Randell 2022 User manual

1055 Mendell Davis Drive, Jackson, MS 39272
888-994-7636, unifiedbrands.net
Information contained in this document is known to be current and accurate at the time
of printing/creation. Unified Brands recommends referencing our product line websites,
unifiedbrands.net, for the most updated product information and specifications.
Description:
Randell Series 2000 Upright are built for years of efficient, high
performance service. The top mounted, expansion valve refrig-
eration system offers the highest, most consistent performance
available while maximizing usable interior space.
model 2022 2022P
model 2022 shown
Specifications:
CABINET EXTERIOR: Cabinet body is constructed of all metal,
inside & out. The top, bottom, & back are galvanized steel.
Front and sides are available in finishes as listed above. Doors
and louvers are stainless steel. Both the doors and louver
are removable without tools. Unit on 6" casters, front two are
locking.
CABINET INTERIOR: Interior of cabinet is fully coved to meet N.S.F.
standard #7.The interior walls, ceiling and door liner are available
in either stainless steel or anodized aluminum as listed above.
Foamed in place, CFC free urethane insulation. Snap-in A.B.S.
breaker strips allow access to condensate heater wires.
DOORS: Doors to be thermalpane glass on rollers with extruded
aluminum frames,nylon track and self-closing mechanism requir-
ing no lubrication and allowing door removal without use of tools.
Locks, keyed alike, are standard.
REFRIGERATION:Topmountedcondensingunitand evaporatorcoil,
expansion valve system with thermostatic control, factory tested
and balanced to maintain 38˚ F.average interior temperature utiliz-
ing CFC free 134a refrigerant. Evaporator coil is coated to resist
corrosion. Unit supplied with master on/off switch and 8' cord and
plug. Access to service points without tools is standard.
Standard Features:
• Expansion Valve
• Exterior LED Temperature Display
• Top mounted Compressor & Evaporator Coil
• C.F.C. Free R-134a Refrigerant
• Efficient Hot Gas Condensate Evaporator
• Automatic Defrost
• 8' Cord & Plug
• Main Power Supply Switch
• 6" Casters - Factory Mounted (Front two Locking)
• Polyurethane Insulation
• 3 Baked Epoxy Coated Wire Shelves Per
Section With Stainless Steel Support Clips
(Adjustable every 1")
• Snap-In Magnetic Door Gaskets
• Fully Coved Interior Meeting N.S.F. Standard #7
Upright Sliding Door Refrigerator models 2022
Standard Series Doors/Louver: Stainless steel.
Exterior Sides: Anodized aluminum. Interior: Anodized aluminum
E Series Cabinet interior, exterior sides, fronts,
and doors stainless steel.
Finishes:
Universal Tray Slides (set of two) Qty. Sets
*1/2 Doors Solid Glass Qty. Location
6" Legs
Remote (Add Suffix “R”)
Extra Interior Shelves Qty.
(maximum of (23) or (20) additional on 1.5" centers-leaves 1" clear)
Finished Back
Export Voltage(s) Specify Voltage
Prison Package
*Split doors option available on 2022P only.
Options & Accessories:
Randell Upright, Page 7
Revised 08/05
33°F to 40°F 18°F to 22°F33°F to 41°F

Randell, Unified Brands 888-994-7636, unifiedbrands.net
Information contained in this document is known to be current and accurate at the time
of printing/creation. Unified Brands recommends referencing our product line websites,
unifiedbrands.net, for the most updated product information and specifications.
Models 2022
SELF-CONTAINED SLIDING GLASS DOOR MODELS
*Based on 90˚ ambient and -10˚ evaporator.
Model
2022
2022P pass-thru
L
55”
55”
D
33 1/2"
33 1/2"
H
81.25”
81.25”
Doors
2
4
HP
1/3
1/2
Volt
115/60/1
115/60/1
Amps
8.6
11.7
NEMA
5-15P
5-15P
BTU Rating
2300*
4400*
Ship Wt.
605
605
Cu./Ft.
46.08
46.08
Shelves
6
6
Shelves Sq. Ft.
26
26
FOR REMOTE MODELS
Use same specifications as self-contained model except for:
Model No. Rec. H.P. Rec. BTU/Hr. Amp. Ship Wt.
2022R 1/3 2300 5 555
2022PR 1/3 2300 5 555
Note: All remote Upright come standard on 6" legs in lieu of casters.
TRAYSLIDE CAPACITIES
Universal Pan Slides .... Model....RIUNIVPS - set of two.
For 12 x 20 food pans or 18 x 26 sheet pans.
Maximum capacity of 12" x 20" food pans per full height section:
(6) 6" deep pans, (8) 4" deep pans, (18) 2" deep pans.
Maximum capacity of 18" x 26" sheet pans with 2" spacing is (22).
11.7 Amps
OC CONDENSATE DRAIN 1/2"
EH EVAPORATOR HOUSING
115V/60Hz/1Ph
1/2hp COMPRESSOR
9' LONG CORD SET
MODEL # 2022P
LEGEND FOR
(NEMA 5-15P)
JUNCTION BOX
4400 BTU/Hr
J
HP
EVAPORATOR
CONDENSATE
HOT GAS
OC CONDENSATE DRAIN 1/2"
HOT GAS
CONDENSATE
EVAPORATOR
2300 BTU/Hr
LEGEND FOR
MODEL # 2022
9' LONG CORD SET
1/3hp COMPRESSOR
JUNCTION BOX
115V/60Hz/1Ph
8.6 Amps
(NEMA 5-15P)
EH EVAPORATOR HOUSING
HP
J
INDUSTRIESCOMPANY
31.742"
81"
EH
OC
HP
J
55"
81"
33.5"
LIGHT SWITCH
MODEL #2022
