RanSpec SC Recessed Coldwall Refrigerator models 51000PO
Description:
Self-contained refrigerator storage units with mechanically
cooled pan opening. These units are offered in variety of lengths
to meet your specific base storage or pan storage requirements.
The mechanically cooled pan opening uses Randell’s exclusive
design technologies, such as our Exclusive Refrigerated Pan
Opening Thermostat allowing customers to make adjustments
to the opening temperatures (independent of the base).
model 51362PO shown with
optional finished end
Specifications:
CABINET EXTERIOR: Top to be one piece of die-formed 16 gauge
stainless steel with 2 1/2” nosing. Backsplash to be coved
cornered, with 45˚ return at top and overall height of 6 3/4”.
Ends at top fitted with recessed heavy duty steel bars for field
bolting units together, producing a hairline seam. Hinged louver
panel to be stainless steel. Exterior body to be corrosion resistant
steel. Door opening frames are ABS and contain magnetic strip
for positive seal of door gaskets. Work surface to be at 36” work
height. Legs to be 6” high stainless steel with adjustable bullet
foot. Legs mounted to full length channel frame assembly which
is integrally welded to bottom of body assembly. Legs can be
moved left to right to avoid floor obstacles during installation.
CABINET INTERIOR: Base interior to be ABS thermoplastic at ends
only. Stainless steel interior liner to be coved cornered to form
bottom, back and top. Unit insulation to be CFC free foamed in
place urethane.
DOORS: Door fronts to be 22-gauge stainless steel exterior front
with 16 gauge stainless steel door pulls/handles. The interior
liner is vacuumed formed ABS with integral gasket retainer for
easy cleaning and accepts Randell’s Exclusive Press Fit Gasket
System. Doors are mounted on concealed hinges.
REFRIGERATION: System is a balanced heavy duty R-404A
refrigerant system with an energy efficient hot gas automatic defrost
(for base evaporator coil). The base is cooled by an independent
blower coiled operating on its own expansion valve and thermostat
and operates through a dedicated solenoid valve. The rail is provided
with a pressure control to operate the condensing unit on demand
and a rail thermostat (located in the compressor housing) making it
easily adjustable for specific ambient conditions without effecting
the balance of the system. An on/off switch for the rail is located
behind the hinged louver panel.
Standard Features:
• Low profile 2” recess pan design provides easy reach and optimal pan
temperatures & reliability
• Full Length Poly Cutting Board
• Front breathing compressor housing with directed air flow -
A Randell Exclusive.
• Easy maintenance Press-Fit gaskets - A Randell Exclusive
• Pan opening thermostat- A Randell Exclusive
• Drain in pan opening for easy cleaning
• Hinged louver for easy access
• Hinged Removable stainless steel covers
• Foamed in place urethane insulation providing superior insulation and durability
• 6” high adjustable legs, moveable left to right if needed
• Available up to 16’ under one common assembly
• Adapter bars are standard to accommodate a compliment of 1/6 size pans
• Front breathing louver design allows sealing to wall & curb mounting without
special requirements
Options & Accessories:
Hinged slide back cover
Lift-off (removable) night covers
Stainless Steel Ends
Stainless Steel Back
Laminate fronts, ends and back options
Casters in lieu of legs
Export voltages
Over-shelving storage options
Wide pan opening
Randell RanSpec, Page 18a
Revised 07/07
model 51341PO 51344PO 51347PO 51356PO 51359PO 51362PO 51365PO
51368PO 51377PO 51380PO 51383PO 51386PO 51389PO 51395PO
513114PO 513126PO
33°F to 40°F 18°F to 22°F33°F to 41°F

