Randell 2168 User manual

1055 Mendell Davis Drive, Jackson, MS 39272
888-994-7636, unifiedbrands.net
Information contained in this document is known to be current and accurate at the time
of printing/creation. Unified Brands recommends referencing our product line websites,
unifiedbrands.net, for the most updated product information and specifications.
Upright Roll-In Double Door Refrigerator model 2168
Specifications:
CABINETEXTERIOR:Cabinetbody is constructed of all metal,inside
& out. The top, bottom, & back are galvanized steel. Front and
sides are available in finishes as listed above. Doors and louver
are stainless steel and are removable without tools. Provided with
two stainless steel removable ramps.
CABINET INTERIOR: Interior of cabinet is fully coved to meet N.S.F.
standard #7. Solid core stainless steel interior floor is standard.
The interior walls, ceiling and door liner are available in either
stainless steel or anodized aluminum as listed above. Foamed in
place, CFC free urethane insulation. Snap-in A.B.S. breaker strips
allow access to condensate heater wires. Provided with stainless
steel rack guide.
DOORS: Stainless steel front with either anodized aluminum or
stainless steel liner, mounted on (3) heavy duty cam lift hinges
with heavy duty chrome handle, and cylinder door lock.
REFRIGERATION:Top mountedcondensingunitandevaporatorcoil,
expansion valve system with thermostatic control, factory tested
and balanced to maintain 38˚ F.average interior temperature utiliz-
ing CFC free 134a refrigerant. Evaporator coil is coated to resist
corrosion. Unit supplied with master on/off switch and 8' cord and
plug. Access to service points without tools is standard.
Description:
Randell Series 2000 Two Section Roll-Ins are built for years of
efficient, high performance service. The top mounted, expansion
valve refrigeration system offers the highest, most consistent
performance available while maximizing usable interior space.
Standard Features:
• Expansion Valve
• Exterior LED Temperature Display
• Top mounted Compressor & Evaporator Coil
• C.F.C. Free R-134a Refrigerant
• Efficient Hot Gas Condensate Evaporator
• Automatic Defrost
• 8' Cord & Plug
• Main Power Supply Switch
• Self-Closing, Cam Lift Hinges with 120˚ Open Feature
(Lifetime Warranty)
• Triple Hinged Doors
• Cylinder Door Locks
• Solid Core Stainless Steel Interior Bottom
• Fully Coved Interior meeting N.S.F. Standard #7
• Stainless Steel Interior Rack Guide
• Polyurethane Insulation
• Stainless Steel Removable Ramps
• Snap-In Magnetic Door Gaskets
Standard Series Doors/Louver: Stainless steel.
Exterior Sides: Anodized aluminum. Interior: Anodized aluminum
E Series Cabinet interior, exterior sides, fronts,
and doors stainless steel.
Finishes:
Randell Upright, Page 18
Revised 04/06
33°F to 40°F 18°F to 22°F33°F to 41°F

Randell, Unified Brands 888-994-7636, unifiedbrands.net
Information contained in this document is known to be current and accurate at the time
of printing/creation. Unified Brands recommends referencing our product line websites,
unifiedbrands.net, for the most updated product information and specifications.
TWO SECTION ROLL-IN REFRIGERATOR
* Based on 90˚ ambient and +20˚ evaporator.
Model
2168 two section
L
68”
D
34 1/2"
H
84"
Doors
2
HP
1/2
Volt
115/60/1
Amps
11.7
NEMA
6-15P
BTU/HR
4400*
Ship Wt.
1275
Cu./Ft.
70.98
Model 2168
FOR REMOTE MODEL
Use same specifications as self-contained model except for:
Model No. Rec. H.P. Rec. BTU/Hr. Amp. Ship Wt.
2168R 1/2 4400 5 1205
NOTE:
Unit designed to accommodate one 66" high x 26" wide x 29" deep rack.
Actual rack clearance dimensions: 66 1/2" high x 26 1/2" wide x 29 1/2" deep.
Actual door opening dimensions: 67 1/2" high x 28 1/2" wide.
120V/60Hz/1Ph
LEGEND FOR
4400 BTU/Hr
1/2hp COMPRESSOR
OC CONDENSATE DRAIN 1/2"
EH EVAPORATOR HOUSING
9' LONG CORD SET
MODEL # 2168
JUNCTION BOX
11.7 Amps
(NEMA 5-20P)
J
HP
CONDENSATE
EVAPORATOR
HOT GAS
HEATED
INDUSTRIESCOMPANY
J
HP
EH
OC
66"H x 26"W x 29"D RACK.
66.5" x 26.5" x 29.5" DEEP
DESIGNED TO ACCOMMODATE
ACTUAL CLEARANCE DIM.
THERMOMETER
ON/OFF SWITCH
DOORS
TRIPLE HINGED
RAMPS
S/S REMOVABLE
68"
84"
33"
32.5"
34.5"
