Equipped ......84
RAMBOX — IF EQUIPPED...................................... 86
Locking And Unlocking RamBox......................86
RamBox Cargo Storage Bins ...........................86
RamBox Safety Warning..................................88
Bed Divider — If Equipped ...............................88
TRI-FOLD TONNEAU COVER — IF EQUIPPED ..... 90
Tonneau Cover Components...........................90
Tri-Fold Tonneau Cover Folding For Driving
Or Removal.......................................................91
Tri-Fold Tonneau Cover Installation ................94
Tri-Fold Tonneau Cover Cleaning ....................96

4
GETTING TO KNOW YOUR
INSTRUMENT PANEL
BASE / MIDLINE INSTRUMENT CLUSTER —
GASOLINE ............................................................... 97
Base / Midline Instrument Cluster
Descriptions — Gasoline ..................................98
PREMIUM INSTRUMENT CLUSTER —
GASOLINE ............................................................... 99
Premium Instrument Cluster
Descriptions — Gasoline ............................... 100
BASE / MIDLINE INSTRUMENT CLUSTER —
DIESEL...................................................................101
Base / Midline Instrument Cluster
Descriptions — Diesel.................................... 102
PREMIUM INSTRUMENT CLUSTER — DIESEL ..103
Premium Instrument Cluster Descriptions —
Diesel ............................................................ 104
INSTRUMENT CLUSTER DISPLAY ......................104
Instrument Cluster Display Controls ............ 105
Oil Life Reset.................................................. 106
Display Menu Items ...................................... 106
Diesel Particulate Filter (DPF) Messages ...114
Displays.......................................................... 115
Diesel Exhaust Fluid (DEF) Warning
Messages....................................................... 115
Diesel Exhaust Fluid (DEF) Fault Warning
Messages....................................................... 115
Battery Saver On/Battery Saver Mode
Message — Electrical Load Reduction
Actions — If Equipped.................................... 116
WARNING LIGHTS AND MESSAGES.... ............. 118
Red Warning Lights....................................... 118
Yellow Warning Lights................................... 121
Yellow Indicator Lights.................................. 124
Green Indicator Lights .................................. 125
White Indicator Lights ................................... 126
Blue Indicator Lights ..................................... 127
ONBOARD DIAGNOSTIC SYSTEM — OBD II...... 127
Onboard Diagnostic System (OBD II)
Cybersecurity ................................................. 127
EMISSIONS INSPECTION AND MAINTENANCE
PROGRAMS.......................................................... 128
STARTING AND OPERATING
STARTING THE ENGINE ..................................... 129
Automatic Transmission ............................... 130
AutoPark ........................................................ 130
Tip Start Feature .......................................... 131
Keyless Enter ‘n Go™ — Ignition................... 131
Normal Starting Using ENGINE START/
STOP Button — Gasoline Engine ................. 131
Normal Starting Using ENGINE START/
STOP Button — Diesel Engine ...................... 133
Cold Weather Operation (Below –22°F Or
−30°C) .......................................................... 134
After Starting ................................................. 134
Starting Fluids — Diesel Engine Only ........... 134
NORMAL OPERATION — DIESEL ENGINE .... .....134
Cold Weather Precautions............................ 135
Engine Idling.................................................. 136
Stopping The Engine..................................... 136
ENGINE BLOCK HEATER — IF EQUIPPED..........137
ENGINE BREAK-IN RECOMMENDATIONS —
GASOLINE ENGINE .............................................137
ENGINE BREAK-IN RECOMMENDATIONS —
DIESEL ENGINE....................................................138
PARKING BRAKE .................................................138
Electric Park Brake (EPB) ............................. 138
AUTOMATIC TRANSMISSION ............................141
Ignition Park Interlock................................... 142
Brake/Transmission Shift Interlock System
(BTSI).............................................................. 142
8-Speed Automatic Transmission................ 142
FOUR-WHEEL DRIVE OPERATION —
IF EQUIPPED ........................................................146
Four-Position Electronically Shifted
Transfer Case — If Equipped ....................... 146
Five-Position Electronically Shifted
Transfer Case — If Equipped ....................... 148
ACTIVE-LEVEL FOUR CORNER AIR
SUSPENSION SYSTEM — IF EQUIPPED.............150
Description .................................................... 150
Air Suspension Modes.................................. 152
Instrument Cluster Display Messages......... 153
Operation....................................................... 153

