RanSpec SC Ice Cream Cabinet models 69000
Description:
Self-contained ice cream storage and dipping cabinet with R-
404a cooling system. 16 gauge stainless steel top, and integral
backsplash with 45˚ return. Die-stamped openings in top with
insulated lids. Stainless steel fronts, stainless steel interior with
welded-in-place refrigeration lines. 6" high adjustable and
movable legs.
Shown with optional finished end, sink and dipperwell.
Standard Features:
• Refrigeration system features “CFC free” R-404a refrigerant,
expansion valve for fast recovery and even temperature
regulation
• Superb low temperature unit for ice cream storage and
dipping
• Stainless steel interior allows double stacking of standard 3
gallon containers
• Foamed in place “CFC free” urethane insulation
• Sink and dipper well available
• 6" high legs—adjustable and movable
• 45˚ integral stainless backsplash is standard. 90˚ stainless
backsplash is optional.
Specifications:
CABINET EXTERIOR: Top to be one piece of die-formed 16 gauge
stainless steel with 2 5/8" nosing. Backsplash to be coved
cornered, with 45˚ return at top and overall height of 6 3/4".
Ends at top fitted with recessed heavy duty steel bars for field
bolting units together, producing a hairline seam. Top to have
die-stamped cut-outs with raised rims, fitted with removable,
hinged, insulated lids. Exterior body to be corrosion resistant
steel. Front panels to be removable, constructed of 22 gauge
die-stamped stainless steel. Louver panel to be die-stamped
stainless steel. Work surface to be at 36" work height. Legs to be
6" high stainless steel with adjustable bullet foot. Legs mounted
to full length channel frame assembly which is integrally welded
to bottom of body assembly. Legs can be moved left to right to
avoid floor obstacles during installation.
CABINET INTERIOR: Unit interior to be stainless steel, with interior
sides to be wrapped with refrigerating lines held firmly in place
with holding clips welded to unit body. Unit insulation to be CFC
free foamed in place urethane.
REFRIGERATION: Cooling system to utilize R-404a refrigerant.
Expansion valve fitted to refrigeration line with pressure control
installed for temperature control. Condensing unit sized and
installed for proper cooling in housing at right end. Unit totally
prewired and to be supplied with 8' cordset (NEMA 5-15P) for
115V operation.
Randell RanSpec, Page 29
PP SPEC0144 Rev. A
Revised 08/07
model 69345 69357

1055 Mendell Davis Drive, Jackson, MS 39272, 888-994-7636, unifiedbrands.net
Information contained in this document is known to be current and accurate at the time
of printing/creation. Unified Brands recommends referencing our product line websites,
unifiedbrands.net, for the most updated product information and specifications.
69000 Series
29" Deep Equipment
Length 45" 57"
Height* 36" 36"
Storage
Capacity 24 gal. 36 gal.
H.P. 1/3 1/3
Volts 115/60/1 115/60/1
Amps. 6.5 6.5
NEMA 5-15P 5-15P
Ship Wt. 418 lbs. 458 lbs.
* All units on 6" high adjustable, movable legs for 35 1/2" to 36 3/4" high work surface.
Designed for 7˚ ice cream, 45˚ rail temperature.
33" Deep Equipment
Length 45" 57"
Model No. 69345 69357
Height* 36" 36"
Storage
Capacity 24 gal. 36 gal.
H.P. 1/3 1/3
Volts 115/60/1 115/60/1
Amps. 6.5 6.5
NEMA 5-15P 5-15P
Ship Wt. 418 lbs. 458 lbs.
MTD.BELOW J-BOX
8' LONG CORD SET
20 AFF.
EXPANSION VALVE
(NEMA 5-15P)
PVC 10" AFF.
CONDENSATE DRAIN 1/2"
EXPANSION VALVE
V
OC
LEGEND
HP COMPRESSOR
AFF = ABOVE FIXED FLOOR
115V/60Hz/1Ph
JUNCTION BOX 26" AFF
HP
36"
43.75"
42.75"
33"
3
gal
3
gal 3 gal
3
gal
3
gal 3 gal
57"
OC
HP
J
V
3
gal
3
gal
3
gal
3
gal
COMPR. HSG.
45"
14"
6"
13"
SECTION VIEW
