Randell 40024 Series User manual

1055 Mendell Davis Drive, Jackson, MS 39272
888-994-7636, fax [phone]
Information contained in this document is known to be current and accurate at the time
of printing/creation. Unified Brands recommends referencing our product line websites,
unifiedbrands.net, for the most updated product information and specifications.
Options & Accessories:
Door Lock
Display Merchandiser Refrigerated Countertop models 40024
model 40024 40024SS
model 40024A shown
Standard Features:
• Self-contained, top-mounted refrigeration system with
thermostatic control, system utilizes “CFC free”,
R-134a refrigerant
• Insulated glass doors, stainless steel front louver panel
- lighted sign panel on back louver
• Foamed in place “CFC free” urethane insulation
• Stainless steel exterior
• Adjustable shelving set up and condensate evaporator
mounted at factory
• Fluorescent interior illumination
• Totally self-contained for plug-in installation
• Stainless steel louver panel on one side - lighted sign panel
on other side (sign by others)
• Single service model 40024SSA with insulated glass back
in lieu of hinged door
Description:
24" long x 24" deep self-contained single service, or pass-thru
countertop display case on adjustable legs with insulated glass
door, stainless steel exterior. Adjustable shelving and fluorescent
illumination. Top- mounted R-134a forced air refrigeration
system with high capacity evaporator coil and thermostatic
control. Foamed in place, “CFC free” insulation and cordset for
115V operation.
Specifications:
CABINET EXTERIOR: Cabinet body to be stainless steel with glass
display door and solid glass back. (MODEL 40024 with pass-thru
door setup). Front louver panel to be die-formed stainless steel,
allowing ventilation of condensing unit. Back louver panel to be
a lighted sign panel (signage by others). Door opening frames to
be stainless steel with ABS breaker strips and heater elements
to prevent condensation on fronts. Unit to be supplied on 4" high
adjustable leg set.
CABINET INTERIOR: Interior bottom to be all stainless steel with
ABS plastic formed sided with molded shelf supports to hold two
powder coat finished shelves provided. Interior light with external
switch provided. Interior top with fluorescent lighting fixture. Unit
insulated with CFC free, foamed in place urethane insulation.
ABS interior sides provided with mirror to accentuate lighting
and products.
DOORS: Door to be insulated glass, mounted on concealed hinges
with stainless steel frames, magnetic gaskets, and handles.
REFRIGERATION: CFC free, HFC-134a refrigeration system with
condensing unit, evaporator blower coil, condensate evaporator,
and thermostatic control for operator adjustability. Unit totally
prewired and to be supplied with 8' cordset (NEMA 5-15P) for
115V plug-in operation.
Randell Display Merchandiser, Page 4
Revised 08/05

Randell, Unified Brands 888-994-7636, fax [phone]
Information contained in this document is known to be current and accurate at the time
of printing/creation. Unified Brands recommends referencing our product line websites,
unifiedbrands.net, for the most updated product information and specifications.
Door Opening Sizes - Interior Depths
Unit Clearances Through Door Interior Depth Behind
Length Lt. to Rt. Top to Bottom Sliding Glass Door
24" 19 1/4" 18 1/2" 19"
Models 40024
Lighted Sign Panel Size:
Exposed Area: 21.5" x 8"
Overall Panel Size: 23.5" x 11.25"
Storage Shelves
Model L D H Style Cu. Ft. Sq. Ft. H.P. Volt Amp. NEMA Ship Wt.
40024 24" 24 1/2" 38 1/2" Pass-Thru 4.75 11* 1/4 115/60/1 5.9 5-15P 240
40024SS 24" 24 1/2" 38 1/2" Single Service 4.75 11* 1/4 115/60/1 5.9 5-15P 240
* Includes interior bottom.
R134A
REFRIGERANT
SPECIFY IF
OTHERWISE
9' LONG CORD
SET (NEMA
JUNCTION BOX
115V/60Hz/1Ph
DRAIN 1/2 "
OC CONDENSATE
EVAPORATOR
HOT GAS
CONDENSATE
5.9 Amps
5-15P)
J
LEGEND FOR
#40024
COMPRESSOR
FIXED FLOOR
AFF =ABOVE
1/4hp
HP
MODEL
J
OC
HP
MODEL # 40024A
24.0
4.0
38.5
24"
10.5
23.5
71"
23.5"
47.5"
HP
J
OC
MODEL # 40024SSA
24"
24.0
10.5
4.0
23.5
47.5"
38.5
Drawings are to be viewed in the same order as the chart