5
ACTIVE-LEVEL FOUR CORNER AIR
SUSPENSION SYSTEM (OFF-ROAD GROUP) —
IF EQUIPPED.........................................................154
Description..................................................... 154
Air Suspension Modes .................................. 156
Instrument Cluster Display Messages ......... 156
Operation ....................................................... 156
AXLE LOCK SYSTEM — IF EQUIPPED ................157
LIMITED-SLIP DIFFERENTIAL — IF EQUIPPED..158
POWER STEERING ..............................................158
Electric Power Steering ................................ 158
FUEL SAVER TECHNOLOGY 5.7L ENGINES
ONLY — IF EQUIPPED ..........................................159
STOP/START SYSTEM — IF EQUIPPED .............159
Autostop Mode .............................................. 159
Possible Reasons The Engine Does Not
Autostop......................................................... 159
To Start The Engine While In Autostop
Mode .............................................................. 159
To Manually Turn Off The Stop Start
System ........................................................... 160
To Manually Turn On The Stop Start
System ........................................................... 160
System Malfunction ...................................... 160
CRUISE CONTROL SYSTEMS —
IF EQUIPPED ........................................................160
Cruise Control................................................ 161
Adaptive Cruise Control (ACC) ...................... 162
PARKSENSE FRONT/REAR PARK ASSIST
SYSTEM — IF EQUIPPED.... ................................. 172
ParkSense Sensors....................................... 173
ParkSense Warning Display ......................... 173
ParkSense Display ........................................ 173
Enabling And Disabling Front And/Or Rear
ParkSense ..................................................... 176
Service The ParkSense Park Assist
System ........................................................... 176
Cleaning The ParkSense System ................. 176
ParkSense System Usage Precautions........ 177
PARKSENSE ACTIVE PARK ASSIST SYSTEM —
IF EQUIPPED ........................................................ 178
Enabling And Disabling The ParkSense
Active Park Assist System............................. 178
Parallel/Perpendicular Parking Space
Assistance Operation.................................... 179
LANESENSE — IF EQUIPPED ............................. 182
LaneSense Operation ................................... 182
Turning LaneSense On Or Off....................... 182
LaneSense Warning Message...................... 182
Changing LaneSense Status ........................ 184
PARKVIEW REAR BACK UP CAMERA............... 184
AUX Camera — If Equipped .......................... 186
SURROUND VIEW CAMERA SYSTEM —
IF EQUIPPED ....................................................... 186
AUX Camera — If Equipped .......................... 190
REFUELING THE VEHICLE — GASOLINE
ENGINE ................................................................. 190
REFUELING THE VEHICLE — DIESEL
ENGINE .................................................................192
Avoi d Using Contaminated Fuel................... 192
Bulk Fuel Storage — Diesel Fuel .................. 192
Diesel Exhaust Fluid ..................................... 193
Diesel Exhaust Fluid Storage ....................... 193
Adding Diesel Exhaust Fluid......................... 193
VEHICLE LOADING...............................................195
Gross Vehicle Weight Rating (GVWR) ......... 195
Payload .......................................................... 195
Gross Axle Weight Rating (GAWR)................ 195
Tire Size ......................................................... 195
Rim Size......................................................... 195
Inflation Pressure.......................................... 195
Curb Weight................................................... 195
Loading .......................................................... 195
TRAILER TOWING ................................................196
Common Towing Definitions......................... 196
Trailer Hitch Type and Maximum Trailer
Weight............................................................ 199
Trailer Towing Weights (Maximum Trailer
Weight Ratings) ............................................. 199
Trailer And Tongue Weight ........................... 199
Trailer Reverse Steering Control .................. 200
Towing Requirements .................................. 202
Towing Tips ................................................... 207

