Ravenheat HE 85 A User guide

Supplied By www.heating spares.co Tel. [phone]
HE 85 A (T)

Supplied By www.heating spares.co Tel. [phone]
3
CONDENSING SYSTEM INNOVATION AUTOMATIC MODULATING BOILER
FOR CENTRAL HEATINGAND DOMESTIC HOT WATER
This new super high efficient turbo-modulating boiler is designed to meet domestic hot water and central heating requirements
at super high efficiency, unheard of only a few years ago.
POSITION
The appliance is extremely versatile as it can be fitted in almost any room. The appliance is room sealed, there is no contact
between combustion chamber and living accommodation. This guarantees maximum safety and efficiency. Indeed, our
depression/combustion front cover has been designed to fit, achieving maximum air tight seal using screw down fasteners at
15 cm. This should not hinder service of the appliance, but does ensure maximum efficiency and safety - something which
Ravenheat take great pride in.
Each boiler has been designed and manufactured in our modern plant to exacting ISO 9001 discipline, all boilers carry full CE
marking of approval. Technical sales and commercial service are available throughout the UK. This product is guaranteed by
Ravenheat Manufacturing, Chartists Way, Morley, LEEDS, LS27 9ET. Telephone No [phone].
BASIC COMPONENTS - (See figure 1)
Guaranteeisafull12monthsfromdateofpurchaseprovidingtheappliancehasbeenfittedinaccordancewiththeseinstructions
and relevant codes of practice.
- Gas valve with flame modulator.
- Variable head pump suitable for any type of central heating system.
- Burner with flame stabiliser designed to operate under all thermal conditions.
- Primary heat exchanger constructed from copper.
- Unique patented condensing heat exchanger for high thermal flue transfer gases to water.
- Stainless steel plate heat exchanger for super high heat transfer to domestic hot water.
- Highly reliable diverter valve with ethylene propylene diaphragm permitting primary flow circulation
in the boiler during domestic hot water supply.
- Built in frost protection.
- Printed circuit board designed to connect to room stat and/or timer/frost stat.Aesthetically pleasing
panels and controls.
- On/Off ball valves for shutting off gas central heating and domestic hot water circuit Safety relief
valve (for safety discharge).
Programmable 7 day module with digital display (optional model).
All front panel controls not often used have been hidden. This achieves simplicity of operation with easy to clean
panels.
NOTE: Due to the high efficiency of this boiler a plume of water vapour will form at the flue
terminal during operation.
COSHH - CONTROL OF SUBSTANCES HARMFUL TO HEALTH
IMPORTANT
This appliance contains materials that are indicated below.
It is the Users/Installers responsibility to ensure that the necessary personal protective clothing is-worn when han-
dling, where applicable, the pertinent parts that contain any materials that cót3ld be interpreted as being injurious to
health and safety.
WARNING When installing the appliance, care should be taken to avoid any possibility of injury when handling sheet
metal parts.
GENERAL INFORMATION:
GLUES AND SEALANTS - exercise caution - if these are still in liquid form.
INSULATION PADS, CERAMIC FIBRE - may be harmful if inhaled, may be irritating to skin, eyes, nose and throat.
When handling keep dust generation to a minimum, avoid inhaling and contact with skin or eyes.
When disposing of the product keep dust generation to a minimum and ensure that parts are securely wrapped.
When servicing avoid inhalation by using a vacuum cleaner or in conjunction with other tools. After handling wash
hands and other exposed parts.
RAVENHEAT use only high quality material for production of this product, in an effort to protect the environment
components should be re-cycled.
MAJOR COMPONENTS

Supplied By www.heating spares.co Tel. [phone]
TABLE OF CONTENTS
SECTIONS
1
2
3
4
5
6
7
8
9
10
11
INTRODUCTION
DESIGN PRINCIPLES AND
OPERATING SEQUENCE
TECNICAL DATA
GENERAL REQUIREMENTS
INSTALLATION
COMMISSIONING
SERVICING INSTRUCTIONS
FAULT FINDING
ELECTRICAL SYSTEM DIAGRAM
EXPLODED PARTS DIAGRAM
LIST OF SPARE PARTS
PAGE
6
6
8-9
6
15
26
30
39
40
45
46
4
KEY
1 - Heat exchanger
2 - Heat exchanger for D.H.W water
3 - Burner
4 - Sensing electrode
6 - Condensing heat exchanger
9 - Ignition electrode
11 - Frame
12 - Modulating gas valve
15 - Heating control
22 - Overheat cut off thermostat
16-Hotwatercontrol
17-D.H.W. sensor
18-Waterpressureswitch(heatingcircuit)
23-Safetyreliefsystem
24-Three way valve
26-Autoairventvalve
28-Pressureswitch
29-Circulationpump
30-Waterpressuregauge
33 - Main switch
34 - C.H. sensor
35 - Condensing trap
36 - Fan
37 - Expansion tank
38 - Sealed chamber
45 - Combustion chamber
50 - Flue gas exhaust hood
105 - Timer
106 - Flue restriction ring

Supplied By www.heating spares.co Tel. [phone]
KEY
1 - Heat exchanger
2 - Heat exchanger for D.H.W water
3 - Burner
4 - Sensing electrode
5 - Flue restriction ring
6 - Condensing heat exchanger
8 - Condensing trap
9 - Ignition electrode
10 - Condensate sensor
12-Modulatinggasvalve
15-Heatingcontrolpotentiometer
16-Hotwatercontrolpotentiometer
17-Waterpressureswitch
18-Overheatcut-off thermostat
20-Gasservicecock
21-Compressionballvalves
23-Safetyreliefsystem
24-Three way valve
25-Flowregulator
26 -Auto air vent valve
27 - Pressure switch giving priority
28 - Pressure switch
29 - Circulating pump
30 - Water pressure gauge
36 - Fan
37 - Expansion tank
38 - Sealed chamber
5