1055 Mendell Davis Drive, Jackson, MS 39272, 888-994-7636, unifiedbrands.net
Information contained in this document is known to be current and accurate at the time
of printing/creation. Unified Brands recommends referencing our product line websites,
unifiedbrands.net, for the most updated product information and specifications.
51000PO Series
NOTE:
Pan capacity reflected is the actual amount of pans that are clearly accessible by the operator. Units with multiple covers may actually have
additional pan capacity that is partially obstructed by the cover divider/mullion.
BTU load and capacity ratings based on 86F ambient.
Length 77" 80" 83" 86" 89" 95" 114" 126"
Model 33" 51377PO 51380PO 51383PO 51386PO 51389PO 51395PO 513114PO 513126PO
# of doors (3) 21" (2) 21", (1)
24"
(2) 24", (1)
21"
(3) 24" (2) 24", (1)
27”
(3) 27" (4) 24" (4) 27"
Min. Compr. Hsg. 14" 14" 14" 14" 14" 14" 18" 18"
# Pans (10-18) 1/6 (10-18) 1/6 (10-20) 1/6 (10-20) 1/6 (10-20) 1/6 (12-22) 1/6 (14-26) 1/6 (14-30) 1/6
Min. Length of
Opening
41” 41” 41” 41” 41” 48” 55” 55”
Storage Cu. Ft. 12.47 13.15 13.83 14.51 15.19 16.55 19.95 21.76
Cutting Board
Width
10” Wide 10” Wide 10” Wide 10” Wide 10” Wide 10” Wide 10” Wide 10” Wide
H.P./Refrigerant 1/2hp/404a 1/2hp/404a 1/2hp/404a 1/2hp/404a 1/2hp/404a 1/2hp/404a 5/8hp/404a 3/4hp/404a
Amps 12 12 12 12 12 12 12.8 12.8
Volt/Cycle/Phase 115/60/1 115/60/1 115/60/1 115/60/1 115/60/1 115/60/1 115/60/1 115/60/1
NEMA 5-15P 5-15P 5-15P 5-15P 5-15P 5-15P 5-20P 5-20P
Ship Wt. - lbs. 611 627 644 660 693 726 809 875
BTU Design load 588/671 588/693 647/714 647/735 706/757 764/799 882/983 1000/1068
BTU System
Cap.
1866/3319 1866/3319 1966/3319 1966/3319 2061/3319 2151/3319 2735/3947 3330/6435
51000PO SERIES (COMPRESSOR LEFT) SELF-CONTAINED REFRIGERATORS WITH STANDARD DEPTH RECESSED PAN OPENING
Length 41" 44" 47” 56" 59" 62" 65" 68"
Model 33" 51341PO 51344PO 51347PO 51356PO 51359PO 51362PO 51365PO 51368PO
# of doors (1) 21" + 6"
coil hsg.
(1) 24" + 6"
coil hsg.
(1) 27" + 6"
coil hsg.
(2) 21" (1) 21", (1)
24"
(2) 24" (1) 24", (1)
27”
(2) 27"
Min. Compr. Hsg. 14" 14" 14" 14" 14" 14" 14" 14"
# Pans (6-10) 1/6 (6-10) 1/6 (6-10) 1/6 (6-14) 1/6 (8-14) 1/6 (8-16) 1/6 (8-16) 1/6 (8-16) 1/6
Min. Length of
Opening
27” 27” 27” 27” 34” 34” 34” 34”
Storage Cu. Ft. 4.31 4.99 5.67 7.71 8.39 9.07 9.75 10.43
Cutting Board
Width
10” Wide 10” Wide 10” Wide 10” Wide 10” Wide 10” Wide 10” Wide 10” Wide
H.P./Refrigerant 1/3hp/404a 1/3hp/404a 1/3hp/404a 1/3hp/404a 1/3hp/404a 1/3hp/404a 1/3hp/404a 1/3hp/404a
Amps 9.0 9.0 9.0 9.0 9.0 9.0 9.0 9.0
Volt/Cycle/Phase 115/60/1 115/60/1 115/60/1 115/60/1 115/60/1 115/60/1 115/60/1 115/60/1
NEMA 5-15P 5-15P 5-15P 5-15P 5-15P 5-15P 5-15P 5-15P
Ship Wt. - lbs. 418 435 451 495 512 528 545 561
BTU Design load 294/262 294/283 353/304 412/445 412/467 470/488 470/509 529/531
BTU System Cap. 1109/2141 1109/2141 1201/2141 1283/2141 1283/2141 1356/2141 1356/2141 1423/2141

1055 Mendell Davis Drive, Jackson, MS 39272, 888-994-7636, unifiedbrands.net
Information contained in this document is known to be current and accurate at the time
of printing/creation. Unified Brands recommends referencing our product line websites,
unifiedbrands.net, for the most updated product information and specifications.
51000PO Series
Page 18b

1055 Mendell Davis Drive, Jackson, MS 39272, 888-994-7636, unifiedbrands.net
Information contained in this document is known to be current and accurate at the time
of printing/creation. Unified Brands recommends referencing our product line websites,
unifiedbrands.net, for the most updated product information and specifications.
51000PO Series
DOOR OPENING SIZES - INTERIOR DEPTHS
Clearances Through Door Interior Depth Behind Door
Door Width Lt. to Rt. Top to Bottom (unit depths in parentheses)
18 " 13 1/4 " 13 1/2 " (33 ")- 26 " (29 ")- 22 " (22 ")- 15.5 "
21 " 16 1/4 " 13 1/2 " (33 ")- 26 " (29 ")- 22 " (22 ")- 15.5 "
24 " 19 1/4 " 13 1/2 " (33 ")- 26 " (29 ")- 22 " (22 ")- 15.5 "
27 " 22 1/4 " 13 1/2 " (33 ")- 26 " (29 ")- 22 " (22 ")- 15.5 "
•Shelf depth is 25 1/4 " on 33 " deep equipment, 21 1/4 " on 29 " deep equipment,
and 14 1/2 " on 22" deep equipment.
SECTION VIEW