6
SNOWPLOW .........................................................207
Before Plowing............................................... 208
Snowplow Prep Package Model
Availability...................................................... 208
Over The Road Operation With Snowplow
Attached......................................................... 208
Operating Tips ............................................... 208
General Maintenance ................................... 208
RECREATIONAL TOWING (BEHIND
MOTORHOME) .....................................................209
Towing This Vehicle Behind Another
Vehicle............................................................ 209
Recreational Towing — Two-Wheel Drive
Models ........................................................... 209
Recreational Towing — Four-Wheel Drive
Models ........................................................... 210
DRIVING TIPS .......................................................212
Driving On Slippery Surfaces ....................... 212
Driving Through Water ................................. 212
Off-Road Driving Tips..................................... 213
MULTIMEDIA
UCONNECT SYSTEMS .........................................215
CYBERSECURITY .................................................215
UCONNECT SETTINGS ........................................216
Customer Programmable Features ............. 216
HEAD-UP DISPLAY (HUD) ..................................235
UCONNECT INTRODUCTION................................237
System Overview .......................................... 237
Safety And General Information................... 239
UCONNECT MODES.... ......................................... 240
Steering Wheel Audio Controls .................... 240
Radio Mode .................................................. 240
Media Mode .................................................. 248
Phone Mode ................................................. 250
CONNECTED VEHICLE SERVICES —
IF EQUIPPED ....................................................... 260
Is My Vehicle Connected?............................. 260
Introduction To Connected Vehicle
Services ........................................................ 260
Getting Started With Connected Vehicle
Services ........................................................ 262
Using SiriusXM Guardian™ .......................... 264
Manage My SiriusXM Guardian™ Account .. 277
CONNECTED SERVICES FAQS .......................... 277
Connected Services SOS FAQs .................... 278
Connected Services Remote Door Lock/
Unlock FAQs .................................................. 278
Connected Services Roadside Assistance
FAQs .............................................................. 278
Connected Services Send & Go FAQs ......... 278
Connected Services Vehicle Finder FAQs ... 279
Connected Services Stolen Vehicle
Assistance FAQs ........................................... 279
Connected Services Remote Vehicle Start
FAQs .............................................................. 279
Connected Services Remote Horn & Lights
FAQs ............................................................... 280
Connected Services Account FAQs .............. 280
Data Collection & Privacy ............................. 282
RADIO OPERATION AND MOBILE PHONES.... ..282
Regulatory And Safety Information.............. 282
OFF-ROAD PAGES — IF EQUIPPED ...................283
Off-Road Pages Status Bar .......................... 283
Vehicle Dynamics ......................................... 284
Accessory Gauge........................................... 284
Pitch & Roll .................................................... 285
Suspension.................................................... 285
SAFETY
SAFETY FEATURES ..............................................286
Anti-Lock Brake System (ABS) ..................... 286
Electronic Brake Control (EBC) System ....... 287
AUXILIARY DRIVING SYSTEMS ..........................293
Blind Spot Monitoring (BSM) —
If Equipped ................................................... 293
Forward Collision Warning (FCW) With
Mitigation — If Equipped............................... 299
Tire Pressure Monitoring System (TPMS)....301
OCCUPANT RESTRAINT SYSTEMS ...................307
Occupant Restraint Systems Features ....... 307
Important Safety Precautions ...................... 307
Seat Belt Systems ........................................ 308
Supplemental Restraint Systems (SRS) ...... 314
Child Restraints............................................. 326