Supplied By www.heating spares.co Tel. [phone]
SECTION 1 INTRODUCTION
1.1 The Ravenheat boiler is for the use of central
anddomestichotwatercombined in one unit.
It is fitted with an automatic domestic hot
water priority valve.
A / (winter/summer) selector
switch is fitted to the left hand side of control
panel.With the only (summer) position
being for domestic hot water.
position being for central heating
with domestic hot water priority. The boiler
is equipped with a front cover which can be
removed for servicing. The data badge with
technical data is placed on the lower right
hand side of the frame.
1.2 Fig.1 Illustrates the general layout of
components.
Fig.2 Illustrates the operating princi-
ples described in section 2.
SECTION 2
2.1 DESCRIPTION OF CONTROL SYSTEM
AND SEQUENCE OF OPERATION
2.2 Domestic hot water mode
When the appliance is in rest mode with
the mains neon and switch on.
Switch the summer/winter switch tap
position, with the heating circuit charged
with water (above 1 bar). If the domestic
hot water tap is turned on, the boiler will
function in the following sequence:
2.2.1 The pump starts.
The control board sensors.
The fan operates via the pressure switch and
sends a signal back to the ignition board that the
fan is running at maximum speed.
2.2.2 The spark ignition system is powered which in
turn commences the spark igniter to operate
and light the burner.
At this point the ignition board opens the gas
valve to light the burner.
2.2.3 When the electrode/sensor senses the signal
of the burner, the spark igniter stops.
2.2.4 From the minimum gas rate setting the
boiler increases to the maximum permissible
pressure over a period of 3 to 4 seconds and
will remain at its maximum required power
until its maximum regulated temperature.
2.2.5 When the domestic hot water tap is closed the
diverter valve goes back into rest mode, the
main burner is shut down along with the pump
and fan which are also switched off.
The pressure switch returns to its rest mode
2.2.6 Central heating mode
2.2.7 If the switch is positioned on with
a demand for heat to supply radiators,
6
etc ,with heating circuit fully so as to operate
thelowwatersensordevicetheboilerwillstart
in the same way as domestic hot water mode
but with slightly differing time delay in that it
will start on minimum and remain at this level
for about 1 minute, after which the flame will
lift to its maximum setting as governed by a
potentiometer range rates the heating circuit
between maximum and minimum power. As
the heating sensor reaches temperature the
gas burner power modulates down, the fan
speed willalsoreducetominimumfanspeed.
When starting, the fan will always start at
maximum speed.
2.2.8 On the control panel are mounted two
potentiometers (thermostats) these control
the temperature. One is for domestic hot
water and the other for heating.
2.2.9 The boiler is fitted with an anti-cycling device
on the control board. This delays the boiler
from re-firing over a 2/5 minute period when
in heating mode. The domestic hot water will
always take priority and is unaffected by the
anti-cycling device.
GENERAL FUNCTION
2.3 Central Heating Mode
2.3.1 A potentiometer installed on the electric circuit
board permits regulation of the boiler to partial
heating requirements, between maximum and
minimum settings.
2.3.2 Air is drawn by the fan for combustion.
2.3.3 Thefanalsoforcesexhaustgasthroughtheflue
to the outside, this creates a lesser pressure in
the sealed combustion chamber, thus sucking
in combustion air, through the inlet duct.
2.3.4 The boiler water temperature is automatically
controlled by a built in thermostat
2.3.5 Interior space temperature is set by the room
thermostat to be installed in the heating
system. The boiler already carries connection
terminals for this thermostat, as well as for a
timeclock.
The burner continues to operate until it is
stopped by the timer or one of the thermostats
2.3.6 When the internal C.H. temperature sensor
intervenes the main burner shuts down. The
fan stops but the pump continues to operate.
2.3.7 When the room thermostats intervene the
main burner shuts down. The fan stops and
the pump turns off.
2.3.8 The condensate trap is fitted with a blockage
safety sensor. This prevents the boiler
operating should there be a blockage in the
condensate discharge trap.

Supplied By www.heating spares.co Tel. [phone]
7
2.4 Domestic hot water mode
2.4.1 The heat exchanger in the D.H.W. circuit
is built into the main heat exchanger, and
domestic water is heated by converting
the water in the central heating circuit The
transference of heat is very high because the
two fluids move in a counter direction flow to
each other.
2.4.2 Switch 33 in the (winter) position.
Whenahotwatertapisturnedonadiaphragm
diverter valve excludes the central heating
circuit, the boiler automatically modulates to
maintain the domestic hot water at a constant
temperature.
Water temperature can be regulated using
the D.H.W. thermostat located on the front
control panel.
2.4.3 When domestic hot water is being drawn the
main burner and pump perform as they do
during central heating except that the burner
is commanded by the D.H.W. thermostat.
2.4.4 When D.H.W. is no longer called for the boiler
automatically returns to the central heating
mode.
2.4.5 Switch 33 in the (summer) position The
boilerfunctionslikeanautomaticgashotwater
heater When D.H.W. is no longer required the
main burner fan and pump immediately turn
off.
This also takes place when switch 33 is on
(winter) if there is no demand for
heat to the central heating system or until
the room thermostat/time clock demands for
central heating circuit.
3.1 SAFETY DEVICE
In both central heating and domestic hot
water mode safe operating is ensured by:
A differential pressure switch shuts off the
main burner if the fan stops or the flue or
combustion air intake duct is obstructed
3.1.2 An overheat cut off thermostat set slightly
higher than the high limit thermostat acts
to turn of the burner to resetable “lockout”
(Fig. 50) item 3.
3.1.3 A safety valve is fitted on the
central heating circuit set at
43 psi (3 bar).
3.2.1 A heating circuit (low water)
pressure switch is set at 0.4
bar.

