Edition Notes
The K2 , User Manual Rev. 1 covers the description,
safety precautions, installation, programming, operation,
and maintenance of the K2. Rasha released this edition of
the K2 User Manual in July 2022.
Trademarks
Rasha®Is a registered trademark of RASHA
PROFESSIONAL A/S. (D/b/a RASHA®or Rasha). The
RASHA® logo in its entirety including the RASHA®name
and the Globe with Rings, and all other trademarks in this
manual pertaining to services, products, or marketing
statements are owned or licensed by RASHA®. Any other
product names, logos, brands, company names, and other
trademarks featured or referred to within this document
are the property of their respective trademark holders.
Copyright
Notice
RASHA owns the content of this User Manual
in its entirety, including but not limited to
pictures, logos, trademarks, and resources.
© Copyright 2015 RASHA. All rights reserved.
Electronically published by Rasha in the United States of
America.
Manual Use
Rasha authorizes its customers to download and print this
manual for professional information purposes only. Rasha
expressly prohibits the usage, copy, storage, distribution,
modication, or printing of this manual or its content for
any other purpose without written consent from Rasha.
Document
Printing
For better results, print this document in color, on letter
size paper (8.5 x 11 in), double-sided. If using A4 paper
(210 x 297 mm), congure your printer to scale the content
accordingly.
Intended
Audience
Any person in charge of installing, operating, and/or
maintaining this product should completely read through
the guide that shipped with the product, as well as this
manual, before installing, operating, or maintaining this
product.
Document
Revision
The K2 User Manual Rev. 1 supersedes all previous
versions of this manual. Discard any older versions of
this manual and replace with this version. Go to www.
rashaprofessional.com for the latest version.
Author Date Editor Date
Deepak T. 27/06/2022

Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 || 951-654-3585
rashaprofessional.com || [email protected]
3
1. Before You Begin................................. 4
What Is Included .................................. 4
Claims .................................................. 4
Manual Conventions ............................ 4
Symbols ............................................... 4
Safety Notes......................................... 5
Personal Safety.................................... 5
Mounting And Rigging .......................... 5
Power And Wiring................................. 5
Operation ............................................. 5
2. Introduction.......................................... 6
Description ........................................... 6
Features ............................................... 6
Overview .............................................. 6
Dimensions .......................................... 7
3. Setup..................................................... 8
Power Supply ....................................... 7
AC Plug ................................................ 8
Fuse Replacement ............................... 8
Power Linking....................................... 8
DMX Linking......................................... 8
DMX Personalities................................ 8
Mounting .............................................. 9
Orientation............................................ 9
Rigging ................................................. 9
Procedure............................................ 9
4. Menu Map........................................... 10
Menu Map ..................................... 10-11
Control Panel Description .................. 12
DMX Channels ..............................13-22
Returns.............................................. 23
Contact Us ........................................ 24
Table of Contents

Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 || 951-654-3585
rashaprofessional.com || [email protected]
4
What Is
Included
• Rasha K2
• Edition to PowerCON®
• DMX Cable
• Quick reference guide
Claims
Carefully unpack the product immediately
and check the box to make sure all the parts
are in the package are in good condition.
If the box or the contents (the product and included
accessories) appear damaged from shipping or show signs
of mishandling, notify the carrier immediately, not Rasha.
Failure to report damage to the carrier immediately may
Void your claim. In addition, keep the box and contents
for inspection.
For other issues, such as missing components or parts,
damage not related to shipping, or concealed damage, le
a claim with Rasha within 7 days of delivery.
Manual
Conventions
Convention Meaning
1–512 DMX value range in number
50/60 A set of mutually exclusive values in the text
<SET> A button on the product’s control panel
Settings A product function or a menu option
0-512 A sequence of menu options
1-10 A range of menu values from which to choose in a menu
Yes/No A set of two mutually exclusive menu options in a menu
ON A unique value to be entered or selected in a menu
Symbols
Symbols Meaning
Display
Flashing
DMX Single lost or disconnected

Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 || 951-654-3585
rashaprofessional.com || [email protected]
5
Safety Notes
Read all the following Safety Notes before working with this product. These
notes include important information about the installation, usage, and
maintenance of this product. This product contains no user-serviceable
parts. Any reference to servicing in this User Manual will only apply to
properly trained Rasha certied technicians. Do not open the housing or
attempt any repairs. All applicable local codes and regulations apply to
proper installation of this product.
Personal
Safety
Avoid direct eye exposure to the light source while the product is on. Always
disconnect this product from its power source before servicing. Always
connect this product to a grounded circuit to avoid the risk of electrocution.
Do not touch this product’s housing during operation because it may be
very hot.
Rigging
This product is for indoor use only! To prevent risk of re or shock, do
not expose this product to rain or moisture. (IP20) CAUTION: When
transferring product from extreme temperature environments, (e.g. Cold
truck to warm humid ballroom) condensation may form on the internal
electronics of the product. To avoid causing a failure, allow product
to fully acclimate to the surrounding environment before connecting it
to power. Mount this product in a location with adequate ventilation,
at least 20 in (50 cm) from adjacent surfaces. Make sure there are
no ammable materials close to this product while it is operating.
Always carry
this product by the handles. Do not carry from the head. When hanging this
product, always secure to a fastening device using a safety cable.
Power And
Wiring
Always make sure you are connecting this product to the proper voltage
in accordance with the specications in this manual or on the product’s
specication label. Never connect this product to a dimmer pack or rheostat.
Never disconnect this product by pulling or tugging on the power cable.
Operation
Do not operate this product if you see damage to the housing, lenses,
or cables. Have the damaged parts replaced by an authorized
technician at once. To eliminate unnecessary wear and improve
its lifespan, during periods of non-use completely disconnect the
product from power via breaker or by unplugging it. Do not cover the
ventilation slots when operating to avoid internal overheating. Do not
aim this product toward the Sun. The lenses could concentrate the
solar energy and cause internal overheating. The maximum ambient
temperature is 113 °F (45 °C). Do not operate this product at a
higher temperature. In case of a serious operating problem, stop using this
product immediately!
The term “DMX” used throughout this manual refers to the DMX512 digital data
transmission protocol

Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 || 951-654-3585
rashaprofessional.com || [email protected]
6
Features • Highest e󰀩ciency & way to power ratio.
• Light weight, compact size.
• 19x RGBW led ring.
• 1.5 Millions of single or mix colors.
• Supports RDM Functions.
• Ultra fast and smooth electronic moments.
• Produce high denition colors wash, parallel beam and concentric
circles.
Description
K2 is the perfect moving head wash and parallel beam luminaire for small
to big event production, venues, arenas & TV studio, Fitted with 19 LED
emitters, K2 delivers luminous ow of over 10000 lumen, over powering
conventional luminaire.
K2 features outstanding 6 is to 1 ratio optical zoom in a range of 10 to
60 degree, controllable concentric circles to adjust the luminaries output
e󰀨ect, combination of high denition colors & power with high output.
Furthermore, powerful 3 phase-step motor and 16 bit controlling system
drives the pan and tilt axis for fast, accurate & silent.
INTRODUCTION
Product Overview
Sound Mode
Master Mode
Slave/DMX
Menu
LCD Display Enter
Down
Up

Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 || 951-654-3585
rashaprofessional.com || [email protected]
7
DIMENSIONS

Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 || 951-654-3585
rashaprofessional.com || [email protected]
8
SETUP
Power Supply
Each K2 has an auto-ranging power supply that works with an input
voltage range of 100 to 240 VAC, 50/60 Hz. To determine the power
requirements for each K2 refer to the label a󰀩xed to the product. You
c a n a l s o r e f e r t o t h e T e c h n i c a l S p e c i  c a t i o n s c h a r t i n t h i s m a n u a l
The listed current rating indicates the maximum current draw during
normal operation. For more information, you may download Sizing Circuit
Breakers from the Rasha website: www.rashaprofessional.com
Always connect this product to a protected circuit with an appropriate
electrical ground to avoid the risk of electrocution or re. To eliminate
unnecessary wear and improve its lifespan, during periods of non-use
completely disconnect the product from power via breaker or by unplugging it.
Never connect this product to a rheostat (variable resistor) or dimmer circuit,
even if the rheostat or dimmer channel serves only as a 0 to 100% switch.
AC Plug
The K2 comes with a power input cord terminated with a Neutrik®
powerCON®A connector on one end and an Edison plug on the other end
(U.S. Market). If the power input cord that came with your product has no
plug, or if you need to change the Edison plug, use the table below to wire
the new plug.
Fuse
Replacement
1. Disconnect this product from the power outlet.
2. Using a at-head screwdriver, unscrew the fuse holder cap from the
housing.
3. Remove the blown fuse and replace with a another fuse of the same
type and rating (F 10 A, 250 V).
4. Screw the fuse holder cap back in place and reconnect power.
Make sure to disconnect the product’s power cord before replacing a
blown fuse. Always replace the blown fuse with another of the same type
and rating
Power Linking
On 20 AMP circuit, you can link up-to 5 Fixtures @ 120V and 10 xtures
@ 240V.
DMX
Personalities
• The K2 uses a 3 pin DMX data connection for the 10/15/21/37/39
channel DMX personalities.
• Refer to the Introduction chapter for a brief description of each DMX
personality.
• Refer to the Operation chapter to learn how to congure the K2 to work
in these personalities.
• The DMX Values section provides you with detailed information regarding
the DMX personalities
Connection Wire (U.S.) Wire (Europe) Screw Color
AC Live Black Brown Yellow or Brass
AC Neutral White Blue Silver
AC Ground Green/Yellow Green/Yellow Green

Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 || 951-654-3585
rashaprofessional.com || [email protected]
9
Before mounting this product, read and follow the Safety Notes. For our
Rasha®Professional line of mounting clamps, go to
https://www.rashaprofessional.com/clamps
Orientation Always mount this product in a safe position and make sure there is
adequate room for ventilation, conguration, and maintenance.
Rigging
Rasha recommends using the following general guidelines when
mounting this product.
• When selecting an installation location, consider easy access to
this product for operation, programming adjustments, and routine
maintenance.
• Make sure to mount this product away from any ammable material as
indicated in the Safety Notes.
• Never mount in places where rain, high humidity, extreme temperature
changes, or restricted ventilation may a󰀨ect the product.
• If hanging this product, make sure that the mounting location can
support the product’s weight. See the Technical Specications for the
weight-bearing requirements of this product.
• When hanging this product, always secure to a fastening device using
a safety cable.
Procedures
The K2 comes with a pre-installed mounting clamp. Make sure
the clamps are bolted proprely and capable of supporting the
weight of this product. Use at least 1 mounting point per product.
In addition, use a safety cable to link the product to the structure.
MOUNTING
Display:
Button:
To show Menu options and the selected functions
SETTING
DOWN
UP
ENTER To conrm the selected functions
To go forward in the selected functions
To go backward in the selected functions
To select the programming functions
Dimmer Curve
• Select Dimmer Curve.
• Press ENTER button to conrm (present mode will blink on the display)
• Use UP or DOWN button to select: Linear, Square Law, Inverse Squ or S-Curve
• Once selected, press ENTER button to store
• Press MENU button to access the previous menu

Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 || 951-654-3585
rashaprofessional.com || [email protected]
10
MENU MAP
Menu Programming Level Description
DMX Address 001-503 Sets Starting address
Channel Set
10 Mode Selects and sets 10 Channel
DMX mode
15 Mode Selects and sets 15 Channel
DMX mode
21 Mode Selects and sets 21 Channel
DMX mode
37 Mode Selects and sets 37 Channel
DMX mode
39 Mode Selects and sets 39 Channel
DMX mode
Show Mode
Show 1
Selects and sets Preset light
show mode 1(Fixture must
be master)
Show 2
Selects and sets Preset light
show mode 2((Fixture must
be master)
Show 3
Selects and sets Preset light
show mode 3(Fixture must
be master)
Show 4
Selects and sets Preset light
show mode 4(Fixture must
be master)
Slave Mode
Slave 1 Selects and save xture on
Slave Mode 1
Slave 2 Selects and save xture on
Slave Mode 2
Master Selects and save xture on
Master Mode
Sound Mode
ON Selects and Set xture on
sound mode
OFF Selects and turn o󰀨 sound
mode
Sound Sense 000-100 Sets and sets sound sense
Display Invert
YES Sets and sets LCD display
Inverse
NO Sets and turn o󰀨 LCD
display Inverse
Pan Inverse
ON Select and sets Pan inverse
OFF Select and turn o󰀨 Pan
inverse
Tilt Inverse
YES Select and sets Tilt inverse
NO Select and turn o󰀨 Tilt
inverse
BK P/T Moving
YES Selects and sets Pan & Tilt
on home position
NO Selects and turn of Pan &
Tilt on home position

Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 || 951-654-3585
rashaprofessional.com || [email protected]
11
Menu Programming Level Description
Dimmer Curve
Liner Selects and sets dimmer
(light intensity)to linear curve
Inv Sq
Selects and sets dimmer
(light intensity)to Inverse
square curve
Sq Law
Selects and sets dimmer
(light intensity)to Square Law
curve
S- Curve Selects and sets dimmer
(light intensity)to S-curve
Dimmer Freq
1200K Selects and sets Dimmer
frequency to 1200K
2400K Selects and sets Dimmer
frequency to 2400K
4000K Selects and sets Dimmer
frequency to 4000K
6000K Selects and sets Dimmer
frequency to 6000K
Fan Speed
Auto Selects and sets auto fan
speed
Slow Selects and sets slow fan
speed
High Selects and sets high fan
speed
White Balance Red/Green/Blue Selects and sets led display
white balance
Language
English Select and sets English
language
Chinese Select and sets Chinese
language
RDM Info 0X……. RDM Information
Auto Test ON Select and test xture
Reset All Reset Select and reset xture
P/T Reset Select and reset pan and tilt
Zoom Reset Select and reset Zoom
Version
Display V… Fixtures Version (Display
control board)
Led & Zoom ……….. Fixtures Version (Led and
Zoom control board)

Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 || 951-654-3585
rashaprofessional.com || [email protected]
12
CONTROL PANEL
1. Mode Indicator
2. LED Display
4. DMX IN
5. DMX OUT
6. Mains IN
Shows the various menus and the selected function
Power ON / DMX ON input present.
DMX512 link, use 3/5-pin XLR cable to link the unit and the
DMX controller.
DMX512 link, use 3/5-pin XLR cable to link the next unit and
output DMX signal.
PowerCon connection from main power supply
3. Button
7. Mains OUT PowerCon loop connection for main power supply to the next
unit.
8. Fuse (T10A) Protects the unit from over‐voltage or short circuit.
MENU
DOWN
UP
ENTER To conrm the selected functions
To go forward in the selected functions
To go backward in the selected functions
To select the programming functions

Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 || 951-654-3585
rashaprofessional.com || [email protected]
13
DMX CHANNELS
K2 - 10 Channel Mode DMX Personality
1CH Pan 000 - 255
2CH Pan Fine 000 - 255
3CH Tilt 000 - 255
4CH Tilt Fine 000 - 255
5CH PanTilt Speed 000 - 255
6CH Special Function 0-69 NULL
70-79 Moving Blackout Open
80-89 Moving Blackout O󰀨
90-99 Pan Invert Open
100-109 Tilt Invert Open
110-119 Pan Tilt Invert O󰀨
120-139 NULL
140-149 Pan-tilt Reset
150-179 NULL
180-189 Zoom Reset
190-199 NULL
200-209 All Reset
210-255 NULL
7CH Virtual Color
Wheel
0 No function (0=default)
1-3 White 2700 K
4-6 White 3200 K
7-9 White 4200 K
10-12 White 5600 K
13-15 White 8000 K
16 Blue (Blue=full,
Red+Green+White=0)
17-55 Red=0, Green->up,Blue =full,
White=0
56 Light Blue (Red=0, Green=full,
Blue =full, White=0)
57-95 Red=0, Green=full, Blue->down,
White=0

Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 || 951-654-3585
rashaprofessional.com || [email protected]
14
7CH Virtual Color
Wheel
96 Green (Red=0, Green=full, Blue
=0, White=0)
97-134 Red->up, Green=full, Blue=0,
White=0
135 Yellow (Red=full, Green=full,
Blue=0, White=0)
136-174 Red=full, Green->down, Blue=0,
White=0
175 Red(Red=full, Green=0, Blue=0,
White=0)
176-214 Red=full, Green=0, Blue->up,
White=0
215 Magenta (Red=full, Green=0,
Blue=full, White=0)
216-246 Red -> down, Green=0, Blue=-
full, White=0
247 Blue (Red=0, Green=0, Blue=full,
White=0)
248-255 NULL
8CH ZOOM 000 - 255
9CH Shutter 0 - 15 LED_EFFECT_OPEN
16 - 131 LED_EFFECT_FLASH
132 - 139 LED_EFFECT_THUNDER
140 - 181 LED_EFFECT_PULSE_CLOSE_
FADE_OPEN
182 - 189 LED_EFFECT_OPEN
190 - 231 LED_EFFECT_PULSE_OPEN_
FADE_CLOSE
232 - 239 LED_EFFECT_OPEN
240 - 247 LED_EFFECT_RANDOM_
FLASH
248 - 255 LED_EFFECT_OPEN
10CH Dimmer 000 - 255

Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 || 951-654-3585
rashaprofessional.com || [email protected]
15
K2-15 Channel DMX Personality
1CH Pan 000 - 255
2CH Pan Fine 000 - 255
3CH Tilt 000 - 255
4CH Tilt Fine 000 - 255
5CH PanTilt Speed 000 - 255
6CH Special Function 0-69 NULL
70-79 Moving Blackout Open
80-89 Moving Blackout O󰀨
90-99 Pan Invert Open
100-109 Tilt Invert Open
110-119 Pan Tilt Invert O󰀨
120-139 NULL
140-149 Pan-tilt Reset
150-179 NULL
180-189 Zoom Reset
190-199 NULL
200-209 All Reset
210-255 NULL
7CH Red 000 - 255
8CH Green 000 - 255
9CH Blue 000 - 255
10CH White 000 - 255
11CH CTC 0 NULL
1-255 2700K-8000K
12CH Virtual Color
Wheel
0 No function (0=default)
1-3 White 2700 K
4-6 White 3200 K
7-9 White 4200 K
10-12 White 5600 K
13-15 White 8000 K
16 Blue (Blue=full,
Red+Green+White=0)

Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 || 951-654-3585
rashaprofessional.com || [email protected]
16
12CH Virtual Color
Wheel
17-55 Red=0, Green->up,Blue =full, White=0
56 Light Blue (Red=0, Green=full, Blue
=full, White=0)
57-95 Red=0, Green=full, Blue->down,
White=0
96 Green (Red=0, Green=full, Blue =0,
White=0)
97-134 Red->up, Green=full, Blue=0, White=0
135 Yellow (Red=full, Green=full, Blue=0,
White=0)
136-174 Red=full, Green->down, Blue=0,
White=0
175 Red(Red=full, Green=0, Blue=0,
White=0)
176-214 Red=full, Green=0, Blue->up, White=0
215 Magenta (Red=full, Green=0, Blue=full,
White=0)
216-246 Red -> down, Green=0, Blue=full,
White=0
247 Blue (Red=0, Green=0, Blue=full,
White=0)
248-255 NULL
13CH Zoom 000 - 255
14CH Shutter 0 - 15 LED_EFFECT_OPEN
16 - 131 LED_EFFECT_FLASH
132 - 139 LED_EFFECT_THUNDER
140 - 181 LED_EFFECT_PULSE_CLOSE_FADE_
OPEN
182 - 189 LED_EFFECT_OPEN
190 - 231 LED_EFFECT_PULSE_OPEN_FADE_
CLOSE
232 - 239 LED_EFFECT_OPEN
240 - 247 LED_EFFECT_RANDOM_FLASH
248 - 255 LED_EFFECT_OPEN
15CH Dimmer 000 - 255

Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 || 951-654-3585
rashaprofessional.com || [email protected]
17
1CH Pan 000 - 255
2CH Pan Fine 000 - 255
3CH Tilt 000 - 255
4CH Tilt Fine 000 - 255
5CH PanTilt Speed 000 - 255
6CH Special Function
0-69 NULL
70-79 Moving Blackout Open
80-89 Moving Blackout O󰀨
90-99 Pan Invert Open
100-109 Tilt Invert Open
110-119 Pan Tilt Invert O󰀨
120-139 NULL
140-149 Pan Tilt Reset
150-179 NULL
180-189 Zoom Reset
190-199 NULL
200-209 All Reset
210-255 NULL
7CH Red 000 - 255
8CH Red Fine 000 - 255
9CH Green 000 - 255
10CH Green Fine 000 - 255
11CH Blue 000 - 255
12CH Blue Fine 000 - 255
13CH White 000 - 255
14CH White Fine 000 - 255
15CH CTC
0NULL
1-255 2700K-8000K
K2 - 21 Channel Mode DMX Personality

Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 || 951-654-3585
rashaprofessional.com || [email protected]
18
16CH Virtual Color
Wheel
0 No function (0=default)
1-3 White 2700 K
4-6 White 3200 K
7-9 White 4200 K
10-12 White 5600 K
13-15 White 8000 K
16 Blue (Blue=full, Red+Green+White=0)
17-55 Red=0, Green->up,Blue =full,
White=0
56 Light Blue (Red=0, Green=full, Blue
=full, White=0)
57-95 Red=0, Green=full, Blue->down,
White=0
96 Green (Red=0, Green=full, Blue =0,
White=0)
97-134 Red->up, Green=full, Blue=0,
White=0
135 Yellow (Red=full, Green=full, Blue=0,
White=0)
136-174 Red=full, Green->down, Blue=0,
White=0
175 Red(Red=full, Green=0, Blue=0,
White=0)
176-214 Red=full, Green=0, Blue->up,
White=0
215 Magenta (Red=full, Green=0,
Blue=full, White=0)
216-246 Red -> down, Green=0, Blue=full,
White=0
247 Blue (Red=0, Green=0, Blue=full,
White=0)
248-255 NULL
17CH Zoom 000 - 255
18CH Zoom Fine 000 - 255
19CH Shutter
1-15 LED_EFFECT_OPEN
16 - 131 LED_EFFECT_FLASH
132 - 139 LED_EFFECT_THUNDER
140 - 181 LED_EFFECT_PULSE_CLOSE_
FADE_OPEN
182 - 189 LED_EFFECT_OPEN
190 - 231 LED_EFFECT_PULSE_OPEN_
FADE_CLOSE
232 - 239 LED_EFFECT_OPEN
240 - 247 LED_EFFECT_RANDOM_FLASH
248 - 255 LED_EFFECT_OPEN
20CH Dimmer 000 - 255
21CH Dimmer Fine 000 - 255

Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 || 951-654-3585
rashaprofessional.com || [email protected]
19
1CH Pan 000 - 255
2CH Pan Fine 000 - 255
3CH Tilt 000 - 255
4CH Tilt Fine 000 - 255
5CH Pan Tilt Speed 000 - 255
6CH Special Funcon
0-69 NULL
70-79 Moving Blackout Open
80-89 Moving Blackout O
90-99 Pan Invert Open
100-109 Tilt Invert Open
110-119 Pan Tilt Invert O
120-139 NULL
140-149 Pan Tilt Reset
150-179 NULL
180-189 Zoom Reset
190-199 NULL
200-209 All Reset
210-255 NULL
7CH Zoom 000 - 255
8CH Zoom Fine 000 - 255
9CH Shuer
0 - 15 LED_EFFECT_OPEN
16 - 131 LED_EFFECT_FLASH
132 - 139 LED_EFFECT_THUNDER
140 - 181 LED_EFFECT_PULSE_CLOSE_FADE_
OPEN
182 - 189 LED_EFFECT_OPEN
190 - 231 LED_EFFECT_PULSE_OPEN_FADE_
CLOSE
232 - 239 LED_EFFECT_OPEN
240 - 247 LED_EFFECT_RANDOM_FLASH
248 - 255 LED_EFFECT_OPEN
10CH Dimmer 000 - 255
11CH Dimmer Fine 000 - 255
K2 - 37 Channel Mode DMX Personality

Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 || 951-654-3585
rashaprofessional.com || [email protected]
20
12CH CTC 0 NULL
1-255 2700K-8000K
13CH Virtual Color Wheel
0 No function (0=default)
1-3 White 2700 K
4-6 White 3200 K
7-9 White 4200 K
10-12 White 5600 K
13-15 White 8000 K
16 Blue (Blue=full, Red+Green+White=0)
17-55 Red=0, Green->up,Blue =full, White=0
56 Light Blue (Red=0, Green=full, Blue =full,
White=0)
57-95 Red=0, Green=full, Blue->down, White=0
96 Green (Red=0, Green=full, Blue =0, White=0)
97-134 Red->up, Green=full, Blue=0, White=0
135 Yellow (Red=full, Green=full, Blue=0, White=0)
136-174 Red=full, Green->down, Blue=0, White=0
175 Red(Red=full, Green=0, Blue=0, White=0)
176-214 Red=full, Green=0, Blue->up, White=0
215 Magenta (Red=full, Green=0, Blue=full, White=0)
216-246 Red -> down, Green=0, Blue=full, White=0
247 Blue (Red=0, Green=0, Blue=full, White=0)
248-255 NULL
14CH Red1 000 - 255
15CH Red Fine 1 000 - 255
16CH Green1 000 - 255
17CH Green Fine 1 000 - 255
18CH Blue1 000 - 255
19CH Blue Fine 1 000 - 255
20CH White1 000 - 255
21CH White Fine 1 000 - 255
22CH Red2 000 - 255
23CH Red Fine 2 000 - 255
24CH Green2 000 - 255
25CH Green Fine 2 000 - 255
26CH Blue2 000 - 255
27CH Blue Fine 2 000 - 255
28CH White2 000 - 255
29CH White Fine 2 000 - 255
30CH Red3 000 - 255
31CH Red Fine 3 000 - 255
32CH Green3 000 - 255
33CH Green Fine 3 000 - 255
34CH Blue3 000 - 255
35CH Blue Fine 3 000 - 255
36CH White 3 000 - 255
37CH White Fine 3 000 - 255
