Rath 2500-PWR24U User manual

Installation & Specications Manual
2500-PWR24U 24vdc
Power Supply
N56W24720 N. Corporate Circle Sussex, WI 53089
800-451-1460 www.RATHCommunications.com
RP8500225B
Ver. 6
12/18
Made in the USA
3 Year Warranty

Thank you for purchasing RATH’s 2500-PWR24U Power Supply. We are the largest Emergency
Communication Manufacturer in North America and have been in business for over 35 years.
We take great pride in our products, service, and support. Our Emergency Products are of the highest
quality. Our experienced customer support teams are available to remotely assist with site preparation,
installation, and maintenance. It is our sincere hope that your experience with us has and will continue
to surpass your expectations.
Thank you for your business,
®
N56W24720 N. Corporate Circle Sussex, WI 53089
800-451-1460 www.RATHCommunications.com
Table of Contents
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Specications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Page 3
Page 4
Page 5
Page 5
Page 5
Page 6

Page 3
The 2500-PWR24U is designed for use with RATH® signaling devices and systems (SmartRescue Base Station and
2100 Series Phones).
Wiring methods shall be in accordance with NFPA 72 and with all local codes and Authorities Having Jurisdiction.
1. Mount the 2500-PWR24U in the desired location near the power source and power runs for the devices.
a. Mark and predrill holes in the walls to line up with the top two keyholes in the enclosure (Fig. 8, pg. 6).
b. Install two upper fasteners and screws in the wall, with the screw heads protruding.
c. Place the enclosure’s upper keyholes over the two upper screws and mark the position of the lower two holes.
d. Remove the enclosure, drill the lower holes, and install two fasteners.
e. Place the enclosure’s upper keyholes over the upper screws, install the lower two screws, and tighten all of
the screws.
2. Connect earth ground to the terminal located within the enclosure (Fig. 1, pg. 4).
3. Connect the three-prong 120vac power cord to the AC input (100-120vac, 50/60Hz).
Note: The green LED on the 2500-PWR24U will illuminate when power is present (Fig. 2, pg. 4).
4. The slide switch S1 should be in the OFF position for 24vdc (Fig. 3, pg. 4). Measure the DC voltage using the
rim potentiometer SVR1 and adjust to 24vdc if necessary (Fig. 4, pg. 4).
5. Select the appropriate knockouts on the enclosure for routing the low voltage devices.
6. Connect each low voltage device (SmartRescue Base Station and 2100 Series Phones) to each output
terminal 1 - 12 (Fig. 5, pg. 4).
Note: The SmartRescue and 2100 Series Phones are NOT polarity sensitive.
Note: 18AWG or larger wire is recommended to connect devices. Keep power-limited circuits separate from
non power-limited wiring (120vac).
7. Move the slide switch S1 to the ON position (Fig. 3, pg. 4).
Note: All LEDs on the output board will illuminate green when power is present (Fig. 6, pg. 4).
8. Recheck the output voltage to conrm that the connected devices have not caused the level to drop. If required,
adjust the output voltage to 24vdc using the trim potentiometer SVR1 (Fig. 4, pg. 4).
9. Once wiring is complete, secure the enclosure door with the supplied screws (Fig. 9, pg. 6).
10. The power cord plug MUST be secured to the receptacle using the included Power Cord Plug Bracket Assembly
(Fig. 10, pg. 6).
Installation

Neutral Hot
2500-PWR24U
Note: A three prong plug is
included with the Power Supply.
120V Supply
Ground
- - - - - -- - -- - -
+
-
NC COM NO
OFF ON
+ + + + + ++ + ++ + +
Relay
POWER FAILURE
NC NO
S1
Ground
1 2 3 4 5 76 8 10911 12
POWER IN
+V -V N L
R13 D13
PTC1
R1 D1
PTC2
R2 D2
PTC3
R3 D3
PTC4
R4 D4
PTC5
R5 D5
PTC6
R6 D6
PTC7
R7 D7
PTC8
R8 D8
PTC9
R9 D9
PTC10
R10 D10
PTC11
R11 D11
PTC12
R12 D12
RATH MICROTECH
SYSTEM
POWER
PTC13
Brown
Blue
Green
Page 4
Note: A three-prong plug is included with the 2500-PWR24U.
Note: The 2500-PWR24U is enabled with DC Fail Supervision using contact closures which indicate loss of DC power.
Example: The contact closures can be connected to an annunciator alarm panel (Fig. 7, pg. 4). The relay is
normally energized when DC power is present. Loss of DC power will trip the annunciator alarm panel.
FIG. 1
FIG. 2
FIG. 3
FIG. 4
FIG. 5
FIG. 6
FIG. 7
120v Supply
Brown
Blue
Green
2500-PWR24U Wiring Diagram

Input:
• 100-120vac, 50/60Hz, 4.0A
Output:
• 24vdc @5A total continuous output
• Filtered and electronically regulated output
• 12 PTC protected outputs @0.500A current limited
• Class 2
• 24vdc adjustable output
• 24vdc S1 on/off switch
• Input and output status LED indicators
Protection:
• Short Circuit/Overload/Over Voltage
Supervision:
• DC power failure supervision (form C contacts)
Environmental:
• For indoor use ONLY
• Operating temperature 32° F to 120° F (0° C to 49° C) ambient
Power Distribution Module:
Page 5
Terminal Identication:
Under normal conditions, the 2500-PWR24U should be checked for proper operation annually. It is recommended to
check the output voltage and verify that 24vdc is present under normal load conditions. It is also recommended to
check the current draw to ensure that the current is within specications.
Conforms to UL STD 2017
Specications
Maintenance
Troubleshooting
Terminal Legend Function/Description
L, G, N Connections for VAC terminals: L to Hot, N to Neutral, Ground to Chassis
+ DC - 24vdc @5A cotinuous power limited output
DC Power Failure Indicates loss of DC power, e.g. connect to annunciator/alarm panel
NC, C, NO Relay normally energized when DC power is present. Contract rating at 1A @ 28vdc.
Earth Ground Stud Used for making connection from enclosure to earth ground
1+ to 12+ Positive DC power outputs
1- to 12- Negative DC power outputs
Problem Possible Cause & Solutions
Green power LEDs are
not illuminated:
• Verify the power switch S1 on the Distribution Board is set to “ON” (Fig. 3, pg. 4).
• Verify the 2500-PWR24U is connected to a good 120vac power source.
Device does not have
power:
• Verify the green LEDs are illumninated on the 2500-PWR24U (Fig. 2 and 6, pg. 4).
• Verify that each output on the 2500-PWR24U is producing 24vdc.

Page 6
2.81”
7.00” 8.78”
10.50”
12.29”
2.81”
FIG. 9
FIG. 9
FIG. 8
Mounting
FIG. 10
2.81”
12.29”
10.5”
2.81”
7” 8.78”