Supplied By www.heating spares.co Tel. [phone]
NOMINAL HEAT INPUT NET QMS 22.6 kW
MINIMUM HEAT INPUT NET 11.6 kW
NOMINAL HEAT OUTPUT 22.3 kW
NOMINAL HEAT OUTPUT CONDENSING 23.9 kW
MINIMUM HEAT OUTPUT 11.4 kW
MINIMUM HEAT OUTPUT CONDENSING 12.3 kW
GAS RATE max 2.3 m3/h
AFTER 10 MINUTES min 1.2 m3/h
INLET PRESSURE 20 mbar
BURNER PRESSURE C.H. max 10.5 mbar
min 2.0 mbar
MAIN BURNER INJECTORS Nr. 13 x 1.25
ELECTRICAL SUPPLY 230 V ~ 50 HZ
POWER CONSUMPTION 150 W
EXTERNAL FUSE RATING 3A
INTERNAL FUSE 2 A (20 mm to BS 4265)
DRY WEIGHT 51 kg
WATER CONTENT C.H. 2.1 litre
WATER CONTENT 0.5 litre
GAS SUPPLY CONNECTION 15 mm compression isolating valve
FLOW CONNECTION C.H. 22 mm compression isolating valve
RETURN CONNECTION C.H. 22 mm compression isolating valve
INLET CONNECTION D.H.W. 15 mm compression isolating valve
OUTLET CONNECTION D.H.W. 15 mm copper pipe
SAFETY DISCHARGE C.H. 15 mm copper pipe
CONDENSATION DRAIN 3/4” (21.5 mm) push fit over flow
MAX COLD WATER CAPACITY WITHOUT ADDITIONAL EXPANSION VESSEL 110 LITRE
SEALED WATER SYSTEM C.H.
MAX PRESSURE PHS 2.5 bar
MINIMUM WORKING PRESSURE 0.5 bar
7 LITRES EXPANSION VESSEL PRE-CHARGE-PRESSURE 0.5 bar
CENTRAL HEATING OPERATING TEMPERATURE MAX 85°C MIN 45°C
DESIGN FLOW RATE 1102 I/h 20 °C RISE
MINIMUM FLOW RATE C.H. 503 I/min
D.H.W. FLOW RATE 30 °C rise 12.3 l/min
D.H.W. FLOW RATE 35 °C rise 10.5 l/min
D.H.W. FLOW RATE 40 °C rise 9.2 l/min
D.H.W. TEMPERATURE max 65 °C min 35 °C
BURNER PRESSURE D.H.W. max 11.2 mbar min 2.0 mbar
Qmw Input Net max 26 kW min 11.6 kW
D.H.W. PRESSURE max 10 bar (147 p.s.i.)
D.H.W. PRESSURE PMW min 0.8 bar (118 p.s.i.) To obtain heat input 1.2 bar
D.H.W. MINIMUM FLOW RATE 3 I/min
FLUE OUTLET NOM. DIAMETER 100 mm specially supplied with boilers
DESTINATION: AT, DK, Fl, SE, CATEGORY I2H
DESTINATION: GB, IE, CH, ES, IT, PT CATEGORY II2H3+
FLUE TYPE - C12 - C32 - C52 NOX 4
SECTION 3 TECHNICAL DATA HE 85 A (T)
TABLE 1 NATURAL GAS (G 20) І2H - П2H3+
8

