Range Master WiFi King User manual

Version: 2.0
iii
802.11n Long-Range
USB WiFi Antenna
User Manual
Version: 2.0

Version: 2.0
iii
TABLE OF CONTENTS
OVERVIEW ..........................................................1
UNPACKING I NFORMATION ................................................................................................. 1
INTRODUCTION TO THE WiFi King WIRELESS USB ADAPTER .............................................. 1
KEY FEATURES ................................................................................................................ 2
INSTALLATION GUIDE ........................................2
SOFTWARE INSTALLATION ................................................................................................. 2
MANAGEMENT GUIDE.........................................5
MAKING A BASIC NETWORK C ONNECTION .......................................................................... 5
Select a configuration tool .......................................................................................... 5
To connect with Microsoft Zero Configuration tool...................................................... 5
To connect with 802.11n Wireless LAN Utility............................................................ 7
INTRODUCTION TO THE 802.11NWIRELESS LAN UTILITY .................................................... 8
Interfaces.................................................................................................................... 8
Link Status Information............................................................................................... 9
Profile ....................................................................................................................... 10
Network .................................................................................................................... 19
Advanced.................................................................................................................. 20
Statistics................................................................................................................... 21
WMM........................................................................................................................ 22
WPS ......................................................................................................................... 24
CCX.......................................................................................................................... 35
Radio On/Off............................................................................................................. 35
AP MODE MANAGEMENT GUIDE FOR WINDOWS 2000/XP/VISTA ......................................... 36
Config....................................................................................................................... 38
Security Setting ........................................................................................................ 40
Access Control ......................................................................................................... 41
MAC Table................................................................................................................ 42
Event Log ................................................................................................................. 43
Statistics................................................................................................................... 44

Version: 2.0
1
Overview
Thank you for purchasing this product. Read this chapter to learn about your Range Master WiFi
King 802.11n Wireless USB Adapter.
Unpacking Information
Before getting started, please verify that your package includes the following items:
1. WiFi King Wireless USB Adapter.
2. Outdoor Omnidirectional Antenna.
3. Utility/Manual CD.
Introduction to the WiFi King Wireless USB Adapter
The WiFi King Wireless USB adapter is an IEEE 802.11n wireless 150 Mbps wireless adapter
which is also compatible with IEEE 802.11b/g and IEEE 802.11a/b/g wireless devices at
11/54 Mbps. You can configure this adapter with ad-hoc mode to connect to other 2.4GHz
wireless computers or in infrastructure mode to connect to a wireless AP or router for accessing
the internet. This adapter includes a convenient utility for scanning available networks and
saving preferred networks that users usually connected with. Security encryption can also be
configured by this utility.

Version: 2.0
2
Key Features
yComplies with IEEE 802.11n wireless standards ySupports wireless data encryption with
64/128-bit WEP, WPA, WPA2, TKIP, AES
y2.4GHz frequency band, MIMO ySupports QoS: WMM, WMM-PS
yComplies with USB 2.0 ySupports multiple BSSID
yHigh speed transfer data rate up to 150 Mbps
ySupports auto-installation
ySupports driver for Windows 2000, XP 32/64,
Vista 32/64, Windows 7, Linux (2.4.x/2.6.x), and
Mac (10.3.x/10.4.x/10.5.x/10.6.x) Power PC &
PC
Installation Guide
Software Installation
Note:
yFor Linux or Mac driver installation guide, please refer to the instruction in
/Driver/Linux/README or /Driver/Mac/README in the CD-Rom.
yThe screenshots will vary slightly depending on the version of Windows but the procedures
and screens are similar.
1. The system finds the newly installed device automatically. Click Cancel to close this window.
2. Insert the CD-Rom that came with this product to your CD-Rom drive. The menu window pops
up automatically. Please click the Driver button of this product.
Note: If the CD-Rom fails to auto-run, please click on My Computer >your CD-Rom drive
> (folder of this product) > Driver then double-click the Setup icon to start this menu.

Version: 2.0
3
3. Select if you are going to install the driver and wireless utility; or install the driver only.
4. Select if you are going to configure your wireless network with this device or with Microsoft
Zero Configuration tool.
Note: This can be changed after installing this software.

Version: 2.0
4
5. Click the Install button to start installing.
6. Click the Finish button to complete installation.

Version: 2.0
5
…..
Management Guide
Read this chapter to understand the management interface of the device and
how to manage the device.
Making a Basic Network Connection
Select a configuration tool
In the following instructions for making a network connection, we use the utility we provide to
configure your wireless network settings.
Note: You could use either the software we provide or Microsoft Zero Configuration tool to
configure this adapter. To switch between the two configuration tools, please right click on the
icon on system tray to select.
To connect with Microsoft Zero Configuration tool
After specifying the Microsoft Zero Configuration tool to configure your wireless network, right
click on the icon on system tray. Select View Available Wireless Networks to specify your
wireless network.

Version: 2.0
6
The tool shows the available wireless networks. Select the network you want to connect to. To
connect to a wireless network with more security settings, please click Change advanced
settings and configure to be compatible with your wireless network security settings.

Version: 2.0
7
To connect with 802.11n Wireless LAN Utility
We provide this utility for users to connect to a wireless network easily. It provides more
information and configuration for this adapter. As default, the utility is started automatically upon
starting your computer and connects to a connectable wireless network with best signal strength
and with no security setting. Right click on the icon in the system ray and select Launch
Config utilities if the utility does not start. Please refer to the following chapters to get
information regarding to the functions of this utility.

Version: 2.0
8
Introduction to the 802.11n Wireless LAN Utility
Note: The Utility in Linux and Mac are different from the following.
Interfaces
This utility basically consists of three parts:
1
2
3
1. Function Buttons: on top of the window. You can click each button to access each
configuration window.
Note: Click to enable/disable wireless connection status.
2. Configuration Column: Center of the Utility window. Make your changes for each function in
this part.
3. Link Status Information: bottom of the utility window. Shows the connection status and
system information.