7
SAFETY TIPS.........................................................339
Transporting Passengers.............................. 339
Transporting Pets .......................................... 339
Safety Checks You Should Make Inside
The Vehicle ................................................... 339
Periodic Safety Checks You Should Make
Outside The Vehicle ...................................... 340
Exhaust Gas .................................................. 341
Carbon Monoxide Warnings ......................... 341
IN CASE OF EMERGENCY
HAZARD WARNING FLASHERS .........................342
ASSIST AND SOS SYSTEM — IF EQUIPPED .....343
JACKING AND TIRE CHANGING ........................346
Preparations For Jacking .............................. 346
Jack Location................................................. 346
Removal Of Jack And Tools........................... 347
Removing The Spare Tire.............................. 348
Jacking Instructions ...................................... 349
To Stow The Flat Or Spare ........................... 352
Reinstalling The Jack And Tools................... 353
JUMP STARTING ..................................................354
Preparations For Jump Start......................... 354
Jump Starting Procedure .............................. 355
REFUELING IN EMERGENCY – IF EQUIPPED ..356
IF YOUR ENGINE OVERHEATS ...........................357
MANUAL PARK RELEASE ...................................358
FREEING A STUCK VEHICLE ..............................359
TOWING A DISABLED VEHICLE .... ..................... 360
Two-Wheel Drive Models .............................. 361
Four-Wheel Drive Models ............................. 361
Emergency Tow Hooks — If Equipped.......... 361
ENHANCED ACCIDENT RESPONSE SYSTEM
(EARS) .................................................................. 362
EVENT DATA RECORDER (EDR) ........................ 362
SERVICING AND MAINTENANCE
SCHEDULED SERVICING — GASOLINE
ENGINE ................................................................ 363
Maintenance Plan ......................................... 364
SCHEDULED SERVICING — DIESEL ENGINE ... 367
Maintenance Plan — Diesel Fuel Up To B5
Biodiesel ....................................................... 368
Additional Maintenance — B6 To B20
Biodiesel ........................................................ 370
ENGINE COMPARTMENT.................................... 371
3.6L Engine With Stop/Start ....................... 371
5.7L Engine Without Stop/Start................... 372
5.7L Engine With Stop/Start ........................ 373
3.0L Diesel Engine ........................................ 374
Checking Oil Level......................................... 375
Adding Washer Fluid ..................................... 375
Maintenance-Free Battery............................ 375
Pressure Washing ......................................... 376
VEHICLE MAINTENANCE .... ................................376
Engine Oil — Gas Engine............................... 376
Engine Oil Filter ............................................. 377
Engine Air Cleaner Filter ............................... 377
Draining Fuel/Water Separator Filter —
Diesel Engine ................................................ 378
Underbody Mounted Fuel Filter
Replacement — Diesel Engine...................... 379
Priming If The Engine Has Run Out Of
Fuel — Diesel Engine..................................... 380
Intervention Regeneration Strategy —
Message Process Flow (Diesel Engine)....... 381
Diesel Exhaust Fluid ..................................... 381
Air Conditioner Maintenance........................ 381
Accessory Drive Belt Inspection................... 384
Body Lubrication ........................................... 384
Windshield Wiper Blades.............................. 385
Exhaust System ............................................ 386
Cooling System ............................................. 387
Charge Air Cooler — Inter-Cooler (Diesel
Engine)........................................................... 390
Brake System ............................................... 390
Automatic Transmission .............................. 391
Rear Axle And 4x4 Front Driving Axle Fluid
Level .............................................................. 392
Transfer Case ............................................... 393
Fuses.............................................................. 393
Bulb Replacement ........................................ 403

8
TIRES .....................................................................409
Tire Safety Information ................................. 409
Tires — General Information ......................... 416
Tire Types....................................................... 419
Spare Tires — If Equipped............................. 420
Wheel And Wheel Trim Care......................... 422
Snow Traction Devices.................................. 423
Tire Rotation Recommendations ................ 425
DEPARTMENT OF TRANSPORTATION
UNIFORM TIRE QUALITY GRADES ....................425
Treadwear ...................................................... 425
Traction Grades............................................. 426
Temperature Grades..................................... 426
STORING THE VEHICLE .......................................426
BODYWORK..........................................................426
Protection From Atmospheric Agents .......... 426
Body And Underbody Maintenance.............. 427
Preserving The Bodywork ............................. 427
INTERIORS ...........................................................429
Seats And Fabric Parts.................................. 429
Plastic And Coated Parts .............................. 430
Leather Surfaces........................................... 430
Glass Surfaces .............................................. 430
TECHNICAL SPECIFICATIONS
VEHICLE IDENTIFICATION NUMBER (VIN)........ 431
BRAKE SYSTEM .................................................. 431
WHEEL AND TIRE TORQUE SPECIFICATIONS.. 431
Torque Specifications ................................... 431
FUEL REQUIREMENTS — GASOLINE
ENGINE ................................................................ 432
3.6L Engine .................................................. 432
5.7L Engine ................................................... 432
Reformulated Gasoline................................. 433
Materials Added To Fuel............................... 433
Gasoline/Oxygenate Blends......................... 433
Do Not Use E-85 In Non-Flex Fuel
Vehicles.......................................................... 433
CNG And LP Fuel System Modifications ...... 433
Methylcyclopentadienyl Manganese
Tricarbonyl (MMT) In Gasoline...................... 434
Fuel System Cautions ................................... 434
FUEL REQUIREMENTS – DIESEL ENGINE ........ 434
Diesel Fuel Specifications ............................ 435
Biodiesel Fuel Requirements ....................... 435
FLUID CAPACITIES ............................................. 437
ENGINE FLUIDS AND LUBRICANTS................... 438
CHASSIS FLUIDS AND LUBRICANTS ................ 441
CUSTOMER ASSISTANCE
SUGGESTIONS FOR OBTAINING SERVICE FOR
YOUR VEHICLE ....................................................442
Prepare For The Appointment ...................... 442
Prepare A List ................................................ 442
Be Reasonable With Requests..................... 442
IF YOU NEED ASSISTANCE ................................442
FCA US LLC Customer Center....................... 442
FCA Canada Inc. Customer Center .............. 442
Mexico............................................................ 443
Puerto Rico And US Virgin Islands ............... 443
Customer Assistance For The Hearing Or
Speech Impaired (TDD/TTY)......................... 443
Service Contract ........................................... 443
WARRANTY INFORMATION................................444
MOPAR® PARTS .................................................444
REPORTING SAFETY DEFECTS ..........................444
In The 50 United States And
Washington, D.C............................................ 444
In Canada ...................................................... 444
PUBLICATION ORDER FORMS ..........................445
GENERAL INFORMATION....................................445