Supplied By www.heating spares.co Tel. [phone]
SECTION 3 TECHNICAL DATA HE 85 A (T)
TABLE 1/A LPG (G 30 - G 31) І3+ - П2H3+
NOMINAL HEAT INPUT NET QMS 22.6 kW
MINIMUM HEAT INPUT NET 11.6 kW
9
NOMINAL HEAT OUTPUT 22.3 kW
NOMINAL HEAT OUTPUT CONDENSING 23.9 kW
MINIMUM HEAT OUTPUT 11.4 kW
MINIMUM HEAT OUTPUT CONDENSING 12.3 kW
GAS RATE max G31 0.9 m3/h G30 0.7 m3/h
AFTER 10 MINUTES min 0.4 m3/h 0.3 m3/h
INLET PRESSURE G31 37mbar G30 28-30 mbar
BURNER PRESSURE C.H. max G31 35.4mbar G30 27.3 mbar
min 7.3 mbar 7.0 mbar
MAIN BURNER INJECTORS Nr 13 x 0.75
ELECTRICAL SUPPLY 230 V ~ 50 HZ
POWER CONSUMPTION 150 W
EXTERNAL FUSE RATING 3A
INTERNAL FUSE 2 A (20 mm to BS 4265)
DRY WEIGHT 51 kg
WATER CONTENT C.H. 2.1 litre
WATER CONTENT 0.5 litre
GAS SUPPLY CONNECTION 15 mm compression isolating valve
FLOW CONNECTION C.H. 22 mm compression isolating valve
RETURN CONNECTION C.H. 22 mm compression isolating valve
INLET CONNECTION D.H.W. 15 mm compression isolating valve
OUTLET CONNECTION D.H.W. 15 mm compression
SAFETY DISCHARGE C.H. 15 mm copper pipe
CONDENSATION DRAIN 3/4” (21.5 mm) push fit over flow
MAX COLD WATER CAPACITY WITHOUT ADDITIONAL EXPANSION VESSEL 110 LITRE
SEALED WATER SYSTEM C.H.
MAX PRESSURE PHS 2.5 bar
MINIMUM WORKING PRESSURE 0.5 bar
6 LITRES EXPANSION VESSEL PRE-CHARGE-PRESSURE 0.5 bar
CENTRAL HEATING OPERATING TEMPERATURE MAX 85°C MIN 35°C
DESIGN FLOW RATE 1102 I/h 20 °C RISE
MINIMUM FLOW RATE C.H. 503 I/min
D.H.W. FLOW RATE 30 °C rise 12.3 l/min
D.H.W. FLOW RATE 35 °C rise 10.5 l/min
D.H.W. FLOW RATE 40 °C rise 9.2 l/min 10°C inlet temperature
D.H.W. TEMPERATURE max 65 °C min 35 °C
BURNER PRESSURE D.H.W. MAX G31 35.4 - G30 27.3 mbar
MIN G31 7.3 - G30 7.0 mbar
Qmw Imput Net MAX 22.6 Kw - MIN 11.6 Kw
D.H.W. PRESSURE max 10 bar (147 p.s.i.)
D.H.W. PRESSURE PMW min 0.8 bar (11.8 p.s.i.) To obtain heat input 1.2 bar
D.H.W. MINIMUM FLOW RATE 3 I/min
FLUE OUTLET NOM. DIAMETER 100 mm specially supplied with boilers
DESTINATION: BE, FR CATEGORY I2H+
DESTINATION: GB, IE, CH, ES, IT, PT CATEGORY II2H3+
FLUE TYPE - C12 - C32 - C52 NOX 4

Supplied By www.heating spares.co Tel. [phone]
10
The manufacturer’s notes must NOT be
taken, in any way, as overriding statutory
obligations.
IMPORTANT:
These appliances are CE certificated for
safety and performance. It is, therefore,
important that no external control devices e.g.
flue dampers, economisers etc., are directly
connected to this appliance unless covered by
these Installation and Service Instructions or
as otherwise recommended by Ravenheat in
writing. If in doubt please enquire.
Any direct connection of a control device
not approved by Ravenheat could invalidate
the certification and the normal appliance
warranty.
Itcouldalsoinfringe the Gas Safetyregulations
and the above regulations.
NOTE:
The Ravenheat HE 85 combination boiler
has been tested and examined by BG, and is
certified to comply with PrEN 483 and BS EN
625.
Manufactures instructions must NOT be taken
in any way as overriding statutory obligations.
If in doubt on any point please consult
Ravenheat Manufacturing Ltd.
4.2 LOCATION OF BOILER
4.2.1 Siting of Ravenheat HE 85 Combi Boiler must
be as follows.
The position of installation should be within
the building, unless otherwise protected by a
suitable enclosure.
Adequate space for installation, servicing and
air circulation around boiler must be allowed
for.
The Ravenheat HE 85 Combi Boiler must be
fitted on a flat and vertical wall capable of
adequately supporting the weight of the boiler
and any ancillary equipment.
Theappliancemaybeinstalledonacombustible
wall subject to the requirements of the Local
Authority and Building Regulations.
LPG versions of this appliance shall not be
installed in cellars or basements.
4.3 CLEARANCES AROUND THE APPLIANCE
4.3.1 The following minimum free spaces, required
for installation inspection and servicing, must
be left around the boiler
18 inches (450 mm) in front
5 inches (125 mm) above
6 inches (150 mm) below
0.2 inches (5 mm) on each side
1 inch (25 mm) in front when installed in a
cupboard.
SECTION 4 GENERAL REQUIREMENTS
4.0.1 SAFETY
Gas Safety (Installation and Use)
Regulations, 1994 and amended 2000.
It is law that all gas appliances are installed
and serviced by a CORGI registered installer
in accordance with the above regulations
and these installation instructions. All CORGI
registered installers carry a CORGI I.D. card
and have a registration number. Both should
be recorded in your boiler log book. You can
check your installer by calling CORGI direct
on:01256732300. Failuretoinstallappliances
correctly could lead to prosecution. It is in
your own interest, and that of safety, to ensure
the law is complied with. Check the boiler
and flue is the correct type for installation.
The installation of the boiler MUST be
in accordance with the latest I.E.E. (BS
7671) Wiring Regulations, local building
regulations, bye-laws of the local water
authority, the building regulations and the
Building Standards (Scotland) and any
relevant requirements of the local authority.
4.1 GENERAL INFORMATION
Both the user and the manufacturer rely
heavily on the installer, whose job it is to
install the combination boiler and connect
it to a correctly designed heating system.
Acquaint yourself with the British Standards
concerning installation requirements. If you
need advice on any points your Ravenheat
Technical Services Office would be pleased to
help. It is recommended that tools suitable for
brass fittings are used, and have a capability
to accomodate hexagon sizes up to 50 mms.
CODES OF PRACTICE/Ref: Documents
Detailedrecommendationsarecontainedinthe
following British Standard Codes of Practice:
BS.6891 Low pressure installation pipes.
BS.6798 Installation of gas fired hot water
boilers of rated input not exceeding
60 kW.
BS.5449 Forcedcirculationhotwatersystems.
BS.5546 Installation of gas hot water supplies
domestic purposes (2ndFamily
Gases).
BS.5440:1 Flues (for gas appliances of rated
input not exceeding 60 kW).
BS.5440:2 Ventilation (for gas appliances of
rated input not exceeding 60 kW).
DD 189: 1990 Discharge of condensate.
Health & Safety Document No.635
The Electricity at Work Regulations, 1989.

