Randell 44250PA User manual

1055 Mendell Davis Drive, Jackson, MS 39272
888-994-7636, fax [phone]
Specifications subject to change without notice.
For the most current specs, visit unifiedbrands.net.
Custom SC Full View Display Case models 44000A
Description:
Self-contained refrigerated display unit with insulated self-
closing doors in upper display structure. Display area with
stainless steel interior, (2) angled display mirrors, (4) display
shelves and side mounted illumination. R-134a forced air
refrigeration system with expansion valve and thermostatic
control. Refrigerated storage base with service ledge. Foamed
in place, “CFC free” insulation and cordset for 115V operation.
Unit has 6" high adjustable and movable legs. Available as a
Pass-Thru unit.
model 44250A shown
CABINET EXTERIOR: Cabinet body is constructed of all metal.
Service ledge to be one piece of die-formed 16 gauge stainless
steel finish with 2 1/2" nosing. Ends at top fitted with recessed
heavy duty steel bars for field bolting units together, producing
a hairline seam. Upper display structure; to have stainless steel
exterior and interior sides. Self-closing, thermalpane glass doors
that are easily removable for cleaning, riding in nylon track.
Base; Door opening frames to be ABS and contain magnetic
strip for positive sealing of gaskets. Exterior body to be corrosion
resistant steel. Louver panel to be die-stamped stainless steel.
Unit totally prewired to junction box. Legs to be 6" high stainless
steel with adjustable bullet foot. Legs mounted to full length
channel frame assembly which is integrally welded to bottom
of body assembly. Legs can be moved left to right to avoid floor
obstacles during installation.
CABINET INTERIOR: Upper display structure; (4) powder
coated wire shelves provided, with (2) angled display mirrors.
Illumination to be provided by (2) fluorescent fixtures, (1) per
side, removable without the need for tools. Base; interior to be
ABS thermoplastic at ends only. Stainless steel interior liner to
be coved cornered to form bottom and back. One powder coat
finished shelf provided behind each door. Upperstructure, and
base with high density, CFC free, urethane expanding foam.
DOORS: Stainless steel fronts with easy to grasp stainless
handles, mounted on heavy duty concealed hinges. Hinges are
all stainless steel with bronze pivot pin in nylon bushing, spring
loaded to be self-closing. Doors with foamed in place insulation,
and magnetic gaskets.
REFRIGERATION: Base and upperstructure supplied with
separate refrigeration coils. R-134a refrigeration system to
include condensing unit installed with high capacity evaporator
Standard Features:
• Self-contained refrigeration system that utilizes “CFC free”
R-134a refrigerant
• Display area illuminated from sides for shadow free display
• Fluorescent illumination
• Adjustable shelving
• Insulated glass doors are self-closing and easily removed
for cleaning
• Foamed in place “CFC free” urethane insulation
• Separate coil for upperstructure for more effective cooling of
display area
• 6" high legs—adjustable and movable
Specifications:
blower coils, blower coils fitted with expansion valves for fast recovery
and thermostatic control for field adjustability. Condensing unit sized and
installed for proper cooling in housing at left end. Optional condensate
evaporator to be installed in compressor airflow. Unit totally prewired
and to be supplied with 8' cordset for 115V plug-in operation.
PASS THRU Model Same as above except to have (2) sets of self-closing
doors, and no angled display mirrors or mirrored back. (4) fluorescent
fixtures-(2) per side provided.
Randell Custom, Page 15
Revised 08/05
model 44350A 44362A 44374A 44250PA 44262PA 44274PA
44350PA 44362PA 44374PA

Randell, Unified Brands
888-994-7636, fax [phone]
Specifications subject to change without notice. For the most current specs, visit unifiedbrands.net.
115V-60-1PH
JUNCTION BOX 26" AFF.
AFF = ABOVE FIXED FLOOR
MODEL #44000A
LEGEND FOR
AT 10" AFF
CONDENSATE DRAIN 1/2 "
hp COMPRESSOR
(NEMA #5-15P)
8' LONG CORD SET
OC
J
HP
25.25"
33"
80"
44"
36"
31"
35"
26.5"
44"
80"
36"
J
HP
OC
27" REFRIG. 27" REFRIG.
74"
18"REFRIG. 27"REFRIG.
62"
27" REFRIG.
C
I
O
L
50"
17"
13"
29" Deep Models Length Height No. of Doors No. of 4" dp. pans in base top H.P./Refrigerant Amps. Volt/Cycle/Phase NEMA BTU Capacity Ship Wt. - lbs
50" 80" (1) 27" (4) 1/2 1/2 hp/134a 11.1 115/60/1 5-15P 3932 593
62" 80" (1) 18" (1) 27" (4) 1/2 (1) 1/3 1/2 hp/134a 11.5 115/60/1 5-15P 4322 746
74" 80" (2) 27" (6) 1/2 3/4 hp/134a 15.1 115/60/1 5-20P 5793 834
33" Deep Models
44350A 50" 80" (1) 27" (4) 1/2 1/2 hp/134a 11.1 115/60/1 5-15P 3932 593
44362A 62" 80" (1) 18" (1) 27" (4) 1/2 (1) 1/3 1/2 hp/134a 11.5 115/60/1 5-15P 4322 746
44374A 74" 80" (2) 27" (6) 1/2 3/4 hp/134a 15.1 115/60/1 5-20P 5793 834
PASS THRU MODELS
31" Deep Models
44250PA 50" 80" (1) 27" (4) 1/2 1/2 hp/134a 11.1 115/60/1 5-15P 4170 593
44262PA 62" 80" (1) 18" (1) 27" (4) 1/2 (1) 1/3 1/2 hp/134a 11.5 115/60/1 5-15P 4170 746
44274PA 74" 80" (2) 27" (6) 1/2 3/4 hp/134a 15.1 115/60/1 5-20P 5541 834
35" Deep Models
44350PA 50" 80" (1) 27" (4) 1/2 1/2 hp/134a 11.1 115/60/1 5-15P 4170 593
44362PA 62" 80" (1) 18" (1) 27" (4) 1/2 (1) 1/3 1/2 hp/134a 11.5 115/60/1 5-15P 4170 746
44374PA 74" 80" (2) 27" (6) 1/2 3/4 hp/134a 15.1 115/60/1 5-20P 5541 834
44000A Series
FULL VIEW DISPLAY CASE DOOR OPENING SIZES - INTERIOR DEPTHS
Clearances Through Door Interior Depth Behind
Unit Length Lt. to Rt. Top to Bottom Sliding Glass Door
50" 18 3/4" 32" 19 1/4"
62" 24 3/4" 32" 19 1/4"
74" 30 3/4" 32" 19 1/4"