9
INTRODUCTION
Dear Customer,
Congratulations on the purchase of your new Ram vehicle. Be assured that it represents precision workmanship, distinctive styling, and high quality.
This is a specialized utility vehicle. It can go places and perform tasks that are not intended for conventional passenger vehicles. It handles and maneuvers
differently from many passenger vehicles both on-road and off-road, so take time to become familiar with your vehicle. If equipped, the two-wheel drive version
of this vehicle was designed for on-road use only. It is not intended for off-road driving or use in other severe conditions suited for a four-wheel drive vehicle.
Before you start to drive this vehicle, read the Owner’s Manual. Be sure you are familiar with all vehicle controls, particularly those used for braking, steering,
transmission, and transfer case shifting. Learn how your vehicle handles on different road surfaces. Your driving skills will improve with experience. When driving
off-road, or working the vehicle, don’t overload the vehicle or expect the vehicle to overcome the natural laws of physics. Always observe federal, state, provincial
and local laws wherever you drive. As with other vehicles of this type, failure to operate this vehicle correctly may result in loss of control or a collision Úpage 212.
This Owner's Manual has been prepared with the assistance of service and engineering specialists to acquaint you with the operation and maintenance of your
vehicle. It is supplemented by customer-oriented documents. Within this information, you will find a description of the services that FCA US LLC offers to its
customers as well as the details of the terms and conditions for maintaining its validity. Please take the time to read all of these publications carefully before
driving your vehicle for the first time. Following the instructions, recommendations, tips, and important warnings in this manual will help ensure safe and
enjoyable operation of your vehicle.
This Owner's Manual describes all versions of this vehicle. Options and equipment dedicated to specific markets or versions are not expressly indicated in the
text. Therefore, you should only consider the information that is related to the trim level, engine, and version that you have purchased. Any content introduced
throughout the Owner's Information, which may or may not be applicable to your vehicle, will be identified with the wording “If Equipped”. All data contained in
this publication are intended to help you use your vehicle in the best possible way. FCA US LLC aims at a constant improvement of the vehicles produced. For
this reason, it reserves the right to make changes to the model described for technical and/or commercial reasons. For further information, contact an authorized
dealer.
When it comes to service, remember that authorized dealers know your Ram vehicle best, have factory-trained technicians, genuine Mopar® parts, and care
about your satisfaction.
1