Supplied By www.heating spares.co Tel. [phone]
11
4.4 IMPORTANT NOTICE
4.4.1 If the combination boiler is to be fitted in a
timber framed building it should be fitted in
accordance with the British Gas Publication
Guide for Gas Installations in Timber Frame
Housing Reference DM2 If in doubt advice
must be sought from the local gas supplier The
combination boiler may be installed in any room
or internal space, although particular attention
is drawn to the requirements of the current
I.E.E. Wiring Regulations, and in Scotland the
electrical provisions of the Building Regulations
applicable in Scotland, with respect to the
installation of the combination boiler in a room
or internal space containing a bath or shower.
Where a room sealed appliance is installed
in a room containing a bath or shower, any
electrical switch or appliance control, utilising
mains electricity should be so situated that it
cannot be touched by a person using a bath or
shower.
Acompartmentusedtoenclosethecombination
boiler MUST be designed and constructed
specifically for this purpose. An existing
cupboard, or compartment, may be used
provided it is modified accordingly Samples
of the CSI combination boiler have been
examined by B.G. Technology Notified Body,
and is certified to comply with the essential
requirements of the Gas Appliance
Directive 90/396/EEC, the Low Voltage
Directive 72/23/EEC and shows compliance
with the Electro Magnetic Compatibility
Directive 89/336/EEC and are therefore
permitted to carry the CE Mark.
The appliance has been tested and approved
by the WRc as meeting the requirements of
G3 and L of the Building regulations and water
Bylaws Scheme - Approved Products.
4.5 GAS SUPPLY
4.5.1 A gas meter is connected to the service pipe
by the Local Gas Region or the Local Gas
Region contractor. An existing meter should
be checked preferably by the Gas Region to
ensure that the meter is adequate to deal with
the rate of gas supply required for all appliances
it serves. Installation pipes should be fitted in
accordance with BS 6891. Pipework from the
meter to the boiler must be of adequate size
(22 mm) min To within at least 3 metre of
the boiler (15 mm) min. can then be used for
remaining pipe work to the appliance. A smaller
size than the boiler inlet gas connection should
not be used The complete installation must be
tested for soundness as described in the above
Code
N.B. if the gas supply for the boiler serves
other appliances ensure an adequate
supply is available both to the boiler and the
other appliances when they are in use at the
same time.
4.6 FLUE SYSTEM
4.6.1 The terminal should be located where dispersal
of combustion products is not impeded and with
due regard for the damage or discolouration
that might occur to building products in the
vicinity (see fig. 6).
The terminal must not be located in a place
where it is likely to cause a nuisance In cold
and/or humid weather water vapour may
condense on leaving the flue terminal.
The effect of such steaming must be
considered
The terminal must not be closer than 25 mm (1
in) to any combustible material For protection
of combustibles, refer to BS 5440.1.
Where a flue terminal is installed less than
1000 mm. from a plastic, or painted gutter;
or 500 mm from painted eaves, an aluminium
shield 1000 mm. long, should be fitted to the
underside of the gutter or painted surface.
Pluming will occur at the terminal so, where
possible, terminal positions which could cause
a nuisance should be avoided.
The flue must be installed in accordance with
the recommendations of BS 5440: Part 1.
IMPORTANT NOTES
For greater flue lengths see twin flue instruc-
tions.
Flue must be positioned in a place not likely
to cause a nuisance.
IMPORTANT: The following notes are intended for
general guidance
The boiler MUST be installed so that the terminal
is exposed to external air.
It is important that the position of the terminal al-
lows the free passage of air across it at all tirnes.
Minimum acceptable spacing from the terminal to
obstructions and ventnation opening are specified
in Fig. 6.
Note positions: Due to the terminal design,
installation is possible with clearances less than
those specified in BS 5440, Part 1

Supplied By www.heating spares.co Tel. [phone]
12
Terminal position for fan assisted boiler
(minimum distance) mm
A - Directly below an open window or other 300
opening (e.g. air brick)
B - Below gutters, soil pipes or drain pipes 25
C - Below eaves 25
D - Below balconies or car port roof 25
E - From vertical drain pipes and soil pipes 25
F - From internal or external corners 25
G - Above ground or below balcony level 300
H - From a surface facing a terminal 600
I - From a terminal facing a terminal 1200
J - From an opening in the car port
(e.g. door window) into dwelling. 1200
K - Vertically from a terminal on the same wall 1500
L - Horizontally from a terminal on the same wall 300
NOTE: The flue must be terminated in a place not
likely to cause a nuisance.
4.6.2 A concentric vertical flue kit is available for
flueing applications up to a maximum height of
4 metres.
For further details see vertical flue installation
instructions.
4.7 AIR SUPPLY
4.7.1 The following notes are intended for general
guidance.
The room sealed fan flued boiler does not
require a permanent air vent for combustion
air supply.
Where installed in a cupboard or compartment
ventilation is not required.
4.8 WATER CIRCULATION (central heating)
4.8.1 Detailed recommendations are given in
BS 6798:1987/5449:1990 (for smallbore
and microbore central heating systems).
The following notes are given for general
guidance.
4.8.2 Pipework
Copper tubing to BS 2871 1.1.1971 is
recommended for water pipes. Jointing should
be either with capillary soldered or with
compression fittings.
Where possible pipes should have a gradient
to ensure air is carried naturally to air release
points and water flows naturally to drain taps.
It should be ensured as far as possible that
the appliance heat exchanger is not a natural
collecting point for air except where providing
useful heat, pipes should be insulated to
prevent heat loss and to avoid freezing.
Particular attention should be paid to pipes
passing through ventilated spaces in roofs and
under floors.
4.8.3 The water through the appliance heat
exchanger circuit must exceed the min. 2.38
gals/min. (650 It/h) when the burner is firing. It
is important to ensure that this rate is achieved
when sections of the system are shut off either
manually or by automatic controls.
Therefore a by-pass must be fitted to the
system (15 mm min.) (Fig. 6A).
If the volume of circulating water is too low, the
boiler water temperature will rise too rapidly.
This could cause noise in the system or even
cause the safety thermostat to trip.

Supplied By www.heating spares.co Tel. [phone]
13
4.8.4 Draining tap
These must be located in accessible positions
to permit the draining of the whole system.
The taps must be at least 15 mm nominal size
and manufactured in accordance with BS 2870
1980.
4.8.5 Air release points
These must be fitted at all high points where
air will naturally collect, and must be sited to
facilitate complete filling of the system.
4.8.6 Theappliancehasanintegralsealedexpansion
vessel to accommodate the increase of water
volume when the system is heated.
It can accept up to 6 Its of expansion water.
If the appliance is connected to a system with
an unusually high water content, calculate
the total expansion and add additional sealed
expansion capacity as appropriate (Fig. 7).
In general, modern systems will present no
problem.
4.8.7 Mains water feed: central heating
There must be no direct connection to the
mains water supply, even through a nonreturn
valve, without the approval of the Local Water
Authority.
Figure 1 depicts the requirements of Diagram R24.2a
of the Water Supply (Water Fittings) regulations 1999.

Supplied By www.heating spares.co Tel. [phone]
14
B) Where fitting of a make up vessel would be
difficult, re pressurisation of the system can be
done. See section on FILLING. If the capacity
of the central heating system should exceed
110 Litres, an additional vessel should be
installed on the return to the combination boiler
from the heating system (Fig. 7). Guidance on
vessel sizing is given in (Table 3).
Reference should be made to British Gas
Publications, «Material and Installation
Specifications for Domestic Central Heating
and Hot Water». Draining taps should be
at least 1/2” in BSP nominal size and be in
accordance with BS 2879.
4.8.9 Installation to an existing central heating
system
The combination boiler is designed to operate
on a sealed system only. Therefore if the
existing system is of the open water type it will
have to be modified to comply with BS 5376
Part 2.
Before installing a new combination boiler to
an existing system, flush out the old system
with a recommended descaling agent.
Itismostimportantthatthecorrectconcentration
of the water treatment product is maintained
in accordance with the manufacturers’
instructions.
If the boiler is installed in an existing system
any unsuitable additives MUST be removed by
thorough cleansing.
BS 7593:1992 details the steps necessary
to clean domestic central heating system.
Also check pipework and renew any corroded
pipework or fittings. Valve glands must be
repacked or replaced wherever necessary and
any defective controls exchanged.
WATER TREATMENT
This boiler has a secondary ALUMINIUM alloy
heat exchanger Ravenheat recommended only
the use of FERNOX- COPAL or SENTINEL
X100 water treatment products, which must
be used in accordance with the manufacturers
instructions. For further information contact:
Fernox Manufacturing Co. Ltd.
Tel [phone]
Sentinel Division Betz Dearborn Ltd.
Tel. [phone]
Safety
valve setting (bar) 3.0
Vessel charge
pressure (bar) 0.5 1.0 1.5
Initial system
pressure (bar) 0.5 1.0 1.5 2.0 1.0 1.5 2.0 1.5 2.0
Total water
content of system EXPANSION VESSEL VOLUME (LITRES)
Litres
25
50
75
100
125
150
175
200
225
250
275
300
325
350
375
400
425
450
475
500
2.1
4.2
6.3
8.3
10.4
12.5
14.6
16.7
18.7
20.8
22.9
25.0
27.0
29.1
31 .2
33.3
35.4
37.5
39.6
41.6
3.5
7.0
10.5
14.0
17.5
21.0
24.5
28.0
31.5
35.0
38.5
42.0
45.5
49.0
52.5
56.0
59.5
63.0
66.5
70.0
6.5
12.9
19.4
25.9
32.4
38.8
45.3
51.8
58.3
64.7
71 .2
77.7
84.1
90.6
97.1
103.6
110.1
116.5
123.0
125.9
13.7
27.5
41.3
55.1
68.9
82.6
96.4
110.2
124.0
137.7
151.5
165.3
179.1
192.8
206.6
220.4
239.2
247.9
261.7
275.5
2.7
5.4
8.2
10.9
13.6
16.3
19.1
21.8
24.5
27.2
30.0
32.7
35.7
38.1
40.9
43.6
46.3
49.0
51.8
54.5
4.7
9.5
14.2
19.0
23.7
28.5
33.2
38.0
42.7
47.5
52..2
57.0
61.7
66.5
71 .2
76.0
80.7
85.5
90.2
95.0
10.3
20.6
30.9
41.2
51.5
61.8
72.1
82.4
92.7
103.0
113.3
123.6
133.9
144.2
154.5
164.8
175.1
185.4
195.7
206.0
3.9
7.8
11.7
15.6
19.5
23.4
27.3
31.2
35.1
39.0
42.9
46.8
50.7
54.6
58.5
62.4
66.3
70.2
74.1
78.0
8.3
16.5
24.8
33.1
41.3
49.6
57.9
66.2
74.5
82.7
91.0
99.3
107.6
115.8
124.1
132.4
140.7
148.9
157.2
165.5
For system volumes
other than those given
above, multiply the
system volume by
the factor across
0.0833 0.140 0.259 0.551 0.109 0.190 0.412 0.156 0.331
SIZING OF ADDITIONAL EXPANSION VESSEL: TABLE 3
Deduct from the value given in the table the 7 litre vessel supplied.
Note: This pressure can be increased up to 1.5 bar to suit high static head situations, see item 10, other appliance components in the
SERVICING INSTRUCTIONS.