10
SYMBOLS KEY
If you do not read this entire Owner’s Manual, you may miss important
information. Observe all Cautions and Warnings.
VAN CONVERSIONS/CAMPERS
The New Vehicle Limited Warranty does not apply to body modifications or
special equipment installed by van conversion/camper manufacturers/body
builders. US residents refer to the Warranty Information, Section 2.1.C.
Canadian residents refer to the “What Is Not Covered” section of the Warranty
Information. Such equipment includes video monitors, DVD/Blu-Ray™,
heaters, stoves, refrigerators, etc. For warranty coverage and service on these
items, contact the applicable manufacturer.
CONSUMER INFORMATION — TRUCK-CAMPER LOADING
This information is provided in fulfillment of the requirement by the United
States Government, Department of Transportation, National Highway Traffic
Safety Administration, that “every manufacturer of trucks that are capable of
accommodating slide-in campers, manufactured on or after April 1, 1973 shall
provide... at the time of original purchase to the first person who purchases the
truck”... information on Truck Camper Loading.
A slide-in camper document is provided in your vehicle’s glove compartment
that contains your Vehicle Identification Number, truck model, cargo weight
rating, and the forward/rearward limit of a camper. To obtain additional
dimensional and technical specifications for your vehicle, please visit https://
www.ramtrucks.com.
Figure 1 illustrates the dimensions describing the forward and rearward limits
of the zone in which the Center of Gravity (CG) of a slide-in camper must be
located, to provide satisfactory vehicle handling and to prevent overload of the
front and rear axles.
Figure 2 illustrates a proper match between truck and camper.
WARNING!
These statements are against operating
proce
dures that could result in a collision, bodily
injury and/or death.
CAUTION! These statements are against procedures that
could result in damage to your vehicle.
NOTE:
A suggestion which will improve installation,
operation, and reliability. If not followed, may
result in damage.
TIP: General ideas/solutions/suggestions on easier
use of the product or functionality.
PAGE REFERENCE
ARRO
W Follow this reference for additional information on
a pa rticular feature.
FOOTNOTE
Supplementary and relevant information
pertaining to the topic.

11
NOTE:
The camper Center of Gravity falls within the specified zone.
When the truck is used to carry a slide-in camper, the total cargo load of the truck consists of the manufacturer’s camper weight figure, the weight of installed
additional camper equipment not included in the manufacturer’s camper weight figure, the weight of camper cargo, and the weight of passengers in the camper.
The total cargo load should not exceed the truck’s cargo weight rating and the camper’s CG should fall within the truck’s recommended CG zone when installed.
A — Forward Limit of Camper CG
B — Rearward Limit of Camper CG
1

12
Secure loose items to prevent weight shifts that could affect the balance of
your vehicle. When the truck camper is loaded, drive to a scale and weigh the
front and rear wheels separately, to determine axle loads. Individual axle loads
should not exceed either of the Gross Axle Weight Ratings (GAWR). The total of
the axle loads should not exceed the Gross Vehicle Weight Rating (GVWR). If
weight ratings are exceeded, move or remove items to get the total weight
below the ratings.
NOTE:
These ratings are also provided on the vehicle certification label located on the
driver’s side B-pillar. See Úpage 195 for more information.
For any additional instructions, please contact your conversion/camper
manufacturer or an authorized dealer.
VEHICLE MODIFICATIONS/ALTERATIONS
SYMBOL GLOSSARY
Some car components have colored labels with symbols indicating
precautions to be observed when using this component. It is important to
follow all warnings when operating your vehicle. See below for the definition of
each symbol Úpage 118.
NOTE:
Warning and Indicator lights are different based upon equipment options and
current vehicle status. Some telltales are optional and may not appear.
WARNING!
Any modifications or alterations to this vehicle could seriously affect its
roadworthiness and safety and may lead to a collision resulting in serious
injury or death.
Red Warning Lights
Air Bag Warning Light
Úpage 118
Battery Charge Warning Light
Úpage 119
Brake Warning Light
Úpage 118
Door Open Warning Light
Úpage 119
Electric Power Steering (EPS) Fault Warning Light
Úpage 119
Electronic Throttle Control (ETC) Warning Light
Úpage 119
Engine Coolant Temperature Warning Light
Úpage 119
Hood Open Warning Light
Úpage 120