Supplied By www.heating spares.co Tel. [phone]
15
SALAMANDER CURROSION GUARD
Salamander (Eng) Ltd
Tel: [phone]
4.8.10 Hard water areas
If the area of installation is recognized as hard
water, it is recommended that a suitable water
treatment device is installed in the mains.
The water hardness can be determined by using
the standard test paper or by referring to local
water authority.
4.9 DOMESTIC WATER
4.9.1 The domestic hot water must be in accordance
with the relevant recommendations of BS 5546.
Copper tubing to BS 2871 1 is recommended
for water carrying pipework and MUST be used
for pipework carrying potable water.
4.10 ELECTRICAL SUPPLY
Warning: this appliance must be earthed
4.10.1 External wiring to the appliance must be carried
outbyacompetentpersonandbe in accordance
with the current I.E.E. Regulations and local
regulationswhichapply.The Ravenheat boiler is
suppliedforconnectiontoa230V~50Hzsingle
phasesupply.Thesupplymust befused at3A.
NOTE. The method of connection to the
electricity supply MUST facilitate complete
electrical isolation of the appliance, by the
use of a fused, double pole isolator, having a
contact separation of at least 3 mm in all poles.
The point of connection to the electricity supply
must be readily accessible and adjacent to
the appliance except, where the appliance is
installed in a bathroom, this MUST be sited
outside the bathroom.
SECTION 5 INSTALLATION
5.1 WARNING
5.1.1 It is MOST IMPORTANT that this appliance is
installed in a VERTICAL POSITION, with the
flue air duct passing through the wall.
Make sure flue slopes 2.5° down towards the
boiler that is 45 mm/m fall per metre of flue
length.

Supplied By www.heating spares.co Tel. [phone]
16
5.2 DELIVERY
5.2.1 The appliance carton containing (Fig 10)
a) boiler fully assembled
b) installation instructions and
user instructions
c) white paper template
Polythene bag containing
a) 2-22 mm flanged copper tails complete
with 3/4” brass nuts and washers
b) 1-15 mm compression ball valve
(with drain screw for domestic cold water inlet)
c) 1-1/2” BSP Union Gas Cock
d) - 2.15 mm flanged copper tails complete
with 1/2” brass nuts and washers
- 2.22 mm flanged copper tails complete
with 1/2” brass nuts and washers
e) - 4 coach bolts and wall plugs
- screws and dowels
Separate Box containing (Fig 12)
Horizontal HE flue kit
56 - Flue gas assembly
57 - Flue bend assembly
59 - Rubber seal Ø 60
60 - Air intake duct
61 - Flue exhaust duct
62 - Terminal
65 - Pipe centering spring
66 - Flue gas sample point
127 - Terminal Rubber
OPTIONAL EXTRAS:
Small carton containing: (Fig 13)
57 - Straight header supplied as an extra cost only when
requested
59 - Rubber seal Ø 60
66 - Flue gas sample point
FLUE EXTENSION BOX CONTAINING (Fig. 14)
1000 mm flue extension duct as an extra cost only when
requested for side and vertical flue applications
59 - Rubber seal Ø 60
63 - Air intake duct extension
64 - Flue exhaust duct extension
65 - Pipe centering spring
WARNING
Maximum allowable flue length 2.5 m
maximum No 2x1000 mm
Flue duct extension used with standard flue

Supplied By www.heating spares.co Tel. [phone]
17

Supplied By www.heating spares.co Tel. [phone]
18
5.4 POSITIONING OF THE BOILER
5.4.1 - Remove the 2 screws that secure the upper
part of the front panel of the casing (Fig 19).
- Carefullyslidethefrontpanelafewmillimetres
up towards the top of the appliance until it is
free from its slot, and then lift off (Fig. 20).
5.4.2 Unscrew the 2 screws that fasten the lower
grating on the casing and remove it from the
sides of the casing (Fig. 22)
5.4.3 Push down the 2 plastic clips that fasten the
instrument panel (Fig. 23).
5.4.4 Lower the instrument panel down by rotating it
on its own hinges (Fig. 25)
Unscrew the two screws fastening panels (Fig.
21).
5.4.5 Remove the two sides of the casing by slightly
lifting them and carefully sliding towards the
top of the appliance, to release them from their
upper suspension hooks (Fig. 26-27)
5.4.6 Make sure the casing and screws are put to
one side in a safe place.
5.5 INSTALLING THE APPLIANCE FOR REAR
FLUE OUTLET
5.5.1 Use adhesive tape to attach the template to
the wall, making sure that the centre line is
vertical.
- Mark the four boiler fastening holes on the
wall as well as the centre of the flue duct
- Detach the template from the wall.
- Use a 10 mm. dia drill to make the 4 boiler
securing holes. Insert the plastic expansion
plugs.
- Cut or core drill a 105 mm. dia hole for
inserting the flue duct
- Screw in the two upper coach bolts leaving
them about 10 mm. out from the wall to
enable the boiler to be located on the wall
Fit the elbow header positioning it towards the
required direction (Fig 30).
IMPORTANT: Make sure that the elbow’s dia.
60 mm duct is inserted into the fan, the rubber
seal and orifice (F2) have been correctly
fitted.

Supplied By www.heating spares.co Tel. [phone]
Fig 32
19
5.5.2 Locate the rubber Ø 60 into the flue elbow
header (Fig 30).
5.5.3 If the standard duct furnished with the boiler is
too long (the wall to go through is less than
680 mm thick) it can be shortened as follows:
- Remove the centering spring 65, the flue
terminal to disengage inner flue duct
- Measure the thickness W of the wall.
- Cut the outer flue duct at right angles to a
length equal to W + 152 mm
Must be de-burred.
- Cut the inner flue duct (60 mm) at right angles
to a length equal to W + 264 mm
Insert from cut end Reassemble the two tubes
Insert centering spring 65 Must be de-burred
- Reassemble together inner and outer flue duct
insert centering spring
KEY
56 - Straight header
57 - Elbow header
58 - Header gasket
59 - Rubber seal Ø 60
60 - STD air intake duct
61 - STD flue exhaust duct
62 - Terminal
63 - Air intake duct extension
64 - Flue exhaust duct extension
65 - Pipe centering spring
66 - Sample point
127 - Terminal Rubber

Supplied By www.heating spares.co Tel. [phone]
20
5.5.4 Insert the flue assembly into the wall, being
careful to make sure that the outer air duct
comes flush to the inner surface of the wall.
5.5.5 Lift the boiler on to the wall (Fig 34), locating
onto the top coach bolts Fit the two lower
coach bolts and tighten all four securing bolts.
5.5.6 Working above the boiler pull the flue exhaust
duct towards the boiler in order to engage tube
61 into its header 57A.
Position flue into elbow header and push so as
to locate inner and outer flue correctly ensuring
good seal is made with o rings.
5.5.8 Fit terminal cover plate and terminal guard
(Fig. 36-37))
5.5.9 Extensions kits are available on order for flue
extension of up to2.5 metres total length
(Fig. 31).

Supplied By www.heating spares.co Tel. [phone]
CSI 85
F = 200 mm
G = 275 mm
21
5.5.10 Each extension length extends the pipe by
approximately 1000 mm long up to a maximum
of two extensions
Pipeline length can be established using the
instructions in section 5.5 for rear flue outlets
and section 5.7 for side flue outlets. Extensions
must be installed with the widened end of the
air intake pipe and the tapered end of the
flue pipe aimed towards the exhaust terminal.
Extensions must be joined together with the
standard terminal pipe, and inserted in each
other as far as they can go
If an extension must be shortened, this must
be done from the straight end, and not from the
widenedortaperedend.Tomeasurethepipeline
properly all components must be assembled
and total length measured before cutting. The
straight end of the extension connects to the
boiler. The flue output pipe fits into the boiler
header until it stops. The air intake pipe should
be located approximately 2 mm. from the boiler
header (Fig. 31).
When cutting both inner and outer ducts of the
extension, always ensure that the reduced end
(male) of the inner duct is longer than the outer
duct.
All joints must be sealed with the rubber seals
supplied.
It is important to put the centering spacer,
supplied with the unit, inside between the two
pipes, from the side opposite the extension’s
straight end.
NOTE: a suitable support bracket is available
from Ravenheat Manufacturing and should
be used to support flue length at least every
1.8 metre preferably at each joint this bracket
should be secured to wall and flue duct.
5.5.11 IN LINE FLUE BEND
Measure the distance between the flue bends or
the flue/terminal assembly. The measurements
should be taken from the outer edge of the flue
and bend (Fig. 39B).
IMPORTANT: inline flue bend - 1680 mm
must be deducted from overall length for each
90°bend. Obtuse flue bend - 1680 mm must
be deducted from overall length for each 135°
bend (Fig. 39B).
5.6 COMPLETING BOILER INSTALLATION
5.6.1 Reassemble the outer casing (sect 5.4)
proceeding in this order
1)Fit the two sides.
2)Refit the instrument panel in reverse order
as in sect. 5.4.4.
3)Refit the lower grating (sect. 5.4)
5.7 INSTALLING THE APPLIANCE FOR SIDE
FLUE OUTLET (Fig. 39)
5.7.1 - Attach the template to the wall with adhesive
tape, making sure that the centre line is
vertical and that the distance from the centre
line to the nearest side wall is not less than
measurement in table 6.
- Mark the four boiler securing holes on the wall
and extend the axis of the flue duct hole to the
side wall ensuring it is horizontal.
- Trace the centre of the flue duct hole measure
distance F (table 6). From the corner of
the wall (Fig. 28), measure the distance Y
between the centre of flue duct hole to the
corner Detach the template from wall.
- Use a dia. 10 mm. drill to make the 4 holes for
securingtheboiler.Inserttheplasticexpansion
plugs. Core drill a 105 mm dia. hole in the
side wall for inserting the flue duct.
TABLE 6