13
Oil Pressure Warning Light
Úpage 120
Oil Temperature Warning Light
Úpage 120
Seat Belt Reminder Warning Light
Úpage 120
Tailgate Open Warning Light
Úpage 120
Trailer Brake Disconnected Warning Light
Úpage 120
Transmission Temperature Warning Light
Úpage 120
Vehicle Security Warning Light
Úpage 121
Red Warning Lights Yellow Warning Lights
Adaptive Cruise Control (ACC) Fault Warning Light
Úpage 121
Anti-Lock Brake System (ABS) Warning Light
Úpage 121
Air Suspension Fault Warning Light
Úpage 121
Cruise Control Fault Warning Light
Úpage 123
Engine Check/Malfunction Indicator Warning Light (MIL)
Úpage 122
Electronic Park Brake Warning Light
Úpage 121
Electronic Stability Control (ESC) Active Warning Light
Úpage 121
Electronic Stability Control (ESC) OFF Warning Light
Úpage 121
1

14
Service LaneSense Warning Light
Úpage 121
Low Washer Fluid Warning Light
Úpage 122
Low Fuel Warning Light
Úpage 122
Tire Pressure Monitoring System (TPMS) Warning Light
Úpage 123
Rear Axle Locker Fault Indicator Light
Úpage 122
Service Forward Collision Warning (FCW) Light
Úpage 122
Service Stop/Start System Warning Light
Úpage 122
Service 4WD Warning Light
Úpage 122
Yellow Warning Lights Yellow Indicator Lights
Forward Collision Warning Off Indicator Light
Úpage 124
Air Suspension Payload Protection Indicator Light
Úpage 124
Trailer Merge Assist Indicator Light
Úpage 125
TOW/HAUL Indicator Light
Úpage 125
Cargo Light
Úpage 124
Air Suspension Off-Road 1 Indicator Light
Úpage 124
Air Suspension Off-Road 2 Indicator Light
Úpage 124
Air Suspension Normal Height Indicator Light
Úpage 124

15
Air Suspension Aerodynamic Height Indicator Light
Úpage 124
Entry/Exit Indicator Light
Úpage 125
Air Suspension Ride Height Raising Indicator Light
Úpage 124
Air Suspension Ride Height Lowering Indicator Light
Úpage 124
Rear Axle Lock Indicator Light
Úpage 125
4WD Indicator Light
Úpage 125
4WD Low Indicator Light
Úpage 125
4WD High Indicator Light
Úpage 125
Yellow Indicator Lights
NEUTRAL Indicator Light
Úpage 124
Low Diesel Exhaust Fluid (DEF) Indicator Light
Úpage 124
Wait To Start Light
Úpage 125
Water In Fuel Indicator Light
Úpage 125
Green Indicator Lights
Adaptive Cruise Control (ACC) Set With Target Light
Úpage 125
Adaptive Cruise Control (ACC) Set With No Target Detected
Indicator Light
Úpage 125
ECO Mode Indicator Light
Úpage 126
Yellow Indicator Lights
1

16
Parking/Headlights On Indicator Light
Úpage 126
LaneSense Indicator Light
Úpage 126
Front Fog Indicator Light
Úpage 126
Turn Signal Indicator Lights
Úpage 126
Cruise Control SET Indicator Light
Úpage 126
Stop/Start Active Indicator Light
Úpage 126
4WD AUTO Indicator Light
Úpage 126
Green Indicator Lights White Indicator Lights
Adaptive Cruise Control (ACC) Ready Light
Úpage 126
Cruise Control Ready Indicator
Úpage 126
Cruise Control SET Indicator Light — If Equipped With Base/
Midline Instrument Cluster Display
Úpage 127
Hill Descent Control (HDC) Indicator Light — If Equipped
Úpage 127
LaneSense Indicator Light — If Equipped
Úpage 127
Blue Indicator Lights
High Beam Indicator Light
Úpage 127

17
GETTING TO KNOW YOUR VEHICLE
KEYS
KEY FOB
Your vehicle is equipped with a key fob which
supports Passive Entry, Remote Keyless Entry
(RKE), Keyless Enter ‘n Go™ (if equipped), and
Remote Start (if equipped). The key fob allows you
to lock or unlock all doors, tailgate, and the
RamBox (if equipped) as well as activate the Panic
Alarm from distances up to approximately 66 ft
(20 m). The key fob does not need to be pointed at
the
vehicle to activate the system. The key fob also
contains an emergency key, which is stored in the
rear of the key fob.
NOTE:
The key fob’s wireless signal may be blocked if
the key fob is located next to a mobile phone,
laptop, or other electronic device. This may
result in poor performance.
If your vehicle is equipped with a Wireless
Charging Pad, the key fob may not be detected
if it is placed within 6 inches (15 cm) of the pad
Úpage 72.
With the ignition in the ON position and the
vehicle moving at 2 mph (4 km/h), all RKE
comma nds are disabled.
Key Fob
In case the ignition switch does not change with
the push of a button, the key fob may have a low or
fully depleted battery. A low key fob battery can be
verified by referring to the instrument cluster
display, which will display directions to follow.
NOTE:
A low key fob battery condition may be indicated by
a message in the instrument cluster display, or by
the LED light on the key fob. If the LED key fob light
no longer illuminates from key fob button pushes,
then the key fob battery requires replacement
Úpage 445.
To Lock/Unlock The Doors And Tailgate
Push and release the unlock button on the key fob
once to unlock the driver’s door, or, twice within
five seconds to unlock all doors, the tailgate and
the RamBox (if equipped). To lock all the doors and
the tailgate, push the lock button once.
When the doors are unlocked, the turn signals will
flash and the illuminated entry system will be
activated. When the doors are locked, the turn
signals will flash and the horn will chirp.
All doors can be programmed to unlock on the first
push of the unlock button. The horn chirp when the
lock button is pushed can be programmed on/off
within Uconnect Settings Úpage 216.
1 — LED Indicator Light
2 — Unlock
3 — Tailgate Lowering (If Equipped)
4 — Air Suspension Remote Lowering
(If Equipped)
5 — Lock
6 — Remote Start
7 — PANIC
8 — Emergency Key
2

18 GETTING TO KNOW YOUR VEHICLE
Air Suspension (Remote Lowering Of The
Vehicle) — If Equipped
For easy entry and loading, your vehicle
can be lowered by pushing the key fob air
suspension lowering button two times.
When air suspension lowering is
requested using the key fob, the vehicle will send a
series of chirps and flashes to alert the customer
that the operation has begun and will continue
these alerts until it successfully lowers.
The following conditions must be met for the
vehicle to lower remotely:
The vehicle must not already be in Entry/Exit
(Park) ride height.
The vehicle battery must be fully charged.
All doors must be closed.
The key fob must be out of the vehicle.
NOTE:
Ensure the vehicle is clear of all objects, pets, and
people prior to remote lowering.
Canceling Remote Lowering
Vehicle lowering can be canceled at anytime.
When vehicle lowering is canceled, the vehicle will
raise up to the next defined level and lock out the
remote lowering feature until the ignition has been
cycled ON/OFF.
To cancel vehicle lowering, push the key fob air
susp ension lowering button one time during the
lowering process. When vehicle lowering is
canceled, the horn will chirp two times and the turn
signal lamps will flash four times. Once raising is
completed, the horn will chirp one time.
NOTE:
More information on air suspension is provided
later in this manual Úpage 150.
Replacing The Battery In The Key Fob
The replacement battery model is one CR2450
battery.
NOTE:
Customers are recommended to use a battery
obtained from Mopar®. Aftermarket coin
battery dimensions may not meet the original
OEM coin battery dimensions.
Perchlorate Material — special handling may
apply. See www.dtsc.ca.gov/hazardouswaste/
perchlorate for further information.
Do not touch the battery terminals that are on
the back housing or the printed circuit board.
Do not replace the coin battery if the LED on the
key fob above the top row buttons blinks when
a button is pressed. The coin battery should last
a minimum of three years with normal vehicle
usage.
1. Remove the emergency key (1) by pushing
the emergency key release button (2) on the
side of the key fob, and pulling the emergency
key out with your other hand.
Emergency Key Removal
2. Hold the key fob with the button side facing
down, and locate the small rectangular gap on
the left side between the housing and the back
cover of the key fob. Use a small screwdriver
(or similar tool) to pry open the left side of the
fob cover while applying pressure until the
cover snaps open.
1 — Emergency Key
2 — Emergency Key Release Button
